Maple Systems MOD-SENT01 User manual

-1 -
USER MANUAL
MAPLE MODULAR PLC
Ethernet Module
• MOD-SENT01

-2 -
Contents
General Specifications................................. 7
Performance Specifications ......................... 8
Features.....................................................9
Dimensions ..............................................10
Product Warranty ......................................11

-3 -
Before You Start
This manual contains important information on the use and operation of this device. Please
read all the information carefully for optimal performance and to prevent any damage or
misuse of the device.
To keep products safe, all activities including product installation, wiring operation, and
maintenance are required to be treated by trained personnel.
Reproduction of contents, in whole or part of this manual, without written permission from
MAPLE SYSTEMS Inc. is prohibited.
Safety symbols are classified into two categories: “WARNING” and “CAUTION”.
Warning: This symbol describes situations that could cause major or fatal injury to the
user.
Caution: This symbol describes situations that may cause minor injury or damage to the
device.
SAFETY SYMBOLS USED IN THIS PRODUCT MEAN:
This symbol warns the user of potential hazards.
This symbol warns the user of uninsulated voltage within the unit that can cause
dangerous electric shock.
Keep this manual near the operating devices so it can be easily checked.

-4 -
Design Precautions ( Warning)
Please install a safety circuit to protect the entire control system in case of an unexpected
power shutdown or PLC module malfunction. Such anomalies may severely compromise the
integrity of the overall system.
External to the PLC, please install circuits and switches to safeguard the system from
mechanical damages (ex. emergency stop, upper/lower limit switches, forward/reverse
direction interlocking circuits, etc).
When the PLC detects either of the following failure conditions, it may stop operation and
turn off all outputs.
-The overcurrent protection or overvoltage protection of the power supply module is
activated.
-The PLC CPU detected a failure, such as the watchdog timer error or module installation
failure, with its self-diagnostic function.
In addition, all outputs may be turned on when there is a failure that the PLC CPU cannot
detect, such as in the relay or TR terminal. Build an extra monitoring circuit that will monitor
any output signal that could cause serious accidents.
A greater than normal current passed through the PLC for an extended period of time, or a
short-circuited load flowing through the output module may cause a fire.
Build a circuit that turns on the external power supply after the PLC power supply is turned
on. If the external power supply is turned on first, it could result in output failure or
malfunction.
In order to ensure that the system operates safely, please configure an interlock circuit in the
scan program for the following situations:
-When exchanging data with a computer or other devices.
-When operated by a computer or other devices.
Not doing so could result in output failure or malfunction.
Precautions for design ( Caution)
Do not bundle the input/output signal or communication cables with the main circuit and
power cables. They should be installed at least more than 100 mm (3.94 inches) apart. Not
doing so could result in output failure or malfunction.

-5 -
Precautions for mounting ( Caution)
Use the PLC in an environment that meets the general specifications given in this manual.
Using this PLC in any environment outside the range of the general specifications could
result in electric shock, fire, malfunction, or damage to or deterioration of the product.
Please ensure that each module is installed correctly in its place. Loosely or incorrectly
installed pieces may result in malfunction, failure, or free-fall.
The PLC power supply should be turned off before mounting the module. Not doing so could
cause an electric shock or damage to the device.
Install I/O devices or extension connectors correctly. If they are installed incorrectly, it may
result in an input or output failure.
Do not convey direct vibration into the PLC. Doing so could cause electric shock, fire or
malfunctions.
After wiring work, please make sure to close the terminal cover before turning on the power
for the PLC system.
Precautions for wiring ( Warning)
Make sure to check the device’s rated voltage and circuit arrangement before wiring. Failure
to do so may cause electric shock or damage to the device.
Make sure to close the terminal cover before turning on the power of the PLC system after
wiring work. Failure to do so may cause electric shock.
Precautions for wiring ( Caution)
Make sure to check the device’s regular voltage and sequence of terminals. Failure to do so
may cause fire, electric shock, and malfunctions.
Make sure to tighten the screws with standard torque. Loose connections may cause a short
circuit, fire, or malfunctions.
When grounding the FG ground terminals, be sure to conduct the product with at least D
type (Class 3) grounding. Not doing so could result in electric shock or malfunctions.
When wiring, make sure that wiring debris does not enter the module. Failure to do so may
cause fire, equipment damage, or malfunctions.

