Parts Breakdown LS1221
Page 1 of 5 2/8/2008

Parts Breakdown LS1221
Page 2 of 5 2/8/2008

Parts Breakdown LS1221
Fig # Part ID Part Name Quantity
1 853489-9 NAME PLATE, LS1221 1
2 265999-8 TAPPING SCREW M4X25, HM1800 2
3 265995-6 TAPPING SCREW 4X18, 4323K 2
4 687052-4 STRAIN RELIEF, HM1500B 1
5 664463-0 CORD (2X14X8 SJ), 2414B 1
6 682505-8 CORD GUARD, 2711 1
7 182954-4 HANDLE SET, LS1220 1
8 265995-6 TAPPING SCREW 4X18, 4323K 2
9 416356-5 LOCK-OFF LEVER, LS1220 1
10 231026-3 COMP. SPRING 4, 2416S 1
11 416404-0 SWITCH BUTTON, LS1220 1
12 651923-1 SWITCH, LS1211 1
13 416357-3 SWITCH LEVER, LS1220 1
14 182954-4 HANDLE SET, LS1220 1
15 265995-6 TAPPING SCREW 4X18, 4323K 4
17 231297-2 COMP. SPRING 9, LS1011 1
18 211206-7 B. BEARING 6202LLB, NHP1310 1
19 253147-1 F. WASHER 15, 5037NB 1
20 343641-2 SHAFT LOCK, LS1030 1
21 240003-4 FAN 80, 2012NB 1
22 510048-9 ARMATURE ASSY 115V, LS1221 1
23 681640-9 INSULATION WASHER, LS1040 1
24 211061-7 B. BEARING 6000LLB, 6222DWE 1
25 416361-2 BAFFLE PLATE, LS1220 1
26 266044-2 T. SCREW FLANGE 5X60, 5037NB 2
27 596236-2 FIELD ASSY, LS1221 1
28 150787-5 MOTOR HOUSING COMPLETE, LS1220 1
29 911383-2 P.H. SCREW M6X60, LS1030 4
31 417833-0 REAR COVER, LS1221 1
32 265995-6 TAPPING SCREW 4X18, 4323K 2
33 266026-4 TAPPING SCREW 4X12,9046 1
34 687095-6 STRAIN RELIEF, LS1220 1
35 819064-1 MAKITA MARK, HM1100C 1
36 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
37 181047-4 CARBON BRUSH SET 154,5402A 1
38 265371-4 HEX BOLT M8X30, LS1011 1
39 251961-9 H.S.H. SCREW M6X10, LS1040 2
40 266179-9 BINDING HEAD SCREW M6, LS1220 1
41 253758-2 F. WASHER 10, 9901 1
42 265984-1 H.S.B. HEAD BOLT M6, LS1040 1
43 253823-7 F. WASHER 7, LS1011 1
44 257162-7 RING 7, LS1030 1
45 344542-7 LINK PLATE, LS1220 1
46 265995-6 TAPPING SCREW 4X18, 4323K 2
47 416367-0 DUST NOZZLE, LS1220 1
48 150789-1 BLADE CASE COMPLETE, LS1220 1
48 150789-1 BLADE CASE COMPLETE, LS1220 1
49 421612-0 CUSHION, LS1220 1
50 911223-4 P.H. SCREW M5X16, 4301BV 2
51 265324-3 H.F.H. BOLT M8X12, LS1030 1
52 266034-5 TAPPING SCREW 4X16, 9524NB 1
53 344540-1 CENTER PLATE, LS1220 1
54 344539-6 CENTER WASHER, LS1220 1
55 231634-0 TORSION SPRING 45, LS1220 1
56 417836-4 SAFETY COVER B, LS1221 1
57 316940-5 SAFETY COVER A, LS1220 1
57 316940-5 SAFETY COVER A, LS1220 1
58 266026-4 TAPPING SCREW 4X12,9046 3
59 265985-9 HEX.SOCKET HEAD BOLT M6, LS1211 1
60 344541-9 CENTER COVER, LS1220 1
Page 3 of 5 2/8/2008

