INSTRUCTION MANUAL
Construction Coil Nailer
AN935H
ENGLISH: Original instructions
Read before use.

2ENGLISH
SPECIFICATIONS
Model: AN935H
Air pressure 1.28 - 2.26 MPa (12.8 - 22.6 bar)
Nail length Wire-collated coil nail 45 mm - 90 mm
Sheet-collated coil nail 45 mm - 75 mm
Nail capacity Wire-collated coil nail 120 pcs - 300 pcs
Sheet-collated coil nail 200 pcs
Minimum hose diameter 4.0 mm
Pneumatic tool oil ISO VG32 or equivalent
Dimensions (L x W x H) 299 mm x 125 mm x 330 mm
Net weight 2.7 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• WeightaccordingtoEPTA-Procedure01/2003
Symbols
Thefollowingshowthesymbolsusedfortheequip-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
Wear safety glasses.
Donotuseonscaffoldings,ladders.
Intended use
Thetoolisintendedforthepreliminaryinteriorwork
suchasxingoorjoistsorcommonraftersandframing
workin2″x4″housing.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ingtoEN792:
Sound pressure level (LpA):84dB(A)
Sound power level (LWA):97dB(A)
Uncertainty(K):3dB(A)
WARNING: Wear ear protection.
Vibration
Thevibrationtotalvaluedeterminedaccordingto
EN792:
Vibration emission (ah):4.5m/s2
Uncertainty(K):1.5m/s2
NOTE:Thedeclaredvibrationemissionvaluehas
been measured in accordance with the standard test
method and may be used for comparing one tool with
another.
NOTE:Thedeclaredvibrationemissionvalue
may also be used in a preliminary assessment of
exposure.
WARNING:Thevibrationemissionduringactual
use of the power tool can differ from the declared
emission value depending on the ways in which the
tool is used.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it is
running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
to this instruction manual.
SAFETY WARNINGS
Pneumatic nailer/stapler safety
warnings
WARNING: WARNING Read all safety warn-
ings and all instructions. Failure to follow the
warningsandinstructionsmayresultinseriousinjury,
electricshockand/orre.
Save all warnings and instruc-
tions for future reference.
For personal safety and proper operation and maintenance
ofthetool,readthisinstructionmanualbeforeusingthetool.
General safety
1.
Do not permit those uninstructed to use the tool.
2. No horseplay. Respect the tool as a working
implement.
3. Do not operate when under the inuence of
alcohol, drugs or the like.
4. Never alter the tool.

