Parts Breakdown LS1013
Page 1 of 6 2/8/2008

Parts Breakdown LS1013
Page 2 of 6 2/8/2008

Parts Breakdown LS1013
Fig # Part ID Part Name Quantity
1 911373-5 P.H. SCREW M6X50, LS1013 4
2 159962-0 MOTOR HOUSING COMPLETE, LS1013 1
3 265995-6 TAPPING SCREW 4X18, 4323K 2
4 416075-3 REAR COVER, LS1013 1
5 631218-8 CONTROLLER, LS1013 1
6 265995-6 TAPPING SCREW 4X18, 4323K 1
7 181047-4 CARBON BRUSH SET 154,5402A 1
8 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
9 858580-8 NAME PLATE 1
10 596141-3 FIELD ASS'Y 115V, LS1013 1
11 266029-8 T. SCREW FLANGE PT 5X65,JR3020 2
12 911223-4 P.H. SCREW M5X16, 4301BV 2
13 233165-5 COMP.SPRING 28,LS1013 1
14 344464-1 SPRING HOLDER, LS1013 1
15 257163-5 RING 6, LS1011 1
16 253804-1 F. WASHER 6, 6012HDW 1
17 922331-6 H.S.H. BOLT M6X20, LS1013 1
18 344415-4 LINK PLATE, LS1013 1
19 257163-5 RING 6, LS1011 1
20 253804-1 F. WASHER 6, 6012HDW 1
21 961018-5 STOP RING E-5, LS1011 1
22 231240-1 COMP. SPRING 7, 2414B 1
23 256633-1 PIN 6, LS1013 1
24 231928-3 RING SPRING 8, LS1013 1
25 961057-5 RETAINING RING S-17, 2711 1
26 211275-8 BALL BEARING 6003DDW, LS1013 1
27 285686-3 BEARING RETAINER 94, LS1013 1
28 240001-8 FAN 80, LS1013F 1
29 516721-9 ARMATURE ASS'Y 115V, LS1013 1
30 681642-5 INSULATION WASHER, LS1013 1
31 211061-7 B. BEARING 6000LLB, 6222DWE 1
32 416107-6 BAFFLE PLATE, LS1013 1
33 664463-0 CORD (2X14X8 SJ), 2414B 1
34 682505-8 CORD GUARD, 2711 1
35 687052-4 STRAIN RELIEF, HM1500B 1
36 265995-6 TAPPING SCREW 4X18, 4323K 2
37 414546-4 CAM, LS1011 1
38 416000-4 LOCK OFF LEVER, LS1040 1
39 411478-6 SWITCH BUTTON, LS1011 1
40 182910-4 HANDLE SET, LS1013 1
41 231457-6 COMP. SPRING 3, HR2400 1
42 651923-1 SWITCH, LS1211 1
43 415999-0 SWITCH LEVER, LS1040 1
44 265995-6 TAPPING SCREW 4X18, 4323K 6
45 182910-4 HANDLE SET, LS1013 1
46 921467-8 HEX BOLT M8X45, LS1013 1
47 262003-4 RUBBER RING 6, LS1013 1
48 911323-0 P.H. SCREW M6X16, LS1211 1
49 421562-9 GRIP, LS1013 1
50 344420-1 GRIP HOLDER, LS1013 1
51 911323-0 P.H. SCREW M6X16, LS1211 1
52 188370-8 N/A 1
52 153598-7 BLADE CASE COMPLETE 1
52 151469-2 BLADE CASE COMPLETE, LS1013 1
52 151484-6 BLADE CASE CPL. 1
53 819064-1 MAKITA MARK, HM1100C 1
53 819214-8 MAKITA LOGO LABEL, LS1013L 1
54 344045-1 STOPPER ARM PLATE, LS1211 1
55 911113-1 P.H. SCREW M4X10, 4301BV 1
56 213460-9 O RING 35, HM1500 1
Page 3 of 6 2/8/2008

