INSTRUCTION MANUAL
Cordless Belt Sander
DBS180
ENGLISH: Original instructions
Read before use.

2ENGLISH
SPECIFICATIONS
Model: DBS180
Belt size 9 mm x 533 mm
Belt speed 600 - 1,700 m/min
Overall length 500 mm *1
Rated voltage D.C. 18 V
Net weight 2.1 kg
*1. With abrasive belt and battery cartridge (BL1860B).
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydi󰀨erfromcountrytocountry.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2014
Applicable battery cartridge and charger
Battery cartridge BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /
BL1840B / BL1850 / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH
• Some of the battery cartridges and chargers listed above may not be available depending on your region of residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
andchargersmaycauseinjuryand/orre.
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Read instruction manual.
Wear safety glasses.
Ni-MH
Li-ion
Only for EU countries
Do not dispose of electric equipment or
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries and Accumulators
and Waste Batteries and Accumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
Intended use
The tool is intended for the sanding of large surface of
wood, plastic and metal materials as well as painted
surfaces.
Noise
The typical A-weighted noise level determined accord-
ing to EN62841-2-4:
Sound pressure level (LpA) : 77 dB(A)
Uncertainty (K) : 3 dB(A)
NOTE: The declared noise emission value(s) has
been measured in accordance with a standard test
method and may be used for comparing one tool with
another.
NOTE: The declared noise emission value(s)
may also be used in a preliminary assessment of
exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can di󰀨er from the declared
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
o󰀨 and when it is running idle in addition to the
trigger time).
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN62841-2-4:
Work mode: sanding metal plate
Vibration emission (ah) : 2.5 m/s2or less
Uncertainty (K) : 1.5 m/s2

3ENGLISH
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also
be used in a preliminary assessment of exposure.
WARNING: The vibration emission during
actual use of the power tool can di󰀨er from the
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
o󰀨 and when it is running idle in addition to the
trigger time).
EC Declaration of Conformity
For European countries only
The EC declaration of conformity is included as Annex A
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
1.
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodiedplugsand
matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However, users of pacemakers and other similar
medical devices should contact the maker of their
device and/or doctor for advice before operating
this power tool.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication. A moment of inattention while operating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the o󰀨-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
resultinpersonalinjury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8.
Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
causesevereinjurywithinafractionofasecond.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.

4ENGLISH
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct
powertoolwilldothejobbetterandsaferatthe
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and o󰀨. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool. Power tools are dangerous in the
hands of untrained users.
5. Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may a󰀨ect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
foroperationsdi󰀨erentfromthoseintendedcould
result in a hazardous situation.
8. Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for
safe handling and control of the tool in unexpected
situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled. The entangle-
ment of cloth work gloves in the moving parts may
resultinpersonalinjury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
onetypeofbatterypackmaycreateariskofre
when used with another battery pack.
2. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
may exhibit unpredictable behaviour resulting in
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
perature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions. Charging improperly or at temperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
3. Follow instruction for lubricating and chang-
ing accessories.
CORDLESS BELT SANDER SAFETY
WARNINGS
1. Ventilate your work area adequately when you
perform sanding operations.
2. Some material contains chemicals which may
be toxic. Take caution to prevent dust inhala-
tion and skin contact. Follow material supplier
safety data.
3. Always use the correct dust mask/respirator
for the material and application you are work-
ing with.
4.
Always use safety glasses or goggles. Ordinary
eye or sun glasses are NOT safety glasses.
5. Hold the tool rmly with both hands.
6. Make sure the belt is not contacting the work-
piece before the switch is turned on.
7. Keep hands away from rotating parts.
8. Do not leave the tool running. Operate the tool
only when hand-held.

5ENGLISH
9. This tool has not been waterproofed, so do not
use water on the workpiece surface.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper the battery
cartridge.Itmayresultinare,excessiveheat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge. Such conduct may result in a
re,excessiveheat,orexplosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
Tapeormasko󰀨opencontactsandpackupthe
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
sive heat, explosion, or leak of electrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge. It may result in poor performance or
breakdown of the tool or battery cartridge.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near high-voltage electri-
cal power lines. It may result in a malfunction or
breakdown of the tool or battery cartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causingres,personalinjuryanddamage.Itwill
also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).