3ENGLISH
Personal protective equipments
1. Always wear safety glasses to protect your
eyes from dust or fastener injury.
WARNING: It is an employer's responsibility
to enforce the use of safety eye protection
equipment by the tool operators and by other
persons in the immediate working area.
For Australia and New Zealand only
Always wear safety glasses and face shield to
protect your eyes from dust or fastener injury.
Thesafetyglassesandthefaceshieldshould
conformwiththerequirementsofAS/NZS1336.
2. Wear hearing protection to protect your ears
against exhaust noise and head protection.
Also wear light but not loose clothing. Sleeves
should be buttoned or rolled up. No necktie
should be worn.
Work area safety
1. Keep work area clean and well lit.Clutteredor
dark areas invite accidents.
2. Do not operate the tool in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Operating the tool can
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating the tool. Distractions can cause you to
lose control.
4. Illuminate the work area sufciently.
5.
There may be local regulations concerning
noise which must be complied with by keeping
noise levels within prescribed limits. In certain
cases, shutters should be used to contain noise.
Safety devices
1. Make sure all safety systems are in working
order before operation. Thetoolmustnotoper-
ate if only the trigger is pulled or if only the contact
arm is pressed against the wood. It must work only
whenbothactionsareperformed.Testforpossible
faulty operation with fasteners unloaded and the
pusher in fully pulled position.
2. Do not play with the contact element: it pre-
vents accidental discharge, so it must be kept
on and not removed. Securing the trigger in the
ON position is also very dangerous. Never attempt
to fasten the trigger. Do not operate a tool if any
portionofthetooloperatingcontrolsisinoperable,
disconnected,altered,ornotworkingproperly.
3. Do not attempt to keep the contact element
depressed with tape or wire. Death or serious
injurymayoccur.
4. Always check contact element as instructed
in this manual. Fasteners may be driven acci-
dentally if the safety mechanism is not working
correctly.
Loading fasteners
1. Do not load the tool with fasteners when any
one of the operating controls is activated.
2. Use only fasteners specied in this manual.
Theuseofanyotherfastenersmaycausemal-
function of the tool.
Power source
1. Never connect the tool to compressed air line
where the air pressure can exceed the suitable
air pressure range of the tool, specied in the
"SPECIFICATIONS" table, by 10%. Make sure
that the pressure supplied by the compressed air
system does not exceed the suitable air pressure
range of the tool. Set the air pressure initially to
the lower value of the suitable air pressure range.
2. When using the tool operated by compressed
air, particular attention must be paid to avoid
exceeding the maximum allowable pressure.
3. Operate the tool at the lowest pressure
required for the application, in order to prevent
unnecessarily high noise levels, increased
wear and resulting failures.
4. Never use the tool with other than compressed
air.Ifbottledgas(carbondioxide,oxygen,
nitrogen,hydrogen,air,etc.)orcombustiblegas
(hydrogen,propane,acetylene,etc.)isusedasa
powersourceforthistool,thetoolwillexplodeand
causeseriousinjury.
5. Always disconnect the air hose and remove all
of the fasteners:
— when unattended;
— before performing any maintenance or
repair;
— beforecleaningajam;
— before moving the tool to a new location.
6. Use only pneumatic tool oil specied in this
manual.
Operational safety
1. Always check the tool for its overall condition
and loose screws before operation. Tighten as
required.
2. Handle the tool carefully, as there is high pres-
sure inside the tool that can be dangerous if a
crack is caused by rough handling (dropping
or striking). Do not attempt to carve or engrave
on the tool.
3. Stop the operation immediately if you notice
something wrong or out of the ordinary with
the tool. An improperly functioning tool must not
be used.
4. Do not point the ejection port at anyone in the
vicinity. Keep hands and feet away from the
ejection port area.
5. Always assume that the tool contains
fasteners.
6. Never point the tool toward yourself or anyone
whether it contains fasteners or not.
7. Do not rush the job or force the tool. Handle
the tool carefully.

4ENGLISH
8. Do not activate the tool unless the tool is
placed rmly against the workpiece.
9. Never hold or carry the tool with a nger on the
trigger or hand it to someone in this condition.
Accidentalringcancauseseriousinjury.
10. Never use fastener driving tools marked with
the symbol "Do not use on scaffoldings, lad-
ders" for specic application for example:
— when changing one driving location to
anotherinvolvestheuseofscaffoldings,
stairs,ladders,orladderalikeconstructions,
e.g. roof laths;
— closing boxes or crates;
— ttingtransportationsafetysystemse.g.on
vehicles and wagons.
11. Check walls, ceilings, oors, roong and
the like carefully to avoid possible electrical
shock, gas leakage, explosions, etc. caused by
striking live wires, conduits or gas pipes.
12. Do not use the tool for fastening electrical
cables. It is not designed for electric cable instal-
lation and may damage the insulation of electric
cablestherebycausingelectricshockorre
hazards.
13. Watch your footing and maintain your balance
with the tool. Make sure there is no one below
whenworkinginhighlocations,andsecuretheair
hosetopreventdangerifthereissuddenjerking
or catching.
14. On rooftops and other high locations, drive
fasteners as you move forward. It is easy to lose
your footing if you drive fasteners while inching
backward. When driving fasteners against perpen-
dicularsurface,workfromthetoptothebottom.
You can perform driving operations with less
fatigue by doing so.
15. A fastener will be bent or the tool can become
jammed if you mistakenly drive fastener on
top of another fastener or strike a knot in the
wood. The fastener may be thrown and hit
someone, or the tool itself can react danger-
ously. Place the fasteners with care.
16. Do not leave the loaded tool or the air com-
pressor under pressure for a long time out in
the sun. Be sure that dust, sand, chips and
foreign matter will not enter the tool in the
place where you leave it setting.
17. Never attempt to drive fasteners from both the
inside and outside at the same time. Fasteners
mayripthroughand/oryoff,presentingagrave
danger.
Service
1. Perform cleaning and maintenance right after
nishing the job. Keep the tool in tip-top condi-
tion. Lubricate moving parts to prevent rusting and
minimize friction-related wear. Wipe off all dust
from the parts.
2. Ask Makita authorized service center for peri-
odical inspection of the tool.
3. To maintain product SAFETY and RELIABILITY,
maintenance and repairs should be performed
by Makita Authorized Service Centers, always
using Makita replacement parts.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
PARTS DESCRIPTION
1
2
3
4
5
►1.Trigger2.Triggerlocklever3. Hook 4. Magazine
cap 5. Nose adapter (contact element)
INSTALLATION
Selecting compressor
0
0
10 20 30 40 50 60
20
40
60
80
100
120
140
1
2
3 4
5
1.Nailingfrequency(times/min)2.Compressorair
outputperminute(L/min)3. 2.26 MPa (22.6 bar) 4. 1.77
MPa (17.7 bar) 5. 1.28 MPa (12.8 bar)

