Makita TD0101 User manual

INSTRUCTION MANUAL
Impact Driver
TD0101
TD0101F
ENGLISH: Original instructions
DOUBLE INSULATION
Read before use.

2ENGLISH
SPECIFICATIONS
Model TD0101/TD0101F
Capacities Machine screw 4 mm - 8 mm
Standard bolt 5 mm - 14 mm
High tensile bolt 5 mm - 10 mm
No load speed (min-1)0 - 3,600
Impacts per minute (min-1)0 - 3,200
Max. fastening torque 100 N.m
Dimensions (L x W x H) 184 mm x 67 mm x 192 mm
Net weight 0.99 kg
Safety class II
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• WeightaccordingtoEPTA-Procedure01/2014
Symbols
The following show the symbols used for the equip-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
DOUBLE INSULATION
Only for EU countries
Do not dispose of electric equipment
together with household waste material!
InobservanceoftheEuropeanDirective,
on Waste Electric and Electronic Equipment
and its implementation in accordance with
nationallaw,electricequipmentthathave
reached the end of their life must be col-
lectedseparatelyandreturnedtoanenvi-
ronmentally compatible recycling facility.
Intended use
Thetoolisintendedforscrewdrivinginwood,metal
and plastic.
Power supply
The tool should be connected only to a power supply of the
samevoltageasindicatedonthenameplate,andcanonly
be operated on single-phase AC supply. They are double-in-
sulated in accordance with European Standard and can,
therefore, also be used from sockets without earth wire.
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
darkareasinviteaccidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust.Powertoolscreatesparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
7.
Use of power supply via an RCD with a rated resid-
ual current of 30 mA or less is always recommended.
8. Power tools can produce electromagnetic elds
(EMF) that are not harmful to the user.However,
users of pacemakers and other similar medical
devicesshouldcontactthemakeroftheirdeviceand/
ordoctorforadvicebeforeoperatingthispowertool.
9. Do not touch the power plug with wet hands.

3ENGLISH
10. If the cord is damaged, have it replaced by the
manufacturer or his agent in order to avoid a
safety hazard.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication. A moment of inattention while operating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection.Protectiveequipmentsuch
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertools
thathavetheswitchoninvitesaccidents.
4.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotatingpartofthepowertoolmayresultinpersonalinjury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
longhaircanbecaughtinmovingparts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8.
Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
causesevereinjurywithinafractionofasecond.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct
powertoolwilldothejobbetterandsaferatthe
rate for which it was designed.
2.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools.Suchpreventivesafetymeasuresreduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool.Powertoolsaredangerousinthe
hands of untrained users.
5.
Maintain power tools and accessories. Check for
misalignment or binding of moving parts, break-
age of parts and any other condition that may
affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
6. Keep cutting tools sharp and clean.Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
8.
Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled. The entangle-
mentofclothworkglovesinthemovingpartsmay
resultinpersonalinjury.
Service
1.
Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
2. Follow instruction for lubricating and chang-
ing accessories.
Impact driver safety warnings
1. Hold the power tool by insulated gripping
surfaces, when performing an operation where
the fastener may contact hidden wiring or its
own cord.Fastenerscontactinga"live"wiremay
makeexposedmetalpartsofthepowertool"live"
andcouldgivetheoperatoranelectricshock.
2. Always be sure you have a rm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool rmly.
4. Wear ear protectors.
5. Do not touch the bit or the workpiece immedi-
ately after operation. They may be extremely
hot and could burn your skin.

4ENGLISH
6. Keep hands away from rotating parts.
7. Use auxiliary handle(s), if supplied with the
tool.Lossofcontrolcancausepersonalinjury.
8.
Hold the power tool by insulated gripping sur-
faces, when performing an operation where the
cutting accessory may contact hidden wiring or
its own cord.Cuttingaccessorycontactinga"live"
wire may make exposed metal parts of the power tool
"live"andcouldgivetheoperatoranelectricshock.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace strict
adherence to safety rules for the subject product.
MISUSE or failure to follow the safety rules stated in this
instruction manual may cause serious personal injury.
FUNCTIONAL
DESCRIPTION
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
unpluggedbeforeadjustingorcheckingfunction
on the tool.
Switch action
1
►1. Switch trigger
CAUTION:
• Beforeplugginginthetool,alwayschecktosee
that the switch trigger actuates properly and
returns to the "OFF" position when released.
To start the tool, simply pull the switch trigger. Tool
speed is increased by increasing pressure on the switch
trigger. Release the switch trigger to stop.
Lighting up the lamp (Model
TD0101F only)
1
►1. Lamp
CAUTION:
• Donotlookinthelightorseethesourceoflight
directly.
Connect the plug to light up the lamp. The lamp keeps
on lighting while the plug is connected.
NOTE:
• Useadryclothtowipethedirtoffthelensof
lamp. Be careful not to scratch the lens of lamp,
or it may lower the illumination.
• Donotusethinnerorgasolinetocleanthelamp.
Suchsolventsmaydamageit.
Reversing switch action
A
1
B
►1.Reversingswitchlever
Thistoolhasareversingswitchtochangethedirection
ofrotation.Depressthereversingswitchleverfromthe
A side for clockwise rotation or from the B side for coun-
terclockwise rotation.
CAUTION:
• Alwayscheckthedirectionofrotationbefore
operation.
• Usethereversingswitchonlyafterthetool
comes to a complete stop. Changing the direc-
tion of rotation before the tool stops may dam-
age the tool.

