Features
ř80 t (90 USt)capacity
ř11,4m –43,2m (38 ft –142 ft)five-section,
full power boom
ř10 m –17 m (33 ft –56 ft)osettable bi-fold
lattice, swingaway extension
ř4,8m (16 ft)or 9,7m (32 ft)extension
inserts
řGrove MEGAFORM™ boom
ř9979 kg (22,000 lb)counterweight
hydraulically installed and removed
Grove RT890E
Product Guide

Features
Cab
The Full Vision cab on
the RT890E tilts up to
20˚providing the operator
additional comfort when
working at long boom and
extension lengths.
Boom
e RT890E is equipped with a 11,4 m - 43,2 m (38 ft - 142 ft)
ve-section, full power boom. e Grove MEGAFORM™ boom
shape eliminates weight and increases capacity compared to
conventional shapes.
Removable counterweight
Counterweight and auxiliary hoist is
hydraulically removed/installed for easier
hauling from job to job.
Power lung extension
For improved up-and-over reach, a power lung
extension is available on the RT890E and
hydraulically osets from the super-structure cab
from 50to 400.
CraneSTAR is an exclusive and innovative crane asset
management system that helps improve your profitability
and reduce costs by remotely monitoring critical crane data.
Visit www.cranestar.com for more information.

Contents
Features 2
Specifications 4
Dimensions and weights 7
Working range 8
Mode A vs. (Mode B)9
Load chart (Mode B)10
Load chart fixed osettable swingaway 11
Working range with one 16 ft insert 12
Working range with two 16 ft inserts 13
Load charts fixed osettable
swingaway with inserts 14
Load charts (Mode A)15
Lung extension charts 17
Load handling 21

4
Specifications
Load moment
and anti-two block system
Standard “Graphic Display” load moment and anti-two
block system with audio-visual warning and control
lever lockout. These systems provide electronic display
of boom angle, length, radius, tip height, relative load
moment, maximum permissible load, load indication
and warning of impending two-block condition. The
standard Work Area Definition System allows the
operator to pre-select and define safe working areas.
If the crane approaches the pre-set limits, audio-visual
warnings aid the operator in avoiding job-site
obstructions.
Cab
20° tilt, Full-vision, all-steel fabricated with acoustical
lining and tinted safety glass throughout. Deluxe seat
incorporates armrest-mounted hydraulic single-axis
controllers. Tilt/telescoping steering wheel with various
controls incorporated into the steering column.
Other standard features include:, hot water heater,
cab circulating air fan, sliding side and rear windows,
sliding skylight with electric wiper and sunscreen,
electric windshield wash/wipe, fire extinguisher, seat
belt, air conditioning, and dual cab mounted work
lights.
Swing
Two speed, planetary swing drive with foot applied
multi-disc wet brake. Spring applied, hydraulically
released swing brake. Single position mechanical house
lock, operated from cab. Maximum speed: 2.0 rpm.
Counterweight
9979 kg (22,000 lb). Hydraulically installed and
removed.
Superstructure (continued)
Superstructure
Boom
11,4 m – 43,2 m (38 ft – 142 ft) five-section, sequenced
synchronized full power boom with A and B mode.
Maximum tip height: 45,7 m (150 ft).
*Optional lattice extension
10 m – 17 m (33 ft – 56 ft) offsettable bi-fold lattice
swingaway extension. Offsets 0°, 20° and 40°. Stows
alongside base boom section.
Maximum tip height: 62,7 m (206 ft).
*Optional lattice extension
10 m – 17 m (33 ft – 56 ft) hydraulically offsettable
bi-fold lattice swingaway extension. Offsets from 0° to
40°. Stows alongside base boom section.
Maximum tip height: 62,7 m (206 ft).
*Optional lattice extension inserts
(2) x 4,8 m (16 ft) lattice extension inserts. Installs
between the boom nose and bi-fold extension,
non-stowable.
Maximum tip height: 72,5 m (238 ft)
Boom nose
Five nylatron sheaves mounted on heavy duty tapered
roller bearings with removable pin-type rope guards.
Quick reeving type boom nose. Removable auxiliary
boom nose with removable pin type rope guard.
Boom elevation
One double acting hydraulic cylinder with integral
holding valve provides elevation from -3° to +78°.
*Denotes optional equipment

