Makita 3612B User manual

1/2" MODEL 3612B
Collet chuck Main body
No load Overall
capacity stroke speed length
INSTRUCTION MANUAL
Net
weight
DOUBLE
INSULATION
112"
0 ~ 65 mm
23,000 287 mm 5 7 kg
(0 - 2-9/16") R/min. (11-5/16") (12.7 Ibs)

IMPORTANT
SAFETY INSTRUCTIONS
(For All Tools)
WARNING:
WHEN USING ELECTRIC TOOLS, BASIC SAFE-
REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, AND PER-
TY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO
SONAL INJURY, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS.
1.
2.
3.
4.
5.
6.
7.
8.
9.
IO.
11.
12.
KEEP WORK AREA CLEAN. Cluttered areas and benches invite injuries.
CONSIDER WORK AREA ENVIRONMENT. Don't use power tools in damp
or wet locations. Keepwork area well
lit. Don't expose powertools torain.
Don't use tool in presence of flammable liquids or gases.
KEEP CHILDREN AWAY. All visitors should be kept away from work area.
Don't let visitors contact tool or extension cord.
STORE IDLETOOLS. When notinuse, tools should be stored indry, andhigh
or locked-up place
- out of reach of children.
DON'T FORCE TOOL.
It will do thejob betterandsafer at the ratefor which
it was intended.
USE RIGHT TOOL. Don't force small tool or attachment to
do the job of a
heavy-duty tool. Don't use tool for purpose not intended.
DRESS PROPERLY. Don't wear loose clothing orjewelry. They canbe caught
in moving parts. Rubber gloves and non-skid footwear are recommended
when working outdoors. Wear protective hair covering to contain long hair.
USE SAFETY GLASSES. Also use face or dust mask
if cutting operation is
dusty.
DON'T ABUSE CORD. Never carry tool by cord or yank
it todisconnect from
receptacle. Keep cord from heat, oil, and sharp edges.
SECURE WORK. Use clamps or a vise to hold work. It's safer than using
your hand and
it frees both hands to operate tool.
DON'T OVERREACH. Keep proper footing and balance at all times.
MAINTAIN
TOOLS WITH CARE. Keep tools sharp and clean for better and
safer performance. Follow instructions for lubricating and changing acces-
sories. Inspecttoolcords periodicallyand if damaged, have repairedby autho-
rized service facility. inspect extension cords periodically and replace if
damaged. Keep handles dry, clean, and free from oil and grease.
2

13.
14.
15.
16.
17.
18.
19.
20.
DISCONNECT TOOLS. When not in use, before servicing, and when chang-
ing accessories, such as blades, bits, cutters.
REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to
see that keys and adjusting wrenches are removedfrom tool beforeturning
it on.
AVOID UNINTENTIONAL STARTING. Don't carry plugged-intool
with finger
on switch. Be sure switch is OFF when plugging in.
OUTDOOR USE EXTENSION CORDS. When tool isusedoutdoors, use only
extension cords intended for use outdoors and so marked.
STAY ALERT. Watch what youare doing, use common sense. Don't operate
tool when you are tired.
CHECK DAMAGED PARTS. Before further use of the tool, a guard or other
part that isdamaged should be carefully checked to determine that
it will
operate properly and perform its intendedfunction. Check for alignment of
movingparts, bindingof movingparts, breakage of parts, mounting, andany
other conditions that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced
by an authorized serv-
ice center unless otherwise indicatedelsewhere in this instruction manual.
Have defective switches replaced by authorized service center. Don't use
tool
if switch does not turn it on and off.
GUARD AGAINST ELECTRIC SHOCK. Prevent body contact
with grounded
surfaces. For example; pipes, radiators, ranges, refrigerator enclosures.
REPLACEMENT PARTS. When servicing, use only identical replacement parts.
VOLTAGE WARNING: Before connecting the tool toa power source (receptacle,
outlet, etc.) be sure the voltage supplied is the same as that specified on the
nameplate of the tool. A power source
with voltage greater than that specified
for the toolcan result in SERIOUS INJURY tothe user - as well as damage to
the tool. If
in doubt, DO NOT PLUG IN THE TOOL. Using a power source with
voltage less than the nameplate rating is harmful to the motor.
3

