OPERATOR MANUAL
This Manual is divided into the following sections:
SECTION 1 INTRODUCTION
SECTION 2 SAFETY INFORMATION
SECTION 3 OPERATING CONTROLS AND PROCEDURES
SECTION 4 SET-UP AND INSTALLATION
SECTION 5 LUBRICATION
SECTION 6 MAINTENANCE CHECKLIST
NOTICE
The serial number of the crane and applicable attachments (i.e. luffing jib, MAX-ER®) is
the only method your Manitowoc distributor or Manitowoc Crane Care has of providing
you with correct parts and service information.
The serial number is located on a crane identification plate attached to the operator’s
cab and each attachment. Refer to the Nameplate and Decal Assembly Drawing in
Section 2 of this manual for the exact location of the crane identification plate.
Always furnish serial number of crane and its attachments when ordering parts or
discussing service problems with your Manitowoc distributor or Manitowoc Crane Care.
To prevent death or serious injury:
•Avoid unsafe operation and maintenance.
Crane and attachments must be operated and maintained by trained and
experienced personnel. Manitowoc is not responsible for qualifying these
personnel.
•Do not operate or work on crane or attachments without first reading and
understanding instructions contained in Operator Information Manual and
Service Manual supplied with crane and applicable attachments.
•Store Operator Information Manual and Service Manual in operator’s cab.
If Operator Information Manual or Service Manual is missing from cab,
contact your Manitowoc distributor for a new one.
WARNING
1
2
3
4
5
6
This manual has been prepared for and is considered part of -
2250
Crane Model Number
2251000
Crane Serial Number

Reference Only

Reference Only
Manitowoc Published: 01-18-13, Control # 039-14_v6 TOC-i
2250 OPERATOR’S MANUAL TABLE OF CONTENTS
SECTION 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Introduction
Crane Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Crane/Attachment Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Change of Ownership Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Crane Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Identification and Location of Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Outline Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Crane Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
English and Metric Conversions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Manitowoc Dealer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
SECTION 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Safety Information
Continuous innovation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Nameplates and Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Safety Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Safety and Information Signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Crane Access Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Getting On or Off Crane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Operator’s Manual/Capacity Chart Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Safe Operating Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Safety Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Operational Aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Assembling, Disassembling, or Operating Crane Near Electric Power and Transmission Lines . . . . . 2-16
Refueling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Fire Extinguishers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Accidents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Safe Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Environmental ProtectioN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Boom Disassembly Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Personnel Handling Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Pedestal/barge Mounted Cranes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
SECTION 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . Operating Controls And Procedures
Standard Hand Signals for Controlling Crane Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Symbol Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Front Window Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Controls Identification and Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Limit Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-28
Seat Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
Preparing Crane For Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-33
Stopping Engine / Leaving Crane Unattended . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-42
Special Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
Remote Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
Programmable Controller Calibration Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-62
Digital Display Readings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
Diagnostic Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-71
Engine Diagnostics (Cummins QSX15 Engine) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-78
Drum Interlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-79
Swing Speed/Torque Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-82
Swing Limiter Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-82
Swing Drive Disconnect Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-87
Pile Driving System Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-88
Wind Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-91
Cold Weather Heater Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-92