6ENGLISH
FUNCTIONAL DESCRIPTION
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridgermlymaycausethemtoslipo󰀨yourhands
and result in damage to the tool and battery cartridge
andapersonalinjury.
1
2
3
►1. Red indicator 2. Button 3. Battery cartridge
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
itmayaccidentallyfalloutofthetool,causinginjuryto
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Tool / battery protection system
The tool is equipped with a tool/battery protection system. This
systemautomaticallycutso󰀨thepowertoextendtoolandbat-
tery life. The tool will automatically stop during operation if the
tool or battery is placed under one of the following conditions:
Overload protection
This protection works when the tool is operated in a
manner that causes it to draw an abnormally high cur-
rent.Inthissituation,turnthetoolo󰀨andstoptheappli-
cation that caused the tool to become overloaded. Then
turn the tool on to restart.
Overheat protection
This protection works when the tool or battery is over-
heated. In this situation, let the tool and battery cool
before turning the tool on again.
Overdischarge protection
This protection works when the remaining battery
capacity gets low. In this situation, remove the battery
from the tool and charge the battery.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
1
2
►1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
cate the remaining battery capacity. The indicator lamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydi󰀨erslightly
from the actual capacity.
NOTE:Therst(farleft)indicatorlampwillblinkwhen
the battery protection system works.

7ENGLISH
Adjusting arm inclination
Thearmcanbepivotedandxedatanydesiredangle
withintherange"A"(-5°to90°)inthegure.Adjustthe
angle to make a comfortable working position.
Loosen the lock lever by raising it. Pivot the arm to the
desiredposition,andsecurethelocklevertoxthearm
rmly.
“A”
1
2
►1. Lock lever 2. Arm
Replacing arm
6mm(1/4″)and13mm(1/2″)widthbeltscanbe
installed with the optional arms that are designed for
the corresponding belt widths. Loosen the screw that
secures the arm and replace the standard-equipped
armwiththeoptionalarm,thentightenthescrewrmly.
1 2
►1. Screw 2. Arm
Switch action
WARNING: For your safety, this tool is
equipped with the lock-o󰀨 switch which prevents
the tool from unintended starting. NEVER use
the tool if it runs when you simply pull the switch
trigger without releasing the lock-o󰀨 switch.
Return the tool to our authorized service center
for proper repairs BEFORE further usage.
CAUTION: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the "OFF" position when released. Operating a tool
with a switch that does not actuate properly can lead
tolossofcontrolandseriouspersonalinjury.
NOTICE: Do not pull the switch trigger hard with-
out releasing the lock-o󰀨 switch. This can cause
switch breakage.
NOTICE: The lock-o󰀨 switch cannot be released
while the arm is being pivoted beyond 90°.
To prevent the switch trigger from being accidentally
pulled,alock-o󰀨switchisprovided.Depresstheswitch
lever ( ) from the A side to unlock the switch trigger,
and ( ) from the B side to lock in.
A
B
1
1
►1.Lock-o󰀨switch
To start the tool, pull the switch trigger. Release the
switch trigger to stop.
For continuous operation, pull the switch trigger and
then push in the lock button. To stop the tool from the
locked switch position, pull the switch trigger fully, and
then release it.
1
2
►1. Lock-on button 2. Switch trigger

8ENGLISH
Lighting up the front lamp
CAUTION: Do not look in the light or see the
source of light directly.
Thelightingdirectioncanbeadjustedatthreelevels
through an angle of 60°. Pull the switch trigger to turn on
thelamp.Toturno󰀨,releaseit.Thelampgoesoutapproxi-
mately 10 seconds after releasing the switch trigger.
1
►1. Lamp
NOTE:
Whenthetoolisoverheated,thelightashesforone
minute. In this case, cool down the tool before operating again.
NOTE:Useadryclothtowipethedirto󰀨thelensof
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
Speed adjusting dial
Thebeltspeedcanbeadjustedbetween600mand1,700
m per minute (1,970 - 5,600 ft/min) by turning the speed
adjustingdialtoagivennumbersettingfrom1to5.
Higher speed is obtained when the dial is turned in the
direction of number 5; lower speed is obtained when it
is turned in the direction of number 1. Select the proper
speed for the workpiece to be sanded.
CAUTION: The speed adjusting dial can only be
turned between the numbers indicated on the dial. Do
not apply an excessive force to turn the dial outside
that range, or the speed adjustment may not function.
1
►1.Speedadjustingdial
ASSEMBLY
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before carrying out any work on the tool.
Removing and installing abrasive
belt
Pull the cam lever back to release the tension in the
belt, and remove the belt.
To install the belt, place one side of the belt over the
rearpulleyinrst,hooktheothersideoverthefrontpul-
ley, and then set the cam lever to the original position.
1
32
4
►1. Cam lever 2. Abrasive belt 3. Rear pulley 4. Front
pulley
Adjusting belt tracking
Make sure that the belt is aligned with the arm properly
on a trial run at low speed.
Use the thumb screw to center the belt tracking. Turn
the screw clockwise to incline the arm to the right when
looking down at the tool with its arm pointed forward,
and in counterclockwise to the left.
12
►1. Arm 2. Thumb screw

