Parts Breakdown AN621
Page 1 of 3 2/8/2008

Parts Breakdown AN621
Fig # Part ID Part Name Quantity
1 265903-7 H.S.H.BOLT M5X12, AN451 1
2 267171-8 FLAT WASHER 6, AN611 1
3 317345-2 EXHAUST COVER, AN621 1
4 213255-0 O RING 18, 4200H 1
5 323863-0 EXHAUST FILTER, AG125 1
6 213604-1 O RING 50, 6911D 1
7 922242-5 H.S.H. BOLT M5X25, AF502 4
8 317287-0 TOP CAP, AN611 1
9 931202-6 HEX NUT M5, HR2410 1
10 421573-4 CUSHION R, AN611 1
11 213513-4 O RING 39, AN611 1
12 416234-9 SEPARATOR, AN611 1
13 213393-8 O RING 23, AN611 1
14 213616-4 O RING 48, AN611 1
15 233199-8 COMPRESSION SPRING 3, AN611 8
16 416236-5 HEAD VALVE, AN611 1
17 421576-8 VALVE SHEET, AN611 1
18 323979-1 CUSHION GUIDE, AN621 1
19 213616-4 O RING 48, AN611 1
20 331573-5 CYLINDER, AN621 1
21 213608-3 O RING 47, AN8300, T1 1
22 213706-3 O RING 67, AN8300 1
23 416235-7 CYLINDER SEPARATOR, AN611 1
24 152756-2 DRIVER CPL.,AN621 1
25 213521-5 O RING 36, AN611 1
26 852995-1 NAME PLATE, AN621 1
27 216008-6 STEEL BALL 4.0, 6820V 1
28 231236-2 COMP. SPRING 3, AN611 1
29 162189-3 LOCK PIN 6, AN611 1
30 344895-4 HOLDER, AN621 1
31 951075-1 SPRING PIN 3-28, UM401DW 1
32 951075-1 SPRING PIN 3-28, UM401DW 1
33 233269-3 COMPRESSION SPRING 7, AN621 1
33 233382-7 COMPRESSION SPRING 6, AN621 1
34 310104-3 STOPPER, AN621 1
35 233267-7 COMPRESSION SPRING 7, AN621 1
36 310101-9 ADJUSTER, AN621 1
37 233269-3 COMPRESSION SPRING 7, AN621 1
37 233382-7 COMPRESSION SPRING 6, AN621 1
38 344865-3 CONTACT ARM, AN621 1
39 951010-9 SPRING PIN 2-14, AN611 1
40 415790-6 TRIGGER, AN611 1
41 258004-8 SPRING PIN 2.5-16, 420S 1
42 344265-7 IDLER, AN611 1
43 258010-3 SPRING PIN 2.5-25, AF502 2
44 323727-8 TRIGGER VALVE CASE, AN611 1
45 213315-8 O RING 19, AN611 1
46 257229-1 RING 12, AN621 1
47 415789-1 PILOT VALVE, AN611 1
48 213162-7 O RING 14, 2414B 1
49 213023-1 O RING 4, AF501 1
50 213023-1 O RING 4, AF501 1
51 323978-3 TRIGGER VALVE STEM, AN621 1
52 213023-1 O RING 4, AF501 1
53 233189-1 COMPRESSION SPRING 6, AN611 1
54 416379-3 TRIGGER VALVE GUIDE, AN611 1
55 213162-7 O RING 14, 2414B 1
56 162190-8 TOP CAP GASKET, AN611 1
57 152844-5 HOUSING CPL.,AN621 1
58 961011-9 STOP RING E-4, 4301BV 1
Page 2 of 3 2/8/2008

Parts Breakdown AN621
59 162198-2 INLET CAP GASKET, AN611 1
60 415784-1 INLET FILTER, AN611 1
61 317340-2 INLET CAP, AN901 1
62 922252-2 H.S.H. BOLT M5X30, AF501 3
63 286219-7 CAP 12, AF502 1
65 922216-6 H.S.H. BOLT M5X14, 5077B 1
66 344720-9 HOOK, AN901 1
67 414934-5 HOLDER CAP, AN451 1
68 417173-6 CHANGE PLATE, AN621 1
69 152843-7 MAGAZINE CPL.,AN621 1
69 152843-7 MAGAZINE CPL.,AN621 1
70 265973-6 H.S.H.BOLT M5X20, AF631 1
71 813776-8 INDICATION LABEL, AN621 1
72 423232-6 RUBBER PLATE 6-20, AN451 1
73 231791-4 TENSION SPRING 5, AN611 1
74 414934-5 HOLDER CAP, AN451 1
75 265903-7 H.S.H.BOLT M5X12, AN451 2
76 344864-5 CYLINDER COVER, AN621 1
77 310102-7 CHANGE LEVER, AN621 1
78 310103-5 PISTON STOPPER, AN621 1
79 233198-0 COMPRESSION SPRING 9, AN611 1
80 233268-5 COMPRESSION SPRING 14, AN621 1
81 213379-2 O RING 21, AG125 1
82 323977-5 PISTON, AN621 1
83 213055-8 O RING 10, HR3851 1
84 344862-9 CHECK CLAW F, AN621 1
85 262054-7 URETHANE RING 3, AN451 1
86 344863-7 CHECK CLAW R, AN621 1
87 421722-3 CUSHION F, AN621 1
88 213569-7 O RING 45, AN611 1
89 213017-6 O RING 6, 5177B 1
90 151924-4 DRIVER GUIDE CPL, AN621 1
91 265844-7 H.S.H BOLT M6X20, AN611 4
92 262054-7 URETHANE RING 3, AN451 1
93 310106-9 DOOR, AN621 1
94 417175-2 CONTACT ARM COVER, AN621 1
95 417174-4 COVER, AN621 1
96 266233-9 H.S.H. BOLT M5X12, AG125 2
97 344861-1 MAGAZINE LOCK, AN621 1
98 417176-0 MAGAZINE CAP, AN621 1
99 268025-2 PIN 5, AN611 1
100 233265-1 COMPRESSION SPSRING 5, AN621 1
101 233265-1 COMPRESSION SPSRING 5, AN621 1
102 922216-6 H.S.H. BOLT M5X14, 5077B 1
103 323976-7 LOCK PIN, AN621 1
104 233197-2 COMPRESSION SPRING 7, AN611 1
105 267010-2 F. WASHER 5, AN451 1
106 414933-7 LOCK LEVER, AN451 1
108 266233-9 H.S.H. BOLT M5X12, AG125 1
109 268050-3 PIN 4, AN621 1
110 310105-1 FEEDING CLAW, AN621 1
111 262054-7 URETHANE RING 3, AN451 1
112 268051-1 PIN 4, AN621 1
113 233266-9 COMPRESSION SPRING 5, AN621 1
1,001 192517-8 SAFETY GOGGLE, AN611 1
1,002 181434-7 OIL SUPPLY 30CC, AF502 1
1,003 783202-0 HEX WRENCH 4, JR3000V 1
1,004 824582-6 PLASTIC TOOL CASE, AN621 1
