Manhattan 702911 User manual

MAN-702911-UM-0706-01
HI-SPEED USB 2.0
8-IN-1 2.5"
EXTERNAL ENCLOSURE
WITH CARD READER
USER MANUAL
MODEL 702911
702911_man.dlrev4C2.indd 1 8/1/06 4:33:32 PM

Congratulations on purchasing the MANHATTAN® Hi-Speed USB 2.0 8-in-1 2.5" External Enclo-
sure with Card Reader, Model 702911. This device will let you quickly and easily transfer, share
and archive data, and expand storage capacities for desktop and notebook PCs. Plus, the bat-
tery-power feature allows photo download anywhere to keep your digital cameras ready for use.
Among the external enclosure’s main features:
• Supports Hi-Speed USB 2.0 data transfer rates of up to 480 Mbps
• Reads eight popular flash memory card formats with convenient one-touch copy function
(adapter needed for some formats)
• Lightweight, compact design and optional battery power increase portability
• Sturdy aluminum case protects drive and facilitates cooling
• Fits standard 2.5” PATA (IDE) drives with easy, quick installation
• Windows compatible, Plug and Play, hot swappable
• Lifetime Warranty
Package contents:
• External Enclosure with CD Driver and 8-in-1 Card Reader
• USB cable, A-type male to mini-B male, 4 ft. (1.2 m)
• Battery power adapter with cable (4 AA batteries required; not included)
• Travel case with snap closure and storage pockets
• User manual
702911_man.dlrev4C2.indd 2 8/1/06 4:33:33 PM

SETTING UP THE EXTERNAL ENCLOSURE
NOTE: Before making connections to the external enclosure, format the IDE drive to be used in
the enclosure to FAT32. To partition the hard disk drive, format the drive as a "Primary partition"
with FAT32; you can then use the one-touch copy feature. If desired, format the other partitions as
"Extended partition" or "Logical partition" using NTFS or FAT32.
If your hard disk drive is larger than 32 Gb, it’s necessary to partition the drive to less than 32
Gb. You can then format the IDE drive to FAT32.
It’s recommended that you create a copy of your original data to prevent the possibility of data
loss should a mistake be made during the setup procedure. MANHATTAN accepts no
responsibility for lost data.
702911_man.dlrev4C2.indd 3 8/1/06 4:33:33 PM

USB 2.0 Windows 98SE Installation: Place the installation CD in the CD-ROM and connect the
external enclosure to your computer. Auto Detect will run the Add New Hardware wizard, which
searches for new drivers for the USB 2.0 external enclosure. Click "Next."
Select "Search for the best driver for your device (recommended)"; then click "Next."
Select "Specify location," then browse to "CD-ROM E:\UR250\Win98 driver\wind98drv." Click
"Next."
With the prompt "Windows driver file search for the device VIA USB Memory Card Reader
E:\UR250\Win98 driver\wind98drv," click "Next."
With the prompt "Windows has finished installing the software that your new hardware device
1. Remove the tray
from the enclosure.
2. Carefully connect the
interface to the hard disk
drive.
3. Use the screws to
secure the hard
disk drive.
4. Insert the hard disk
drive back into the
enclosure and attach
the back cover with
the screws.
702911_man.dlrev4C2.indd 4 8/1/06 4:33:34 PM

requires," click "Finish."
Installation is complete; just restart your computer.
NOTE: For Windows Me/2000/XP, there is no need to install the additional driver: It’s already
installed. Windows XP needs to be updated with SP2.
Show Icon Tool Installation: Put the installation CD in the CD-ROM and connect the external
enclosure to your computer. Click "CD-ROM disk driver," then click the "UR250\Show icon tool\
SETUP.EXE" icon.
With the prompt "VIA USB Peripheral Setup Program Wizard," click "Next."
With the prompt "VIA SOFTWARE LICENSE AGREEMENT," select "I agree" and click "Next."
With the prompt "VIA-P Set Icon Utility 1.10," click "Next."
Click "Next" to begin the setup.
Click "Next."
Click "Finish."
Installation is now complete. You’ll see gray icons for SD/MMC and MS/MS PRO: Inserting a
flash memory card turns the icons to color.
702911_man.dlrev4C2.indd 5 8/1/06 4:33:34 PM