ADDITIONAL SAFETY RULES
1. These bits come fully sharpened. Handle them carefully to prevent injury.
2. Check the bit carefully for cracks or damage before operation. Replace
3. Avoid cutting nails. Inspect for and remove all nails from the workpiece be-
4. Make sure the shaft lock is released before the switch is turned on.
5. Hold the tool firmly with both hands.
6. Keep hands away from rotating parts.
7. Check the bit is not contacting the workpiece beforethe switchisturned on.
8. Before using the tool on an actual workpiece, let it simply run for several
minutes first. Watch for flutter that might be caused by poor installation or
a poorly balanced.
cracked or damaged bit immediately.
fore operation.
9. Be careful of the bit rotating direction and the feed direction.
IO. Do not leave tool running. Operate the tool only when hand-held.
11. Always switch off and wait for the bit to come to a complete stop before
12. Do nottouchthe bit right after operation, it is extremely hotand could burn
13. Keep the bit retracted so as not to protrude from the bottomexcept during
removing the router from workpiece.
your skin.
actual operation.
SAVE THESE INSTRUCTIONS.
4

Installing bit
0 Loosen the collet nut and insert the bit
into the chuck hole. Press the shaft lock
and use the wrench tosecurethe bitcare-
fully. Use the collet
sleeve if necessary.
I
CAUTION :
0 Do not tighten the collet chuck without inserting a bit; do not install a small bitwith-
out using
a collet sleeve.
Either can lead to collet chuck breakage.
Adjusting cutting depth
Release the lock lever and lower the tool
to the desired depth. Then pull up on the
lock lever to lock.
Now adjust the stopper
block and pole
so that, even if the lock
lever is released, the router stops at the
uniform depth.
If you press the fast-feed button on the
stopper pole, the pole can be advanced
rapidly.Ordinarily the pole moves
1.5 mm
(1/16”) per turn. Minute depth adjust-
ments can be obtained by raising or
lowering the stopper pole.
5

Stopper block
.The stopper block has an adjustment hex
bolts which move
1 mm (1/32") per turn.
After obtaining the desired depth setting,
tighten the hex nut on the bolt with the
spanner.
\ block
I
Nylon nut
By turning the nylon nut, the upper limit
of the tool can be adjusted.When the tip
of the bit is retractedmore than required
in relation to the base plate surface, turn
the nylon nut to lower the upper limit for
more effective routing.
CAUTION
:
0 Do not lower the nylon nuttoo lowor the bitwill dangerously protrude.
0 Before operating the tool, check to be sure that the router automatically rises to the
upper limit.
Switch action
*To start the tool, position the switch
lever
to "ON" side. To stop, to "OFF"
side.
CAUTION
Prevent accidental starting by making
sure the tool
is switched off before you
plug it in.
Switch
lever
6

Operation
*After switching on the tool, lower the
router, keeping the base plate firmly
against the work surfacewhile routing.
CAUTION
0 When doing edge routing, the workpiece surfaceshould be on the left side of the bitin
the router feed direction or
a dangerous kickback may result.
(3 Bit revolving
direction
Correct bit feed direction
0 Adjustment should not be more than 15 mm (5/8") at once when usingstraight bit.
7