Parts Breakdown LS1013
57 419277-0 DUST NOZZLE, LS1013 1
57 416133-5 DUST NOZZLE, LS1013 1
58 265717-4 SCREW M6X43, LS1211 1
59 262001-8 RING 5, 6906 1
60 317176-9 STOPPER ARM, LS1212 1
61 211021-9 BALL BEARING 607LLB, LS1013 1
62 961054-1 RETAINING RING S-14, 6302 1
63 226742-0 SPIRAL BEVEL GEAR 33, LS1013 1
64 262074-1 RUBBER RING 20, LS1013 1
65 267035-6 F. WASHER 14, 6805BV 1
66 316836-0 HOUSING W/O BEARING, (A) LS1013 1
67 254202-2 KEY 4, 9924DB 1
68 322899-6 SPINDLE, LS1013 1
69 211275-8 BALL BEARING 6003DDW, LS1013 1
70 285828-9 BEARING RETAINER 66, LS1211 1
71 257022-3 RING 16, LS1013 1
72 224333-1 FLANGE 53, LS1040 1
73 257060-5 RING 15.88,LS1013 1
74 224333-1 FLANGE 53, LS1040 1
75 265355-2 H. F. H. BOLT, LS1030 1
76 343639-9 CENTER PLATE, LS1030 1
77 344380-7 CENTER COVER, LS1040 1
78 265324-3 H.F.H. BOLT M8X12, LS1030 1
79 231593-8 TORSION SPRING 36, LS1030 1
80 416105-0 SAFETY COVER, LS1013 1
80 450047-8 SAFETY COVER, LS1013F 1
81 267136-0 FLAT WASHER 5, 9046 1
82 911213-7 P.H. SCREW M5X12, LS1040 1
83 265008-3 SCREW M5, LS1011 1
83 265985-9 HEX.SOCKET HEAD BOLT M6, LS1211 1
84 911223-4 P.H. SCREW M5X16, 4301BV 2
85 265406-1 H.BOLT M10X130, LS1211 1
86 253024-7 F. WASHER 10, LS0714 1
87 331428-4 PIPE, LS1211 1
88 252105-4 HEX LOCK NUT M8-13, HM1800 1
89 941201-0 F. WASHER 8, 5037NB 1
90 152970-0 ARM COMPLETE, LS1013F 1
90 153838-3 ARM COPL., LS1013 1
90 154779-6 ARM CPL., LS1013L 1
90 317182-4 ARM, LS1013 1
91 322317-4 STOPPER PIN, LS1040 1
92 213021-5 O RING 5, LS1030 1
93 687095-6 STRAIN RELIEF, LS1220 1
94 266026-4 TAPPING SCREW 4X12,9046 1
95 252130-5 HEX LOCK NUT M10 LS1211 1
96 253024-7 F. WASHER 10, LS0714 1
97 265371-4 HEX BOLT M8X30, LS1011 2
98 265412-6 HEX. BOLT M8X20, LS1013 2
99 216003-6 STEEL BALL 10, 2401B, LS1013 2
100 344414-6 GUIDE PLATE, LS1013 1
100 345418-1 GUIDE PLATE, LS1013 1
101 231626-9 TORSION SPRING 28, LS1013 1
102 413067-3 INDICATION PLATE, LS1013 2
103 911113-1 P.H. SCREW M4X10, 4301BV 2
104 233168-9 COMPRESSION SPRING 5, LS1013 2
105 266131-7 HEX SOCKET HEAD BOLT M12X12, LS1013 2
106 253852-0 F. WASHER 8, LS1211 1
107 265442-7 HEX BOLT M8X40, LS1013 1
108 415209-5 KERF BOARD, LS1013,LS1013F 2
108 416886-6 KERF BOARD, LS1211,LS1212 2
109 266026-4 TAPPING SCREW 4X12,9046 4
Page 4 of 6 2/8/2008

