Makita LS1045 User manual

Compound Miter Saw
255 mm (10”) MODEL LS1045
Equipped with Electric Brake
INSTRUCTION MANUAL
DOUBLE
INSULATION

SPECIFICATIONS
Blade diameter ........................................................................................... 255 mm (1 0")
Hole diameter ........................................................................................ 15.88 mm (5/8")
Max. cutting capacities (H x W)
90.5 mm x 95 mm
69 mm x 130mm
(3-9/16" x 3-3/4")
(2-3/4" x 5-1/8")
Bevel angle
90.5 mm x 67 mm
69 mm x 92 mm
(3-9/16" x 2-5/8")
(2-3/4" x 3-5/8")
Miter angle
450
(left)
00
48 mm x 95 mm 48 mm x 67 mm
35 mm x 130 mm 35 mm x 92 mm
(1-7/8" x 3-3/4") (1-7/8" x 2-5/8")
(1-3/8" x 5-118") (1-3/8" x 3-5/8")
I
45O (left and right)
00
* Manufacturer reserves the right to change specifications without notice.
Note: Specifications may differ from country to country.
WARNING: For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
2

For Your Own Safety Read Instruction
Manual Before Operating
Compound
Saw
Save it for future reference
GENERAL SAFETY PRECAUTIONS
(For All Tools)
1. KNOW YOUR POWER TOOL. Read the owner's manualcarefully. Learnthe
tools applications and limitations, as well as the specific potential hazards
peculiar to
it.
2. KEEP GUARDS IN PLACE and in working order.
3. REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to
see that keysand adjusting wrenches are removed from tool before turning
it on.
4. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
5. DON'T USE INDANGEROUSENVIRONMENT. Don't usepower tools indamp
or wet locations, or expose them to rain. Keep work area well lighted.
Don't use tool
in presence of flammable liquids or gases.
6. KEEP CHILDREN AWAY. All visitors should be kept safe distance from work
area.
7. MAKE WORKSHOP KID PROOF with padlocks, master switches, or by
removing starter keys.
8. DON'T FORCETOOL. It will do thejob better and safer at the ratefor which
it was designed.
9. USE RIGHT TOOL. Don't force tool or attachment to do a job for which it
was not designed.
IO. WEAR PROPER APPAREL. Wear no loose clothing, gloves, neckties, rings,
bracelets, or other jewelry which may get caught in moving parts. Nonslip
footwear is recommended. Wear protective hair coveringtocontain longhair.
11. ALWAYS USE SAFETY GLASSES. Also use face or dust mask if cutting
operation is dusty. Everyday eyeglasses only have impact resistant lenses,
they are NOT safety glasses.
12. SECURE WORK. Useclamps or a vise to holdwork when practical. It's safer
than using your hand and
it frees both hands to operate tool.
13. DON'T OVERREACH. Keep proper footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and
safest performance. Follow instructions for lubricatingand changing acces-
sories.
15. DISCONNECTTOOLS before servicing; when changing accessories such as
blades, bits, cutters, and the like.
3

16. EXTENSION CORDS. Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy enough to carry
the current your product will draw. An undersized cord will cause a drop
in
line voltage resulting in loss of power and overheating. Table 1 shows the
correct size touse depending oncord length and nameplate ampere rating.
If
in doubt, usethe next heavier gage. The smaller the gage number, the heav-
ier the cord.
Minimum gage for cord
I
AmDere Ratina
Volts
I Total length of cord in feet
120V I 25ft. 50 ft. 100 ft. 150 ft.
Not
More Than More Than
0 6
6 10
10 12
12 16
4
AWG
18 16 16 14
18 16 14 12
16 16 14 12
14 12
Not Recommended

