Parts Breakdown HR4510C
Page 1 of 4 2/8/2008

Parts Breakdown HR4510C
Fig # Part ID Part Name Quantity
1 286272-3 TOOL HOLDER CAP, HR4001C 1
1 286285-4 N/A 1
2 233948-3 RING SPRING 25, HR5210C 1
3 257280-1 RING 29, HR5210C 1
4 450064-8 N/A 1
5 419002-9 SPACER, HR4001C 1
6 233948-3 RING SPRING 25, HR5210C 1
7 324752-2 N/A 1
8 450030-5 N/A 1
9 310178-4 TOOL RETAINER, HR5210C 2
10 345804-6 SPRING GUIDE, HR5210C 1
11 233496-2 COMPRESSION SPRING 49, HR5210C 1
12 345804-6 SPRING GUIDE, HR5210C 1
13 922148-7 H.S.H. BOLT M4X25, 6922NB 1
14 158300-3 N/A 1
15 922353-6 H. S. H. BOLT M6X30,HR5001C 4
16 158576-2 N/A 1
17 213754-2 O RING 71, HR5000 1
18 267357-4 N/A 1
19 262135-7 N/A 1
20 267357-4 N/A 1
21 324872-2 N/A 1
22 213980-3 N/A 1
23 213431-6 FLUORIDE RING 28, HR5001C 1
24 213394-6 O RING 23, HR5001C 1
25 324802-3 N/A 1
26 324805-7 N/A 1
27 424032-7 N/A 1
28 450024-0 N/A 1
29 213656-2 O RING 53, AN451 1
30 450031-3 N/A 1
31 165465-4 N/A 1
32 450032-1 N/A 1
33 424024-6 SEAL PLATE, HR5210C 2
34 324800-7 N/A 1
35 331599-7 RING 38, HR4500C 1
36 234024-6 N/A 1
37 227526-9 N/A 1
38 324804-9 N/A 1
39 213981-1 N/A 1
40 324803-1 N/A 1
41 233956-4 N/A 1
42 213460-9 O RING 35, HM1500 2
43 257283-5 N/A 1
44 233955-6 N/A 1
45 331598-9 PIPE 10, HR4500C 1
46 450025-8 N/A 1
47 213407-3 O RING 26, 4200H 1
48 450026-6 N/A 1
49 213981-1 N/A 1
50 213030-4 O RING 8, AN451 2
51 318169-9 N/A 2
52 213118-0 O-RING 12, 5277NB 2
53 450027-4 N/A 2
54 234023-8 N/A 2
55 213373-4 O RING 22, GEO600 2
56 331778-7 N/A 2
57 213373-4 O RING 22, GEO600 2
58 324806-5 N/A 2
59 234023-8 N/A 2
Page 2 of 4 2/8/2008