Reference Only
TOC-ii Published: 01-18-13, Control # 039-14_v6
TABLE OF CONTENTS 2250 OPERATOR’S MANUAL
Preparation for Cold Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-95
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-96
SECTION 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Set-Up And Installation
Rigging Drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Optional Attachments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
General Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Crane Orientation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
FACT™ Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Assembly and Disassembly Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Assist Crane Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Assembly and Disassembly Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Accessing Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Crane Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Retaining Connecting Pins. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Miscellaneous Loose Parts Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Shipping Crane Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Component Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Special Blocking Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Under Carriage Lubrication at Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Crane Assembly — Without Self-Erect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Disassembly — Without Self-Erect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Tapered Mounting Pin Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Elevated Cab Assembly - 35 ft Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Drum Spacer/Lagging Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Counterweight Installation And Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
Counterweight Installation and Removal — with Auxiliary Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
Gantry Raising And Lowering — Without Boom Butt Handling Cylinder . . . . . . . . . . . . . . . . . . . . . . . . 4-46
Drum 5 Installation and Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-53
Boom Ladder Assembly — with #44 Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-55
Boom Rigging Guide — #44 HL and LR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-55
Lower Boom Point Sheaves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-77
Extended Upper Boom Point Rigging Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-79
Boom Handling — with Intermediate Gantry Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-85
Jib Installation — #132 Jib. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-87
Jib Removal — #132 Jib . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-93
Wire Rope Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-96
Pad Eye Usage for Wire Rope Reeving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-101
Load Line Reeving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-103
Universal Anchor Joint. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-115
Load Block Tieback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-116
SECTION 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Lubrication
Lubrication Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Lube and Coolant Product Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
SECTION 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Maintenance Checklist
Inspection and Maintenance Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Fiberglass Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-i
1
SECTION 1
INTRODUCTION
TABLE OF CONTENTS
Crane Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Crane/Attachment Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Change of Ownership Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Crane Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Identification and Location of Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Current Tier 3 Production . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Current Tier 4 Production . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Outline Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Standard Crane (Series 3 Counterweight Arrangement Shown) . . . . . . . . . . . . . . . 1-6
35 Foot Elevated Cab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Crane Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
English and Metric Conversions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Direct Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Inverse Conversion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-11
Manitowoc Dealer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12

Reference Only

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-1
2250 OPERATOR’S MANUAL INTRODUCTION
1
SECTION 1
INTRODUCTION
CRANE DATA
See the end of this section for crane data specific to your
crane:
•Basic Specifications.
•EC Declaration (if applicable).
CRANE/ATTACHMENT IDENTIFICATION
An identification plate is attached to the outside of the
operator’s cab (see Figure 1-1) and to the attachments (i.e.
luffing jibs, MAX-ER’s, and Ringers) available for this crane.
The crane or attachment model, application, and serial
number are provided on the plate.
For the exact location of the identification plates on your
crane and attachments, see the Nameplates and Decals
Drawing in Section 2 of this manual.
CHANGE OF OWNERSHIP REGISTRATION
A new owner of a Manitowoc crane should register the crane
with Manitowoc Crane Care so we can contact you if the
need arises. To register your crane:
1. Go to
www.manitowoccranes.com/en/services/crane-
care/service-and-tech-support/Change-of-
Ownership-Form
2. Complete the form.
CRANE ORIENTATION
The terms RIGHT, LEFT, FRONT, REAR used in this manual
see operator’s right, left, front, and rear sides when seated in
the operator’s cab looking forward.
•The boom is on the front of the rotating bed.
•The crawler drive shafts are at the rear of the crawlers
and carbody.
FIGURE 1-1
Serial
Number
Model
Number
Current Production
Past Production
Serial
Number
Model
Number
Application:
LIFT = Liftcrane
CLAM = Clamshell
DRAG = Dragline

Reference Only
INTRODUCTION 2250 OPERATOR’S MANUAL
1-2 Published 01-18-13, Control # 039-14
IDENTIFICATION AND LOCATION OF COMPONENTS
A1048
19
2
4
5(both ends)
1
18
21
22
9
13
12 14
11
3
77
15 16
6(both ends)
810
20
17
Item Description
1 Boom, #44 Heavy Lift
2 Cab, Operator’s
3 Cylinder, Boom Butt Handling
4 Adapter, Rotating Frame
5 Counterweight, Carbody (both ends)
6 Step (both ends)
7 Cylinders, Jacking
8 Carbody (undercarriage)
9 Crawler (both sides)
10 Bed, Rotating
11 Counterweight, Upper
12 Backhitch, Gantry (telescopic)
13 Gantry
14 Boom Stop, Air Cushioned Physical
15 Equalizer
16 Guide, Wire Rope (boom butt)
17 Straps, Boom
18 Guide, Wire Rope (boom top)
19 Boom Point, Upper
20 Boom Point, Lower
21 Ball, Weight
22 Block, Load
23 Jib, Fixed
24 Stop, Jib
25 Strut, Jib
26 Pendant, Backstay
27 Pendant, Jib
28 Point, Jib
25
28
21
23
24
26
27