VOLTAGE WARNING: Before connectingthe tool to a power source (receptacle,
outlet, etc.) be sure the voltage supplied is the same as
that specified on the
nameplate of the tool. A power source with voltage greater than that specified
for the tool can result
in SERIOUS INJURYto the user - as well as damage to
the tool.
If in doubt, DO NOT PLUG IN THE TOOL. Using a power source with
voltage less than the nameplate rating is harmful to the motor.
ADDITIONAL SAFETY RULES
1. Wear eye protection.
2. Do not operate saw without guards in place.
3. Don't use the tool in the presence of flammable liquids or gases.
4. Check the blade carefully for cracks or damage before operation.
5. Use only flanges specified for this tool.
6. Be carefulnottodamagethe arbor, flanges (especially the installing surface)
7. Make sure that the turn base is properly secured so it will not move during
8. For your safety, removethe chips, small pieces, etc. fromthetable top before
9. Avoid cutting nails. Inspect for and remove all nailsfromthe workpiece before
Replace cracked or damaged blade immediately.
or bolt. Damage to these parts could result in blade breakage.
operation.
operation.
operation.
IO. Make sure the shaft lock is released before the switch is turned on.
11. Be sure that the bladedoes notcontactthe turnbase inthe lowest position.
12. Hold the handle firmly. Be aware that the saw moves up or down slightly
during start-up and stopping.
13. Do not perform any operation freehand. The workpiece must be secured
firmly against the turn base and guide fence during all operations.
14. Keephands out of pathof saw blade. Avoid contact withany coasting blade.
It can still cause severe injury.
15. Never reach around saw blade.
16. Make sure the blade is not contacting the workpiece before the switch is
turned on.
17. Before using the tool on an actual workpiece, let it run for a while. Watch
for vibration or wobbling that could indicate poor installation or a poorly
balanced blade.
18. Wait until the blade attains full speed before cutting.
19. Stop operation immediately if you notice anything abnormal.
20. Do not attempt to lock the trigger in the on position.
5

21. Shut off power and wait for saw blade tostop before servicing or adjusting
tool.
22. Be alert at all times, especially during repetitive, monotonous operations.
Don't belulled intoafalse sense of security. Blades areextremely unforgiving.
23. Do not cut cross-armed as shown I
24. Always use accessories recommended in this manual. Use of improper
25. Don't abusecord. Neveryank cord todisconnect it fromthe receptacle.Keep
accessories such as abrasive wheels may cause an injury.
cord away from heat, oil, water and sharp edges.
. SAVE THESE INSTRUCTIONS.
6

Carryingtool
When carrying the tool, lower the handle
fully and press the stopper pin to lock the
handle in the lowered position. Secure the
turn base by means of the grip. The tool can
then beconveniently carried by the carrying
grip.
WARN
I NG:
Besure that the tool is unpluggedfirst.
Stopper pin is for carrying purposes only
and not for any cutting operations.
Carryinggrip
Benchmounting miter saw
This tool should be bolted with two boltsto
a level and stable surface using the bolt
holes provided in the tool's base. This will
helpprevent tipping and possible injury.
Removingor installing
saw blade
CAUTION:
Always be sure that the
tool is switched off
andunpluggedbefore removingor installing
the blade.
To remove the blade, use the socket
wrench to loosen the hex bolt holding the
center cover by turning it more than three
turns counterclockwise. Raise the safety
cover and center cover.
7

Pressthe shaft lock so that the blade can-
not revolve and use the socket wrench to
loosenthe hex bolt clockwise.Then remove
the hex bolt, outer flange andblade.
To install the blade, mount the blade onto
the spindle, making sure that the direction
of the arrow on the surface of the blade
matches the direction of the arrow on the
blade case. Install the outer flange and hex
bolt, and then use the socket wrench to
tighten the hex bolt securely counterclock-
wise while pressing the shaft lock. Then
tighten the hex bolt clockwise to secure
the center cover.
CAUTION:
Use only the Makita socket wrench provided to install or remove the blade. Failureto do
so may result in overtightening or insufficient tightening of the hex bolt. This could cause
an injury.
Safety
cover
When lowering the handle, the safety
cover risesautomatically.The cover returns
to its originalpositionwhen the cut is com-
pleted and the handle is raised. NEVER
DEFEAT
OR REMOVE THE SAFETY
COVER. In the interest of your personal
safety, always maintain the safety cover in
good condition. Any irregular operation of
the safety cover should becorrected imme-
diately. NEVER
USE THE TOOL WITH A
FAULTY SAFETY COVER. If the see-
through safety cover becomes dirty, or
cover
sawdust adheres to it in such a way that the bladeand/or workpiece is no longereasilyvis-
ible, unplugthe saw and cleanthe cover carefully with a damp cloth. Do not use solvents
or any petroleum-basedcleanerson the plastic cover.
.
8

Dust bag
The use of the dust bag makes cutting
operations clean and dust collections easy.
To attach the dust bag, fit the bags entry
port over the dust spout.
When the dust bag is about half full,
remove the dust bagfrom the tool and pull
the fastener out. Empty the dust bag of its
contents, tapping it lightly
so as to remove
particles adhering to the insides which
might hamperfurther collection.
Switch action
To prevent the switch lever from being
accidentallypulled,
a lock-off button is pro-
vided.
To start the tool, press in the lock-off but-
ton and pull the switch lever. Release the
switch leverto stop.
I
\
Dust spout -
- Fastener
Lock-off button
CAUTION:
*Before plugging inthe tool, always checkto see that the switchtrigger actuates properly
*When not using the tool, remove the lock-off button and store it in a secure place.This
*Do not pull the trigger hardwithout pressing in the lock-off button. This can cause break-
and returnsto the
"OFF" position when released.
prevents unauthorizedoperation.
age of the switch.
9