Parts Breakdown HR4510C
60 450027-4 N/A 2
61 213118-0 O-RING 12, 5277NB 2
62 318169-9 N/A 2
63 213030-4 O RING 8, AN451 2
64 922353-6 H. S. H. BOLT M6X30,HR5001C 4
65 266192-7 TAPPING SCREW 4X14, 2012NB 1
66 419020-7 CHANGE LEVER, HR4001C 1
67 233436-0 COMP. SPRING 3, HR4001C 2
68 419009-5 LOCK BUTTON, HR4001C 1
69 266192-7 TAPPING SCREW 4X14, 2012NB 2
70 318171-2 N/A 1
71 419784-3 CRANK LEVER, HR5210C 1
72 213515-0 O RING 36, 9040L 1
72 213534-6 N/A 1
73 233506-5 TORSION SPRING 16, HR5210C 1
74 310207-3 LINK LEVER, HR5210C 1
75 911133-5 P.H. SCREW M4X18, N9501B 6
76 450034-7 N/A 1
77 345778-1 RETAINER PLATE, HR5210C 1
78 266020-6 TAPPING SCREW,PT4X12,9046 1
79 424034-3 N/A 1
80 345822-4 N/A 1
81 450029-0 N/A 1
82 158297-6 N/A 1
83 419008-7 FIX GUIDE, HR4001C 2
84 423345-3 CUSHION PLATE, HR4001C 1
85 324801-5 N/A 1
86 211279-0 BALL BEARING 6303LLU, HM0810B 1
87 961057-5 RETAINING RING S-17, 2711 1
88 254220-0 KEY 5, LP1812C 2
89 227181-7 N/A 1
90 226655-5 N/A 1
91 961054-1 RETAINING RING S-14, 6302 1
92 253180-3 F. WASHER 10, 6222DWE 1
93 125415-1 N/A 1
98 424033-5 N/A 1
99 158299-2 N/A 1
100 419796-6 HANDLE COVER, HR5210C 1
101 265995-6 TAPPING SCREW 4X18, 4323K 1
102 650567-4 SWITCH, HR4001C 1
103 154626-1 SWITCH HOLDER CPL.,HR4001 1
104 419028-1 SWITCH LEVER, HR4001C 1
107 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 6
108 450040-2 N/A 1
111 864092-1 N/A 1
117 450036-3 N/A 1
118 631750-2 N/A 1
119 266192-7 TAPPING SCREW 4X14, 2012NB 1
120 638510-3 LEAD UNIT, HR5210C 1
121 687169-3 STRAIN RELIEF, HP1621F 1
122 266192-7 TAPPING SCREW 4X14, 2012NB 1
123 419024-9 CORD LAMP BASE, HR4001C 1
124 265995-6 TAPPING SCREW 4X18, 4323K 4
125 266192-7 TAPPING SCREW 4X14, 2012NB 1
126 419774-6 LENS, HR5210C 1
127 682560-0 CORD GUARD 10, HM1202C 1
128 664471-1 CORD, 2X14X16;SJ, HM1500 1
129 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 2
130 450035-5 N/A 1
131 252178-7 HEX NUT M8-12, 4112H 1
132 253165-9 F. WASHER 8, 4303C 1
Page 3 of 4 2/8/2008

Parts Breakdown HR4510C
133 240016-5 FAN 90, HR5001C 1
134 419782-7 FAN GUIDE, HR5210C 1
135 194412-8 CARBON BRUSH CB-171, HR5210C 1
136 638447-4 BRUSH HOLDER UNIT, HR5210C 1
137 450041-0 N/A 1
138 636311-3 N/A 1
139 266046-8 T. SCREW FLANGE PT5X50,HR2010 2
140 210059-1 BALL BEARING 6000DDW, HR4040C 1
141 681642-5 INSULATION WASHER, LS1013 1
142 517766-0 N/A 1
143 267025-9 F. WASHER 15, HR4500C 1
144 211238-4 BALL BEARING 6202LLU, HR4500C 1
145 331596-3 SLEEVE 12, HR4500C 1
146 213231-4 OIL SEAL 15, HR4500C 1
147 450033-9 N/A 1
148 266192-7 TAPPING SCREW 4X14, 2012NB 1
149 419786-9 SWITCH BOX, HR5210C 1
150 263027-3 RUBBER PIN 4, HM0860C 1
151 651418-4 SWITCH, JN1601 1
152 232209-8 LEAF SPRING, HM0860C 1
153 154635-0 SLIDE LEVER CPL.,HR4001C 1
154 450042-8 N/A 1
1,001 158131-0 GRIP 36 CPL.,HR4041C 1
1,002 158275-6 PLASTIC CARRYING CASE, HR5210C 1
1,003 181573-3 BIT GREASE, HR2400 1
1,004 134890-0 SIDE HANDLE 68 ASS'Y,HR4000C 1
1,005 443122-7 CLOTH F/WIPING OIL, HR4001C 1
1,006 265701-9 SCREW M6X14, 5177B 1
1,007 266163-4 C.S.N.BOLT M8X80, HR4000C 1
1,008 321248-4 DEPTH GAUGE, HR3851 1
1,009 344491-8 GRIP SPRING 68, HR4000C 1
1,010 344492-6 PLATE, HR4000C 1
1,011 416299-1 SIDE GRIP BASE 68, HR4000C 1
1,012 931302-2 HEX NUT M6, HR2400 1
Page 4 of 4 2/8/2008