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-3
2250 OPERATOR’S MANUAL INTRODUCTION
1
A468
13
9
8
12
Item Description
1 Motor, Left Swing (optional)
2 Motor, Right Swing
3 Drum, Luffing Hoist
4 Swivel
5 Motor, Load Drum(s)
6 Drum, Right Rear Load
7Engine
8 Drive, Right Crawler
9 Drum, Boom Hoist
10 Drive, Right Crawler
11 Pumps, Pump Drive and System
12 Drum, Left Rear Load
13 Drum, Front Load
14 Cab, Operator’s
15 Cylinder, Gantry Backhitch (air)
16 Boom Hoist
17 Gantry
18 Backhitch, Gantry (telescopic)
19 Link, Counterweight Handling
20 Cylinder, Boom Hoist Pawl (air)
21 Cylinder, Gantry Lifting (hydraulic)
22 Cylinders, Counterweight Connecting Pin (air)
Rear View with Upper Counterweight Removed
Upper Counterweight Attached to Crane with Items 22
20
21
22
19
21
1615 15 P892
18
17
19
1
3
5
6
14 4
7
2
11
10

Reference Only
INTRODUCTION 2250 OPERATOR’S MANUAL
1-4 Published 01-18-13, Control # 039-14
Current Tier 3 Production
Item1 Description
1 Engine Cooler (under covers)
2 Muffler
3 Exhaust
4 Air Cleaner
5 Coolant Reservoir
6 Fuel Fill
7 Hydraulic Reservoir
2
1
3
5
6
2
Left Side of
Crane RightSideof
Crane
7
7
1
4

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-5
2250 OPERATOR’S MANUAL INTRODUCTION
1
Current Tier 4 Production
Item1 Description
1 Engine Cooler (under grating)
2 Diesel Particulate Filter (DPF)
3 Exhaust
4 Air Cleaner
5 Coolant Surge Tank
6 Fuel Fill
7 Hydraulic Reservoir
8 Engine Cooler Surge Tank
1
2
3
4
3
8
7
6
7
5
1
Left Side of
Crane
1
RightSideof
Crane
View from Top Left of Crane to
the Right Rear
View from Right Underside of
Engine Cooler

Reference Only
INTRODUCTION 2250 OPERATOR’S MANUAL
1-6 Published 01-18-13, Control # 039-14
OUTLINE DIMENSIONS
Standard Crane (Series 3 Counterweight Arrangement Shown)
3 ft
0,91 m
Rotation
Rotation
35 ft -9 in
10,89 m
2 ft -7 1/2 in
0,80 m
17 ft -2 in
5,23 m
37 ft 2 1/2 in
11,34 m
16 ft -6 in
5,03 m
11 ft -11 1/2 in
3.64 m
8 ft
2,44 m
2 ft -5 in
0,73 m
15 ft-3 in
4,65 m 6ft,6in
1,98 m
30 ft -9 in
9,37 m
42 ft -4 in
12,90 m
23 ft 6 in
7,16 m
23 ft 9 1/2 in
7,25 m
Tailswing
11 ft -11 in
3,63 m 7 ft -10 in
2,40 m 4 ft -2 in
1,27 m
Without Counterweights
32 ft - 9 in
9,98 m
With 4 ft Crawlers
With 5 ft Crawlers (Optional)
27 ft
8,23 m
7,91 m
5 ft
1,52 m
(Optional)
4 ft
1,22 m
10 in
0,26 m
23 ft
7,01 m
3 ft-8 1/2 in
1,12 m
25 ft -11 1/2 in