5ENGLISH
Theaircompressormustcomplywiththerequirements
ofEN60335-2-34.
Select a compressor that has ample pressure and air
outputtoassurecost-efcientoperation.Thegraph
showstherelationbetweennailingfrequency,applica-
ble pressure and compressor air output.
Thus,forexample,ifnailingtakesplaceatarateof
approximately 40 times per minute at a compression of
1.77MPa(17.7bar),acompressorwithanairoutput
over100liters/minuteisrequired.
Pressure regulators must be used to limit air pressure to
the rated pressure of the tool where air supply pressure
exceeds the tool's rated pressure. Failure to do so may
resultinseriousinjurytotooloperatororpersonsinthe
vicinity.
Selecting air hose
CAUTION: Low air output of the compressor,
or a long or smaller diameter air hose in relation
to the nailing frequency may cause a decrease in
the driving capability of the tool.
Use a high pressure resistant air hose.
Use an air hose as large and as short as possible to
assurecontinuous,efcientnailingoperation.
Lubrication
1
►1. Pneumatic tool oil
Oil the tool with pneumatic tool oil by placing two or
threedropsintotheairtting.Thisshouldbedone
before and after use.
Forproperlubrication,thetoolmustberedacoupleof
times after pneumatic tool oil is introduced.
FUNCTIONAL
DESCRIPTION
CAUTION: Before adjusting or checking func-
tion on the tool, always lock the trigger by turning
the trigger lock lever to the lock position , and
disconnect the air hose from the tool.
Adjusting depth of nailing
Thistollhastheadjusterofthenailingdepth.Tomod-
ulatethenailingdepth,turntheadjustertotheproper
depth.
1
►1.Adjuster
Theadjustablerangeis8.5mm(11/32").(Onefullturn
allows1.25mm(1/16")adjustment.)
123
►1.Toodeep2. Flush 3.Tooshallow
Hook
CAUTION: Always disconnect the hose when
hanging the tool using the hook.
CAUTION: Never hook the tool at high loca-
tion or on potentially unstable surface.
CAUTION: Do not hang the hook from the
waist belt.Ifthenaileraccidentallydrops,itmay
resultinmisringandpersonalinjuries.
Thehookisusefulforhangingupthetooltemporarily.
Thehookcanbeturnedwhilepushingthebottomtothe
desired angle.