Straight guide
.The straight guide is effectively used for
straight cuts when chamfering or groov-
ing. When grooving, the router tends to
pull away to the left in relation to the
feed direction. Install the straight guide
on the right side
to assure a good finished
cut.
.The straight guide with the guide holder
installs on the router by means of the
thumb bolts
A. To obtain the desired dis-
tance between the bit and the straight
guide, turn the fine adjustment screw
(1.5" or 1/16" per turn).Then tighten
the thumb bolt
B to secure the straight
guide inplace.
By bolting larger pieces of wood onto the
straight guide, an even larger (wider)
guide can be obtained as shown.
When using a board-jointing bit, attach
pieces
of wood to the straight guide
which have a thickness of more than
15mm (5/8") so that the bit does not
strike the straightguide.
Thumb bolt A
Thiimh hnlt B
Fine adjustment screw
(2 3/16")
55 mm
(2 3/16")
(2 3/16")
8

Trimmer guide
.Trimming, inside work and curvedcuts in
veneers
for furniture and the like can be
done easily with the trimmer guide. The
guide roller rides the curve and assures
a
fine cut.
*The trimmer guide can be attachedto the
guide holder with the thumb bolt
B.
Looseningthe thumb bolt B, the distance
between the bit and the guide surface
can be adjusted by the fine adjustment
screw
(1.5 mm or 1/16" per turn). When
the thumb bolt
C is released, the guide
roller can be moved.
1 1 \ f' / Guide roller 1
ment screw
I Thumb bolt B I \ Thumb bolt C I
Templet guide
.The templet guide provides a sleeve through which the router bit passes, when making
exact duplicates of
a given pattern (templet). The templet guide is installed by loosen-
ing the two panhead screws on the router base, inserting the templet guide and then
securingthe two screws.
9

MAINTENANCE
CAUTION :
Always be sure that the tool is switched off and unplugged beforeattempting to perform
inspectionand maintenance.
Replacingcarbon brushes
0 Remove and check the carbon brushes
regularly. Replace when they wear down
to about
6 mm (1/4") or less. Keep the
brushes clean and free to slip in the
holders. Both brushes should be changed
at the same time. Use only Makitacarbon
brushes.
0 Use a screwdriver to remove the brush
holder cap
as shown on the figure.
.Take out the worn brush, insert the new
one and secure the brush holder cap.
k4
6 mm (1 /4")
BNSh holder cap
Any other maintenance should be performed by an Authorized MakitaService Center or
pointof purchase.
10