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-7
2250 OPERATOR’S MANUAL INTRODUCTION
1
35 Foot Elevated Cab
Underside
Turntable
Bearing
3 ft -11 in
1,19 m
34 ft -7 in
10,55 m
38 ft - 6 in
11,73 m
16 ft 6 in
5,03 m
3 ft
0,91 m
32 ft -9 in
9,98 m
Without Counterweights
4 ft - 2 in
1,27 m
7 ft -10 in
2,40 m
11 ft -11 in
3,63 m
23 ft -9 1/2 in
7,25 m
Tailswing
23 ft -6 in
7,16 m
42 ft -4 in
12,90 m
30 ft -9 in
9,37 m
6 ft -6 in
1,98 m
15 ft -3 in
4,65 m 2 ft - 5 in
0,73 m
8 ft
2,44 m
37 ft 2 1/2 in
11,34 m
17 ft -2 in
5,23 m
2 ft -7 1/2 in
0,80 m
35 ft -9 in
10,89 m

Reference Only
INTRODUCTION 2250 OPERATOR’S MANUAL
1-8 Published 01-18-13, Control # 039-14
CRANE WEIGHTS
NOTE: Weights may fluctuate ±3% due to manufacturing
tolerances
Description Weight
Pounds Kilograms
LIFTCRANE:
Rotating bed and under carriage complete, counterweight, gantry, backhitch, fully rigged 70 ft
(21,3 m) boom No. 44 with one piece butt and heavy lift top (including upper boom point, 300 USt
(272 t) block, and 15 USt (14 t) hook and weight ball), boom stops and load lines
2250 SERIES 1 - - - - - - - - - - - - - - - - - - 449,615 203 941
2250 SERIES 2 - - - - - - - - - - - - - - - - - - 549,740 249 357
2250 SERIES 3 - - - - - - - - - - - - - - - - - - 649,740 294 717
2250 SERIES 1 with RINGER prep - - - - - - - - 461,340 209 260
2250 SERIES 2 with RINGER prep - - - - - - - - 561,465 254 676
2250 SERIES 3 with RINGER prep - - - - - - - 661,465 300 035
ROTATING BED MACHINERY MODULE:
Rotating bed rear section, split rear drums with load lines, rotating bed pin pullers, boom hoist,
gantry, gantry lifting cylinders, equalizer, boom hoist line, operator’s cab, Cummins power plant,
hydraulic reservoir (full), and fuel tank (1/2 full) - - - - - - - - - - - - - - - - - - - - - - - - 77,695 35 241
With RINGER prep - - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 83,930 38 070
ROTATING MODULE WITH CARBODY:
Rotating bed front section with bearing turntable, swing drive, carbody with pin pullers, rotating
union, piping and installation, 40 ft (12,2 m) boom butt and boom stops - - - - - - - - - - - - 69,465 31 508
With RINGER prep - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 74,955 33 999
Replace 40 ft (12,2 m) butt and boom stops with 12 ft 3,7 m) lower 2 piece butt - - - - - - - - 63,475 28 791
CRAWLERS:
30 ft 9 in (9 373 mm) crawler assembly with 48 in (1 219 mm) treads (each) - - - - - - - - - 53,820 24 412
COUNTERWEIGHT - UPPER:
Tray - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38,775 17 588
Lifting frame (each) 2 required - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 170 77
Center counterweight - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 37,000 16 782
Lower side counterweight (6 on all SERIES) (each) - - - - - - - - - - - - - - - - - - - - - 15,500 7 030
Upper side counterweight (2 on SERIES 2; 4 on SERIES 3) (each) - - - - - - - - - - - - - - 20,000 9 071
Upper power pin with cylinder (each) - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 30 13
Lower power pin with cylinder (each) - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 20 9
Center couterweight lifting pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - 20 9
Total rotating bed counterweight - - - - -2250 SERIES 1 - - - - - - - - - - - - - - - - - 169,200 76 747
2250 SERIES 2 - - - - - - - - - - - - - - - - 209,200 94 891
2250 SERIES 3 - - - - - - - - - - - - - - - - 249,200 113 035
COUNTERWEIGHT - LOWER:
Carbody center counterweight (2 on SERIES 2 and SERIES 3) (each) - - - - - - - - - - - - 30,000 13 607
Carbody side counterweight (4 only on SERIES 3) (each)- - - - - - - - - - - - - - - - - - - 15,000 6 803
GANTRY:
28 ft 0 in (8 534 mm) gantry with polyamide sheaves - - - - - - - - - - - - - - - - - - - - - 11,330 5 139
Backhitch (each leg) - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 1,585 718
Counterweight handling link (each) - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 90 40