9ENGLISH
Installing side grip
CAUTION: Securely tighten the thumb screw
before operation.
CAUTION: Avoid exerting a strong external
force on the side grip, otherwise the grip base
becomes loosely attached and the tool may fall
o󰀨 causing damage or personal injury in the fol-
lowing conditions:
• Apply a full impact on the side grip during
operation
• Handle the tool carelessly only with one hand on
the side grip
• Carry the tool only with one hand on the side
grip
Thesidegrip(auxiliaryhandle)helpsholdthetoolrmly
during operation.
1. Screw the grip into the fastening nut placed in the
grip base.
12
3
►1. Grip 2. Grip base 3. Fastening nut
2. Loosen the thumb screw in the grip base.
Attach the base to the barrel of the motor housing align-
ing the locking tab on the base with the shallow groove
in the surface of the housing.
Tighten the thumb screw to secure the grip.
1
2
►1. Thumb screw 2. Motor housing
Connecting to Makita vacuum
cleaner
CAUTION: Always close the nozzle cap when
a vacuum cleaner is not connected to the nozzle.
Never insert your nger into the nozzle.
NOTICE: Read the instruction manual supplied
with your vacuum cleaner before using it.
NOTE:Optionalfrontcu󰀨s22,jointsortooladapters
may be required to make connections depending on
your vacuum cleaner system.
Cleaner sanding operations can be performed by con-
necting the belt sander to Makita vacuum cleaner.
Open the nozzle cap, and install the dust nozzle.
Connect the hose of a vacuum cleaner to the dust
nozzle.
1
2
3
4
►1. Dust nozzle 2.Frontcu󰀨s/joint/adapter3. Hose
of vacuum cleaner 4. Vacuum cleaner
OPERATION
CAUTION: Secure workpiece with clamps,
etc. if it possibly moves during operation.
CAUTION: Avoid any sanding operations on
ignitable materials such as aluminum and magne-
sium. Itmayresultinare,explosionorriskofinjury.
CAUTION: Be sure that not any part of the
sanding belt is placed on the surface of work-
piece before you turn the tool on or o󰀨. Otherwise
apoorsandingnish,damagetothebeltorlossof
control of the tool may result.
CAUTION: Avoid body contact with the belt
and rotating parts of the tool during operation.
Always be aware of your surroundings and
bystanders, and stay alert for possible hazards.
CAUTION: Do not attempt to hold and operate
the tool upside down. It may cause a serious acci-
dentresultinginpersonalinjury.

10 ENGLISH
Turn the tool on and wait until it attains full speed. Hold the
toolrmlywithbothhands.Gentlyapplythetooltothework-
piece surface and move the tool forward and backward.
Alwaysusetherange"C"(betweentheendofatshoeand
frontpulley)intheguretosandtheworkpiece.
Press the belt only lightly on the workpiece. Excessive pres-
sure may damage the belt and shorten the life of the tool.
“C”
1
2
►1. Flat shoe 2. Front pulley
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
Storage
CAUTION: Be careful not to pinch your n-
gers when moving the arm. Failure to do so may
causepersonalinjury.
The arm can move through an angle of up to 160°. Fold
the arm up to save a storage space.
1. Loosen the lock lever by raising it. Pivot the arm at
an angle of 90°.
2. Pushandholdthesliderknob,andthenadjustthe
angle of the arm in the range "B" (90° to 160°) in
thegure.
“B”
3
2
1
►1. Lock lever 2. Slider knob 3. Arm
3. Securethelocklevertoxthearm.
1
2
►1. Lock lever 2.Lock-o󰀨switch
NOTICE: The lock-o󰀨 switch is automatically
activated while the arm is being pivoted beyond
90°.

11 ENGLISH
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual. The use of any other
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Dust nozzle assembly
• Arm(6,9,13mm(1/4″,3/8″,1/2″))
• Abrasive belts
• Dust cover complete
• Hose complete 28
• Frontcu󰀨s
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
di󰀨erfromcountrytocountry.

www.makita.com
Makita Europe N.V.
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi 446-8502 Japa
n
Jan-Baptist Vinkstraat 2,
3070 Kortenberg, Belgium
885815-220
EN
20200625
