Makita HP002G User manual

HP002G
EN Cordless Hammer Driver Drill INSTRUCTION MANUAL 4
ZHCN 充电式冲击起子电钻 使用说明书 13
ID Bor Obeng Getar Tanpa Kabel PETUNJUK PENGGUNAAN 22
MS Gerudi Pemacu Tukul Tanpa
Kord MANUAL ARAHAN 31
VI Máy Khoan Búa Và Vặn Vít
Cầm Tay Hoạt Động Bằng Pin TÀI LIỆU HƯỚNG DẪN 40
TH   49

1
2
3
Fig.1
1
2
Fig.2
1
Fig.3
1
Fig.4
1
AB
Fig.5
1
Fig.6
4
3
2
1
Fig.7
4
3
2
1
Fig.8
2

1
2
3
Fig.9
3
2
1
Fig.10
1
2
Fig.11
2
3
1
4
Fig.12
Fig.13
1
Fig.14
3

4ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: HP002G
Drilling
capacities
Masonry 13 mm
Steel 13 mm
Wood Auger bit: 38 mm
Self-feed bit: 38 mm
Hole saw: 51 mm
Fastening
capacities
Wood screw 10 mm x 90 mm
Machine screw M6
No load speed
(RPM)
High (2) 0 - 2,200 min-1
Low (1) 0 - 600 min-1
Blows per
minute
High (2) 0 - 33,000 min-1
Low (1) 0 - 9,000 min-1
Overall length 174 mm
Rated voltage D.C. 36 V - 40 V max
Net weight 2.0 - 2.9 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydi󰀨erfromcountrytocountry.
• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
Applicable battery cartridge and charger
Battery cartridge BL4020*/BL4025*/BL4040*/BL4050F
* : Recommended battery
Charger DC40RA/DC40RB/DC40RC
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
andchargersmaycauseinjuryand/orre.
Symbols
Thefollowingsshowthesymbolswhichmaybeused
for the equipment. Be sure that you understand their
meaning before use.
Read instruction manual.
Ni-MH
Li-ion
Only for EU countries
Do not dispose of electric equipment or
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries and Accumulators
and Waste Batteries and Accumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
Intended use
Thetoolisintendedforimpactdrillinginbrick,brickwork
and masonry. It is also suitable for screw driving and
drilling without impact in wood, metal, ceramic and
plastic.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.

5ENGLISH
Save all warnings and instruc-
tions for future reference.
Theterm“powertool”inthewarningsreferstoyour
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.Thereisanincreasedriskofelec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However, users of pacemakers and other similar
medical devices should contact the maker of their
deviceand/ordoctorforadvicebeforeoperating
this power tool.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication. A moment of inattention while operating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the o󰀨-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
resultinpersonalinjury.
5. Do not overreach. Keep proper footing and
balance at all times.Thisenablesbettercontrol
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
cancausesevereinjurywithinafractionofa
second.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application.Thecorrect
powertoolwilldothejobbetterandsaferatthe
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and o󰀨. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.

6ENGLISH
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool. Power tools are dangerous in the
hands of untrained users.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may a󰀨ect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
foroperationsdi󰀨erentfromthoseintendedcould
result in a hazardous situation.
8. Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for
safe handling and control of the tool in unexpected
situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled.Theentangle-
ment of cloth work gloves in the moving parts may
resultinpersonalinjury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
onetypeofbatterypackmaycreateariskofre
when used with another battery pack.
2. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
may exhibit unpredictable behaviour resulting in
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
perature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions. Charging improperly or at temperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts.Thiswillensurethatthesafetyofthepower
tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
3. Follow instruction for lubricating and chang-
ing accessories.
Cordless hammer driver drill safety
warnings
Safety instructions for all operations
1. Wear ear protectors when impact drilling.
Exposure to noise can cause hearing loss.
2. Hold the power tool by insulated gripping
surfaces, when performing an operation where
the cutting accessory or fasteners may contact
hidden wiring. Cutting accessory or fasteners
contactinga“live”wiremaymakeexposedmetal
partsofthepowertool“live”andcouldgivethe
operator an electric shock.
3. Always be sure you have a rm footing. Be
sure no one is below when using the tool in
high locations.
4. Hold the tool rmly.
5. Keep hands away from rotating parts.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Do not touch the drill bit, the workpiece or
chips immediately after operation; they may be
extremely hot and could burn your skin.
8. Some material contains chemicals which may
be toxic. Take caution to prevent dust inhala-
tion and skin contact. Follow material supplier
safety data.
9. If the drill bit cannot be loosened even you
open the jaws, use pliers to pull it out. In such a
case, pulling out the drill bit by hand may result in
injurybyitssharpedge.
10. Make sure there are no electrical cables, water
pipes, gas pipes etc. that could cause a hazard
if damaged by use of the tool.
Safety instructions when using long drill bits
1. Never operate at higher speed than the max-
imum speed rating of the drill bit. At higher
speeds, the bit is likely to bend if allowed to rotate
freely without contacting the workpiece, resulting
inpersonalinjury.
2. Always start drilling at low speed and with the
bit tip in contact with the workpiece. At higher
speeds, the bit is likely to bend if allowed to rotate
freely without contacting the workpiece, resulting
inpersonalinjury.