ACCESSORIES
CAUTION :
These accessories or attachments are recommended for use with your Makita tool specified in this
manual. The use of any other accessoriesor attachmentsmight present
a risk of injury to persons.The
accessoriesor attachmentsshould
be used only inthe proper and intended manner.
Templet guide
Used for finishing
a large quantity of articlesof
complicatedshapes with the
use of a templet.
!mml
Part NO. I Templet wde I A I E I C
Pari No
321492 3
Templet guide adapter
~~~ ~~
A E C
30 11-3/15 'I 35 11.3/8''1 1 7 19132"l
Collet sleeve
Use a sleeve which fits for the diameter
of the bit shank.
s 2e Part No
Pirt No s Le
Straightguide
(Part
No. 342428-9)
Wrench
24
(Part No. 781210-5)
Trimmer guide
(Part
No. 123022-4)
Guideholder
(Part
No. 122256-6)
Wrench
8
(Part No. 781213-9)
11

Bits
STRAIGHT -Single Flute
CARBIDE TIPPED
I PARTNO. A B C 0 E
733002-0A 3/8 1 1-1/2 1
/2 2-3/4
733002-4A 1
/2 1-1/4 1-3/8 112 2-7/8
HIGH SPEED STEEL
PART NO. A B C 0 E
733232-6A 118 5/16 Vl/8 1/4 1.518
STRAIGHT - 2 Flute
CARBIDE TIPPED
PART
NO. A B C D E
733003-2A 3/16 7/16 1-3/8 1/4
2
733003-4A 1/4 3/4 1-3/16 114 2-1
/8
733003-8A 5/16 1 1-1/8 114 2-3/16
HIGH SPEED STEEL (STRAIGHT
- 2 Flute)
PART NO. A
B C 0 E
733233-4A 5/16 7/8 1-3/16 1/4 2-1
18
733234-2A 1 /2 718 1-1/8 1/4 2-118
STRAIGHT - 2 Flute, 1/2” Shank
CARBIDE TIPPED
PART NO.
7330054A 1-1/4 2-1/2
733005-6A 1-1/4 1-7/16 2-718
733005-8A 112 1-1/2 1-1/4
733006-4A 3/4 1-1/4 1-1/4 112 2.112
733006-6A 7/8 1-1/4 1-3/16 1
/2 2-112
733006-8A 1-1/4 1-3/16 112 2-1/2
HINGE MORTISING
CARBIDE TIPPED
PART NO. A B C 0 E
733006-9A 112 1
/2 1-1/16 1/4 1-13/16
HIGH SPEED STEEL
PART NO. A B C
D E
733235-0A 1
/2 1 /2 314 1/4 1-15/16
12

VEINING -Single Flute
SOLIDCARBIDE
PART
NO A B
C D E
733007-8A 3/16 7/32 1-114 114 1-112
ROUND NOSE
CARBIDE TIPPED
PART NO A 8 C D E
733008-2A 114 15/32 1-114 114 1-718
733008-4A 318 9116 1-114 114 2
7330086A 112 11116 1-114 114 2-3116
733008-8A 518 11116 1-114 114 2.114
733009-0A 314 13116 1-114 114 2-318
CORE BOX
4 D c--
& -J
HIGH SPEED STEEL
PART
NO. A B
C D E
733238-2A 114 114 1.3116 114 1-112
I
I
VEE GROOVING
CARBIDE TIPPED
PART
NO.
A B C
D E F
733009-2A 114 112 1-3/16 114 2 318
733009-4A 7116 314 15/16 114
2 518
13

14" DOVE TAIL
CARBIDE TIPPED
PART NO. A B C
D E
733009-6A 1
I2 112 1-1/4 114 1-718
HIGH SPEED STEEL
PART NO. A B C
D E
733239-6A 112 112 1-318 114
2
STAGGER TOOTH
-ID!-
CARBIDE TIPPED
PART NO. A B C
D E
733007-0A 318 1-112 1-1I4
112 3
PANEL PILOT
CARBIDE TIPPED
PART NO. A B
C D E
733030-4A 318 1 1 318 2-1
/2
733030-6A 112 1 118 1-1 /2 112 3-114
HIGH SPEED STEEL
PART NO. A B
C D E
733236-0A 114 314 1 114 2-7116
CORNER ROUNDING
CARBIDE TIPPED - Ball Bearing Pilot
PART NO. A B C
0 E
733120-OA 3/16 318 1-1/4 114 1-15/16
733120-2A 1/4 1
/2 1-1I4 114 2
733120-4A 5/16 112 1-114 114 2-1/16
733120-6A 318 518 1-1/4 1I4 2-118
733120-8A 1
/2
314 1-114 114 2.114
733121-0A 318 5/8 1-1
12 112 2-318
733121-2A 112 314 1-1