5Grove RT890E
Specifications
Superstructure (continued)
Hoist specifications (HP30-19G)
main and auxiliary hoist
Planetary reduction with automatic spring applied
multi-disc wet brake. Electronic hoist drum rotation
indicators, and hoist drum cable followers.
Maximum single line pull:
1st layer: 9185 kg (20,250 lb)
3rd layer: 7715 kg (17,010 lb)
5th layer: 6650 kg (14,660 lb)
Maximum permissible line pull:
7620 kg (16,800 lb) with 6x37 class rope
7620 kg (16,800 lb) with 35x7 class rope
Maximum single line speed: 156 m/min (514 fpm)
Rope construction:
6x36 EIPS IWRC, special flexible
35x7 Flex-X, rotation resistant
Rope diameter: 19 mm (3/4 in)
Rope length:
Main hoist: 182 m (600 ft)
Auxiliary hoist: 182 m (600 ft)
Maximum rope stowage: 256 m (841 ft)
Carrier
Chassis
Box section frame fabricated from high-strength, low
alloy steel. Front/rear towing and tie down lugs.
Outrigger system
Four hydraulic telescoping single-stage double box
beam outriggers with inverted jacks and integral
holding valves. Three position setting, 0%, 50% and
fully extended. Outrigger monitoring comes standard.
All steel fabricated, quick release type outrigger floats,
775 mm (30.5 in) diameter.
Maximum outrigger pad load: 56 700 kg (125,000 lb).
Hydraulic system
Two main pumps ([1] piston and [1] gear) with a
combined capacity of 503 LPM (133 GPM).
Maximum operating pressure: 277.7 bar (4000 psi).
Three section pressure compensated valve bank.
Return line type filter with full flow by-pass protection
and service indicator. Replaceable cartridge with
micron filtration rating of 5/12/16. 959 L (253
gallon) hyd. reservoir. Carrier mounted oil cooler with
thermostatically controlled hydraulic motor driven
fan/air to oil. System pressure test ports.
Outrigger controls
Controls and crane level indicator located in cab.
Engine (Tier IV)
Cummins QSB 6.7L diesel, six-cylinder, turbo-charged.
205 kW (275 hp) at 2500 rpm.
Meets emissions per U.S. E.P.A., Tier IV and E.U.
Stage III B.
Maximum torque: 992 Nm (732 ft/lb) at 1500 rpm.
Fuel requirement: Minimum of 15 ppm sulphur
content (Ultra Low Sulphur Diesel Fuel)
Note: Tier IV engine required in North American and
European Union countries.
Engine (Tier III)
Cummins QSB 6.7 L diesel, six cylinders,
turbo-charged, 205 kW (275 bhp) (Gross) at 2500
rpm.
Maximum torque: 987 Nm (728 ft/lb) at 1500 rpm.
Note: Required for sale outside of North American and
European Union countries.
Fuel tank capacity
280 L (74 gal)
Transmission
Full rangeshift with 6 forward and 6 reverse speeds.
Front axle disconnect for 4 x 2 travel.
Electrical system
Three 12 V - maintenance free batteries.
12 V starting and lighting. Battery disconnect.
CanBus Diagnostic system.
*Denotes optional equipment

6
Specifications
Maximum speed
35 km/h (22 mph)
Gradeability (theoretical)
75%
(Based on 52 607 kg [115,976 lb] GVW, 29.5 x
25 tires, 43,2 m [142 ft] boom, plus 17,0 m [56 ft]
swingaway, 22,000 lb counterweight, 80 t [90 USt]
hookblock and 9,1 t [10 USt] headache ball).
Miscellaneous standard equipment
Full width steel fenders, full length aluminum decking,
dual rear view mirrors, hook-block tie down, electronic
back-up alarm, light package, front stowage well, cab
air conditioning, tachometer/hourmeter, rear wheel
position indicator, 36,000 BTU hot water cab heater,
hoist mirrors, engine distress A/V warning system,
front/rear tie down and tow lugs, coolant sight level
indicator, CraneSTAR asset management system.
*Optional equipment
t Auxiliary Lighting and Convenience Package:
includes cab mounted amber flashing light, dual base
boom mounted floodlights. LMI light bar (in cab),
and rubber mat for stowage trough
t /:$TUZMFNFDIBOJDBMTXJOHMPDL
t 3FBS1JOUMFIPPL
t $BCDPOUSPMMFEDSPTTBYMFEJGGFSFOUJBMMPDLTGSPOU
and rear)
t 1"5FWFOUSFDPSEFS
t SEXSBQJOEJDBUPSGPSNBJOBOEPSBVYJMJBSZIPJTUT
t 8JOETQFFEJOEJDBUPSXJSFMFTT
t$&.BSL$POGPSNBODF
t7BMVF1BDLBHF*ODMVEFTGUGUNBOVBMCJGPME
swingaway, 360° swing lock, and auxiliary hoist
package
t"VYJMJBSZ)PJTU1BDLBHF*ODMVEFT)1(
auxiliary hoist with rotation indicator, cable follower,
auxiliary hoist mirror and 185 m (607 ft) of
non-rotational wire rope.
Carrier (continued)
Drive
4 x 4.
Steering
Fully independent power steering:
Front: Full hydraulic steering wheel controlled.
Rear: Full hydraulic switch controlled.
Provides infinite variations of 4 main steering modes:
front only, rear only, crab and coordinated.
Rear steer indicator.
Turning radius: 7,3 m (24 ft)
Axles
Front: Drive/steer with differential and planetary
reduction hubs rigid mounted to frame.
Rear: Drive/steer with differential and planetary
reduction hubs pivot mounted to frame.
Oscillation lockouts
Automatic full hydraulic lockouts on rear axle permits
25,4 cm (10 in) oscillation only with boom centered
over the front.
Brakes
Full hydraulic split circuit operating on all wheels.
Spring-applied, hydraulically released parking brake
mounted on front axle.
Tires
Standard 29.5 x 25 - 34 bias ply, Titan
Lights
Full lighting including turn indicators, head, tail, brake
and hazard warning lights.
*Denotes optional equipment

7Grove RT890E
Dimensions and weights
Dimensions are in mm (inches)
TiresEF
C
B
ADG
29.5X 25 15,7m
(51.5')
16,3m
(5.35')
13,6m
(44.6')
12,9m
(42.3')
12,5m
(41.0')
10,1m
(33.1')
8,8m
(28.9')
ABCDEFG
11,1m
(36.4')
11,6m
(38.1')
8,4m
(27.6')
7,8m
(25.6')
7,3m
(24.0')
4,9m
(16.1')
4,1m
(13.5')
2wheel steer 4wheel steer
269 (10.6)
830 (32.7)
2x 145 (5.7) 2x 290 (11.4) 205 (8.1)
13 924 (548.2)
11 380 (448.0)
1200
(47.2)
5020 (197.6)
3688 (145.2) 2057 (81.0)
4215 (166.0) 8569 (337.4)
3835 (151.0)
24°20°
1816 (71.5)
REF
3782
(149.0)
355 (14.0)
517 (20.4)
Ground line
C
LRotation
Carrier bearing plate
A
C
D
Outside
curb
clearance
A
F
Inside
turn
radius
E
Outside
turn radius
24°R 4596 (180.9)
Tail Swing
B
G
Inside
Curb
Radius
24°
3340
(131.5)
2556 (100.6) Track
3149 (124.0) Retracted
5283 (208.0) Mid-Extend
7315 (288.0) Full extend
Weights
G.V.W.
kg (lb)
Front
kg (lb)
Rear
kg (lb)
Basic Machine including 43,3m (142 ft)main boom, main and aux. hoist with 182,8m
(600 ft)of rope, manual osettable bifold swingaway, full counterweight, 9,1t (10 USt)
headache ball, and 80 t (90 USt)hookblock:
53 178
(117,235)
25 915
(57,131)
27 263
(60,104)
Substitute: Hydraulic offsettable bifold swing-away 53 496
(117,937)
26 394
(58,187)
27 103
(59,750)
Remove: Counterweight and aux. hoist (manual offsettable S/A)43 250
(95,348)
30 657
(67,587)
12 592
(27,761)
Remove: Counterweight and aux. hoist Hyd. offsettable S/A) 43 407
(95,695)
30 930
(68,188)
12 477
(27,507)
Remove: Counterweight, aux. hoist, and either extension 42 227
(93,094)
27 696
(64,058)
13 171
(29,036)

