Parts Breakdown AN922
Page 1 of 3 2/8/2008

Parts Breakdown AN922
Fig # Part ID Part Name Quantity
1 416892-1 CYLINDER SEPARATOR, AN922 1
2 213809-3 O RING 87, AN8300 1
3 213668-5 O RING 60, AN922 1
4 331548-4 CYLINDER, AN922 1
5 213667-7 O RING 61, HM1800 1
6 421680-3 CUSHION F, AN922 1
7 421687-9 CUSHION GUIDE, AN922 1
8 233243-1 COMPRESSION SPRING 50, AN922 1
9 213504-5 O RING, 9820-2 1
10 213669-3 O RING 56, AN922 1
11 416891-3 HEAD VALVE, AN922 1
12 421679-8 VALVE SEAT, AN922 1
13 267742-1 WASHER 34, AN922 1
14 421678-0 CUSHION R, AN922 1
15 213619-8 O RING 49, AN922 1
16 151619-9 DRIVER COMPLETE, AN922 1
17 265976-0 H.S.H. BOLT M5X10,9040L 3
18 344764-9 EXHAUST COVER, AN922 1
19 922342-1 H.S.H. BOLT M6X25, HR2511 4
20 317168-8 TOP CAP, AN922 1
21 162209-3 TOP CAP GASKET, AN922 1
22 851640-5 NAME PLATE, AN922 1
23 151731-5 HOUSING COMPLETE, AN922 1
24 961011-9 STOP RING E-4, 4301BV 1
25 951075-1 SPRING PIN 3-28, UM401DW 2
26 162208-5 LOCK PIN 6, AN922 1
27 231236-2 COMP. SPRING 3, AN611 1
28 216008-6 STEEL BALL 4.0, 6820V 1
29 162210-8 INLET CAP GASKET, AN922 1
30 416890-5 INLET FILTER, AN922 1
31 317169-6 INLET CAP, AN922 1
32 286221-0 CAP 15, AN8300 1
33 922252-2 H.S.H. BOLT M5X30, AF501 3
34 213176-6 O RING 14, AN922 1
35 416806-0 TRIGGER VALVE GUIDE, AN922-T1 1
35 417695-6 TRIGGER VALVE GUIDE, AN922 1
36 213262-3 O RING 18, 5005BA 1
37 213039-6 O RING 6, AN922 1
38 213040-1 O RING 8, AN922 1
39 317520-0 PILOT VALVE, AN922 1
39 417694-8 PILOT VALVE, AN922-T2 1
39 416804-4 PILOT VALVE, AN922-T1 1
40 213122-9 O RING 12, AN922 1
41 233239-2 COMPRESSION SPRING 3, AN922 1
42 323852-5 TRIGGER VALVE STEM, AN922 1
43 213044-3 O RING 3, AN901 2
43 213034-6 O RING 3, AF502 2
44 317521-8 TRIGGER VALVE CASE, AN922 1
44 416805-2 TRIGGER VALVE CASE, AN922 1
45 344265-7 IDLER, AN611 1
46 258004-8 SPRING PIN 2.5-16, 420S 1
47 415790-6 TRIGGER, AN611 1
48 951075-1 SPRING PIN 3-28, UM401DW 1
49 310084-3 HOLDER, AN922 1
50 951075-1 SPRING PIN 3-28, UM401DW 1
51 310085-1 STOPPER, AN922 1
52 951060-4 SPRING PIN 3-14, 4301BV 1
53 310056-8 ADJUSTER, AN611 1
54 231978-8 CONICAL COMP SPRING 9-16, AN611 1
55 941101-4 F. WASHER 5, JR3000V 2
Page 2 of 3 2/8/2008

Parts Breakdown AN922
56 265973-6 H.S.H.BOLT M5X20, AF631 2
57 165253-9 JOINT, AN922 1
58 416898-9 MAGAZINE CAP, AN922 1
59 151730-7 MAGAZINE COMPLETE, AN922 1
59 153957-5 MAGAZINE CPL., AN922 1
60 266218-5 H.S.H. BOLT M6X10, AN922 2
61 344767-3 NAIL STOPPER, AN922 1
62 922217-4 H.S.H. BOLT M5X14, JS3200,T1 2
63 344769-9 MAGAZINE RAIL, AN922 1
64 344765-7 HOLDER, AN922 1
65 266218-5 H.S.H. BOLT M6X10, AN922 1
65 266218-5 H.S.H. BOLT M6X10, AN922 1
65 266157-9 H.S.H.BOLT M6X12, TW1000 1
66 213654-6 O RING 60, HR3851 1
67 310071-2 DRIVER GUIDE, AN922 1
67 310107-7 DRIVER GUIDE, AN922 1
68 265469-7 H.S.H. BOLT M8X25, AN922 4
69 233080-3 COMPRESSION SPRING 8, AN922 1
70 344774-6 CONTACT ARM, AN922 1
71 421418-6 RUBBER PIN 9.5, AN611 1
72 266218-5 H.S.H. BOLT M6X10, AN922 1
73 265962-1 H.S.H. BOLT M6X20, AN8300 1
74 253058-0 F. WASHER 7, 9030 1
75 417614-2 COVER, AN942 1
75 417614-2 COVER, AN942 1
75 416893-9 COVER, AN922-T1 1
76 267743-9 SHOULDER WASHER 6, AN922 1
77 344766-5 HOLDER, AN922 1
78 163410-3 SPIRAL SPRING COMPLETE, AN922 1
79 414639-7 SPRING GUIDE, AN922 1
80 256428-2 PIN 5-8, AN8300 1
81 262054-7 URETHANE RING 3, AN451 1
82 256760-4 PIN 4, AN922 1
83 416896-3 PUSHER LEVER, AN922 1
84 262054-7 URETHANE RING 3, AN451 1
85 344770-4 LOCK PLATE, AN922 1
86 231309-1 COMP. SPRING 5, AF502 1
87 344772-0 PUSHER, AN922 1
88 233038-2 COMPRESSION SPRING 5, AN451 1
89 256697-5 PIN 4, AF502 1
90 253726-5 F. WASHER 6, 6000LR 1
1,001 192517-8 SAFETY GOGGLE, AN611 1
1,002 181434-7 OIL SUPPLY 30CC, AF502 1
1,003 421677-2 NOSE ADAPTER, AN922 1
2,001 193006-6 FIRST AID KIT, AN922 1
