Parts Breakdown BML185
Page 1 of 2 8/18/2010

Parts Breakdown BML185
Fig # Part ID Part Name Quantity
Products with multiple versions are listed in subsiding order with the newest version on top not indented
1 GM00001003 CASE HEAD, BML185 1
2 GM00001010 BULB CONTACT PLATE(-),BML185 1
3 GM00001002 PROTECTOR F/CONTACT, BML185 1
4 A-90261 BULB SET (2/PKG), BML185 1
5 GM00001012 SCREW 3X12, BML185 1
6 A-90261 BULB SET (2/PKG), BML185 1
7 GM00000130 REFLECTOR, ML140 1
8 GM00000070 LENS, ML140 1
9 GM00001001 REFLECTOR RETAINER, BML185 1
10 GM00001009 BULB CONTACT PLATE(+),BML185 1
11 GM00001006 RUBBER COVER, BML185 1
12 GM00000200 SWITCH, ML180 1
13 GM00001055 BATTERY HOLDER, BUB182 1
13 GM00001116 BATTERY HOLDER, BML185 1
14 GM00001011 N/A 1
14 GM00001029 PCB, BML185 1
15 GM00001005 KNOCK SHAFT, BML185 1
16 GM00000090 COMPRESSION SPRING 4, BML185 1
17 GM00001005 KNOCK SHAFT, BML185 1
18 GM00001000 HOUSING SET, BML185 1
19 632524-4 PIVOT TERMINAL UNIT R, ML702 1
19 GM00001004 LEFT CASE SHAFT, BML185 1
20 233144-3 COMPRESSION SPRING 7, ML702 1
21 632524-4 PIVOT TERMINAL UNIT R, ML702 1
21 GM00001004 LEFT CASE SHAFT, BML185 1
22 GM00001000 HOUSING SET, BML185 1
23 GM00001013 SCREW 3X14, BML185 5
24 GM00001008 NAME PLATE, BML185 1
5,001 810320-2 CAUTION LABEL, BML185W 1
Page 2 of 2 8/18/2010