8
Working range
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
141.7ft main boom 32 ft –56 ft fixed offset swingaway
180
190
210
220
200
H [ft]
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
190 170150 130 110 90 70 50
180 160 140 120 100 80 60 40 30 20 10
Height from the ground in feet
Operating radius in feet from axis of rotation
Boom and extension length in feet
56' EXT.
33' EXT.
141.7
128.8
115.8
102.8
89.8
76.7
63.7
50.5
37.3
10' 2.74"
Dimensions are for largest Grove furnished hook block
and headache ball, with anti-two block activated.
Axis of
Rotation
78o
Max.
boom
angle
0oOFFSET
20oOFFSET
40oOFFSET
60o
50o
40o
30o
20o
10o
0o
70o

9Grove RT890E
Mode A vs. Mode B
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Main boom length in feet
37.350.463.476.489.4102.4115.4141.7
Boom sections: Percent extension
Inner-mid 0000000100
Center-mid 050 100 100 100 100 100 100
Outer-mid 00025 50 75 100 100
Fly 00025 50 75 100 100
Mode A – inner-mid retracted
Main boom length in feet
37.350.563.776.789.8102.8115.8128.8141.7
Boom sections: Percent extension
Inner-mid 050 75 75 100 100 100 100 100
Center-mid 0025 75 100 100 100 100 100
Outer-mid 0000025 50 75 100
Fly 0000025 50 75 100
Mode B – normal mode

10
Load charts
(Mode B)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 22,000 lb 100%
24 ft spread 360˚
Feet Main boom length in feet
37.3 50.5 63.7 76.7 89.8102.8 115.8 128.8 141.7
10 180,000
(68.5) 134,000 (75) *97,500 (78)
12 156,000
(65) 134,000 (72.5) 97,500 (76.5)
15 128,500
(59.5) 127,500 (69) 97,500 (74) 69,950 (77) *46,600 (78)
20 98,650
(49.5) 97,600 (62.5) 86,200 (69) 63,600 (73) 46,600 (76.5) *38,700 (78)
25 78,800
(36.5) 77,800 (55.5) 74,850 (64) 55,100 (69) 41,950 (73) 38,700 (75.5) *37,900 (78) *30,850 (78)
30 51,550
(12.5) 58,700 (47.5) 59,300 (58.5) 48,150 (65) 37,350 (69.5) 37,900 (72.5) 35,000 (75) 30,850 (77.5) *24,400 (78)
35 43,250
(38.5) 43,200 (52.5) 42,450 (60.5) 33,300 (66) 33,200 (69.5) 30,950 (72.5) 28,900 (75) 24,400 (77)
40 33,250
(26) 32,850 (46.5) 33,050 (56) 29,850 (62.5) 29,300 (66.5) 27,450 (70) 25,850 (72.5) 24,250 (75)
45 25,650
(39) 26,000 (51) 25,900 (58.5) 25,950 (63.5) 24,450 (67) 23,150 (70) 21,900 (73)
50 20,350
(30.5) 20,750 (45.5) 20,550 (54.5) 21,950 (60) 21,800 (64.5) 20,750 (67.5) 19,800 (70.5)
55 16,200
(16.5) 16,800 (39.5) 16,450 (50) 17,800 (56.5) 19,150 (61.5) 18,650 (65) 17,900 (68.5)
60 13,600
(33) 13,200 (45.5) 14,550 (53) 15,900 (58.5) 16,800 (62.5) 16,150 (66)
65 11,000
(23.5) 10,600 (40.5) 11,900 (49) 13,250 (55.5) 14,200 (60) 14,650 (64)
70 8420
(34.5) 9750 (45) 11,050 (52) 11,950 (57) 12,850 (61.5)
75 6570
(28) 7910 (40.5) 9250 (48.5) 10,100 (54.5) 10,950 (59)
80 4960
(18) 6340 (36) 7670 (45) 8530 (51.5) 9380 (56.5)
85 4990
(30) 6320 (41) 7150 (48.5) 7980 (54)
90 3780
(23) 5140 (37) 5950 (45) 6770 (51)
95 2710
(10) 4100 (32) 4900 (41.5) 5700 (48.5)
100 3160
(26) 3960 (37.5) 4750 (45.5)
105 2310
(18.5) 3130 (33.5) 3910 (42)
110 2370
(28.5) 3150 (38.5)
115 1680
(22.5) 2460 (35)
120 1050
(13) 1840 (30.5)
125 1250
(25.5)
Minimum boom angle (deg)for indicated length (no load)
02
4
Maximum boom length (ft)at 0deg boom angle (no load)128.8
#LMI operating code. Refer to LMI manual for instructions.
*This capacity is based upon maximum obtainable boom angle.
Note: ()Boom angles are in degrees.
Lifting capacities at zero degree boom angle
Boom
angle
Main boom length in feet
37.3 50.5 63.7 76.7 89.8102.8 115.8
0°27,500
(30.1) 15,950 (43.3) 9560 (56.4) 5840 (69.5) 2730 (82.6) 1910 (95.6) 1200 (108.5)
Note: ()Reference radii in feet.A6-829-103321A