Parts Breakdown LS1221
61 265405-3 H.F.H. BOLT M10X20, LS1211 1
62 224333-1 FLANGE 53, LS1040 1
63 257060-5 RING 15.88,LS1013 1
64 224333-1 FLANGE 53, LS1040 1
65 285828-9 BEARING RETAINER 66, LS1211 1
66 322625-3 SPINDLE, LS1211 1
67 211256-2 B. BEARING 6203LLB, GA7001L 1
68 316473-0 HOUSING W/O BEARING, LS1211 1
69 226482-0 HELICAL GEAR 49, LS1220 1
70 211031-6 BALL BEARING 608LLB, HR2400 1
71 252014-7 HEX LOCK NUT M6-10, LS1040 1
72 344463-3 SUB FENCE PLATE, LS1013 1
73 150732-0 SUB FENCE CPLT., LS1212 1
73 150796-4 SUB FENCE COMPLETE, LS1220 1
74 266061-2 T. SCREW BIND CT4X8, JN1601 1
74 911108-4 P.H. SCREW M4X8, LS1013 1
75 921461-0 HEX BOLT M8X40, LS1220 4
76 253804-1 F. WASHER 6, 6012HDW 1
77 316945-5 GUIDE FENCE, LS1220 1
77 316945-5 GUIDE FENCE, LS1220 1
77 317980-6 GUIDE FENCE, LS1221 1
78 912357-6 C.S.H. SCREW M6X35, LS1013 1
79 323740-6 ROD 16, LS1220 1
80 416358-1 SLEEVE 17, LS1220 1
81 416358-1 SLEEVE 17, LS1220 1
82 231635-8 TORSION SPRING 34, LS1220 1
83 265456-6 HEX BOLT M10X90, LS1220 1
84 941251-5 F. WASHER 10, LS1030 1
85 331524-8 PIPE 16-65, LS1220 1
86 213011-8 O RING 7, HR2511 1
87 322988-7 STOPPER PIN, LS1220 1
88 922412-6 H.S.H. BOLT M8X12, 3705 1
89 150791-4 ARM COMPLETE, LS1220 1
89 150791-4 ARM COMPLETE, LS1220 1
91 416355-7 INDICATION PLATE, LS1220 1
92 253852-0 F. WASHER 8, LS1211 1
93 252105-4 HEX LOCK NUT M8-13, HM1800 1
94 416360-4 KERF BOARD, LS1220 1
95 416360-4 KERF BOARD, LS1220 1
96 266026-4 TAPPING SCREW 4X12,9046 2
97 266026-4 TAPPING SCREW 4X12,9046 2
98 416355-7 INDICATION PLATE, LS1220 1
99 266026-4 TAPPING SCREW 4X12,9046 1
100 911118-1 P.H. SCREW M4X12, 6221D 1
101 416359-9 LOCK LEVER, LS1220 1
102 231325-3 COMPRESSION SPRING 6, LS1220 1
103 256626-8 PIN 4, LS1221 1
104 271308-1 KNOB 40, LS1220 1
105 256158-5 PIN 3, BJR181 1
106 323741-4 LOCK PIN, LS1220 1
107 344538-8 LOCK PLATE, LS1220 1
108 961017-7 STOP RING E-3, 4304 1
109 266026-4 TAPPING SCREW 4X12,9046 2
110 286212-1 CAP 20, LS1011 4
111 816773-3 MITER SCALE PLATE, LS1220 1
112 266026-4 TAPPING SCREW 4X12,9046 3
113 921462-8 HEX BOLT M8X40, 9031 1
114 150790-6 BASE COMPLETE, LS1220 1
114 150790-6 BASE COMPLETE, LS1220 1
115 232075-3 LEAF SPRING, LS1011 1
116 266026-4 TAPPING SCREW 4X12,9046 1
Page 4 of 5 2/8/2008

Parts Breakdown LS1221
117 416403-2 SLIDE PLATE, LS1220 1
118 316943-9 TURN BASE, LS1220 1
118 316943-9 TURN BASE, LS1220 1
119 252130-5 HEX LOCK NUT M10 LS1211 1
120 265371-4 HEX BOLT M8X30, LS1011 2
121 262051-3 RUBBER RING, HR3851 1
122 941251-5 F. WASHER 10, LS1030 1
123 265457-4 HEX BOLT M10, LS1220 1
124 416006-2 LEVER 100, LS1040 1
125 911118-1 P.H. SCREW M4X12, 6221D 1
126 216001-0 STEEL BALL 3.5, 6800DBV 1
127 256226-4 PIN 4, HP2030 1
128 251887-5 SCREW M6X10, LS1030 1
129 251887-5 SCREW M6X10, LS1030 2
1,001 762001-3 TRIANGLE RULE, LS1011 1
1,002 782212-4 SOCKET WRENCH 13, LS1011 1
1,003 122523-9 DUST BAG, LS1040 1
1,004 416404-0 SWITCH BUTTON, LS1220 2
1,005 323726-0 HOLDER 160,LS1221 2
1,006 122540-9 VISE ASS'Y, LS1212 1
1,007 251887-5 SCREW M6X10, LS1030 1
1,008 322983-7 VICE ROD, LS1013 1
1,009 271303-1 KNOB, LS1030-T2 1
1,010 253804-1 F. WASHER 6, 6012HDW 1
1,011 343651-9 VISE PLATE, LS1030 1
1,012 251370-2 PAN HEAD SCREW, LS1030 1
1,014 A-85472 T.C.T. SAW BLADE 60T 1
1,014 A-93619 12 SAW BLADE 32T,LS1221 1
5,001 810159-3 N/A 1
Page 5 of 5 2/8/2008