7ENGLISH
3. Apply pressure only in direct line with the bit
and do not apply excessive pressure. Bits can
bend causing breakage or loss of control, resulting
inpersonalinjury.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper the battery
cartridge.Itmayresultinare,excessiveheat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge. Such conduct may result in a
re,excessiveheat,orexplosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
Tapeormasko󰀨opencontactsandpackupthe
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
sive heat, explosion, or leak of electrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge. It may result in poor performance or
breakdown of the tool or battery cartridge.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near a high-voltage elec-
trical power lines. It may result in a malfunction
or breakdown of the tool or battery cartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causingres,personalinjuryanddamage.Itwill
also void the Makita warranty for the Makita tool and
charger.

8ENGLISH
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridgermlymaycausethemtoslipo󰀨yourhands
and result in damage to the tool and battery cartridge
andapersonalinjury.
►Fig.1: 1. Red indicator 2. Button 3. Battery cartridge
Toremovethebatterycartridge,slideitfromthetool
while sliding the button on the front of the cartridge.
Toinstallthebatterycartridge,alignthetongueonthe
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
itmayaccidentallyfalloutofthetool,causinginjuryto
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Indicating the remaining battery
capacity
Press the check button on the battery cartridge to indi-
catetheremainingbatterycapacity.Theindicatorlamps
light up for a few seconds.
►Fig.2: 1. Indicator lamps 2. Check button
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydi󰀨erslightly
from the actual capacity.
NOTE:Therst(farleft)indicatorlampwillblinkwhen
the battery protection system works.
Tool / battery protection system
Thetoolisequippedwithatool/batteryprotectionsys-
tem.Thissystemautomaticallycutso󰀨thepowerto
extendtoolandbatterylife.Thetoolwillautomatically
stop during operation if the tool or battery is placed
under one of the following conditions:
Overload protection
Thisprotectionworkswhenthetoolorbatteryisoper-
ated in a manner that causes it to draw an abnormally
highcurrent.Inthissituation,turnthetoolo󰀨andstop
the application that caused the tool to become over-
loaded.Thenturnthetoolontorestart.
Overheat protection
Thisprotectionworksandthelampblinkswhenthetool
or battery is overheated. In this situation, let the tool and
battery cool before turning the tool on again.
Overdischarge protection
Thisprotectionworkswhentheremainingbattery
capacity gets low. In this situation, remove the battery
from the tool and charge the battery.

9ENGLISH
Switch action
CAUTION: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the “OFF” position when released.
Tostartthetool,simplypulltheswitchtrigger.Tool
speed is increased by increasing pressure on the switch
trigger. Release the switch trigger to stop.
►Fig.3: 1. Switch trigger
NOTE:Thetoolautomaticallystopsifyoukeeppull-
ing the switch trigger for about 6 minutes.
Electric brake
Thistoolisequippedwithanelectricbrake.Ifthetool
consistently fails to quickly stop after the switch trigger
is released, have the tool serviced at a Makita service
center.
Lighting up the front lamp
CAUTION: Do not look in the light or see the
source of light directly.
Pulltheswitchtriggertolightupthelamp.Thelamp
keeps on lighting while the switch trigger is being pulled.
Thelampgoesoutapproximately10secondsafter
releasing the switch trigger.
►Fig.4: 1. Lamp
NOTE: When the tool is overheated, the tool stops
automaticallyandthelampstartsashing.Inthis
case,releasetheswitchtrigger.Thelampturnso󰀨in
one minute.
NOTE:Useadryclothtowipethedirto󰀨thelensof
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
Reversing switch action
CAUTION: Always check the direction of
rotation before operation.
CAUTION: Use the reversing switch only after
the tool comes to a complete stop. Changing the
direction of rotation before the tool stops may dam-
age the tool.
CAUTION: When not operating the tool,
always set the reversing switch lever to the neu-
tral position.
Thistoolhasareversingswitchtochangethedirection
of rotation. Depress the reversing switch lever from
the A side for clockwise rotation or from the B side for
counterclockwise rotation.
When the reversing switch lever is in the neutral posi-
tion, the switch trigger cannot be pulled.
►Fig.5: 1. Reversing switch lever
Speed change
CAUTION: Always set the speed change lever
fully to the correct position. If you operate the
tool with the speed change lever positioned halfway
betweenthe“1”sideand“2”side,thetoolmaybe
damaged.
CAUTION: Do not use the speed change lever
while the tool is running.Thetoolmaybedamaged.
Displayed
Number
Speed Torque Applicable
operation
1Low High Heavy load-
ing operation
2High Low Light loading
operation
Tochangethespeed,switcho󰀨thetoolrst.Push
thespeedchangelevertodisplay“2”forhighspeed
or“1”forlowspeedbuthightorque.Besurethatthe
speed change lever is set to the correct position before
operation.
If the tool speed is coming down extremely during the
operationwithdisplay“2”,pushthelevertodisplay“1”
and restart the operation.
►Fig.6: 1. Speed change lever
Selecting the action mode
CAUTION: Always set the ring correctly to
your desired mode mark. If you operate the tool
with the ring positioned halfway between the
mode marks, the tool may be damaged.
CAUTION: When you change the position
from “ ” to other modes, it may be a little dif-
culty to slide the action mode changing ring. In
this case, switch on and run the tool for a second
at the “ ” position, then stop the tool and slide
the ring to your desired position.
Thistoolhasthreeactionmodes.
• Drilling mode (rotation only)
• Hammer drilling mode (rotation with
hammering)
• Screwdriving mode (rotation with clutch)
Selectonemodesuitableforyourwork.Turnthe
action mode changing ring and align the mark that you
selected with the arrow on the tool body.
►Fig.7: 1. Action mode changing ring 2.Adjusting
ring 3. Mark 4. Arrow