11Grove RT890E
Load charts
Bi-fold swingaway (fixed offsettable angles)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 22,000 lb33 ft –56 ft 100%
24 ft spread 360˚
Feet
33 ft LENGTH 56 ft LENGTH
0o
OFFSET
20o
OFFSET
40o
OFFSET
0o
OFFSET
20o
OFFSET
40o
OFFSET
#0021 #0022 #0023 #0041 #0042 #0043
40 13,700
(78)
45 13,700
(76.5)
*13,000
(78)
7160
(78)
50 13,700
(75)
12,950
(77.5)
7160
(77.5)
55 13,700
(73)
12,600
(76)
*10,250
(78)
7160
(76)
60 13,700
(71.5)
12,200
(74)
10,050
(77)
7160
(74.5)
*6400
(78)
65 13,700
(69.5)
11,900
(72.5)
9900
(75)
7160
(73)
6250
(77.5)
70 13,500
(68)
11,550
(70.5)
9750
(73)
7160
(71.5)
6110
(76)
75 12,400
(66)
11,250
(68.5)
9610
(71)
7160
(70)
5980
(74.5)
*5110
(78)
80 10,800
(64)
11,000
(67)
9480
(69)
7160
(68.5)
5850
(73)
5020
(77)
85 9330
(62)
10,250
(65)
9370
(67)
7150
(66.5)
5730
(71.5)
4930
(75)
90 8050
(60)
8900
(63)
8980
(65)
6960
(65)
5620
(69.5)
4850
(73.5)
95 6920
(58)
7700
(61)
8530
(63)
6770
(63.5)
5510
(68)
4780
(71.5)
100 5920
(56)
6630
(59)
7360
(61)
6590
(61.5)
5410
(66)
4710
(69.5)
105 5030
(54)
5690
(56.5)
6310
(58.5)
6030
(60)
5310
(64.5)
4650
(68)
110 4230
(52)
4830
(54.5)
5370
(56.5)
5200
(58)
5220
(62.5)
4600
(66)
115 3510
(49.5)
4060
(52)
4520
(54)
4450
(56.5)
5110
(60.5)
4550
(64)
120 2850
(47.5)
3360
(50)
3750
(51.5)
3770
(54.5)
4780
(59)
4500
(62)
125 2250
(45)
2730
(47.5)
3040
(49)
3150
(52.5)
4080
(57)
4460
(60)
130 1700
(42)
2150
(44.5)
2400
(46)
2580
(50.5)
3450
(55)
3970
(58)
135 1200
(39.5)
1610
(42)
2060
(48.5)
2870
(53)
3330
(55.5)
140 1120
(39)
1570
(46.5)
2330
(50.5)
2730
(53)
145 1130
(44)
1830
(48.5)
2180
(50.5)
150 1370
(46)
1670
(48)
155 1200
(45)
Minimum boom angle
(
o
)for indicated length
(no load)
38 38 40 43 44 44
Maximum boom length
(ft)at 0
o
boom angle
(no load)
102.889.8
NOTE: ()Boom angles are in degrees. A6-829-103447
#LMI operating code. Refer to LMI manual for operating instructions.
*This capacity is based upon maximum boom angle.
NOTES:
1. All capacities above the bold line are based on structural
strength of boom extension and do not exceed 85% of
tipping loads, in accordance with SAE J-765.
2. The 33 ft extension length may be used with single
or double part line lifting service. The 56 ft extension
length may be used for single line lifting service only.
3. For main boom lengths less than 141.7ft with the boom
extension erected, the rated loads are determined by
boom angle. Use only the column which corresponds
to the boom extension length and offset for which the
machine is set up. For boom angles not shown, use
rating of the next lower boom angle.
4. WARNING: Operation of this machine with heavier
loads than the capacities listed is strictly prohibited.
Machine tipping with boom extension occurs rapidly
and without advance warning.
5. Boom angle is the angle above or below horizontal of
the longitudinal axis of the boom base section after
lifting rated load.
6. Capacities listed are with outriggers properly extended
and vertical jacks set only.
7. When lifting over the main boom nose with 33 ft or
56 ft extension erected, the outriggers must be fully
extended or 50% extended (17.3ft spread).

12
Working range
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
141.7ft main boom and one 16 ft insert
180
190
210
220
230
240
200
H [ft]
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
220 200 180 160 140 120 100 80
210 190 170150 130 110 90 70 60 50 40 30 20 10
Height from the ground in feet
Operating radius in feet from axis of rotation
Boom and extension length in feet
10' 2.7"
Dimensions are for largest Grove furnished hook block
and headache ball, with anti-two block activated.
Axis of
rotation
72' EXT.
141.7
128.8
115.8
102.8
89.8
76.7
63.7
50.5
37.3
78o
Max.
boom
angle
0oOFFSET
20oOFFSET
40oOFFSET
60o
50o
40o
30o
20o
10o
0o
70o

13Grove RT890E
Working range
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
141.7ft main boom and two 16 ft inserts
180
190
210
220
230
240
250
200
H [ft]
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
230 210 190 170150 130 110 90
220 200 180 160 140 120 100 80 70 60 50 40 30 20
Height from the ground in feet
Operating radius in feet from axis of rotation
Boom and extension length in feet
10' 2.74"
Dimensions are for largest Grove furnished hook block
and headache ball, with anti-two block activated.
Axis of
rotation
88' EXT.
141.7
128.8
115.8
102.8
89.8
76.7
63.7
50.5
37.3
78
o
Max.
boom
angle
0
o
OFFSET
20
o
OFFSET
40
o
OFFSET
60
o
50
o
40
o
30
o
20
o
10
o
0
o
70
o