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-9
2250 OPERATOR’S MANUAL INTRODUCTION
1
BOOM NO. 44:
40 ft 0 in (12,2 m) butt - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 8,605 3 903
30 ft 0 in (9,1 m) top (with lower point, wire rope guide) - - - - - - - - - - - - - - - - - - - - 11,625 5 273
10 ft 0 in (3,0 m) insert - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,890 857
20 ft 0 in (6,1 m) insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3,215 1 458
40 ft 0 in (12,2 m) light insert - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4,250 1 927
40 ft 0 in (12,2 m) insert - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 5,420 2 458
31 ft 1-3/16 in (9,5 m) basic strap (each) -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 425 192
10 ft 0 in (3,0 m) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - - 175 79
20 ft 0 in (6,1 m) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - - 295 133
40 ft 0 in (12,2 m) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - 540 244
3 ft 4-3/8 in (1,0 m) strap (with connector links) (each) - - - - - - - - - - - - - - - - - - - - - 80 36
Intermediate suspension link (each) - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 65 29
47 ft 6 in (14,5 m) intermediate suspension pendant (each) - - - - - - - - - - - - - - - - - - 240 108
29 ft 5 in (9,0 m) intermediate suspension pendant (each) - - - - - - - - - - - - - - - - - - - 175 79
9 ft 9 in (3,0 m) intermediate suspension pendant (each) - - - - - - - - - - - - - - - - - - - - 105 47
Lower intermediate suspension link with pin (each) - - - - - - - - - - - - - - - - - - - - - - 60 27
Upper boom point (single sheave) - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 930 421
Wire rope guide (on butt) - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 2,090 948
Equalizer - - - - - - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,810 821
Strap link (attached to equalizer) (each) 4 required - - - - - - - - - - - - - - - - - - - - - - - 25 11
Boom stop (each tube) - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 825 374
NO. 132 JIB:
20 ft 0 in (6,1 m) butt - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,020 462
20 ft 0 in (6,1 m) top (with jib point sheaves) - - - - - - - - - - - - - - - - - - - - - - - - - 1,885 855
20 ft 0 in (6,1 m) insert - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 800 362
40 ft 0 in (12,2 m) basic pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 175 79
19 ft 2 in (5,8 m) pendant (each) - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 115 52
Jib stop pendant and link (each) - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 35 15
Jib stop strut and additional pendants (used with long reach boom top) - - - - - - - - - - - - 85 38
20 ft 0 in (6,1 m) strut with sheave and links - - - - - - - - - - - - - - - - - - - - - - - - - - 1,360 616
65 ft 7 in (20,0 m) backstay pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - 240 108
7 ft 4 in (2,2 m) backstay pendant (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - 80 36
Backstay link (each) - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 65 29
Backstay spreader - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 285 129
MACHINE OPTIONS:
35 ft (10,7 m) elevated operator’s cab (increase over standard operator’s cab)- - - - - - - - - - 4,370 1 982
35 ft (10,7 m) elevated operator’s cab with 52 in (1 321 mm) wide cab
(increase over standard operator’s cab)- - - - - - - - - - - - - - - - - - - - - - - - - - - 7,390 3 352
45 in (1 143 mm) wide front drum assembly - - - - - - - - - - - - - - - - - - - - - - - - - - 6,190 2 807
73 in (1 854 mm) wider RINGER drum assembly (each) - - - - - - - - - - - - - - - - - - - - 7,310 3 315
Gear case assembly for tandem drums (increase over standard) - - - - - - - - - - - - - - - - 275 124
Luffing jib hoist assembly - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 3,065 1 390
2nd swing drive assembly - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,790 811
Supplemental hydraulic reservoir for RINGER - - - - - - - - - - - - - - - - - - - - - - - - - 300 136
Boom hinge pin pullers - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 395 179
RINGER attachment lugs on carbody -- - - - - - - - - - - - - - - - - - - - - - - - - - - - 3,700 1 678
24-1/2 in (622 mm) Diameter lagging for 45 in (1 143 mm) wide front or right rear drum - - - - - 1,020 462
24-1/2 in (622 mm) Diameter lagging for narrow left rear drum - - - - - - - - - - - - - - - - - 425 192
24-1/2 in (622 mm) Diameter lagging for 73 in (1 854 mm) wide RINGER drum (each) - - - - - 1,800 816
Description Weight
Pounds Kilograms