I2 1 /2 2-112
REPLACEMENT BEARING - NO 733132-4A
~
HIGH SPEED STEEL - Solid Pilot
PART NO. A B C
D E
733240-2A 114 1
/2 1 114 1-314
733240-6A 318 518 1 114 1-718
14

BEADING
CARBIDETIPPED - Ball Bearing Pilot
PART NO. A B C D E
733121-4A 3116 318 1-114 114 1.15116
733121-6A 114 112 1-114 114
2
733121-8A 5116 1
12 1-114 114 2.1116
733122-0A 318 518 1-114 114 2-118
7331
22-2A 112 314 1-114 114 2-114
COVE
CARBIDE TIPPED ~ Ball Bearing Pilot
PART
NO A B C D E
733122-6A 114 318 1 114 1-518
733122-8A 318 112 1 114 1-314
733123-0A 112 518 1 114 1.718
i
REPLACEMENT BEARING - NO 733132-2A
HIGHSPEED STEEL
-Solid Pilot
PART NO. A B C D E
733242-6A 114 112 1 114 1-314
733242-BA 318 314 1 114 2-1/32
45" CHAMFERING
4DI-
CARBIDE TIPPED - Ball Bearing Pilot
PART NO. A €3 C D E F
733124-4A 112 112 1-114 114 2-114 1-3116
REPLACEMENT BEARING
- NO.733132-4A
RABBETING
-1DC
CARBIDE TIPPED - Ball Bearing Pllot
PART NO. A B C D E F
733124-2A 318 112 1-7/16 1/4 2.114 1-114
REPLACEMENT BEARING
- NO. 733132-4A
15

ROMAN OGEE
CARBIDE TIPPED - Ball Bearing Pilot
PART NO. A B
C D E
733123-2A 5/32 15/32 1.114 1/4 2
733123-4A 1I4 21/32 1-114 1
I4 2.118
REPLACEMENT BEARING
- NO.733132-2A
FLUSH TRIMMER -Self Piloting
SOLID CARBIDE
PART NO. A B
C D E
733128-0A 1/4 1/4 1-1/16 114 1-9/16
7’ BEVEL TRIMMER - Self-Piloting
SOLID CARBIDE
PART NO. A B C
D E
733128-2A 3/16 1I4 1-1/16 114 1-9/16
2 FLUTE FLUSH TRIMMER
CARBIDE TIPPED
I PARTNO. A B C D E
733128-8A 3/8 1 1-1I4 114 2-1/16
733128-9A 1
I2 1 I2 1-114
1 14 2-1/16
733129-OA 112 1 1-1/4 114
2-518
3/8” REPLACEMENT BEARING - NO. 733132-2A
112” REPLACEMENT BEARING -NO. 7331324A
16

COMBINATION FLUSH 122" BEVEL TRIMMER
CARBIDE TIPPED
PART NO. A B C D E
733128-6A 7116 112 1-114 114 1-314
~~
3 FLUTE FLUSH TRIMMER ASSEMBLY -Self Piloting
SOLID CARBIDE CUTTER
PART NO. A 8 C D E
733129-2A 518 318 1-114 114 2-318
REPLACEMENT BEARING
- NO. 733132-6A
3 FLUTE 22" BEVEL TRIMMER ASSEMBLY -Self Piloting
SOLID C RBlDE CUTTER
PART NO.
A B C 0 E
733129-4A 518 3/8 1-114 114 2-318
REPLACEMENT BEARING
- NO. 733132-6A
3 FLUTE FLUSH REPLACEMENT CUTTER
T- L A pJ
SOLID CARBIDE
PART NO. A
B C
733129-6A 3/8 114 518
FOR FLUSH TRIMMER ASSEMBLY NO. 733129-2A
17

3 FLUTE 22" BEVEL REPLACEMENT CUTTER
A 8 C
L SOLID CARBIDE
A
t I PARTNO.
733129-8A 318
FOR BEVEL TRIMMER
1 /4" REPLACEMENT ARBOR
PART NO. A
B
C D E
733131-2A
1 /4 318 1-114
1 I4 2.318
FOR FLUSH TRIMMER ASSEMBLY NO. 733129-2A
AND NO. 733129-4A
BALL BEARING PILOT
PART NO. A B
733132-2A 318 O.D.
118 I.D.
733132-4A 1/2 OD.
3/16 I.D.
733132-6A 5/8 O.D.
1/4 ID.
18

Jan -24 -'E6 EN
12 mm (1/2")
ROUTER
Model 3612B
19

MODEL 36128 Jan 24 86 EN
‘EM AiD DESCRIPTION $& DESCRIPTION
MACHINE
~
MACHINE
~
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
-
1
1
1
1
4
1
2
4
1
1
1
1
1
4
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
-
Nut M10
Nylon Nut M10
Name Plate
Rivet 0 5
FIELD ASSEMBLY
Hex Bolt M5xB5 [With Washer]