14
Load charts
Bi-fold swingaway with inserts (fixed angles)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 1or 216 ft
inserts 22,000 lb33 ft –56 ft 100%
24 ft spread360˚
Feet
72 ft (56 ft LENGTH + 1INSERT) 88 ft (56 ft LENGTH + 2INSERTS)
0°
OFFSET 20° OFFSET 40° OFFSET 0° OFFSET 20° OFFSET 40° OFFSET
#0064 #0065 #0066 #0084 #0085 #0086
50 6300
(78)
55 6300
(77.5)
60 6300
(76.5) 5000 (78)
65 6300
(75) 5000 (77.5)
70 6300
(73.5) *6100 (78) 5000 (76)
75 6,00
(72) 5860 (77.5) 5000 (74.5) *4900 (78)
80 6300
(70.5) 5750 (76) *5000 (78) 5000 (73.5) 4900 (77.5)
85 6300
(69) 5650 (74.5) 4890 (77.5) 5000 (72) 4900 (76)
90 6300
(67.5) 5550 (73) 4820 (76) 4900 (70.5) 4900 (74.5) *4800 (78)
95 6300
(66) 5450 (71.5) 4760 (74.5) 4850 (69.5) 4900 (73.5) 4640 (76.5)
100 6300
(64.5) 5360 (70) 4690 (73) 4800 (68) 4710 (72) 4370 (75)
105 5810
(63) 5120 (68) 4580 (71.5) 4670 (66.5) 4420 (70.5) 4120 (73.5)
110 5030
(61.5) 4880 (66.5) 4480 (69.5) 4550 (65) 4130 (69) 3870 (72)
115 4320
(59.5) 4620 (65) 4270 (68) 4240 (63.5) 3880 (67.5) 3650 (70.5)
120 3680
(58) 4370 (63.5) 4060 (66) 3850 (62) 3630 (66) 3440 (69)
125 3100
(56.5) 4110 (61.5) 3870 (64.5) 3260 (60.5) 3410 (64.5) 3240 (67.5)
130 2560
(54.5) 3500 (60) 3680 (62.5) 2720 (59) 3190 (63) 3050 (65.5)
135 2070
(53) 2940 (58) 3510 (60.5) 2220 (57.5) 3000 (61.5) 2880 (64)
140 1610
(51) 2420 (56) 2980 (58.5) 1760 (56) 2630 (60) 2710 (62.5)
145 1190
(49) 1950 (54.5) 2440 (56.5) 1340 (54.5) 2,150 (58) 2560 (60.5)
150 1500
(52.5) 1930 (54.5) 1700 (56.5) 2210 (58.5)
155 1090
(50.5) 1470 (52) 1290 (54.5) 1750 (57)
160 1030
(50) 1310 (55)
Minimum boom angle
(°)for indicated
length (no load)48 49 49 52 53
Maximum boom length
(ft)at 0° boom angle
(no load)76.7 76.7
NOTE: ()Boom angles are in degrees. A6-829-103478
#LMI operating code. Refer to LMI manual for operating instructions.
*This capacity is based upon maximum boom angle.
NOTES:
1. All capacities above the bold line are based on
structural strength of boom extension and do not
exceed 85% of tipping loads, in accordance with
SAE J-765.
2. The 56 ft extension length may be used for single
line lifting service only.
3. For main boom lengths less than 141.7ft with
the boom extension erected, the rated loads are
determined by boom angle. Use only the column
which corresponds to the boom extension length
and offset for which the machine is set up. For
boom angles not shown, use rating of the next
lower boom angle.
4. WARNING: Operation of this machine with
heavier loads than the capacities listed is strictly
prohibited. Machine tipping with boom extension
occurs rapidly and without advance warning.
5. Boom angle is the angle above or below horizontal
of the longitudinal axis of the boom base section
after lifting rated load.
6. When lifting over the main boom nose with 56 ft
extension erected and inserts, the outriggers must
be fully extended and vertical jacks set.