Reference Only
INTRODUCTION 2250 OPERATOR’S MANUAL
1-10 Published 01-18-13, Control # 039-14
BOOM NO. 44 OPTIONS:
30 ft (9,1 m) tapered insert (with wire rope guide) - - - - - - - - - - - - - - - - - - - - - - 4,065 1 843
40 ft (12,2 m) long reach top (with lower point) - - - - - - - - - - - - - - - - - - - - - - - 6,705 3 041
Rigging winch in butt - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 820 371
300 USt (272 t) load block with swivel hook- - - - - - - - - - - - - - - - - - - - - - - - - - 8,000 3 628
100 USt (91 t) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - 4,800 2 177
60 USt (55 t) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - 2,825 1 281
60 USt (55 t) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - 4,425 2 007
15 USt (14 t) hook and weight ball (swivel) - - - - - - - - - - - - - - - - - - - - - - - - - - 1,250 566
SELF-ERECT OPTIONS:
Rotating bed jacking system with pads -- - - - - - - - - - - - - - - - - - - - - - - - - - - 7,325 3 322
Carbody support pedestals - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 400 181
Crawler handling arrangement - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 430 195
12 ft (3,7 m) lower 2 piece butt - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 4,265 1 934
28 ft (8,5 m) upper 2 piece butt with wire rope guide - - - - - - - - - - - - - - - - - - - - - 7,395 3 354
Butt raising cylinder and installation - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 875 396
Assemble and rigging rope guides in butt - - - - - - - - - - - - - - - - - - - - - - - - - - 2,095 950
30 USt (27 t) load block with weight plates - - - - - - - - - - - - - - - - - - - - - - - - - 2,000 907
Rigging line - 160 ft (49 m) of 1-1/8 in (28,6 mm) wire rope 2.34 lb per ft (3,48 kg/m) - - - - - 375 170
Rigging winch line - 800 ft (244 m) of 3/8 in (9,5 mm) wire rope 0.26 lb per ft (0,39 kg/m) - - - 210 95
WIRE ROPE:
Boom hoist - 975 ft (297 m) of 1 in (26 mm) wire rope - 1.85 lb per ft (2.75 kg/m)- - - - - - - - 1,805 818
Load lines
1-1/8 in (28,6 mm) wire rope - 2.70 lb per ft- - - - - - - - - - - - - - - - - - - - - - - - - - 5,535 2 510
Whip line - 1,270 ft (387 m) with heavy lift top - - - - - - - - - - - - - - - - - - - - - - - - 3,430 1 555
Whip line - 1,325 ft (404 m) with long reach top - - - - - - - - - - - - - - - - - - - - - - - 3,580 1 623
29 mm wire rope - 2.85 lb per ft (4.25 kg/m)
Hoist line - 2,050 ft (625 m) - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - 5,845 2 651
Whip line - 1,270 ft (387 m) with heavy lift top - - - - - - - - - - - - - - - - - - - - - - - - 3,620 1 642
Whip line - 1,325 ft (404 m) with long reach top - - - - - - - - - - - - - - - - - - - - - - - 3,775 1 712
Description Weight
Pounds Kilograms