10 ENGLISH
Adjusting the fastening torque
►Fig.8: 1. Action mode changing ring 2.Adjusting
ring 3. Graduation 4. Arrow
Thefasteningtorquecanbeadjustedin21levelsby
turningtheadjustingring.Alignthegraduationswiththe
arrow on the tool body. You can get the minimum fas-
tening torque at 1 and maximum torque at 21.
Before actual operation, drive a trial screw into your
material or a piece of duplicate material to determine
which torque level is required for a particular applica-
tion.Thefollowingshowstheroughguideoftherela-
tionship between the screw size and graduation.
Graduation 12345678910 11 12 13 14 15 16 17 18 19 20 21
Machine screw M4 M5 M6
Wood
screw
Soft wood
(e.g. pine)
–ø3.5 x 22 ø4.1x 38 –
Hard wood
(e.g. lauan)
–ø3.5 x 22 ø4.1x 38 –
ASSEMBLY
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before carrying out any work on the tool.
Installing or removing driver bit/
drill bit
Optional accessory
►Fig.9: 1. Sleeve 2. Close 3. Open
Turnthesleevecounterclockwisetoopenthechuck
jaws.Placethedriverbit/drillbitinthechuckasfar
asitwillgo.Turnthesleeveclockwisetotightenthe
chuck.Toremovethedriverbit/drillbit,turnthesleeve
counterclockwise.
Installing hook
CAUTION: When installing the hook, always
secure it with the screw rmly. If not, the hook
maycomeo󰀨fromthetoolandresultinthepersonal
injury.
CAUTION: Use the hanging/mounting parts
for their intended purposes only. Using for unin-
tended purpose may cause accident or personal
injury.
►Fig.10: 1. Groove 2. Hook 3. Screw
Thehookisconvenientfortemporarilyhangingthetool.
Thiscanbeinstalledoneithersideofthetool.Toinstall
the hook, insert it into a groove in the tool housing on
eithersideandthensecureitwithascrew.Toremove,
loosen the screw and then take it out.
NOTICE: When hanging the tool on your belt
using the hook, remove the driver bit/drill bit and
the side grip.
Installing driver bit holder
Optional accessory
►Fig.11: 1. Driver bit holder 2. Driver bit
Fit the driver bit holder into the protrusion at the tool foot
on either right or left side and secure it with a screw.
When not using the driver bit, keep it in the driver bit
holders. Driver bits 45 mm-long can be kept there.
Installing side grip (auxiliary handle)
Optional accessory
►Fig.12: 1. Protrusion 2. Arm 3. Recess 4. Grip
Insert the side grip so that the protrusions on the arm
tintherecessesonthetool.Thentightenthegripby
turning clockwise.
Depending the operations, you can install the side grip
either right or left side of the tool.
OPERATION
CAUTION: Always insert the battery cartridge
all the way until it locks in place. If you can see the
red indicator on the upper side of the button, it is not
locked completely. Insert it fully until the red indicator
cannot be seen. If not, it may accidentally fall out of
thetool,causinginjurytoyouorsomeonearound
you.
CAUTION: When the speed comes down
extremely, reduce the load or stop the tool to
avoid the tool damage.
Holdthetoolrmlywithonehandonthegripandthe
other hand on the bottom of the battery cartridge to
control the twisting action.

11 ENGLISH
Screwdriving operation
CAUTION: Adjust the adjusting ring to the
proper torque level for your work.
CAUTION: Make sure that the driver bit is
inserted straight in the screw head, or the screw
and/or driver bit may be damaged.
First, turn the action mode changing ring so that the
arrow on the tool body points to the marking.
Place the point of the driver bit in the screw head and
apply pressure to the tool. Start the tool slowly and then
increase the speed gradually. Release the switch trigger
as soon as the clutch cuts in.
►Fig.13
NOTE: When driving wood screw, pre-drill a pilot hole
2/3thediameterofthescrew.Itmakesdrivingeasier
and prevents splitting of the workpiece.
Hammer drilling operation
CAUTION: There is a tremendous and sud-
den twisting force exerted on the tool/drill bit
at the time of hole breakthrough, when the hole
becomes clogged with chips and particles, or
when striking reinforcing rods embedded in the
concrete.
First, turn the action mode changing ring so that the
arrow on the tool body points to the marking.The
adjustingringcanbealignedinanytorquelevelsfor
this operation.
Be sure to use a tungsten-carbide tipped drill bit.
Position the drill bit at the desired location for the hole,
then pull the switch trigger. Do not force the tool. Light
pressure gives best results. Keep the tool in position
and prevent it from slipping away from the hole.
Do not apply more pressure when the hole becomes
clogged with chips or particles. Instead, run the tool at
an idle, then remove the drill bit partially from the hole.
By repeating this several times, the hole will be cleaned
out and normal drilling may be resumed.
Blow-out bulb
Optional accessory
►Fig.14: 1. Blow-out bulb
After drilling the hole, use the blow-out bulb to clean the
dust out of the hole.
Drilling operation
First, turn the action mode changing ring so that the
arrow points to the marking.Thenproceedas
follows.
Drilling in wood
When drilling in wood, the best results are obtained
withwooddrillsequippedwithaguidescrew.Theguide
screw makes drilling easier by pulling the drill bit into
the workpiece.
Drilling in metal
Topreventthedrillbitfromslippingwhenstartinga
hole, make an indentation with a center-punch and
hammer at the point to be drilled. Place the point of the
drill bit in the indentation and start drilling.
Useacuttinglubricantwhendrillingmetals.Theexcep-
tions are iron and brass which should be drilled dry.
CAUTION: Pressing excessively on the tool
will not speed up the drilling. In fact, this excessive
pressure will only serve to damage the tip of your drill
bit, decrease the tool performance and shorten the
service life of the tool.
CAUTION: Hold the tool rmly and exert care
when the drill bit begins to break through the
workpiece.Thereisatremendousforceexertedon
thetool/drillbitatthetimeofholebreakthrough.
CAUTION: A stuck drill bit can be removed
simply by setting the reversing switch to reverse
rotation in order to back out. However, the tool
may back out abruptly if you do not hold it rmly.
CAUTION: Always secure workpieces in a
vise or similar hold-down device.
CAUTION: If the tool is operated continuously
until the battery cartridge has discharged, allow
the tool to rest for 15 minutes before proceeding
with a fresh battery.
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.

OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Drillbits
• Driverbits
• Tungsten-carbidetippeddrillbit
• Blow-outbulb
• Driverbitholder
• Hook
• Sidegrip
• Makitagenuinebatteryandcharger
NOTE: Some items in the list may be included in the
toolpackageasstandardaccessories.Theymay
di󰀨erfromcountrytocountry.
12 ENGLISH

13
中文简体
中文简体 ( 原本 )
规格
型号： HP002G
钻孔能力 石材 13 mm
钢材 13 mm
木材 螺旋钻头：38 mm
自进给钻头：38 mm
孔锯：51 mm
紧固能力 木螺丝 10 mm ×90 mm
机器螺丝 M6
空载速度
（RPM）
高（2）0-2,200r/min
低（1）0-600r/min
每分钟
锤击数
高（2）0-33,000/min
低（1）0-9,000/min
总长度 174 mm
额定电压 D.C. 36 V - 40 V（最大）
净重 2.0 - 2.9 kg
•生产者保留变更规格不另行通知之权利。
•规格可能因销往国家之不同而异。
•重量因附件（包括电池组）而异。根据 EPTA-Procedure01/2014，最重与最轻的组合见
表格。
适用电池组和充电器
电池组 BL4020*/BL4025*/BL4040*/BL4050F
*：建议使用的电池
充电器 DC40RA/DC40RB/DC40RC
•部分以上所列电池组和充电器是否适用视用户所在地区而异。
警告： 请仅使用以上所列电池组和充电器。使用其他类型的电池组或充电器可能会导
致人身伤害和 /或失火。
符号
以下显示本设备可能会使用的符号。在使用
工具之前，请务必理解其含义。
阅读使用说明书。
Ni-MH
Li-ion 仅限于欧盟国家
请勿将电气设备或电池组与
家庭普通废弃物一同丢弃！
请务必遵守欧洲关于废弃电
子电气设备、电池和蓄电池以
及废弃电池和蓄电池的指令
并根据法律法规执行。达到使
用寿命的电气设备和电池组
必须分类回收至符合环境保
护规定的再循环机构。

14
中文简体
用途
本工具用于在砖块、砖结构和砖石上进行冲
击钻孔。它还适用于在木材、金属、陶瓷和
塑料中拧紧螺丝和无冲击钻孔。
安全警告
电动工具通用安全警告
警 告： 阅读随电动工具提供的所有安全
警告、说明、图示和规定。不遵照以下所列
说明会导致电击、着火和／或严重伤害。
保存所有警告和说明书以备
查阅。
警告中的术语“电动工具”是指市电驱动（有
线）电动工具或电池驱动（无线）电动工具。
工作场地的安全
1. 保持工作场地清洁和明亮。杂乱和黑暗
的场地会引发事故。
2. 不要在易爆环境，如有易燃液体、气体
或粉尘的环境下操作电动工具。电动工
具产生的火花会点燃粉尘或气体。
3. 操作电动工具时，远离儿童和旁观者。注
意力不集中会使你失去对工具的控制。
电气安全
1. 电动工具插头必须与插座相配。绝不能
以任何方式改装插头。需接地的电动工
具不能使用任何转换插头。未经改装的
插头和相配的插座将降低电击风险。
2. 避免人体接触接地表面，如管道、散热
片和冰箱。如果你身体接触接地表面会
增加电击风险。
3. 不得将电动工具暴露在雨中或潮湿环境
中。水进入电动工具将增加电击风险。
4. 不得滥用软线。绝不能用软线搬运、拉
动电动工具或拔出其插头。使软线远离
热源、油、锐边或运动部件。受损或缠
绕的软线会增加电击风险。
5. 当在户外使用电动工具时，使用适合户
外使用的延长线。适合户外使用的电线
将降低电击风险。
6. 如果无法避免在潮湿环境中操作电动工
具，应使用带有剩余电流装置（RCD）
保护的电源。RCD 的使用可降低电击
风险。
7. 电动工具会产生对用户无害的电磁场
（EMF）。但是，起搏器和其他类似医疗
设备的用户应在操作本电动工具前咨询
其设备的制造商和／或医生寻求建议。
人身安全
1. 保持警觉，当操作电动工具时关注所从
事的操作并保持清醒。当你感到疲倦，
或在有药物、酒精或治疗反应时，不要
操作电动工具。在操作电动工具时瞬间
的疏忽会导致严重人身伤害。
2. 使用个人防护装置。始终佩戴护目镜。
防护装置，诸如适当条件下使用防尘面
具、防滑安全鞋、安全帽、听力防护等
装置能减少人身伤害。
3. 防止意外起动。在连接电源和 /或电池
包、拿起或搬运工具前确保开关处于关
断位置。手指放在开关上搬运工具或开
关处于接通时通电会导致危险。
4. 在电动工具接通之前，拿掉所有调节钥
匙或扳手。遗留在电动工具旋转零件上
的扳手或钥匙会导致人身伤害。
5. 手不要过分伸展。时刻注意立足点和身
体平衡。这样能在意外情况下能更好地
控制住电动工具。
6. 着装适当。不要穿宽松衣服或佩戴饰品。
让你的头发和衣服远离运动部件。宽松
衣服、佩饰或长发可能会卷入运动部件。
7. 如果提供了与排屑、集尘设备连接用的
装置，要确保其连接完好且使用得当。
使用集尘装置可降低尘屑引起的危险。
8. 不要因为频繁使用工具而产生的熟悉感
而掉以轻心，忽视工具的安全准则。某
个粗心的动作可能在瞬间导致严重的
伤害。
9. 使用电动工具时请始终佩带护目镜以
免伤害眼睛。护目镜须符合美国 ANSI
Z87.1、欧洲 EN 166 或者澳大利亚／新
西兰的 AS/NZS 1336 的规定。在澳大
利亚／新西兰，法律要求佩带面罩保护
脸部。