15Grove RT890E
Load charts
(Mode A)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 22,000 lb 100%
24 ft spread 360˚
Feet 37.350.463.476.489.4102.4115.4141.7
10 180,000
(68.5) 134,000 (75) *80,800 (78)
12 156,000
(65) 134,000 (72.5) 80,800 (76.5) *38,700 (78)
15 128,500
(59.5) 129,000 (68.5) 80,800 (73.5) 38,700 (77) *38,500 (78)
20 98,650
(49.5) 98,950 (62) 70,950 (68.5) 38,700 (73) 38,500 (76.5) *38,400 (78)
25 78,800
(36.5) 79,150 (55) 62,300 (63.5) 38,700 (69) 38,500 (73) 38,400 (76) 24,400 (78)
30 51,550
(12.5) 60,500 (47) 55,250 (58) 38,700 (65) 38,500 (69.5) 37,500 (73) 24,400 (76) *24,400 (78)
35 45,150
(38) 44,900 (52.5) 38,700 (60.5) 36,750 (66) 33,150 (70) 24,400 (73.5) 24,400 (77)
40 35,250
(25.5) 34,700 (46) 36,750 (56) 32,750 (62) 29,550 (67) 24,400 (70.5) 24,250 (75)
45 27,600
(39) 29,450 (51) 29,400 (58.5) 26,500 (63.5) 24,400 (68) 21,900 (73)
50 22,400
(30) 24,000 (45.5) 25,650 (54.5) 23,950 (60.5) 22,050 (65) 19,800 (70.5)
55 18,250
(15.5) 19,850 (39.5) 21,350 (50) 21,750 (57) 20,000 (62) 17,900 (68.5)
60 16,600
(32.5) 17,950 (45.5) 18,900 (53.5) 18,250 (59) 16,150 (66)
65 13,850
(23) 15,200 (40) 16,150 (49.5) 16,700 (56) 14,650 (64)
70 12,950
(34.5) 13,850 (45.5) 14,800 (53) 12,850 (61.5)
75 11,000
(27.5) 11,950 (41) 12,900 (49.5) 10,950 (59)
80 9340
(17) 10,300 (36) 11,250 (45.5) 9380 (56.5)
85 8900
(30) 9830 (42) 7980 (54)
90 7640
(22.5) 8590 (37.5) 6770 (51)
95 6520
(8) 7510 (32.5) 5700 (48.5)
100 6520
(26.5) 4750 (45.5)
105 5640
(18.5) 3910 (42)
110 3150
(38.5)
115 2460
(35)
120 1840
(30.5)
125 1250
(25.5)
Minimum boom angle (deg)for indicated length (no load)24
Maximum boom length (ft)at 0deg boom angle (no load)115.4
6-829-103320A
#LMI operating code. Refer to LMI manual for instructions.
*This capacity is based upon maximum obtainable boom angle.
Note: ()Boom angles are in degrees.
Lifting capacities at zero degree boom angle
Boom
angle
Main boom length in feet
37.350.463.476.489.4102.4115.4
0°27,500
(30.1) 17,300 (43.2) 11,050 (56.2) 8580 (69.2) 6700 (82.2) 5380 (95.2) 4280 (108.2)
Note: ()Reference radii in feet.

16
Load charts
(Mode A)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –76.4ft 22,000 lb Stationary 360˚
Feet 37.350.4 63.476.4
12 39,500
(65) 41,650 (72.5)
15 37,750
(59.5) 38,950 (68.5) 18,900 (73.5) 15,650 (77)
20 24,850
(49.5) 24,850 (62) 18,900 (68.5) 15,650 (73)
25 16,300
(36.5) 16,650 (55) 17,450 (63.5) 15,650 (69)
30 10,200
(12.5) 11,350 (47) 11,450 (58) 13,200 (65)
35 7650
(38) 7630 (52.5) 9280 (60.5)
40 4920
(25.5) 5020 (46) 6510 (56)
45 4490
(51)
Minimum boom angle (°)for
indicated length (no load)39 46
Maximum boom length (ft)at 0°
boom angle (no load)50.4
Boom
angle
Main boom length in feet
37.350.4
0°10,050
(30.1) 3150 (43.2)
NOTE: ()Reference radii in feet. A6-829-103452A
#LMI operating code. Refer to LMI manual for instructions.
Main boom length in feet
Main boom
Lifting capacities at zero degree boom angle
Pounds
37.3ft –76.4ft 22,000 lb Pick and carry
up to 2.5mph Boom centered
over front
Feet 37.3 50.4 63.4 76.4
12 41,600
(65) 41,700 (72.5)
15 41,600
(59.5) 41,700 (68.5) 22,400 (73.5) 15,650 (77)
20 36,250
(49.5) 36,450 (62) 22,400 (68.5) 15,650 (73)
25 27,600
(36.5) 28,250 (55) 22,400 (63.5) 15,650 (69)
30 21,300
(12.5) 22,200 (47) 22,400 (58) 15,650 (65)
35 17,500
(38) 17,950 (52.5) 15,650 (60.5)
40 13,800
(25.5)
14,350
(46)
15,650
(56)
45 11,000
(39)
12,500
(51)
50 8360
(30)
9820
(45.5)
55 6240
(15.5) 7690 (39.5)
Minimum boom angle (°)for indicated length
(no load)36
Maximum boom length (ft)at 0° boom angle
(no load)63.4
Boom
angle
Main boom length in feet
37.3 50.4 63.4
0°21,150
(30.1) 11,600 (43.2) 5790 (56.2)
A6-829-103453
#LMI operating code. Refer to LMI manual for instructions.
Main boom length in feet
Lifting capacities at zero degree boom angle
Main boom
NOTES:
1. Capacities are in pounds and do not exceed 75% of tipping loads as determined by test in accordance with SAE J765.
2. Capacities are applicable to machines equipped with 29.5x25 (34 ply)General tires at 76 psi cold inflation pressure.
3. Capacities appearing above the bold line are based on structural strength and tipping should not be relied upon as a capacity
limitation.
4. Capacities are applicable only with machine on firm level surface.
5. On rubber lifting with boom extensions not permitted.
6. For pick and carry operation, boom must be centered over front of machine, mechanical swing lock engaged and load restrained from
swinging. When handling loads in the structural range with capacities close to maximum ratings, travel should be reduced to creep
speeds.
7. Axle lockouts must be functioning when lifting on rubber.
8. All lifting depends on proper tire inflation, capacity and condition. Capacities must be reduced for lower tire inflation pressures. See
lifting capacity chart for tire used. Damaged tires are hazardous to safe operation of crane.
9. Creep –not over 200 ft of movement in any 30 minute period and not exceeding 1mph.

