Service Manual
Grove TMS9000-2
For
Reference
Only

The original language of this publication is English.
WARNING
California Proposition 65
Breathing diesel engine exhaust exposes you
to chemicals known to the State of California
to cause cancer and birth defects or other
reproductive harm.
• Always start and operate the engine in a
well-ventilated area.
• If in an enclosed area, vent the exhaust to
the outside.
• Do not modify or tamper with the exhaust
system.
• Do not idle the engine except as
necessary.
For more information, go to
www.P65warnings.ca.gov/diesel
Batteries, battery posts, terminals, and
related accessories can expose you to
chemicals, including lead and lead
compounds, which are known to the State of
California to cause cancer and birth defects or
other reproductive harm. Wash hands after
handling. For more information, go to
www.P65warnings.ca.gov
California Spark Arrestor
Operation of this equipment may create
sparks that can start fires around dry
vegetation. A spark arrestor may be required.
The owner/operator should contact local fire
agencies for laws or regulations relating to fire
prevention requirements.
For
Reference
Only

SERVICE MANUAL
This Manual has been prepared for and is considered part of -
TMS9000-2
Crane Model Number
NOTICE
The crane serial number is the only method your distributor or the
factory has of providing you with correct parts and service informa-
tion.
The crane serial number is identified on the builder’s decal
attached to the operator’s cab. Always furnish crane serial
number when ordering parts or communicating service problems
with your distributor or the factory.
An untrained operator subjects himself and others to death or
serious injury. Do not operate this crane unless:
• You are trained in the safe operation of this crane. Manitowoc is not
responsible for qualifying personnel.
• You read, understand, and follow the safety and operating
recommendations contained in the crane manufacturer’s manuals and
load charts, your employer’s work rules, and applicable government
regulations.
• You are sure that all safety signs, guards, and other safety features are
in place and in proper condition.
• The Operator Manual and Load Chart are in the holder provided on the
crane.
DANGER
!
©2019 Grove U.S. L.L.C.
Published 01-14-2021 Control # 707-01
For
Reference
Only

This Page Blank
For
Reference
Only

Manitowoc Cranes
1565 Buchanan Trail East PO Box 21
Shady Grove, PA 17256-0021
T 717 597 8121 F 717 593 5999
www.manitowoc.com
Service Manual Supplement
PURPOSE:To provide guidance for issues related to tire wear, suspension
and/or steering performance.
RECOMMENDED PROCEDURE FOR REPAIRING TIRE WEAR,
SUSPENSION, AND/OR STEERING PERFORMANCE ISSUES: Have a
qualified alignment specialist inspect the machine for compliance with the
following machine specifications:
•Tire pressure (front & rear): 130 psi
(If experiencing tire wear due to over-inflation contact Crane Care
for alternate tire inflation solutions.)
•Tire/Wheel lateral & radial run-out:0.060” maximum
Note: For Runout Tolerances Use the 30/60/90 Rule
0.000" - 0.030": Excellent
0.031" - 0.060": Good
0.061" - 0.090": Use 3R’s - Rotate tire 180 degrees
- Re-lubricate tire and wheel
- Re-inflate with tire laying flat (5 psi. max)
0.091" - Higher: Inspect all wheel end components
•Ride Height–both tandems: 1.80°open +/- 0.50°;max. 0.50°
difference on any one tandem.
•Steer and Drive axles offset: 0.00” +/- 0.19”
•Steer and Drive axles parallelism: 0.00” +/- 0.13”
•Drive tandem thrust: 0.75” maximum
•Steer axles toe: +0.03” +/- 0.03”
•Steer axle wheel ends caster: 3.00° +/- 0.50°
•Steer axle wheel ends camber: +0.06° +/- 0.19°(not adjustable)
X
Information Only
Date
Month/day/year
To:
Mobile Crane Distributor Service Managers
Mobile Crane Field Support Personnel
Subject:
Suspension Alignment Supplement; Rev 2
Model(s) Affected:
TMS700E, TMS800E, & TMS9000-2
For
Reference
Only