6ENGLISH
1
►1. Hook
Furthermore,thishookcanbeinstalledoneitherside
of the tool.
Tochangetheinstallationposition,removetheboltwith
a hex wrench. Install the hook on another side and then
secureitrmlywiththebolt.
2
1
►1. Hook 2. Bolt
Nose adapter
Topreventthesurfaceofworkpiecefrombeing
scratchedordamaged,usethenoseadapter.
Todetachthenoseadapterfromitshousingbase,pull
the nose adapter in the direction of the arrow.
1
►1. Nose adapter
Toattachthenoseadaptertothecontactelement,
press it onto the contact element until the recessed
partsinfourplacesinsidethenoseadaptertinfour
protrusions of the contact element.
3
2
14
►1. Nose adapter 2.Contactelement3. Protrusion
4. Recessed part
Air duster
CAUTION:
Do not aim the ejection port of the air
duster to someone. Also, keep your hands and foot
away from the ejection port. If the air duster button is
accidentallypushed,itmaycauseapersonalinjury.
CAUTION:
Always check your surroundings before
using the air duster.Blowndustorobjectsmayhitsomeone.
CAUTION: Do not connect or disconnect the
air hose while pushing the air duster button.
Theairsuppliedtothetoolcanalsobeusedasanair
duster. You can clean the work area by pressing the
button on the grip end.
1
►1. Button
NOTICE:Afterusingtheairduster,thedrivingforce
of the tool will temporarily decline. Wait until the air
pressure recovers in this case.
NOTICE: Perform a test blow if you use the air
dusterimmediatelyaftertheoilwasapplied.Theoil
may be sprayed with the air.
ASSEMBLY
CAUTION: Before carrying out any work on
the tool, always lock the trigger by turning the
trigger lock lever to the lock position , and
disconnect the air hose from the tool.

7ENGLISH
Loading nailer
CAUTION: Do not use deformed nails or
linked sheet.
1. Disconnect the air hose.
2. Depress the latch lever and open the door and
magazine cap.
1
2
3
►1. Latch lever 2. Door 3. Magazine cap
3. Turntheadjustshaftandsetthestepofthe
change plate suitable for the nail length. Make sure that
the arrow points to the corresponding graduation incre-
mentofthenaillengthmarkedontheadjustshaft.
1
2
3
►1.Changeplate2.Adjustshaft3. Arrow
NOTICE: If the tool is operated with the change
platesettothewrongstep,itmayresultinpoornail
feeding or tool malfunction.
4. Place the nail coil over the change plate and
uncoil enough nails to reach the nail rail.
Thenplacetherstnailinthenailrailandthesecond
nailinthefeedclaw.Also,placeotheruncoilednailson
feeder body.
1
2
►1. Nail rail 2. Feed claw
5.
Checkthatthenailcoilissetproperlyinthemagazine.
6. Closethemagazinecapcarefully.Thenwith
depressingthelatchlever,closethedooruntilthelatch
lever locks.
Connecting air hose
CAUTION: Do not connect the air hose with
a nger on the trigger. An unexpected driving will
causeseriousinjury.
12
►1.Airtting2. Air socket
Sliptheairsocketoftheairhoseontotheairttingon
thenailer.Besurethattheairsocketlocksrmlyinto
positionwheninstalledontotheairtting.
A hose coupling must be installed on or near the tool in
such a way that the pressure reservoir will discharge at
the time the air supply coupling is disconnected.
Changing the trigger for contact
actuation mode
CAUTION: Always disconnect the air hose
and unload the tool with nails before replacing
the trigger.
CAUTION: After the trigger replacement,
always check that the tool operates properly
before actual work. Do not load the tool with any
nails before checking the function to avoid unex-
pected nailing.

8ENGLISH
Thetriggerforsinglesequentialactuationmodeis
factory-installed.Tochangethenailingmodetocontact
actuation,replacethetriggerpartwiththeoneforcon-
tact actuation.
13
24
►1.Triggerforcontactactuation2. Silver part
3.Triggerforsinglesequentialactuation4. Black
part
1. Turnthetriggerlocklevertothelockposition .
1
►1.Triggerlocklever
2. Push the pin securing the trigger from the ure-
thanewasherside,andthenremovetheurethane
washer.Thenpulloutthepinandremovethetrigger.
1
2
3
►1. Pin 2. Urethane washer 3.Trigger
3. Set the trigger assembly for contact actuation.
Withpushinginthehingedpartinward,setthetrigger
so that the hinged part is under the rod of the valve in
the housing.
2
1
►1. Hinged part 2. Rod of the valve
4. Insert the pin to the hole and secure it by urethane
washer.
5. Connecttheairhose,andmakesurethatthe
tooloperatesproperly.Refertothesection“Checking
proper action before operation”.
NOTE:Tosetbacktosinglesequentialactuation,
follow the procedures for changing the trigger above.
OPERATION
CAUTION: Make sure all safety systems are in
working order before operation.
CAUTION: When operating the tool, do not
close the face to the tool. Also keep hands and
feet away from the ejection port area.
CAUTION: When not operating the tool,
always lock the trigger by turning the trigger lock
lever to the lock position .
CAUTION: Make sure that the trigger is
locked when the trigger lock lever is set to the
lock position .
Checking proper action before
operation
Beforeoperation,alwayscheckfollowingpoints.
— Make sure that the tool does not operate only by
connecting the air hose.
— Make sure that the tool does not operate only by
pulling the trigger.