Kerf board I
~~-~~ ~~~~~~~~
This tool is providedwith the kerf board in
the turn base. If the kerf groove has notyet
been cut in the kerf board by the factory,
you should cut the groove before actually
using the tool to cut
a workpiece. Switch
on the tool and lower the blade gently to
cut
a groove inthe kerf board.
Ked
Maintainingmaximum cuttingcapacity
Unplugthe tool beforeany adjustment is attempted.
This tool is factory adjustedto provide the max. cutting capacity for
a 255 mm (10") saw
blade. When the diameter
of the blade has been reduced due to sharpening, adjust the
depth adjusting bolt by turning it with the socket wrench. The saw blade is lowered by
turningthe depthadjustingbolt counterclockwiseand raised by turning it clockwise.Adjust
so that when the handle is in the fully lowered position,there will be a distanceof about
130 mm (5-1/8") from the front face of the guide fence to the point where the front edge
of the blade entersthe kerf.With the tool unplugged, rotatethe blade
by hand while hold-
ing the handle
all the way down. Be sure that the blade does not contact any part of the
lower base whenthe handleis loweredcompletely.
Positioningfor adjusting
the miterangle
Loosen the grip by turning counterclock-
wise. Turn the turn base while pressing
down the lock lever. When you have
moved the grip to the position where the
pointer indicatesthe desired angle on the
miter scale, securely tighten the grip clock-
wise.
.
CAUTIO N :
When turningthe turn base, be sure to raise the handle fully.
10

Positioningfor adjustingthe bevel angle
The saw bladetilts up to
45" to the left. To adjust the bevel angle, loosen the lever at the
rear
of the tool. Tilt the blade to the left so that the pointer indicates the desired angle on
the bevelscale.Then tighten the leverfirmly to securethe arm
Lever
Bevel
scale
Pointer
CAUTION :
When tilting the saw blade, besure to raisethe handlefully
Securing workpiece
Whenever possible, secure the workpiece with the optional vise.
If you must use your
handto holdthe workpiece, then
it must bedone firmly and securely so as not to lose con-
trol of the workpiece. Your hand and arm must be kept well away from the blade area
(4"
minimum).Squeeze the workpiece firmly against the guide fence with your fingers held
over the top of theguide fence. The workpiece must also rest steadily on theturn base.
WARN
I NG :
Never use your hand to holdthe workpiece that requiresyour handto be any closer than
4" from the blade area. Inthis case, always usethe optionalvise to secure the workpiece.
After any cuttingoperation, raise the blade gently. Never raise the blade until
it has come
to
a complete stop. Seriousinjury may result.
1. Verticalvise (optionalaccessory)
The vertical vise can be installed on the guide fence or the holder assembly (optional
accessory).
Insert the vise rod into the hole in the
guide fence or holder assembly and
tighten the screw
to securethe vise rod.
Position the vise arm according to the
thickness and shape of the workpiece
and secure the vise arm by tightening
the screw. Press the workpiece flat
against the guide fence and the turn
base. Position of the workpiece at the
desired cutting position and secure it
firmly by tightening the clamp screw.
-Vise arm
11

2. Horizontalvise (optionalaccessory)
The horizontal vise can be installedon either the left or right side of the base. When
performing
15" or greater miter cuts, installthe horizontal vise on the side oppositethe
direction in which the turn table is to be turned.
By turning the knob on the vise coun-
terclockwise,the screw is releasedand the vise shaft can be moved rapidly in and out.
By turning the knob clockwise, the screw remains secured. To grip workpieces, turn
the knob gently clockwise until the projection reaches it topmost position,then fasten
securely.
If the knob is forced in or pulledout while beingturnedclockwise, the projec-
tion may stop
at an angle. In this case, turn the knob back counterclockwise until the
screw is released, beforeturning again gently clockwise.
Knob -,
3. Holdersand holder assembly
(optionalaccessories)
The holders and the holder assembly
can be installedon either side as
a con-
venient means of supporting work-
pieces horizontally. Install them as
shown in the figure. Then tighten the
screws firmly to secure the holders and
the holderassembly.
When cutting long workpieces, use
the holder-rod assembly (optionalacces-
sory). It consists of two holder assem-
bliesand two rods
12.
'Screw
I Holder assembly A -Screw
Holder assembly
Rod 12
CAUTION:
Always support long workpieces levelwith the top surfaceof the turn base for accurate
cuts and to preventdangerous
loss of control of the tool.
* 12