17Grove RT890E
33 ft –56 ft luffing bi-fold boom extension
(Mode B)(fixed offsettable angles)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 22,000 lb33 ft –56 ft 100%
24 ft spread 360˚
Feet
33 ft LENGTH 56 ft LENGTH
5°20°40°5°20°40°
OFFSET OFFSET OFFSET OFFSET OFFSET OFFSET
#0091 #0091 #0091 #0092 #0092 #0092
40 *13,700
(78)
45 13,700
(77)
50 13,700
(75) 13,700 (77.5) *8200 (78)
55 13,700
(73.5) 13,700 (75.5) *11,000 (78) 8200 (77.5)
60 13,700
(71.5) 13,700 (74) 11,000 (76) 8200 (76)
65 13,700
(70) 12,850 (72) 10,950 (74.5) 8200 (74.5) 8200 (77.5)
70 12,500
(68) 12,000 (70) 10,350 (72.5) 8200 (73) 8200 (76)
75 11,350
(66) 11,200 (68) 9830 (70.5) 8200 (71.5) 8100 (74) 6400 (77.5)
80 9730
(64.5) 10,450 (66.5) 9330 (68.5) 8200 (69.5) 7600 (72.5) 6400 (76)
85 8300
(62.5) 8980 (64.5) 8860 (66.5) 8200 (68) 7150 (71) 6230 (74)
90 7060
(60.5) 7660 (62.5) 8210 (64.5) 7740 (66.5) 6730 (69) 5920 (72.5)
95 5960
(58.5) 6500 (60.5) 6980 (62) 7130 (64.5) 6350 (67.5) 5640 (70.5)
100 4990
(56.5) 5470 (58) 5880 (60) 6130 (63) 6000 (65.5) 5380 (68.5)
105 4120
(54) 4560 (56) 4900 (58) 5230 (61) 5690 (64) 5140 (67)
110 3340
(52) 3730 (54) 4020 (55.5) 4430 (59.5) 5290 (62) 4900 (65)
115 2640
(49.5) 2990 (51.5) 3230 (53) 3700 (57.5) 4490 (60) 4690 (63)
120 2000
(47.5) 2320 (49) 2510 (50.5) 3040 (55.5) 3760 (58.5) 4470 (61)
125 1420
(45) 1700 (46.5) 1850 (47.5) 2440 (53.5) 3100 (56.5) 3710 (58.5)
130 1140
(44) 1250 (45) 1900 (51.5) 2500 (54.5) 3030 (56.5)
135 1390
(49.5) 1940 (52) 2390 (54)
140 1420
(50) 1810 (52)
145 1270
(49)
Minimum boom angle
(°)for indicated
length (no load)42 43 43 48 48 47
Maximum boom length
(ft)at 0° boom angle
(no load)89.8 76.7
NOTE: ()Boom angles are in degrees. A6-829-103522
#LMI operating code. Refer to LMI manual for operating instructions.
*This capacity is based upon maximum boom angle.
NOTES:
1. All capacities above the bold line are based on
structural strength of boom extension and do
not exceed 85% of tipping loads, in accordance
with SAE J-765.
2. The 33 ft luffing folding boom extension may be
used for single or double line lifting service. The
56 ft luffing folding boom extension may be
used for single line lifting service only.
WARNING: Lifting with the 33 ft extension
base, with the 23 ft extension fly either erected
or folded along side of extension base, is
strictly prohibited.
3. WARNING: Operation of this machine with
heavier loads than the capacities listed is
strictly prohibited. Machine tipping with boom
extension occurs rapidly and without advance
warning.
4. Boom angle is the angle above or below
horizontal of the longitudinal axis of the boom
base section after lifting rated load.
5. Capacities listed are with outriggers properly
extended and vertical jacks set only.
6. For main boom lengths less than 141.7ft with
the boom extension erected, the rated loads
are determined by boom angle. Use only
the column which corresponds to the boom
extension length and offset for which the
machine is set up. For boom angles not shown,
use rating of the next lower boom angle.
7. When lifting over the main boom nose with
33 ft or 56 ft extension erected, the outriggers
must be fully extended or 50% extended (17.3ft
spread).

18
33 ft –56 ft luffing bi-fold boom extension
(Mode B)(intermediate offsettable angles)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 22,000 lb33 ft –56 ft 100%
24 ft spread 360˚
Feet
33 ft LENGTH 56 ft LENGTH
5° -20°20° -40°5° -20°20° -40°
OFFSET OFFSET OFFSET OFFSET
#0091 #0092
50 11,850
55 11,550 10,750
60 11,200 10,600
65 10,900 10,450 6150
70 10,650 10,350 5960
75 10,350 9830 5780 5370
80 9730 9330 5610 5280
85 8300 8860 5450 5200
90 7060 7660 5310 5130
95 5960 6500 5170 5070
100 4990 5470 5040 5010
105 4120 4560 4920 4910
110 3340 3730 4430 4810
115 2640 2990 3700 4490
120 2000 2320 3040 3760
125 1420 1700 2440 3100
130 1140 1900 2500
135 1390 1940
140 1420
Min. boom
angle for
indicated
length (no
load)
43°43°48°48°
Max. boom
length at 5°
boom angle
(no load)
89.8'76.7'
#LMI operating code. Refer to LMI manual for
operating instructions.
A6-829-103525A
NOTES:
1. All capacities above the bold line are
based on structural strength of boom
extension and do not exceed 85% of
tipping loads, in accordance with SAE
J-765.
2. The 33 ft luffing folding boom
extension may be used for single or
double line lifting service. The 56 ft
luffing folding boom extension may
be used for single line lifting service
only.
WARNING: Lifting with the 33
ft extension base, with the 23 ft
extension fly either erected or folded
along side of extension base, is
strictly prohibited.
3. WARNING: Operation of this
machine with heavier loads than the
capacities listed is strictly prohibited.
Machine tipping with boom
extension occurs rapidly and without
advance warning.
4. The loads for luffing depend on the
angle of the main boom, angle of
the boom extension and dynamic
working pressure of the luffing
cylinder for the boom extension.
5. Capacities listed are with outriggers
properly extended and vertical jacks
set only.
6. When lifting over the main boom
nose with 33 ft or 56 ft extension
erected, the outriggers must be fully
extended or 50% extended (17.3ft
spread).

