Parts Breakdown 9218SB
Page 1 of 2 2/8/2008

Parts Breakdown 9218SB
Fig # Part ID Part Name Quantity
1 156993-0 GEAR HOUSING COVER 1
2 212004-2 N.BEARING 810,4200N 1
3 961055-9 RETAINING RING S-15, 5057KB 1
4 254001-2 WOODRUFF KEY 4, HM1303B 1
5 221273-4 H. GEAR, 9218SB 1
6 312368-5 GEAR HOUSING, 9218SB 1
7 911171-7 P.H. SCREW M4X45, 9218SB 2
8 911161-0 P.H. SCREW M4X35, 9218SB 2
9 211206-7 B. BEARING 6202LLB, NHP1310 1
10 321957-5 SPINDLE, 9218SB 1
11 285809-3 BEARING RETAINER 23-36, 9218PB 1
12 224517-1 LOCK NUT, 9227CY, 5,7 1
13 263002-9 RUBBER PIN 4, HR2400 1
14 211101-1 BALL BEARING 6001LLB,9218PB 1
15 961052-5 RETAINING RING S-12, 9218PBL 1
16 241044-3 FAN 68, 9218SB 1
17 512402-3 ARMATURE, 9218SB 1
18 213002-9 DUST SEAL 8, 6013BR 1
19 211033-2 B. BEARING 608LB, 5091D 1
20 263002-9 RUBBER PIN 4, HR2400 1
21 411241-7 BAFFLE PLATE, 9218SB 1
22 911681-4 P.H. SCREW M5X60, 9218PBL 2
23 522222-7 FIELD, 9218SB 1
27 811828-9 NAME PLATE, 9218SB 1
28 156105-5 MOTOR HOUSING, 9218PB(T1) 1
28 159596-9 MOTOR HOUSING, 9218PBL 1
29 191945-4 CARBON BRUSH CB-124, 9045B 1
30 643600-9 BRUSH CAP 6-10, 9005B 2
31 651232-8 SWITCH, 9218SB 1
33 664064-4 CORD (2X18X8 SJ), HR2400 1
34 682502-4 CORD GUARD 8-85, HP1621F 1
35 687002-9 STRAIN RELIEF, 9217SPC 1
36 911133-5 P.H. SCREW M4X18, N9501B 2
37 911138-5 P.H. SCREW M4X20, 9218SB 2
38 414994-7 HANDLE COVER, 9218PBL 1
38 411239-4 HANDLE COVER, 9218PB(T1) 1
39 819063-3 MAKITA LABEL, 6992DWDE 1
400 743012-7 7 RUBBER PAD, 9217SPC 1
401 794094-2 N/A 1
402 152492-0 GRIP 36 COMP. 9005B-T2 1
403 781008-0 WRENCH 17, 9217SPC 1
404 782412-6 LOCK NUT WRENCH 28, GA7911 1
404 782413-4 LOCK NUT WRENCH, 9005B-T1 1
900 810146-2 N/A 1
Page 2 of 2 2/8/2008