Countersunk Head Screw M4x14 [With Washer]
Ball Bearing 2012LLB
Knob L
Motor
Bracket
Compression Spring 10
Half Nut
Pan Head Screw M5x40 [With Washer)
Collet Nut
Collet cone
Pan Head
Screw M6x40 lWithWasher)
Knob R
Compression Sprmg 10
Set 8011 M10
Lock Lever
Spring Washer 5
Hex Bolt M5x12
Retaining Ring R - 12
Pin 6
Compression Spring 7
Screw M10x77
Bearing Retainer 50
Fan 92
ARMATURE ASSEMBLY
IWith
Ikem 9 & 29 - 321
InsulationWasher
Ball Bearing 6200LB
MO~O~ nourlng
33
34
35
36
37
38
39
40
41
42
43
44
45
46
41
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
1
2
1
1
1
1
2
1
1
2
1
2
2
1
1
1
2
1
2
2
1
1
1
1
1
1
1
1
1
2
4
1
2
Wave Washer 20
Pan Head Screw M5x12 iWithWasher]
Baffle
Plate
Chip Deflector
Noise S~ppressm
Switch
Pan Head Screw M4x14 [With Washer)
Strain Relief
Switch
Cover
Pan Head Screw M4x20 IWith Washer1
Hex Nut
Brush Holder Cap
Carbon
Brush
Cord Guard
Cord
Pole
Compression Spring 11
Base
Wing Bolt M6x15
Hex 8011 M5x16
Hex Nut M5
Hex Nut M5
Screw M6
Compression Spring 12
Hex Bolt M5x28
Hex Nut M5
Pan Head Screw M5x10 lWithWasher)
Countersunk Head Screw M4x8
Base Plate
Comprerrm sprmg 9
nex soit ~5~40
stopper
Spmg P,” 5-18
Note: The switch. noise suppressor and other part Specifications may differ from country to country
f
MAKITA LIMITEDONE YEAR WARRANTY
Warranty Policy
Every Makita tool is thoroughly inspected and tested before leavingthe factory. It is warranted to
be free of defects from workmanship and materials for the period of ONE YEAR from the date of
original purchase. Should any trouble develop during this one-year period, return the COMPLETE
tool, freight prepaid, to one of Makita’sFactory or Authorized ServiceCenters. If inspection shows
the trouble is caused by defective workmanship or material, Makita will repair (or at our option.
replace) without charge.
This Warranty does not apply where:
repairs have been made or attemptedby others:
repairs are required because of normal wear and tear:
0 The tool has been abused, misused or improperly maintained;
alterationshave been made to the tool.
IN NO EVENT SHALL MAKITA BE LIABLE FOR ANY INDIRECT, INCIDENTALOR CON-
SEQUENTIAL DAMAGES FROM THE SALE OR USE OFTHE PRODUCT. THIS DISCLAIMER
APPLIESBOTH DURING AND AFTER THE TERM OFTHIS WARRANTY.
MAKITA DISCLAIMS LIABILITY FOR ANY IMPLIEDWARRANTIES, INCLUDING IMPLIED
WARRANTIES OF “MERCHANTABILITY” AND “FITNESS FOR A SPECIFIC PURPOSE,”
AFTER THE ONE-YEAR TERM OFTHISWARRANTY.
This Warranty gives you specific legal rights, and you may also have other rights which vary from
state to state. Some states do not allow the exclusion or limitation of incidental or consequential
damages,
so the above limitation or exclusion may not apply to you.
Some states do not allow
limitationon how long an implied warranty lasts, so the above limitation may not apply to you.
-
W
FIIrtkirwana,ud.
11-8, 3-chome, Sumiyoshi-cho, Anjo, Aichi 446, Japan
883503A069
PRINTED IN JAPAN
1986-9-N