Page 2
January 2019
ALTERNATIVE PROCEDURE:To enable a customer’s service department
to make axle and front-end alignment adjustments when suspension, tire,
and/or steering performance is poor:
STEP 1. When an issue with tire, suspension, and/or steering
performance is identified, the customer should fill out a “Field
Alignment Worksheet” (attached to this document) and submit it to
Crane Care for evaluation and instruction.
STEP 2. Crane Care will evaluate the worksheet and provide a list of
adjustments that are required.
STEP 3. The customer’s service department will make the required
adjustments per the instructions on the following pages and test the
machine to validate improved performance. Test results should be
submitted to Crane Care.
For
Reference
Only

Page 3
January 2019
FIELD ALIGNMENT INSTRUCTIONS:Instructions for each adjustment are on
the following pages. Crane Care to check-mark those that are required:
X Machine Preparation.
Inflate tire to 130 psi. Position/s:
Breakdown and re-mount tire/wheel assy. Position/s:
Re-check axial & radial run-out.
Adjust axle offset. Position/s:
Adjust steer axle skew.
Adjust steer axle parallelism.
Adjust steering linkage.
Adjust steer axle turning stops.
Adjust steer wheel-end caster. Position/s:
Steer wheel-end camber is not adjustable. Crane Care is to advise remedy.
Adjust steer wheel-end toe. Position/s:
Adjust drive axle thrust.
Adjust drive axle parallelism.
X Test and report result to Manitowoc Crane Care.
Tools (other than miscellaneous wrenches):
Camber/Caster alignment tool (if available) Dial Indicator/s
Thrust alignment tool (if available) 4 foot level or straight edge
Trammel bar (if available) Can of white spray paint
Toe bar Tire Scribe
(4) Alignment turntables (2) Wheel chocks
Digital angle gauge/s (2) Ø21/64” (0.8mm) rig pin or drill
Tape measure (1/32” graduations) Tape measure (1 mm graduations)
Porta-power (if available) Laser pointer w/mtg for 22.5” wheel
Air pressure >130 psi Air hose with chuck
For
Reference
Only

Page 4
January 2019
Machine Preparation:
NOTE: Alignments should be performed on a level surface. Height of tire patches should be
within 1/8” of each other.
•For field alignment configure the machine in the most common roading condition
and inflate all tires to 130 psi.
•Drive vehicle straight into inspection site, at least 3 full tire rotations to ensure
it’s straight into site. Driving into and backing out of the work area several times
will ensure the vehicle’s suspension components remain relaxed to achieve
proper measurements.
•For final positioning, shift transmission to neutral and allow vehicle to roll
forward to a stop without using the brakes.
•Engage parking brake.(Note: Outriggers do not function unless park brake is engaged.)
For
Reference
Only

Page 5
January 2019
Machine Preparation continued:
•Adjust ride height - front and rear.
Note: When setting ride height and measuring alignment settings be certain that the air
system is at full system pressure; re-charge frequently.
•Place wheel chocks on drive axles and release the park brake.
•Place a calibrated digital angle gauge on the flat surface of the trailing arm
and adjust the ride height valve to achieve a 1.8°+/-0.5°angle, open to the
rear. Repeat the process on all four tandems and maintain a 0.5°tolerance
between left and right on the same tandem.
Note: Calibrate/zero digital angle gauges to the bottom frame rail, positioned in the same
orientation that each is being applied on the suspension.
•Prepare for toe adjustment if it is required:
•Raise the machine on outriggers until the tires are just off the ground.
•Prepare the steer tires for toe measurement by highlighting (white spray
paint) a section/row of tread around each tire and scribing a line into the
highlight around the tires as they are rotated.
•Lower the machine to the ground. Back out and drive straight into the work
area several times to ensure the vehicle’s suspension components remain
relaxed and achieve proper measurements. Place wheel chocks on the drive
axles.
For
Reference
Only

