Manhattan Comfort Franklin FP3 User manual

FIREPLACE TV STAND
FP3

Part Identification
Hardware Identification
Assembly Steps
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5-19
FP3Page 2

Part Identification
◆While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B BOTTOM (1)
C LEFT END (1)
D RIGHT END (1)
E LEFT UPRIGHT (1)
F RIGHT UPRIGHT (1)
G ADJUSTABLE SHELF (2)
HBACK (2)
J LEFT MOLDING (1)
K RIGHT MOLDING (1)
L TOP MOLDING (1)
NDOOR (2)
O
MIDDLE SHELF (1)
O
Page 3
FP3

Hardware Identification
◆Screws are shown actual size. You may receive extra hardware with your unit.
CAM SCREW -16
1
APPLIQUE CARD- 4
4
HIDDEN CAM - 16
2
5
WOOD DOWEL-8
3
1/2" FIAT HEAD SCREW-24
BUMPER CARD- 1
10 3/8" PAN HEAD SCREW-15
ZZ
HINGE- 4
6
METAL PIN- 12
7LOWERD BLACK 2-3/8" PAN
HEAD SCREW - 12
8BLACK 1-3/4" PAN
HEAD SCREW - 3
9
11
FP3Page 4
522,68 22,68
22 kg 22 kg
(Refer to the last step for proper location and application)
WARNING LABEL - 1

HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
Page 5
FP3

1
16 pcs
Step 1
◆Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
Turn sixteen CAM SCREWS (1) into the TOP (A) and MOLDINGS (J and K).
◆
FP3Page 6

Arrow
Arrow
Arrow
Arrow
◆Push sixteen HIDDEN CAMS (2) into the BACK (H), ENDS (C and D) and UPRIGHTS (E and F).
Step 2
Page 7
FP3
Arrow
The arrow in the HIDDEN
CAM must point toward the
Hole
( 16pcs )

Fasten the TOP MOLDING (L) to the TOP (A).
Use three BLACK 1-3/4''PAN HEAD SCREWS through
the MOLDING and align to the holes in the top before
you fasten.
◆
Step 3
FP3Page 8
1-3/4"BLACK PAN HEAD SCREW
(3 used in this step)

Step 4
◆
◆
Push the WOOD DOWELS (3) into the exact hole shown in
the UPRIGHTS (E and F).
Fasten the MOLDINGS (J and K) to the UPRIGHTS (E
and F). Tighten four HIDDEN CAMS
Page 9
FP3
WOOD DOWEL
(2 used in this step)

Fasten the UPRIGHTS (E and F) to the TOP (A). Tighten four
HIDDEN CAMS.
Step 5
◆
FP3Page 10

Step 6
◆Fasten the BACKS (H) to the TOP (A). Tighten four HIDDEN CAMS.
Page 11
FP3

Step 7
◆Fasten the ENDS (C and D) to the TOP (A). Tighten four HIDDEN CAMS.
FP3Page 12

Step 8
◆
◆
Push the WOOD DOWELS (3) into the exact hole shown in
the ENDS (C and D), BACKS (H) and UPRIGHTS (E and F).
Fasten the BOTTOM (B) to the ENDS (C and D), UPRIGHTS (E and F) and the BACKS(H).
Use twelve BLACK 2-3/8'' PAN HEAD SCREWS (8).
NOTE: You should align each SCREW to the holes before completely
tightening any of them.CAMS.
Page 13
FP3
WOOD DOWEL
(6 used in this step)
2-3/8" PAN HEAD SCREW
(12 used in this step)

Step 9
◆
◆
Insert the METAL PINS (7) into the hole locations of your
choice in the ENDS (D and C) and UPRIGHTS (F and E).
Set the ADJUSTABLE SHELVES (G) onto the METAL PINS.BE is positioned as shown.
FP3Page 14

Step 10
◆
◆
Fasten four HINGES (6) to a DOOR (N). Use eight 1/2" FLAT
HEAD SCREWS (10).
Repeat this step for the remaining DOOR (N).
Page 15
FP3
1/2" FIAT HEAD SCREW
(8 used in this step)

Step 11
◆
◆
◆
Before fastening the DOORS to your unit, be sure themounting screw is
against the stops as shown in theright diagram. If it isn't, loosen the
adjusting screw andmounting screw to slide it against the stops.
Then tightenthe mounting screw.
Fasten the DOORS (N) to the ENDS (C and D).
Use sixteen 1/2" FLAT HEAD SCREWS (10).Peel two BUMPERS from the
BUMPER CARD (7) and stick them onto the SHELVES (D) in the locations shown.
FP3Page 16
1/2" FIAT HEAD SCREW
(16 used in this step)

Step 12
◆Please go to step 13 if you want to put the middle shelf (O) as show in
diagram #1 or go to step 15 if you want to put the insert as show in diagram #2.
Page 17
FP3
Ｄiagram #1 Ｄiagram #2

FP3Page 18
Step 13
◆
◆
Insert the METAL PINS (5) into the hole locations of your
choice in the UPRIGHTS (E and F).
Set the ADJUSTABLE SHELF (O) onto the METAL PINS.
5
METAL PIN
(4 used in this step)
O

Step 14
◆
◆
◆
◆
Peel APPLIQUES from the APPLIQUE CARDS (4) and stick them onto each visible HIDDEN CAM.
This completes assembly. Clean with a damp cloth. Wipe dry.
Apply the WARNING LABEL (11) to the TOP (A). You should be able to read the label when the TV is removed from the
unit. When the TV is in place, it should hide the label. Peel off the backing and apply the label as shown in the diagram.
NOTE: This is a permanent label intended to last for the life of the product. Once applied, do not try to remove it.
This completes assembly. Clean with a damp cloth. Wipe dry.
Page 19
FP3
A
11
522,68 22,68
70 lbs. 31,75 kg 31,75 kg
70 lbs.
50 lbs.
15 lbs. each
30 lbs. each
522,68 22,68

Step 15
FP3Page 20
◆Fasten the BRACKETS (X and Y) to the FIREPLACE (W). Use six 3/8" FLAT HEAD
SCREWS (ZZ).
CAUTION!!
Please read all FIREPLACE instructions prior to
installing or removing it from your unit.
Do not plug the FIREPLACE into the power
supply until it is installed and your unit is in its
final position. Do not move the FIREPLACE
while it is plugged into a power supply. Unplug it
before moving it.
3/8" PAN HEAD SCREW
(6 used in this step)
WARNING