15
中文简体
雇主有责任监督工具操作者和其他近工
作区域人员佩带合适的安全防护设备。
电动工具使用和注意事项
1. 不要勉强使用电动工具，根据用途使用
合适的电动工具。选用合适的按照额定
值设计的电动工具会使你工作更有效、
更安全。
2. 如果开关不能接通或关断电源，则不能
使用该电动工具。不能通过开关来控制
的电动工具是危险的且必须进行修理。
3. 在进行任何调节、更换附件或贮存电动
工具之前，必须从电源上拔掉插头和 /或
卸下电池包（如可拆卸）。这种防护性
的安全措施降低了电动工具意外起动的
风险。
4. 将闲置不用的电动工具贮存在儿童所及
范围之外，并且不允许不熟悉电动工具
和不了解这些说明的人操作电动工具。
电动工具在未经培训的使用者手中是危
险的。
5. 维护电动工具及其附件。检查运动部件
是否调整到位或卡住，检查零件破损情
况和影响电动工具运行的其他状况。如
有损坏，应在使用前修理好电动工具。
许多事故是由维护不良的电动工具引
发的。
6. 保持切削刀具锋利和清洁。维护良好地
有锋利切削刃的刀具不易卡住而且容易
控制。
7. 按照使用说明书，并考虑作业条件和要
进行的作业来选择电动工具、附件和工
具的刀头等。将电动工具用于那些与其
用途不符的操作可能会导致危险情况。
8. 保持手柄和握持表面干燥、清洁，不得沾
有油脂。在意外的情况下，湿滑的手柄
不能保证握持的安全和对工具的控制。
9. 使用本工具时，请勿佩戴可能会缠结的
布质工作手套。布质工作手套卷入移动
部件可能会造成人身伤害。
电池式工具使用和注意事项
1. 仅使用生产者规定的充电器充电。将适
用于某种电池包的充电器用到其他电池
包时可能会发生着火危险。
2. 仅使用配有专用电池包的电动工具。使
用其他电池包可能会产生伤害和着火
危险。
3. 当电池包不用时，将它远离其他金属物
体，例如回形针、硬币、钥匙、钉子、
螺钉或其他小金属物体，以防电池包一
端与另一端连接。电池组端部短路可能
会引起燃烧或着火。
4. 在滥用条件下，液体可能会从电池组中
溅出；应避免接触。如果意外碰到液体，
用水冲洗。如果液体碰到了眼睛，还应
寻求医疗帮助。从电池中溅出的液体可
能会发生腐蚀或燃烧。
5. 不要使用损坏或改装过的电池包或工
具。损坏或改装过的电池组可能呈现无
法预测的结果，导致着火、爆炸或伤害。
6. 不要将电池包暴露于火或高温中。电池
包暴露于火或高于 130 ℃的高温中可能
导致爆炸。
7. 遵循所有充电说明。不要在说明书中指
定的温度范围之外给电池包或电动工具
充电。不正确或在指定的温度范围外充
电可能会损坏电池和增加着火的风险。
维修
1. 让专业维修人员使用相同的备件维修电
动工具。这将保证所维修的电动工具的
安全。
2. 决不能维修损坏的电池包。电池包仅能
由生产者或其授权的维修服务商进行
维修。
3. 上润滑油及更换附件时请遵循本说明书
指示。
充电式冲击起子电钻使用安全警告
所有操作的安全注意事项
1. 使用冲击电钻时要戴好耳罩。暴露在噪
声中会引起听力损伤。
2. 当进行作业时切割附件或紧固装置可能
会接触到隐藏的电线，请握住电动工具
的绝缘抓握表面。切割附件或紧固装置
接触到“带电”的电线时，电动工具上
曝露的金属部分可能也会“带电”，并
使操作者触电。
3. 请务必确保立足稳固。在高处使用工具
时确保下方无人。