Page 6
January 2019
Adjust axle offset.
•Measure the distance between the frame side plate to the edge of the tire tread
centered over the axle, left and right; these measurements should be within
3/16 in. (4.8 mm).
Note: steering axle and drive axle measurements will be different; axle lengths and frame
widths are different.
Measure to edge of tread
•Adjust side to side using lateral torque rods. Re-torque bolts 2 to 3 turns into the
locking feature of the nut.
Note: Machine should be on outriggers to perform this adjustment.
Adjust each axle using the lateral torque rod.
•Lower the machine to the ground. Back out and drive straight into the work
area several times to ensure the vehicle’s suspension components remain
relaxed and achieve proper measurements. Place wheel chocks on the drive
axles.
For
Reference
Only

Page 7
January 2019
Adjust steer axle skew.
•Raise the machine on outriggers and place an alignment turntable under each of
the steer tires. Lower the machine making certain not to bottom-out the
turntables or put them in a bind.
•Measure the distance between the “center hook” on the frame to the corner of the
front steer axle mount, left and right; each axle’s left and right measurements
should be within 3/16 in. (4.8 mm) of the other.
#1 axle Center hook location
•Adjust axle mounting shims to achieve squareness. Reposition the shim/s to the
front of the bar pin to move the axle forward, or to the back of the bar pin to move
the axle toward the rear. Slight adjustments might be achieved by adjusting
shims on one side of the axle. Larger adjustments will be achieved by adjusting
both sides in opposite directions. Re-torque hardware to 450-600 lbf*lb. (610-
813 N*m).
Note: Raise the machine on outriggers to take weight off the suspension in order to reposition
the mounting shims. A Porta Power can be used to support the suspension. Be sure to lift the
outriggers and put full weight on the suspension prior to taking subsequent measurements.
Bar pin
Measure to outside edge of mounts Shims
•Lower the machine to the ground. Back out and drive straight into the work area
several times to ensure the vehicle’s suspension components remain relaxed and
achieve proper measurements. Place wheel chocks on the drive axles.
For
Reference
Only

Page 8
January 2019
Adjust steer axle parallelism.
•Distance between the steer axle hub centers on the left and right side of the
machine should be within 1/8 in. (3.2 mm).This can be measured, or the
process can be simplified by use of a Trammel bar if available.
•Adjust rear steer axle mounting shims to achieve parallelism. Reposition the
shim/s to the front of the bar pin to move the axle forward, or to the back of the
bar pin to move the axle toward the rear. Slight adjustments might be achieved
by adjusting shims on one side of the axle. Larger adjustments will be achieved
by adjusting both sides in opposite directions. Re-torque hardware to 450-600
lbf*ft. (610-813 N*m).
Note: Raise the machine on outriggers to take weight off the suspension in order to reposition
the mounting shims. A Porta Power can be used to support the suspension. Be sure to lift the
outriggers and put full weight on the suspension prior to taking subsequent measurements.
Bar pin
Shims
•Lower the machine to the ground. Back out and drive straight into the work area
several times to ensure the vehicle’s suspension components remain relaxed and
achieve proper measurements. Place wheel chocks on the drive axles.
For
Reference
Only

Page 9
January 2019
Adjust steering linkage.
•Rotate the steering wheel to center the front relay arm and pin it with a Ø 21/64
in. (0.8 mm) rig pin or drill bit.
•Adjust the intermediate drag link to center the rear relay arm and pin it with a
Ø 21/64 in. (0.8 mm) rig pin or drill bit. Apply Loctite 243 to clamp bolts and re-
torque to 110-130 lbf*ft. (149-176 N*m).
pin
Adjust intermediate
Driver side front steer axle. drag link
For
Reference
Only