5ENGLISH
ASSEMBLY
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
unplugged before carrying out any work on the
tool.
Installing or removing driver bit or
socket bit
Use only bits that has inserting portion shown in the
gure.
For European and North & South
American countries, Australia and
New Zealand
A=12mm
B=9mm
Use only these type of bit. Follow the
procedure (1).
(Note) Bit-piece is not necessary.
For other countries
To install these types of bits, follow
the procedure (1).
(Note) Makita bits are these types.
To install these types of bits, follow
the procedure (2).
(Note) Bit-piece is necessary for
installing the bit.
A=17mm
B=14mm
A=12mm
B=9mm
1. Toinstallthebit,pullthesleeveinthedirectionof
thearrowandinsertthebitintothesleeveasfar
asitwillgo.Thenreleasethesleevetosecurethe
bit.
1
2
►1. Bit 2.Sleeve
2. Toinstallthebit,pullthesleeveinthedirectionof
the arrow and insert the bit-piece and bit into the
sleeveasfarasitwillgo.Thebit-pieceshouldbe
insertedintothesleevewithitspointedendfacing
in.Thenreleasethesleevetosecurethebit.
1
2
3
►1. Bit 2. Bit-piece 3.Sleeve
Toremovethebit,pullthesleeveinthedirectionofthe
arrowandpullthebitoutrmly.
NOTE:
• Ifthebitisnotinserteddeepenoughintothe
sleeve,thesleevewillnotreturntoitsoriginal
position and the bit will not be secured. In this
case, try re-inserting the bit according to the
instructionsabove.
OPERATION

6ENGLISH
NOTE:
• Thesizeofwoodscrewwhichcanbefastened
with this tool may differ depending upon the type
of material to be fastened. Always perform a test
operation to determine the size of wood screw.
Holding the tool
Hold the tool only by the handle when performing an
operation. Do not touch the metal part.
The proper fastening torque may differ depending upon
the kind or size of the screw/bolt, the material of the
workpiece to be fastened, etc. The relation between fas-
teningtorqueandfasteningtimeisshowninthegures.
M12
M10
M8
80
60
40
20
0
(204)
(408)
(816)
(612)
1.0 2.0 3.0
Standard bolt
N m
(kgf.cm)
M12
M10
M8
(S)
Fastening time
Fastening torque
Proper fastening torque
.
100
120
(1224)
(1020) M14
M14
M10
M8
80
60
40
20
0
(204)
(408)
(816)
(612)
1.0 2.0 3.0
High tensile bolt
N m
(kgf.cm)
M10
M8
(S)
Fastening time
Fastening torque
Proper fastening torque
.
100
(1020)
Holdthetoolrmlyandplacethepointofthedriverbit
in the screw head. Apply forward pressure to the tool to
the extent that the bit will not slip off the screw and turn
the tool on to start operation.
NOTE:
• Usetheproperbitfortheheadofthescrew/bolt
that you wish to use.
• WhenfasteningscrewM8orsmaller,carefully
adjustpressureontheswitchtriggersothatthe
screw is not damaged.
• Holdthetoolpointedstraightatthescrew.
• Ifyoutightenthescrewforatimelongerthan
showninthegures,thescreworthepointof
thedriverbitmaybeoverstressed,stripped,
damaged,etc.Beforestartingyourjob,always
perform a test operation to determine the proper
fastening time for your screw.
Thefasteningtorqueisaffectedbyawidevarietyof
factors including the following. After fastening, always
check the torque with a torque wrench.
1. Driverbitorsocketbit
Failuretousethecorrectsizedriverbitorsocket
bit will cause a reduction in the fastening torque.
2. Bolt
•
Eventhoughthetorquecoefcientandtheclass
of bolt are the same, the proper fastening torque
will differ according to the diameter of bolt.
• Eventhoughthediametersofboltsarethe
same, the proper fastening torque will differ
accordingtothetorquecoefcient,theclass
of bolt and the bolt length.
3.
The manner of holding the tool or the material of
drivingpositiontobefastenedwillaffectthetorque.
4. Operating the tool at low speed will cause a reduc-
tion in the fastening torque.
MAINTENANCE
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
unplugged before attempting to perform inspec-
tion or maintenance.
• Neverusegasoline,benzine,thinner,alcohol
or the like. Discoloration, deformation or cracks
may result.
Replacing carbon brushes
1
►1. Limit mark

7ENGLISH
Removeandcheckthecarbonbrushesregularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
Useascrewdrivertoremovethebrushholdercaps.
Take out the worn carbon brushes, insert the new ones
and secure the brush holder caps.
1
2
►1.Screwdriver2. Brush holder cap
To maintain product SAFETY and RELIABILITY,
repairs, carbon brush inspection and replacement, any
othermaintenanceoradjustmentshouldbeperformed
byMakitaAuthorizedServiceCenters,alwaysusing
Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION:
• Theseaccessoriesorattachmentsarerecom-
mendedforusewithyourMakitatoolspecied
in this manual. The use of any other accessories
orattachmentsmightpresentariskofinjuryto
persons. Only use accessory or attachment for
its stated purpose.
If you need any assistance for more details regard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Screwbits
• Socketbits
• Bitpiece
• Adjustablelocatorwithbit
• Hook
NOTE:
• Someitemsinthelistmaybeincludedinthe
tool package as standard accessories. They
may differ from country to country.
Hook
1
2
3
►1. Screw 2. Hook 3.Groove
Thehookisconvenientfortemporarilyhangingthetool.
This can be installed on either side of the tool.
Toinstallthehook,insertitintoagrooveinthetool
housing on either side and then secure it with a screw.
Toremove,loosenthescrewandthentakeitout.
• Adjustablelocatorwithbit
Adjustable locator with bit
1
2
►1. Bumper 2.Hammercasecover
Tousetheadjustablelocatorwithbit,removethe
bumperandtheninstallit.Thebumpercanberemoved
by pulling forward.

Makita Corporation
www.makita.com
884879B5
EN
20170426