9ENGLISH
— Make sure that the tool does not operate only by
placing the contact element against the workpiece
without pulling the trigger.
1
2
3
►1.Contactelement2. Workpiece 3.Trigger(not
pulled)
— Insinglesequentialactuationmode,makesure
that the tool does not operate when pulling the
triggerrstandthenplacingthecontactelement
against the workpiece.
1
2
Nailing method
Topreventthetriggerfrombeingaccidentallypulled,
the trigger lock lever is provided.
Tolockthetrigger,turnthetriggerlocklevertothelock
position .
Tousethetool,turnthetriggerlocklevertotheunlock
position .
1
1
22
►1.Triggerlocklever2.Trigger
Single sequential actuation
Place the contact element against the workpiece and
pull the trigger fully.
Afternailing,releasethecontactelement,andthen
release the trigger.
1
2
CAUTION: Do not place the contact element
against the workpiece with excessive force. Also,
pull the trigger fully and hold it on for 1-2 seconds
after nailing.
Eveninthe“Singlesequentialactuation”mode,half-
pulledtriggercausesanunexpectednailing,whenthe
contact element re-contacts the workpiece.
Contact actuation
Pullthetriggerrstandthenplacethecontactelement
against the workpiece.
2
1

10 ENGLISH
Nailing on steel plate
WARNING: When nailing on the C-shaped
steel, limit the thickness to 3.2 mm (1/8") or thin-
ner. Otherwise the tool will bounce severely and a
nailstruckback,causingseriousinjuries.
WARNING: Use hardened nails only for steel
plate. Using other purposed nails may cause serious
injuries.
WARNING: When nailing, hold the tool so that
it stands upright to the driving surface. Slanted
nailingmaycausenailstostrikeback,causingseri-
ousinjuries.
WARNING: Do not use the tool for fastening
a corrugated plate or the C-shaped steel directly.
Itmaycausenailstostrikeback,causingserious
injuries.
WARNING: Do not use the tool for nailing on
ceiling or roof.
Chooseandusenails10mm(3/8")ormuchlongerthan
total thickness of all workpiece to be fastened. Refer to
the table below.
Material thick-
ness including
C-shaped steel (A)
C-shaped steel (B)
thickness
Nail length (C)
30 mm - 35 mm
(1-3/16"-1-3/8")
1.6 mm - 3.2 mm
(1/16"-1/8")
45mm(1-3/4")
35 mm - 40 mm
(1-3/8"-1-5/8")
50mm(2")
A
C
B
NOTICE: Depending on the hardness and
total thickness of all workpiece in combination,
enough fastening may not be obtained. Nailing on
steel plate with excessive depth may extremely
reduce the fastening force.Beforenailing,adjust
the nailing depth properly.
NOTICE: Nailing on the steel plate makes the
driver prematurely worn out and it may cause nail
jamming.Whenthedriverisworn,replaceitwitha
new one.
Nailing on concrete
WARNING: Use hardened nails only for con-
crete. Using other purposed nails may cause serious
injuries.
WARNING: Do not nail directly on the con-
crete or do not fasten directly the steel plate to
the concrete.Itmaycauseconcretefragmentstoy
offornailstostrikeback,causingseriousinjuries.
WARNING: When nailing, hold the tool so that
it stands upright to the driving surface. Slanted
nailingmaycauseconcretefragmentstoyoffor
nailstostrikeback,causingseriousinjuries.
WARNING: Do not use the tool for fastening
an object to hang something such as sewer pipe.
Chooseandusenailssothatthepenetrationdepthinto
concreteranges10mm(3/8")-15mm(5/8").Referto
the table below.
Wood thick-
ness (A)
Nail length (B) Penetration depth
into concrete (C)
30 mm - 35 mm
(1-3/16"-1-3/8")
45mm(1-3/4") 10 mm - 15 mm
(3/8"-5/8")
35 mm - 40 mm
(1-3/8"-1-5/8")
50mm(2")
50 mm - 55 mm
(2"-2-3/16")
65mm(2-1/2")
B
A
C
NOTICE: Use the tool only for soft concrete
built up not so long before. Driving nails into hard
concrete may cause nail bending or nailing into insuf-
cientdepth.
NOTICE: When penetrating into concrete
deeper than 15 mm (5/8"), nails may not be driven
sufciently.
Cutting linked sheet
CAUTION: Always disconnect the air hose
from the tool before removing the linked sheet.
Whenusinglinkedsheetnails,thelinkedsheetwillbe
ejectedfromthedriverguideasyoudrivethenails.
Tearawaytheejectedsheetbytwistingasshowninthe
gure.