16
中文简体
4. 请牢握本工具。
5. 手应远离旋转的部件。
6. 运行中的工具不可离手放置。只可在手
握工具的情况下操作工具。
7. 操作之后，请勿立即触摸钻头、工件或
碎屑，此时其温度可能会非常高，从而
导致皮肤烫伤。
8. 某些材料含有有毒化学物质。小心不要
吸入粉尘，并避免皮肤接触。遵循材料
供应商的安全提示。
9. 如果打开卡爪依然无法拧松钻头，请使
用虎钳将其拉出。在这种情况下，徒手
拉出钻头会因尖锐的边缘受伤。
10. 请确保不存在电缆、水管、煤气管道等，
如果其因使用本工具而受损，可能会引
起危险。
使用长钻头时的安全注意事项
1. 操作时的速度切勿高于钻头的额定速
度。在高速状态下，如果让钻头不接触
工件空转，则钻头可能会弯曲，造成人
身伤害。
2. 务必以低速开始钻孔，并将钻头的端部
与工件接触。在高速状态下，如果让钻头
不接触工件空转，则钻头可能会弯曲，
造成人身伤害。
3. 只在与钻头对齐的位置施加压力，切勿
过度施压。否则钻头可能弯曲导致破损
或失控，造成人身伤害。
请保留此说明书。
警 告： 请勿为图方便或因对产品足够熟
悉（由于重复使用而获得的经验）而不严格
遵循相关产品安全规则。使用不当或不遵循
使用说明书中的安全规则会导致严重的人
身伤害。
电池组的重要安全注意事项
1. 在使用电池组之前，请仔细通读所有的
说明以及（1）电池充电器，（2）电池，
以 及（ 3）使用电池的产品上的警告标记。
2. 切勿拆卸或改装电池组。否则可能引起
火灾、过热或爆炸。
3. 如果机器运行时间变得过短，请立即停
止使用。否则可能会导致过热、起火甚
至爆炸。
4. 如果电解液进入您的眼睛，请用清水将
其冲洗干净并立即就医。否则可能会导
致视力受损。
5. 请勿使电池组短路：
(1) 请勿使任何导电材料碰触到端子。
(2) 避免将电池组与其他金属物品如钉
子、硬币等放置在同一容器内。
(3) 请勿将电池组置于水中或使其淋雨。
电池短路将产生大的电流，导致过热，
并可能导致起火甚至击穿。
6. 请勿在温度可能达到或超过 50°C（122°F）
的场所存放以及使用工具和电池组。
7. 即使电池组已经严重损坏或完全磨损，
也请勿焚烧电池组。电池组会在火中
爆炸。
8. 请勿对电池组射钉，或者切削、挤压、抛
掷、掉落电池组，又或者用硬物撞击电池
组。否则可能引起火灾、过热或爆炸。
9. 请勿使用损坏的电池。
10. 本工具附带的锂离子电池需符合危险品
法规要求。
第三方或转运代理等进行商业运输时，
应遵循包装和标识方面的特殊要求。
有关运输项目的准备作业，咨询危险品
方面的专业人士。同时，请遵守可能更
为详尽的国家法规。
请使用胶带保护且勿遮掩表面的联络信
息，并牢固封装电池，使电池在包装内
不可动。
11. 丢弃电池组时，需将其从工具上卸下并
在安全地带进行处理。关于如何处理废
弃的电池，请遵循当地法规。
12. 仅将电池用于 Makita（牧田）指定的产
品。将电池安装至不兼容的产品会导致
起火、过热、爆炸或电解液泄漏。
13. 如长时间未使用工具，必须将电池从工
具内取出。
14. 使用工具期间以及使用工具之后，电池
组温度可能较高易引起灼伤或低温烫
伤。处理高温电池组时请小心操作。
15. 在使用工具后请勿立即触碰工具的端
子，否则可能引起灼伤。
16. 避免锯屑、灰尘或泥土卡入电池组的端
子、孔口和凹槽内。否则可能导致工具
或电池组性能下降或故障。
17. 除非工具支持在高压电源线路附近使
用，否则请勿在高压电源线路附近使用
电池组。否则可能导致工具或电池组故
障或失常。
18. 确保电池远离儿童。
请保留此说明书。

