Parts Breakdown 5377MG
Page 1 of 3 2/8/2008

Parts Breakdown 5377MG
Fig # Part ID Part Name Quantity
1 266400-6 H.S.H.BOLT M8X20, 5377MG 1
2 224275-9 OUTER FLANGE, 5620DWA 1
3 224268-6 INNER FLANGE 40 5277NB 1
4 257279-6 RING 16, 5007MG 1
5 961201-4 RETAINING RING S-42, 5037NB 1
6 231831-8 TENSION SPRING 4, 5277NB 1
7 318068-5 SAFETY COVER, 5377MG 1
8 345422-0 SPACER, 4131 1
9 272255-9 LEVER 50, 5377MG 1
10 266026-4 TAPPING SCREW 4X12,9046 1
11 819236-8 MAKITA LOGO PLATE, 5377MG 1
12 188203-7 BLADE CASE SET, 5377MG 1
13 251350-8 C.H. SCREW M6X28, 5277B 1
14 262553-9 RUBBER SLEEVE 6, 5277NB 1
15 911228-4 P.H. SCREW M5X18, N1900B 3
16 285809-3 BEARING RETAINER 23-36, 9218PB 1
17 211251-2 B.BEARING 6003LLB, 5277B 1
18 324698-2 SPINDLE, 5377MG 1
19 254001-2 WOODRUFF KEY 4, HM1303B 1
20 158142-5 GEAR HOUSING, 5377MG 1
21 911228-4 P.H. SCREW M5X18, N1900B 2
22 421970-4 DECOMPRESSION CHAMBER, 5377MG 1
23 318079-0 PLATE, 5377MG 1
24 911228-4 P.H. SCREW M5X18, N1900B 2
25 256501-8 SHOULDER PIN 6, 5377MG 1
26 213005-3 O RING, 5177B 1
27 911228-4 P.H. SCREW M5X18, N1900B 3
28 213005-3 O RING, 5177B 1
29 253145-5 FLAT WASHER 6, 5177B 1
30 233011-2 COMP. SPRING 8, 5377MG 1
31 419589-1 CAP, 5377MG 1
32 419578-6 GRIP, 5377MG 1
33 911228-4 P.H. SCREW M5X18, N1900B 2
34 125346-4 HOOK ASS'Y, 5377MG 1
35 911323-0 P.H. SCREW M6X16, LS1211 1
36 158143-3 COVER CPL.,5377MG 1
37 318066-9 HOUSING W/O BEARING, 5377MG 1
38 213676-6 O RING 52, 5377MG 1
39 211104-5 BALL BEARING 6001, HM1303 1
40 253744-3 F. WASHER 12, HR2410 1
41 227504-9 HYPOID GEAR 36, 5377MG 1
42 240005-0 FAN 45, 5277NB 1
43 211061-7 B. BEARING 6000LLB, 6222DWE 1
44 681640-9 INSULATION WASHER, LS1040 1
45 516981-3 ARMATURE ASS'Y 115V, 5377MG 1
46 241905-7 FAN 80, 5277NB 1
47 285727-5 BEARING RETAINER, 5377MG 1
48 211251-2 B.BEARING 6003LLB, 5277B 1
49 213226-7 O-RING 16, 5177B 1
50 257198-6 RING 17, 5277B 1
51 961077-9 RETAINING RING, 5177B 1
52 911258-5 P.H. SCREW M5X35, 9045N 4
53 419573-6 BAFFLE PLATE, 5377MG 1
54 911676-7 P.H. SCREW M5X55, 5007NB, T2 2
55 526171-0 FIELD ASS'Y 115V, 5377MG 1
56 163470-5 DEPTH GUIDE, 5377MG 1
57 941201-0 F. WASHER 8, 5037NB 1
58 264006-4 HEX. NUT M8-13, 5377MG 1
59 272254-1 LEVER 59, 5377MG 1
60 257953-6 BOW STOP RING E-12, 5007MG 1
Page 2 of 3 2/8/2008

Parts Breakdown 5377MG
61 266227-4 C.S.N. BOLT M8X28, 5057KB 1
62 345725-2 ANGULAR GUIDE, 5377MG 1
63 256480-0 SHOULDER PIN 6-7, MT581 1
64 324699-0 STOPPER PIN, 5377MG 1
65 941201-0 F. WASHER 8, 5037NB 1
66 264006-4 HEX. NUT M8-13, 5377MG 1
67 272254-1 LEVER 59, 5377MG 1
68 257953-6 BOW STOP RING E-12, 5007MG 1
69 961017-7 STOP RING E-3, 4304 1
70 419571-0 DIAL 22, 5377MG 1
71 816864-0 SCALE PLATE, 5377MG 1
72 922903-7 H.S.H. BOLT M5X50, 6905B 1
73 941101-4 F. WASHER 5, JR3000V 1
74 257761-5 SLEEVE 6, 5377MG 1
75 266229-0 HEX.SCREW M5X8, 4200N 1
76 318071-6 BASE, 5377MG 1
77 266229-0 HEX.SCREW M5X8, 4200N 1
78 266229-0 HEX.SCREW M5X8, 4200N 1
79 256480-0 SHOULDER PIN 6-7, MT581 1
80 253022-1 F. WASHER 8, 5277NB 1
81 158141-7 MOTOR HOUSING CPL.,5377MG 1
82 862845-2 NAME PLATE, 5377MG 1
83 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
84 181047-4 CARBON BRUSH SET 154,5402A 1
85 652014-1 P.H. SCREW M4X8, 2708 1
86 188184-5 REAR COVER SET, 5377MG 1
87 188184-5 REAR COVER SET, 5377MG 1
88 266026-4 TAPPING SCREW 4X12,9046 2
89 188185-3 HANDLE SET, 5377MG 1
90 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 4
91 265995-6 TAPPING SCREW 4X18, 4323K 2
92 651189-3 SWITCH, 5007MG 1
93 188185-3 HANDLE SET, 5377MG 1
94 266020-6 TAPPING SCREW,PT4X12,9046 2
94 266427-6 N/A 2
95 687673-2 STRAIN RELIEF, 5177B 1
96 682564-2 CORD GUARD, 5007NLK 1
97 664840-6 N/A 1
97 551688-4 N/A 1
1,001 A-93625 BLUE M FORCE BLADE, 5007NHK 1
1,001 A-94530 7-1/4 24T BLACK FRAMING BLADE BULK 1
1,002 783204-6 HEX WRENCH, 3705, HR5000 1
1,003 831271-6 TOOL BAG, 5377MG 1
Page 3 of 3 2/8/2008