11 ENGLISH
1
►1.Ejectedlinkedsheet
Removing jammed nails
CAUTION: Always lock the trigger by turning
the trigger lock lever to the lock position , and
disconnect the hose before removing jammed
nails. Also remove the nails from the magazine
before cleaning a jam.
1. Depress the latch lever and open the door. Open
the magazine cap and remove the nail coil.
2. Insertasmallmetalrodintothenailejectionport
and hit it with a hammer lightly.
1
2
3
►1. Metal rod 2.Nailejectionport3. Hammer
3. Removethejammednailwithaat-bladescrew-
driver or other similar tool.
4. Reset the nail coil and close the magazine cap
and the door.
MAINTENANCE
CAUTION: Before attempting to perform
inspection or maintenance, always lock the trig-
ger by turning the trigger lock lever to the lock
position , and disconnect the air hose from the
tool.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Cleaning of tool
Iron dust that adhere to the magnet can be blown off by
using an air duster.
1
►1. Magnet
Storage
Whennotinuse,disconnectthehose.Thencaptheair
ttingwiththecap.Storethenailerinawarmanddry
place.
1
►1.Cap
Maintenance of compressor, air set
and air hose
Afteroperation,alwaysdrainthecompressortankand
theairlter.Ifmoistureisallowedtoenterthetool,
it may result in poor performance and possible tool
failure.

1
►1. Drain cock
Keeptheairhoseawayfromheat(over60°C,over
140°F),awayfromchemicals(thinner,strongacidsor
alkalis).Also,routethehoseawayfromobstacleswhich
it may become dangerously caught on during operation.
Hoses must also be directed away from sharp edges
and areas which may lead to damage or abrasion to
the hose.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
be performed by Makita Authorized or Factory Service
Centers,alwaysusingMakitareplacementparts.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Nails
• Airhose
• Safetygoggles
NOTE: Some items in the list may be included in the
toolpackageasstandardaccessories.Theymay
differ from country to country.
www.makita.com
Makita Europe N.V.
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi 446-8502 Japa
n
Jan-Baptist Vinkstraat 2,
3070 Kortenberg, Belgium
885497-228
EN
20160225
Other manuals for AN935H
2
Table of contents
Other Makita Nail Gun manuals

Makita
Makita AN610H User manual

Makita
Makita AN611 User manual

Makita
Makita AN923 User manual

Makita
Makita GN900 User manual

Makita
Makita AF601 User manual

Makita
Makita AN611 User manual

Makita
Makita AN922 Quick start guide

Makita
Makita DPT353Y1J User manual

Makita
Makita AN8300 User manual

Makita
Makita AN923 User manual

Makita
Makita AF353 User manual

Makita
Makita AN923 User manual

Makita
Makita AF502 User manual

Makita
Makita AN911H User manual

Makita
Makita BPT350 User manual

Makita
Makita GN420C User manual

Makita
Makita AF353 User manual

Makita
Makita DBN500 User manual

Makita
Makita AF550H User manual

Makita
Makita AN610H User manual