Operation
CAUTION:
*Before use, be sure to releasethe handlefrom the lowered position by pulling the stop-
per pin.
*Make sure the bladeis not contacting the workpiece, etc. beforethe switch is turned on.
*Do not apply excessive pressureon the handlewhen cutting. Too muchforce may result
inoverloadof the motor and/or decreasedcutting efficiency.
*Gently press down the handle to perform the cut. If the handle is pressed down with
force or if lateralforce is applied, the bladewill vibrate and leave
a mark (sawmark)inthe
workpiece and the precision
of the cut will be impaired.
When cutting with this tool, the thickness
of the blade is cut out of the workpiece as
well. Therefore,your cutting line should be
on either the left or right side
of the groove
in the kerf board. Switch on the tool and
wait until the blade attainsfull speed before
lowering gently into the cut. When the
I----+
blade, contacts the workpiece, gradually
bear down on the handle to perform the
cut. When the cut is completed, switch off
the tool and WAIT UNTIL THE BLADE HAS
COME TO A COMPLETE STOP before
returningthe bladeto its fully elevatedposi-
tion
. A thin piece of cut off material could
otherwise contact the coastingbladeand bethrown arounddangerously.
CAUTION:
When cutting long workpieces, use sup-
ports that are as high as the top surface
levelof the turn base.
1. Miter cutting
Referto the previouslycovered "Positioning for adjusting the miter angle"
13

2. Bevel cut
*Left 0" - 45' bevelcuts can be performed.
*Loosen the lever and
tilt the saw blade
to set the bevel angle. Switch on the
tool and wait until the blade attains full
speed. Then gently lower the handleto
the fully lowered position while applying
pressure inthedirection of the arrow (in
parallelwith the blade).When the cut is
completed, switchoff thetool andWAIT
UNTIL THE BLADE HAS COME
TO A
COMPLETE STOP before returning the
bladeto itsfully elevated position.
Apply pressure in the
directionof the arrow
(in
parallel withthe blade)
WARNING:
Never use your hand to hold the workpiece that requires your hand to be any closer
than
4" from the blade area. In this case, always use the optional vise to secure the
workpiece. After any cutting operation, raise the blade gently. NEVER raise the blade
until
it has cometo a complete stop. Seriousinjury may result.
CAUTION:
*When performingthe bevel cut with the workpiece secured on the left side of the turn
base, it
will create a condition where the piececut off will come to rest on the blade. If
the bladeis raisedwhile the blade isstill rotating, this piece may be caught inthe blade,
causing fragments to be scattered around which is dangerous. The blade should be
gently raisedonly after the blade has come to a complete stop.
*When pressingdownthe handle,apply pressure inthedirection
of the arrow (inparallel
with the blade). If
a force is applied perpendicularlyto the turn base or if the pressure
direction is changedduring
a cut, the precision of the cut will be impaired.
Bevelcut
*Always set the sub-fence to the leftposition when performingbevel cuts.
Sub
' fence -
14

Bevel angle
45" I Left and right 0' - 45'
Miter angle
When performing the compound cutting, refer to "Miter cutting" and "Bevel cut"
explanations.
4. Cutting crown and cove moldings
*Crown and cove molding can be cut on
a compound cut with the moldings laid flat on
the turn base.
*There are two common types
of crown moldings and one type of cove molding; 52/38"
wall angle crown molding, 45"wall angle crown molding and 45"wall angle cove mold-
ing. See illustrations below.
Ceilina Ceilinq Ceiling
45" type
cove molding
--
-
-
4 4
*There are crown and cove molding joints to fit "Inside" 90" corners (0 and @ in Fig. A)
and "Outside" 90' corners (0 and @ in Fig. A).
- -
Insidecorner Outside corner
Insidecorner Fig. (A)
15