Parts Breakdown LS1013
110 252014-7 HEX LOCK NUT M6-10, LS1040 1
111 344463-3 SUB FENCE PLATE, LS1013 1
112 151572-9 SUB FENCE CPL. 1
112 150710-0 SUB FENCE COMPLETE, LS1013 1
113 253715-0 F. WASHER 6, NHP1310 1
114 912357-6 C.S.H. SCREW M6X35, LS1013 1
115 251887-5 SCREW M6X10, LS1030 1
116 921451-3 HEX BOLT M8X30, LS1011 4
117 316840-9 GUIDE RULE, LS1013 1
117 317183-2 GUIDE RULE, LS1013F 1
117 317183-2 GUIDE RULE, LS1013F 1
118 266132-5 SCREW M8X320, LS1013 1
119 931402-8 HEX NUT M8, 5037NB 1
120 271314-6 KNOB 40, LS1212 1
120 273444-9 GRIP 37, LS1013 1
121 331491-7 PIPE 9-200, LS1013 1
122 152541-3 KNOB 48 COMPLETE, LS1013 1
123 421563-7 CAP 10, LS1013 1
124 322924-3 COIL SPRING, LS1013 1
125 322909-9 LOCK PIN, LS1013 1
126 266034-5 TAPPING SCREW 4X16, 9524NB 1
127 232075-3 LEAF SPRING, LS1011 1
128 961018-5 STOP RING E-5, LS1011 1
129 231307-5 COMP. SPRING 6, LS1013 1
130 316899-6 PIN HOLDER, LS1013 1
131 344411-2 SLIDE STOPPER, LS1013 1
132 251267-5 P.H. SCREW M6, LS1013 1
133 256196-7 PIN 5, LS1013 1
134 266034-5 TAPPING SCREW 4X16, 9524NB 1
135 344412-0 STOPPER HOLDER, LS1013 1
136 331493-3 TURN STOPPER, LS1013 1
137 266034-5 TAPPING SCREW 4X16, 9524NB 2
138 266026-4 TAPPING SCREW 4X12,9046 1
139 816128-2 POINTER, LS1013 1
140 151483-8 TURN BASE CPL. 1
140 153832-5 TURN BASE CPLT., LS1013 1
141 921356-7 HEX BOLT M6X35, LS1013 2
142 152542-1 SQUARE ROD COMPLETE, LS1013 1
143 151459-5 ARM HOLDER COMPLETE, LS1013 1
143 151482-0 ARM HOLDER CPL. 1
144 251668-7 HEX. BOLT M10X90, LS1013 1
145 911113-1 P.H. SCREW M4X10, 4301BV 1
146 416006-2 LEVER 100, LS1040 1
147 252144-4 HEX. NUT M10-17, LS1013 1
148 253024-7 F. WASHER 10, LS0714 1
149 152540-5 BEARING BOX B COMPLETE, LS1013 1
150 922451-6 H.S.H. BOLT M8X30, LS1013 2
151 266026-4 TAPPING SCREW 4X12,9046 2
152 816326-8 MITER SCALE PLATE, LS1013 1
153 344477-2 SLIDE PLATE, LS1013 2
154 251887-5 SCREW M6X10, LS1030 2
155 286212-1 CAP 20, LS1011 4
156 151575-3 N/A 1
156 152649-3 BASE CPL., LS1013 1
156 153833-3 BASE CPL., LS1013 1
157 911108-4 P.H. SCREW M4X8, LS1013 1
162 253804-1 F. WASHER 6, 6012HDW 1
163 941201-0 F. WASHER 8, 5037NB 1
164 231266-3 COMP. SPRING 5, LS711DWBEK 1
166 251961-9 H.S.H. SCREW M6X10, LS1040 1
1,001 762001-3 TRIANGLE RULE, LS1011 1
Page 5 of 6 2/8/2008

Parts Breakdown LS1013
1,002 782212-4 SOCKET WRENCH 13, LS1011 1
1,003 122523-9 DUST BAG, LS1040 1
1,004 411478-6 SWITCH BUTTON, LS1011 2
1,005 322932-4 HOLDER 255, LS1013 2
1,006 251887-5 SCREW M6X10, LS1030 1
1,007 322983-7 VICE ROD, LS1013 1
1,008 271309-9 KNOB 40, LS1013L 1
1,009 122538-6 VERTICAL VISE ASS'Y, LS1013 1
1,010 253804-1 F. WASHER 6, 6012HDW 1
1,011 343651-9 VISE PLATE, LS1030 1
1,012 251370-2 PAN HEAD SCREW, LS1030 1
1,013 A-93550 10 CT SAW BLADE,70T,LS1013L 1
5,035 810143-8 N/A 1
5,036 941202-8 F. WASHER 8, 5037NB 4