19Grove RT890ETHIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
37.3ft –141.7ft 1or 2
16 ft inserts22,000 lb33 ft –56 ft 100%
24 ft spread 360˚
Feet
72 ft (56 ft LENGTH + 1INSERT)
88 ft (56 ft LENGTH + 2INSERTS)
5°20°40°5°20°40°
OFFSET OFFSET OFFSET OFFSET OFFSET OFFSET
#0095 #0095 #0095 #1095 #1095 #1095
55 *6400
(78)
60 6400
(77.5)
65 6400
(76) *5000 (78)
70 6400
(74.5) *6400 (78) 5000 (77)
75 6400
(73.5) 6400 (76.5) 5000 (75.5) *5000 (78)
80 6400
(72) 6400 (75) *5500 (78) 5000 (74.5) 5000 (76)
85 6400
(70.5) 6040 (73.5) 5420 (76) 5000 (73) 5000 (74.5) *4460 (78)
90 6250
(69) 5630 (72) 5100 (74.5) 5000 (71.5) 4790 (73) 4460 (76.5)
95 5800
(67.5) 5260 (70.5) 4800 (73) 4740 (70) 4420 (71.5) 4150 (75)
100 5380
(66) 4910 (69) 4520 (71.5) 4350 (69) 4090 (70.5) 3860 (73.5)
105 5010
(64) 4610 (67.5) 4270 (69.5) 4010 (67.5) 3790 (69) 3600 (72)
110 4570
(62.5) 4310 (65.5) 4020 (68) 3680 (66) 3490 (67.5) 3340 (70.5)
115 3840
(61) 4040 (64) 3790 (66) 3390 (64.5) 3230 (66) 3110 (69)
120 3180
(59.5) 3780 (62.5) 3570 (64.5) 3110 (63) 2980 (64.5) 2890 (67.5)
125 2570
(57.5) 3290 (60.5) 3370 (62.5) 2720 (61.5) 2760 (63) 2680 (66)
130 2020
(56) 2680 (59) 3180 (60.5) 2160 (60) 2540 (61.5) 2480 (64.5)
135 1510
(54) 2120 (57) 2680 (59) 1640 (58.5) 2300 (59.5) 2300 (62.5)
140 1040
(52.5) 1600 (55) 2100 (57) 1170 (57) 1780 (58) 2120 (61)
145 1130
(53) 1560 (54.5) 1300 (56.5) 1820 (59)
150 1060
(52.5) 1320 (57)
Minimum boom angle
(°)for indicated
length (no load)51 52 51 56 55 56
Maximum boom length
(ft)at 0° boom angle
(no load)76.7 63.7
NOTE: ()Boom angles are in degrees. A6-829-103523
#LMI operating code. Refer to LMI manual for operating instructions.
*This capacity is based upon maximum boom angle.
NOTES:
1. All capacities above the bold line are
based on structural strength of boom
extension and do not exceed 85% of
tipping loads, in accordance with SAE
J-765.
2. The 56 ft luffing folding boom
extension may be used for single line
lifting service only.
3. WARNING: Operation of this
machine with heavier loads than the
capacities listed is strictly prohibited.
Machine tipping with boom
extension occurs rapidly and without
advance warning.
4. WARNING: Lifting with the 33
ft extension base, with the 23 ft
extension fly either erected or folded
along side of extension base, or with
either one or two 16 ft insert sections
installed, is strictly prohibited.
5. For main boom lengths less than 141.7
ft with the boom extension erected,
the rated loads are determined by
boom angle. Use only the column
which corresponds to the boom
extension length and offset for which
the machine is set up. For boom
angles not shown, use rating of the
next lower boom angle.
6. When lifting over the main boom
nose with the 56 ft extension erected
and inserts, the outriggers must be
fully extended and vertical jacks set.
33 ft –56 ft luffing bifold boom extension with inserts
(Mode B)(intermediate offsettable angles)

20
33 ft –56 ft luffing bi-fold boom extension with inserts
(Mode B)(intermediate offsettable angles)
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Feet
72 ft LENGTH (56 ft + 1INSERT) 88 ft LENGTH (56 ft + 2INSERTS)
5° -20°
OFFSET 20° -40° OFFSET 5° -20°20° -40°
OFFSET
#0095 #1095
70 6090
75 5920 5000
80 5750 5340 5000
85 5600 5260 5000 4460
90 5460 5100 4790 4460
95 5260 4800 4420 4150
100 4910 4520 4090 3860
105 4610 4270 3790 3600
110 4310 4020 3490 3340
115 3840 3790 3230 3110
120 3180 3570 2980 2890
125 2570 3290 2720 2680
130 2020 2680 2160 2480
135 1510 2120 1640 2300
140 1040 1600 1170 1780
145 1130 1300
Min. boom
angle for
indicated
length (no
load)
52°52°56°56°
Max. boom
length at 5°
boom angle
(no load)
76.7'63.7'
#LMI operating code. Refer to LMI manual for operating instructions.
A6-829-103526
Pounds
37.3ft –141.7ft1or 2
16 ft inserts22,000 lb
33 ft –56 ft 100%
24 ft spread 360˚
NOTES:
1. All capacities above the bold line are
based on structural strength of boom
extension and do not exceed 85% of
tipping loads, in accordance with SAE
J-765.
2. The 56 ft luffing folding boom
extension may be used for single line
lifting service only
WARNING: Lifting with the 33
ft extension base, with the 23 ft
extension fly either erected or folded
along side of extension base, or with
either one or two 16 ft insert sections
installed, is strictly prohibited.
3. WARNING: Operation of this
machine with heavier loads than the
capacities listed is strictly prohibited.
Machine tipping with boom
extension occurs rapidly and without
advance warning.
4. The loads for luffing depend on the
angle of the main boom, angle of
the boom extension and dynamic
working pressure of the luffing
cylinder for the boom extension.
5. When lifting over the main boom
nose with 56 ft extension erected and
inserts, the outriggers must be fully
extended and vertical jacks set only.