Page 10
January 2019
Adjust steering linkage continued.
Note: Steer tires should be on alignment turntables for this step.
•Adjust the front steer axle to “straight ahead.”
•Using a 4 ft. (1.2 meter) or longer straight edge measure the front steer axle
driver’s side tire, front and rear, to the frame side plate.
•Adjust front steer axle drag link until front and rear measurements are
equal. Apply Loctite 243 to clamp bolts and re-torque to 50-60 lbf*ft. (68-81
N*m).
Front steer axle drag link
For
Reference
Only

Page 11
January 2019
Adjust steering linkage continued.
Note: Steer tires should be on alignment turntables for this step.
•Adjust rear steer axle to “straight ahead.”
•Using a 4 ft. (1.2 m) or longer straight edge measure rear steer axle driver
side tire, front and rear, to the frame side plate.
•Adjust rear steer axle drag link until front and rear measurements are
equal. Apply Loctite 243 to clamp bolts and re-torque to 110-130 lbf*ft. (149-
176 N*m).
Rear steer axle #2 drag link
For
Reference
Only

Page 12
January 2019
Adjust steering linkage continued.
•Adjust steering wheel orientation.
•For major adjustments of the steering wheel, loosen the bolt on the steering
column splined coupling, slide the coupling off the steering gear 90°Miter
and rotate until the steering wheel is straight ahead. Slide the coupling
back onto the Miter and retighten the bolt.
Splined coupling
•For minor/fine adjustment of the steering wheel loosen the clamp bolts and
rotate the steering link to orient the steering wheel straight ahead. Apply
Loctite 243 to clamp bolts and re-torque to 50-60 lbf*ft. (68-81 N*m).
Steering link
•Remove rig pins from relay arms.
For
Reference
Only

Page 13
January 2019
Adjust steer axle turning stops.
•Steering stops should be set to provide 1.00 in. (25.4 mm) of clearance to closest
object for any tire.
Note: steering stops are located on the front steer axle only.
Note: steer tires should still be on alignment turntables for this step.
Steering stop
•Steering gearbox relief plungers should actuate 1/16 in. (1.6 mm) prior to contact
with steering stops.
Steering gearbox
Left turn relief Right turn relief
Screw in to decrease travel Screw in to decrease travel
Screw out to increase travel Screw out to increase travel
For
Reference
Only

Page 14
January 2019
Adjust steer wheel-end caster.
Caster should be positive 3.0°+/-0.5°.
Note: Steer tires should be on alignment turntables for this step.
•Use professional alignment caster tool if available, otherwise place a digital angle
gauge, calibrated/zeroed to the bottom frame rail, on the bottom of the king pin
housing, longitudinally.
Caster gauge Digital angle gauge
•Adjust the longitudinal torque rods to achieve this. Re-torque clamp bolts to
2 to 3 turns into the locking feature of the nut.
Adjust longitudinal torque rod
For
Reference
Only

Page 15
January 2019
Steer wheel-end camber is not adjustable.
•Camber should be 1/16° +/- 3/16°; if camber is out of tolerance it’s a sign of a part
defect, wear, or improper installation. Manitowoc Crane Care will provide
direction.
For
Reference
Only

Page 16
January 2019
Adjust steer wheel-end toe.
•Toe should be +1/32 in. (0.8 mm) +/-1/32 in. (0.8 mm).
Note: Steer tires should be on alignment turntables for this step.
•On the front steer axle measure the distance between the scribed lines (see
“machine preparation for toe adjustment”) at hub height on the rear of the tires
and then on the front of the tires. Subtract the front value from the rear.
Positive result is “toe in” and negative is “toe out.” The use of a “toe bar”
provides greater accuracy.
Adjust the front steer axle tie rod to achieve this. Apply Loctite 243 to clamp bolts
and re-torque to 115-125 lbf*ft. (156-169 N*m).
•Repeat this process for the rear steer axle.
Tie rod
For
Reference
Only