-6 -
Precautions for wiring of Ethernet Module ( Caution)
If duplicate station numbers exist, communication does not operate normally.
Be sure to use the designated standard cable. Otherwise a communication failure may
occur.
User must check whether the communication cable is properly connected before use it.
Be sure to wire communication cables correctly. If not, this can cause a critical error in
communication.
For long-distance communication, wiring must be separated from the power line to avoid
inductive noise.
Precautions for test run and repair ( Warning)
Please do not touch the terminals when the power is on. Doing so could cause an electric
shock or malfunctions.
When cleaning or tightening the screws, turn off the power of the PLC and all other systems.
Failure to do so could cause an electric shock or malfunctions.
Do not charge, disassemble, heat up, short, or solder the battery. Doing so could cause the
battery to heat up, rupture, or ignite, thereby harming the user.
Precautions for test run and repair ( Caution)
Do not dissociate the PCB from the module’s casing or make any modifications to the
device. Doing so may cause fire, electric shock, or malfunction.
When mounting or separating the module, make sure to turn off power to the PLC and all
other devices. Failure to do so could cause an electric shock or malfunctions.
Use radio, walkie-talkie, or cell phone devices at least 30 cm away from the PLC. Not doing
so could result in malfunction.
Precautions for disposal ( Caution)
When the product is disposed of, it should be done according to your country’s regulations
for similar types of industrial waste. Not doing so may cause an occurrence of toxic
substances or explosions.

-7 -
Items Specification Standards
Op. Temp.
-10℃–60℃
-
St. Temp.
- 25 ℃ –80 ℃
-
Op. Hum 5–95% RH, Not condensed -
St. Hum 5–95% RH, Not condensed -
Vibration
In case of Intermittent Vibration
IEC 61131-2
Frequency Acceleration Amplitude Sweep
5 ≤f < 9 Hz - 3.5 mm 10 times
in X, Y, Z
9 ≤f ≤150 Hz 9.8 m/s
2
(1G) -
In case of Continuous Vibration
Frequency Acceleration Amplitude Sweep
5 ≤f < 9 Hz - 1.75 mm 10 times
in X, Y, Z
9 ≤f ≤150 Hz 4.9 m/s
2
(1G) -
Shock
• Max. shock Acc.: 147 m/s
2
(15G)
• Time: 11 ms
• Pulse wave: Half sine wave pulse (3 times each in X, Y, Z)
IEC 61131-2
Noise
Square
Wave
Impulse Noise
±2 kV -
Electrostatic
Discharge
±4 kV (contact), ±8 kV (air)
IEC
61131
-
2
IEC 61000-4-2
Radiated
Electromagnetic
Field
80–1000 MHz,10 V/m
IEC 61131-2
IEC 61000-4-3
Fast Transient
Burst Noise
(Voltage)
CPU, Power
2 kV
IEC 61131-2
IEC 61000-4-4
Digital/Analog I/O (AC)
Digital/Analog I/O (DC)
1 kV
Communication
Ambient
Conditions
No corrosive gas and no dust
Altitude 2,000 m or less
Pollution 2 or less
Cooling Natural air cooling
General Specifications

-8 -
▶Module Specification
Model MOD-SENT01
Interface 10BASE-T, 100BASE-TX
Data Transmit Speed 10/100 Mbps
Max. Distance
(Node)
100 m
Service Capacity UDP, TCP 12 Services
Service
Loader
Yes (UDP)
MODBUS
TCP
SIave
Yes
MODBUS
TCP
Master
Yes
User Protocol
Yes (TCP, UDP)
High
Speed
PLC
Link
Yes
DHCP
Yes
▶Cable - Twisted Pair (UTP)
Item Unit Value
Conductor Resistance (Max) Ω/km 93.5
Insulation Resistance (Min) MΩ · km 2500
Withstanding Voltage V/min AC 500
Impedance Ω(1–100 MHz) 100±15
Attenuation
dB/100 m
or less
10 6.5
16 8.2
20 9.3
Near-end Crosstalk
Attenuation
dB/100 m
or Less
10 47
16 44
20 42
Performance Specifications

-9 -
1) Follows IEEE802.3 standard.
2) Supports ARP, ICMP, IP, TCP, UDP, and DHCP protocols.
3) Unlimited cards are supported on one PLC Base.
4) Provides a MODBUS TCP Master for MODBUS protocol communications to other devices.
5) Supports high-speed PLC Link communication between MAPLE SYSTEMS PLCs and
can communicate with a maximum of 64 stations.
6) A maximum of 4 Ethernet modules can be used on one PLC base.
Features and Operation

-10 -
(Unit: mm)
►MOD-SENT01
Dimensions

-11 -
Warranty Statements are included with each unit at the time of
purchase and are available at www.maplesystems.com.
Product Warranty

-12 -
808 134th St SW #120
Everett, WA 98204
Web: www.maplesystems.com