Reference Only
Manitowoc Published 01-18-13, Control # 039-14 1-11
2250 OPERATOR’S MANUAL INTRODUCTION
1
ENGLISH AND METRIC CONVERSIONS
Direct Conversion
MULTIPLY (x) known value by conversion factor to obtain
equivalent value in desired units. For example, 12 ft is
converted to meters (m), as follows:
12 ft x 0.3048 = 3,6576 m
Inverse Conversion
DIVIDE (÷) known value by conversion factor to obtain
equivalent value in desired units. For example, 3,6576 m is
converted to feet, as follows:
3,6576 m ÷0.3048 = 12
To Convert Symbol Application To Symbol Multiply By
AREA
Square Inch in2Filter Area
Clutch Contact Square Centimeter cm26.4516
Square Foot ft2Ground Contact Square Meter m20.0929
FORCE
Pound Force lb Pedal Effort KiloNewton
Newton kN N0.00445 4.4482
Pound Force lb Line Pull KiloNewton kN 0.00445
Pound Force Per Inch lb/in. Spring Force Newton per millimeter Nmm 0.1751
Pound Force Per Foot lb/ft Newton per meter Nm 14.5939
LENGTH
Inch in. Adjustments Millimeter mm 25.4000
Foot ft Outline Dimensions Meter m 0.3048
Mile miles Travel Distance Kilometer km 1.6093
POWER
Horsepower hp Engine Kilowatt kW 0.7457
PRESSURE
Pound/Sq. In. psi Hydraulic & Air Bar 0.0689
TEMPERATURE
Degrees Fahrenheit °FOil, Air, Etc. Degrees Centigrade °C°F - 32 ÷ 1.8
Degrees Centigrade °CDegrees Fahrenheit °F°C x 1.8 + 32
TORQUE
Inch Pound in lb Bolt Torque Newton Meter Nm 0.1129
Foot Pound ft lb Newton Meter Nm 1.3558
VELOCITY
Miles Per Hour mph Vehicle Speed Kilometers Per Hour km/h 1.6093
Miles Per Hour mph Wind Speed Meters Per Second m/s 0.4470
Feet Per Minute fpm Line Speed Meters Per Minute m/min 0.3048
VOLUME
Cubic Yard yd3Bucket Capacity Cubic Meter m30.7646
Cubic Foot ft3Cubic Meter m30.0283
Cubic Inch in3Pump Displacement Cubic Centimeter cm316.3871

Reference Only
INTRODUCTION 2250 OPERATOR’S MANUAL
1-12 Published 01-18-13, Control # 039-14
MANITOWOC DEALER
For questions about this manual or your 2250 crane and
attachments, contact a Manitowoc dealer. Before calling,
find the model and serial number of the crane or attachment.
This information is located on the identification plate on the
crane cab or attachment.
To locate the Manitowoc dealer nearest to you:
1. Go to
www.manitowoccranes.com/en/our-company/
dealers
2. Follow the on-screen prompts to locate your Manitowoc
dealer.
VOLUME (LIQUID)
Ounce oz
Fluid Capacities
Milliliter mL 29.5735
Pint pt Liter L 0.4732
Quart qt Liter L 0.9464
Gallon gal Liter L 3.7854
Gallon Per Minute gpm Pump Flow Liters Per Minute L/min 3.7854
WEIGHT
Pound lb Unit/Component Kilogram kg 0.4536
US Ton (2000 lb) USt Load Ratings Metric Ton t 0.9072
US Ton (2000 lb) USt Kilogram kg 907.1847
To Convert Symbol Application To Symbol Multiply By
