Makita 2708 Manual

TECHNICAL INFORMATION
Specifications
Standard equipment
1. Parallel ruler ( for parallel/standard size treating)...1pc
2. Sliding bevel (for bevel treating)...1pc
3. Cap (for jigsaw/router/blade mouth plate)...1pc
4. Pressing board/L (for attaching jigsaw/router/trimmer)...1pc
5. Pressing board/S (for attaching 3600/3601B)...1pc
6. Wrench 10-13 ( for adjusting Parallel ruler)...1pc
7. Wrench 19 (for attaching Saw)...1pc
8. Wrench 22 (for attaching Saw)...1pc
9. Countersunk head screw M6x50...1pc
New Tool
CONCEPTION AND MAIN APPLICATIONS
In the former easy type of Circular stand, there are some problems to
be improvedsuch as the steadiness or the structure for attaching
Portable circular saw. Also, we thought Switch, Inclination/Up-and-
down of Saw, and Operativity could be improved. Now we have
improved all those points to meet the demand from overseas for a new
product which is easily carried and less expensive.
Motor Series commutator motor
100V
14A
50/60Hz
4500rpm
1350W
61mm
Diameter of Saw attached to Machine (for export) 210mm
45mm
W660mm x D460mm x H 375mm
17kgs
5m
300mm( both right/left sides of Table)
660mm (When attaching Extension holder in special accessories:1200mm)
460mm (When attaching Extension holder in special accessories:730mm)
275mm ( When attaching Circular saw machine stand in specialaccesories :825mm)
Voltage
Current
Frequency
Consuming power
Rotation
Blade size
Capacity
Max. incision depth 90
Max. incision depth 45
Max. cutting width with Parallel ruler
Table
Outer size
Weight
Power supply cord
Width
Depth
Height
Optional accesories
1. Circular saw machine stand( exclusively for Circular saw machine) 1set
2. Holder (w/clamp and screws, for extension table) 1set
3. Grooving cutter Width: 2.4~15mm
 Flat washer 15 ( used for substitute for Plane/Flange)
 Outer flange 30, (Thickness: 13mm, in case of cutter width 9mm or less)
4. Saw blade
 Various saw blades are available; Saw diameter Ø168 ~Ø210
2708
203mm(8") Table saw
Models No.
Description

Adjustment
1. Split blade adjusting:Make a straight line with Saw. Adjust a gap with outer circle of Saw
2. Angle stopper adjusting:Adjust at 45 and 90 degrees on the basis of Table.
3. Scale arrow adjusting:Loosen the attaching screw for Arrow, and adjust it to the scale.
4. Parallel ruler adjusting:Adjust so that it may be parallel with Saw and beright angle with the rail of Table.
5. Knob 45 adjusting:Adjust it when it does not move up-and-down smoothly orturns by vibration.
Disassembly
[ Separation of Gear housing cover from Motor part w/ Gear Housing ]
(1) Remove Saw blade, Inner flange 55 and Outer flange 55.
(2)Turn Knob 45 left, lower Motor part to the lowest limit, and reverse the mainbody.
(3) Remove Gear housing cover, Blade cover and Screws M5x25.
(4) Gear housing cover and Motor part w/ Gear Housing come apart to both sidesfrom Frame separately.
[ Disassembly of Gear 45 and Spindle]
Remove Retaining ring S20 and Ball bearing 6204LLB from the above mentionedGear housing cover ( 4 ).

[ Disassembly of Armature and Field]
Do it by separating Gear housing ( above mentioned ) from Motor part.

[ Disassembly of Lever 80]
(1) Loosen the fastening Front plate of Lever 80
(2) Put Spanner 17 on Hex. Nut M10-6 ( which is farther from Lever 80), put Hex. rod wrench 6 on Hex. Socket head
bolt . Turn Spanner 17 left and Wrench right, and loosen Nut M10-6.
(3) Then, turn Wrench right , gripping Lever 80, pick out Hex. Socket bolt , andremove Lever 80.
Hex. Nut
Outer flange 55
Saw blade Inner flange
Pan head
screw M5x25
Blade
covert Gear housing cover
Table
Gear housing
Motor housing
Frame
Flat washer 40

Note in assembly
(1) Stick Flat washer 40 on Gear housing cover with grease for installation.
(2) Be sure to apply grease only on the teeth in Gear housing. Do not use too much grease, which may cause heat or over-
flow.
[ Disassembly of Frame]
(1) Removing Safety guide and Saw blade, reverse the main body , and takeaway Pointer A, Lever 80, Knob 45.
(2) When removing Hex. Bolt M6x14 (4 pcs) attaching for Table by Spanner10, Frame will come off.

Used tools for the above disassembly:
driver, driver, Spanner 10-13, Spanner 22, Spanner 19,
Spanner 17, Hex. Rod wrench 6, Retaining ring plier
(3) Installation of Lever 80
a)Decide the fastening angle of Lever 80
•Do not fasten Bolt completely ( be careful of Left-
turn screw)
•Put both Nuts and Lever 80 to decide the position.
b)Fasten Bolt
•Heighten Lever 80 and loosen both Nuts.
•Fasten up Nut 1 and Bolt firmly using Hex. Rod
wrench 6..

c) Fasten Nut 2 to Nut 1 side
•Put Spanner 22 on Nuts and fasten up Nuts firmly
using Lever 80together.
Nut 2 Nut 1
Fasten
Loosen
30 ~45