Position Bevel angle
in Fig
(A) 52/38'' type 45' type
0
@ Left 33 90 Left 30"
0
@
For inside corner
For outside corner
~
-
Miter angle
52/38" type 45O type
Right 31
6' Right 35 3'
Left
31 6" Left 35 3"
Right 31
6' Right 35 3'
Molding edge against guide fence
Position
in Fig
(A)
W
Wail contact edge should be
I against guide fence
Finished piece
u, I against guide fence.
For inside corner
h
(Example)
In the case of cutting 52/38' type crown molding at position 0 in Fig
(A)
*Tilt and secure bevel angle setting to 33 9"
*Adjust and secure miter angle setting to 31 6" RIGHT
*Lay crown molding with its broad back surface down on the turn base and its CEILING
CONTACT EDGE against the guide fence on the saw
.The finished piece to be used will always be on the LEFT side of the blade
Ootional crown moldina fence allows easier cuts of crown moldinqwithout tiltinq the saw blade
Finished piece will be on the
Left side
of blade
Ceiling
Wall
Fig. (B)
Position crown moldingwith its WALL CONTACT EDGE againstthe guide fence and its CEILING
CONTACT EDGE against the crown molding stopper as shown in Fig (B) Refer to the table
Table IC)
(C)for the miter angle
For outside corner
@
Finished piece will be on the
Right side of blade
Ceiling contact edge should be
against guide fence
16
Position in Fig (A) Miter angle
0 Right 45"
Left 45'
0
0
@ Right 45"
For inside corner
For outside corner
Finished piece
Save the right side
of blade
Save the left side
of blade
Save the right side of blade
Save the left side of blade

5. Cutting aluminum extrusion
When securing aluminum extrusions,
use spacer blocks or pieces of scrap as
shown in the figure to prevent deforma-
tion of the aluminum. Use
a cutting
lubricant when cutting the aluminum
extrusion
to prevent build-up of the alu-
minum materialon the blade.
n
Aluminum extrusion
CAUTION:
Never attempt to cut thick or round aluminum extrusions. Thick aluminum extrusions
may come loose during operation and round aluminum extrusion cannot be secured
firmly with this tool.
6. Wood facing
Useof wood facing helpsto assure splinter-freecuts in workpieces. Attach awood fac-
ing to the guide fence usingthe holes inthe guide fence
CAUTION:
*Use straight woodof even thickness as the woodfacing.
*See the figure belowconcerningthe dimensions for
a suggested woodfacing
Over 10 mm (3/8')
Over 460 mm (18-1/8")
90
mm
(3-9/16')
90" 107mm 107" 90" Hole
(3-9/16") (4-7/32") (4-7/32") (3-9/16"1
Centerof wood facing
17

7. Cutting repetitivelengths
When cutting several pieces of stock to
the same length, rangingfrom 240 mm
(9-29/64") to 350 mm (13-25/32"), use
of the set plate (optionalaccessory)will
facilitate more efficient operation.Install
the set plate on the holder (optional
accessory)as shown in the figure.Align
the cutting line on your workpiece with
either the left or right side of the groove
in the kerf board, and while holding the
workpiece from moving, move the set
plate flush against the end of the work-
niece. Then secure the set plate with
Holder -
I
;he screw.When the set plate is not used, loosenthe screw and turn the set plateout
of the way.
18

MAINTENANCE
CAUTION:
Always be sure that the tool is switched off and unpluggedbefore attempting to perform
inspection or maintenance.
WARNING:
Always besure that the bladeis sharp and cleanfor the best and safest performance
Alignment
for squareness
This tool was carefully adjusted and alignedfor squarenessof cut at the factory, but rough
handlingmay have affected the alignment. If your tool is not aligned properly, perform the
following.
1) Miter angle
Loosenthe grip and set the turn base at zero degrees
by turning the turn base.Tighten
the grip securely and loosen the hex bolts on the guide fence. Square the side of the
bladewith the face of the guide fence using
a triangularrule,try-square,etc.by moving
the right side of the guidefence. Then securelytighten the hex boltson the guide fence
in the order indicatedinthe figure.
II
\ Hex. bolt
2) Bevelangle
a)
0" bevelangle
Loosen the lever at the rear
of the
tool. Loosenthe hex nut and turn the
hex bolt (A)two or three revolutions
clockwise
so that the blade tilts to
the right.
19

Lower the handle fully and square
the side
of the blade with the top
surface
of the turn base using the tri-
angular rule, try-square, etc. by turn-
ingthe hex bolt (A)counterclockwise.
Then tighten the hex nut to secure
the hex bolt (A).
Make sure that the pointer on the
arm indicates
0" on the bevel scale
on the arm. If the pointer does not
indicate
0', loosen the screw secur-
ingthe pointer and adjust the pointer.
b) 45" bevel angle
Adjust 45" bevel angle after perform-
ing 0" bevel angle adjustment. To
adjust 45" bevel angle, loosen the
leverand tilt the saw bladeto the left
fully. Make sure that the pointer on
the turn base indicates 45' on the
bevel scale on the arm.
If the pointer
does not indicate 45". turn the hex
bolt
(B) on the side of the turn base
untilthe pointer indicates45".
HI
Top surface of turn base
/
scale
Arm 2 Pointer
Lever
1 / Hex bolt (B)
I Arm Pointer
20