17
中文简体
小心： 请仅使用 Makita（牧田）原装
电池。使用非 Makita（牧田）原装电池或经
过改装的电池可能会导致电池爆炸，从而造
成火灾、人身伤害或物品受损。同时也会导
致牧田工具和充电器的牧田保修服务失效。
保持电池最大使用寿命的提示
1. 在电池组电量完全耗尽前及时充电。发
现工具电量低时，请停止工具操作，并
给电池组充电。
2. 请勿对已充满电的电池组重新充电。过
度充电将缩短电池的使用寿命。
3. 请在 10 °C - 40 °C（50 °F - 104 °F）的
室温条件下给电池组充电。请在灼热的
电池组冷却后再充电。
4. 不使用电池组时，请将其从工具或充电
器上拆除。
5. 如果电池组长时间（超过六个月）未使
用，请给其充电。
功能描述
小心： 调节或检查工具功能之前，请务
必关闭工具的电源并取出电池组。
安装或拆卸电池组
小心： 安装或拆卸电池组之前，请务必
关闭工具电源。
小心： 安装或拆卸电池组时请握紧工
具和电池组。否则它们可能从您的手中滑
落，导致工具和电池组受损，甚至造成人身
伤害。
►图片 1: 1. 红色指示器 2. 按钮 3. 电池组
拆卸电池组时，按下电池组前侧的按钮，同
时将电池组从工具中抽出。
安装电池组时，要将电池组上的舌簧与外罩
上的凹槽对齐，然后推滑到位。将其完全插
入到位，直到电池组被锁定并发出卡嗒声为
止。如果插入后仍能看到按钮上侧的红色指
示器，则说明电池组未完全锁紧。
小心： 务必完全装入电池组，直至看不
见红色指示器为止。否则，它可能会从工具
中意外脱落，从而造成自身或他人受伤。
小心： 请勿强行安装电池组。如果电池
组难以插入，可能是插入方法不当。
显示电池的剩余电量
按电池组上的 CHECK（查看）按钮可显示电
池剩余电量。指示灯将亮起数秒。
►图片 2: 1. 指示灯 2. CHECK（查看）按钮
指示灯 剩余电量
点亮 熄灭 闪烁
75% 至
100%
50% 至
75%
25% 至
50%
0% 至
25%
给电池
充电。
电池可
能出现
故障。
注： 在不同的使用条件及环境温度下，指
示灯所示电量可能与实际情况略有不同。
注： 当电池保护系统启动时，第一个（最
左侧）指示灯将闪烁。
工具／电池保护系统
本工具配备有工具／电池保护系统。该系统
可自动切断电源以延长工具和电池寿命。作
业时，如果工具或电池处于以下情况，工具
将会自动停止运转。
过载保护
以导致异常高电流的方式操作工具或电池
时，此保护功能将启动。在这种情况下，请
关闭工具并停止导致工具过载的应用程序。
然后开启工具以重新启动。

18
中文简体
过热保护
当工具或电池过热时，将启动此保护功能，
同时指示灯将闪烁。在这种情况下，请待工
具和电池冷却后再重新开启工具。
过放电保护
当剩余电池电量变低时，将启动此保护功能。
此时，请取出工具中的电池并予以充电。
开关操作
小心： 在将电池组插入工具之前，请务
必检查开关扳机是否能扣动自如，松开时能
否退回至“OFF”（关闭）位置。
启动工具时，只要扣动开关扳机即可。随着
在开关扳机上施加压力的增大，工具速度会
提高。松开开关扳机工具即停止。
►图片 3: 1. 开关扳机
注： 如果持续扣动开关扳机约 6分钟，机
器将自动停止。
电动制动器
本工具配备有电动制动器。如果在松开开关
扳机后，工具始终无法立即停机，则须交由
Makita（牧田）维修中心维修。
点亮前灯
小心： 请勿直视灯光或光源。
扣动开关扳机点亮照明灯。在扣动开关扳机
期间此灯保持常亮。松开开关扳机约 10 秒
后，灯将熄灭。
►图片 4: 1. 照明灯
注： 工具过热时，工具将自动停止运转且
指示灯开始闪烁。在这种情况下，请松开开
关扳机。指示灯将在一分钟内熄灭。
注： 请使用干布擦拭灯头灰。注意不要刮
花灯头，否则会降低亮度。
反转开关的操作
小心： 操作前请务必确认工具的旋转
方向。
小 心： 只有当工具完全停止转动后方可
使用反转开关。如果在工具停止之前改变旋
转方向，可能会损坏工具。
小心： 不使用工具时，请务必将反转切
换柄置于空档位置。
本工具设有反转开关，可改变旋转方向。自 A
侧按压反转切换柄可进行顺时针方向旋转；
自B侧按压则进行逆时针方向旋转。
反转切换柄处于空档位置时，开关扳机无法
扣动。
►图片 5: 1. 反转切换柄
变速
小 心： 请务必将变速杆完全置于正确位
置。在变速杆处于“1”侧与“ 2”侧之间
的半位时操作工具，会使工具受损。
小 心： 不可在机器运转时使用变速杆。
否则可能会损坏工具。
显示的
数字
速度 转矩 适用操作
1低 高 高负荷
操作
2高 低 低负荷
操作
要改变速度，请先关闭工具。需要高速时推
变速杆以显示“2”，需要低速高扭矩时使其
显示“1”。确保使用之前将变速杆置于正确
位置。
如果在显示为“2”的操作中工具速度极速降
低，请推变速杆以显示“1”，然后重新开始
操作。
►图片 6: 1. 变速杆

19
中文简体
选择动作模式
小 心： 一定要将切换环正确设置到所需
的模式标记。如果在切换环位于模式标记之
间中间位置的情况下操作工具，则工具可能
会受损。
小 心： 当 从“ ”位置切换至其他模式
时，动作模式切换环的滑动可能比较困难。
在这种情况下，开启工具并使其在“ ”
位置运转片刻，然后停止工具并将动作模式
切换环滑动至所需位置。
本工具设有三种动作模式。
•钻孔模式（仅旋转）
•冲击钻孔模式（冲击旋转）
•旋紧螺丝模式（离合旋转）
选择适合您的作业的模式。旋转动作模式
切换环并将所选标记与工具机身上的箭头
对齐。
►图片 7: 1. 动作模式切换环 2. 调节环
3. 标记 4. 箭头
调节紧固转矩
►图片 8: 1. 动作模式切换环 2. 调节环
3. 刻度 4. 箭头
可通过转动调节环在 21 个等级范围内调节
紧固扭矩。对齐刻度和工具主体上的箭头。
设至 1时紧固扭矩最小，设至 21 时紧固扭矩
最大。
实际操作前，将试验螺丝拧入材料或与其相
同的材料。以确定具体应用所需的转矩水
平。以下显示了螺丝尺寸和刻度之间的基本
关系。
刻度 12345678910 11 12 13 14 15 16 17 18 19 20 21
机器螺丝 M4 M5 M6
木螺丝 软木
（如
松木）
─ø3.5 x 22 ø4.1 x 38 ─
硬木
（如柳
安木）
─ø3.5 x 22 ø4.1 x 38 ─
装配
小心： 对工具进行任何装配操作前，请
务必关闭工具电源，并取出电池组。
起子头／钻头的安装或拆卸
选购附件
►图片 9: 1. 套筒 2. 关闭 3. 打开
逆时针转动套筒打开卡盘爪。尽量将起子头／
钻头放入卡盘最里侧。顺时针转动套筒旋紧
卡盘。逆时针转动套筒即可卸下起子头／
钻头。
安装挂钩
小心： 安装挂钩时，务必使用螺丝将其
固定。否则挂钩可能会脱离工具，导致人身
伤害。
小 心： 悬挂／安装部件只能用于预期用
途。用作其他用途可能会引发意外或造成人
身伤害。
►图片 10: 1. 凹槽 2. 挂钩 3. 螺丝
挂钩便于临时悬挂工具。可安装在工具的任
一侧。要安装挂钩，请将其插入工具外壳上
任一侧的凹槽中，然后用螺丝加以紧固。要
拆卸挂钩，请将螺丝拧松，然后将其取出。
注意： 使用挂钩将工具悬挂在腰带上时，
请拆下起子头／钻头和侧把手。

20
中文简体
安装起子头夹持器
选购附件
►图片 11: 1. 起子头夹持器 2. 起子头
将起子头夹持器嵌入工具底座左侧或右侧的
突起中，并用螺丝加以紧固。
不使用起子头时，将其存放在起子头夹持器
内。夹持器可存放 45 mm 长的起子头。
安装侧把手（辅助手柄）
选购附件
►图片 12: 1. 凸起部分 2. 钳臂 3. 凹槽
4. 把手
插入侧把手，使钳臂上的凸起部分对准工具
上的凹槽。然后顺时针拧紧把手。
侧把手可安装在工具左侧或右侧，视具体操
作情况而定。
操作
小 心： 插入电池组时请务必使其完全锁
紧到位。如果插入后仍能看到按钮上侧的红
色指示灯，则说明电池组未完全锁紧。此
时，须将电池适配器完全插入，直到红色指
示灯不亮为止。否则它可能会意外从工具中
脱落，从而造成自身或他人受伤。
小心： 如果速度极速降低，请减小负荷
或停止工具以避免损坏工具。
一手握住机器把手，另一只手握住电池组底
部，紧握机器，防止其出现扭动现象。
旋紧螺丝的操作
小心： 将调节环调至适当的转矩等级
操作。
小 心： 务必要将起子头平直地插入螺丝
头端，否则会损坏螺丝和／或起子头。
首先，旋转动作模式切换环，使机身上的箭
头指向 标记。
将起子头的尖端放进螺丝头部并对工具施加
压力。要慢速启动工具，然后逐渐提高转速。
插入离合器的同时即可松开开关扳机。
►图片 13
注： 钉入木螺丝时，应先钻直径为木螺丝
直径 2/3 的引导孔。以便于操作并防止工件
开裂。
冲击钻孔操作
小 心： 钻穿时若钻孔被碎片或粉屑堵塞
或冲击到混凝土中的钢筋，工具／钻头会受
到极大的突然扭力。
首先，旋转动作模式切换环，使机身上的箭
头指向 标记。进行此操作时，调节环可对
齐任何转矩等级。
请务必使用碳化钨钻头。
将钻头对准需钻孔的位置，然后扣动开关扳
机。使用工具时请勿用力过猛。轻轻施压效
果最佳。保持工具定位正确，防止工具偏离
孔位。
当钻孔被碎屑或碎片堵塞时切勿过度用力。
相反，请怠速旋转工具，然后逐渐从孔中取
出钻头。如此重复数次便可将孔眼清理干净，
重新开始正常钻孔。
吹气球
选购附件
►图片 14: 1. 吹气球
钻孔后用吹气球清除孔眼中的尘土。
钻孔操作
首先，旋转动作模式切换环，使箭头指向 标
记。然后进行如下操作。
在木材上钻孔
在木材上钻孔时，使用带有前导螺丝的木材
用钻头将获得最佳效果。这种前导螺丝可令
钻孔操作更加轻松。
在金属上钻孔
开始钻孔时，为了防止钻头打滑，可用一尖冲
头和锤子在金属板上想要钻孔的地方打一痕
记。将钻头尖端放入凹痕，然后开始钻孔。
在金属上钻孔时请使用切割油。但在铁和铜
材料上钻孔时应干钻。
