AEx Operations Manual
AEx Industrial Monitor, Panel PC, and
Box PC Series
For use with the following:
•AEx-100 Series Monitors
•AEx-800 Series Panel PC
•AEx-900 Series Panel PC
•AEx-2400 Series Box PC

Operations Manual: AEx Series 2
Operations Manual: AEx Series 2
TABLE OF CONTENTS
COPYRIGHT NOTICE......................................................................................................3
WARRANTY.....................................................................................................................3
TECHNICAL SUPPORT...................................................................................................3
UNPACKING THE UNIT ..................................................................................................3
SAFETY PRECAUTIONS ................................................................................................4
AEX-100 SERIES MONITORS.........................................................................................5
OVERVIEW.............................................................................................................5
SPECIFICATIONS AND DIMENSIONAL OUTLINES.............................................6
I/O PORTS AND CABLES ......................................................................................9
ON-SCREEN DISPLAY (OSD) OPERATION .......................................................11
OSD MENU PARAMETERS AND OPTIONS .......................................................12
MOUNTING OPTIONS .........................................................................................16
PC CONNECTION ................................................................................................16
AEX-800 SERIES PANEL PC........................................................................................17
OVERVIEW...........................................................................................................17
SPECIFICATIONS AND DIMENSIONAL OUTLINES...........................................18
I/O PORTS AND CABLES ....................................................................................21
MOUNTING OPTIONS .........................................................................................23
BIOS CONFIGURATION OPTIONS .....................................................................24
DRIVER INSTALLATION ......................................................................................26
WINDOWS OPERATING SYSTEM REINSTALLATION ......................................26
WINDOWS 10 IoT ENTERPRISE 2019 LTSC......................................................26
WONDERWARE / AVEVA™ EDGE .....................................................................26
AEX-900 SERIES PANEL PC........................................................................................27
OVERVIEW...........................................................................................................27
SPECIFICATIONS AND DIMENSIONAL OUTLINES...........................................28
MOUNTING OPTIONS .........................................................................................34
BIOS CONFIGURATION OPTIONS .....................................................................35
DRIVER INSTALLATION ......................................................................................37
WINDOWS OPERATING SYSTEM REINSTALLATION ......................................37
WINDOWS 10 IoT ENTERPRISE 2019 LTSC......................................................37
WONDERWARE / AVEVA™ EDGE .....................................................................37
AEX-2400 SERIES BOX PC ..........................................................................................38
OVERVIEW...........................................................................................................38
SPECIFICATIONS AND DIMENSIONAL OUTLINES...........................................39
I/O PORTS AND CABLES ....................................................................................40
MOUNTING OPTIONS .........................................................................................43
BIOS CONFIGURATION OPTIONS .....................................................................44
DRIVER INSTALLATION ......................................................................................46
WINDOWS OPERATING SYSTEM REINSTALLATION ......................................46
WINDOWS 10 IoT ENTERPRISE 2019 LTSC......................................................46
WONDERWARE / AVEVA™ EDGE .....................................................................46

Operations Manual: AEx Series 3
Operations Manual: AEx Series 3
COPYRIGHT NOTICE
This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of
the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of
Maple Systems equipment, is prohibited without the specific written permission of Maple Systems.
WARRANTY
Warranty Statements are included with each unit at the time of purchase and are available at
www.maplesystems.com.
TECHNICAL SUPPORT
This manual is designed to provide the necessary information for trouble-free installation and operation of your new
Maple Systems AEx Series Product. However, if you need assistance, please contact Maple Systems:
•Phone: [phone]
•Email: [email protected]
•Web: http://www.maplesystems.com
UNPACKING THE UNIT
Carefully unpack the equipment and check all material in the container against the packing list. Maple Systems will
not accept responsibility for shortages against the packing list unless notified within 30 days. The equipment and
accessories were inspected and tested by Maple Systems before shipment.
Examine the equipment carefully; if any shipping damage is evident, notify the carrier immediately. Maple Systems is
not responsible for claim negotiations with the carrier.
Save the shipping container and packing material in case the equipment needs to be stored, returned to Maple
Systems, or transported for any reason.
Packing List: AEx-100 Series
AEx-100 Series Industrial Projected Capacitive Touch Monitor
DC Power Cable (M12 to leads – 5’ and 15’)
OSD Controller (with 10’ cable extension)
I/O Cables:
USB 2.0 Cable (M12 to 2x USB 2.0 Type A, 10’)
VGA Cable (M12 to VGA, 10’)
Packing List: AEx-800 Series / AEx-900 Series
AEx-800/900 Series Industrial Panel PC
DC Power Connector (M12 to leads – 5’ and 15’)
I/O Cables:
USB 2.0 Cable (M12 to 2x USB 2.0 Type A, 10’)
VGA Cable (M12 to VGA, 10’)
Ethernet Cable x2 (M12 to RJ45 Ethernet, 10’)
Serial Cable (M12 to DE9, 10’)
Packing List: AEx-2400 Series
AEx-2400 Series Industrial Box PC
DC Power Connector (M12 to leads – 5’ and 15’)
I/O Cables:
USB 2.0 Cable (M12 to 2x USB 2.0 Type A, 10’)
VGA Cable (M12 to VGA, 10’)
Ethernet Cable x2 (M12 to RJ45 Ethernet, 10’)
Serial Cable (M12 to DE9, 10’)

Operations Manual: AEx Series 4
Operations Manual: AEx Series 4
SAFETY PRECAUTIONS
Please observe the following precautions when installing the AEX- Series units. Failure to comply with these
restrictions could result in loss of life, serious personal injury, or equipment damage.
Warning: Disconnect this equipment from any power before cleaning. Do not use liquid or
spray detergents for cleaning. Use a damp cloth.
Warning: Keep this equipment away from humidity.
Warning: Before applying power to the unit make sure the voltage of the power source is
within the input voltage rating of the unit.
Warning: Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
Warning: Never open the equipment and do not operate equipment with its back cover
removed- there are dangerous high voltages present inside. For safety reasons, the equipment
should be opened only by a qualified service technician.
Warning: This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instruction manual, it may cause interference to radio
communications. It has been tested and found to comply with the limits for a Class A computing
device pursuant to FCC Rules, which are designed to provide reasonable protection against
such interference when operated in a commercial environment. Operation of this equipment in
a residential area is likely to cause interference in which case the user at his own expense will
be required to take whatever measures may be required to correct the interference.
Warning: If any of the following situations arise, get the equipment checked by qualified
service personnel.
•The power cord or plug is damaged.
•Liquid has penetrated the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well, or you cannot get it to work according to this manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Warning: Do not leave this equipment in an uncontrolled environment where the storage
temperature is below -30°C (-22°F) or above 70°C (158°F). It may damage the equipment.

Operations Manual: AEx Series 5
Operations Manual: AEx Series 5
AEX-100 SERIES MONITORS
OVERVIEW
The AEx-100 Series Industrial Projected Capacitive Touch Monitor is available in 15.0” and 19.0” screen
sizes. The AEx-100 Series monitors are constructed of 316 Stainless Steel and are ideal for use in
hazardous locations thanks to their CSA Class I, Division 2, Class II Division 2, Class III, and
ATEX/IECEx Zone 2, Zone 22 certifications.
The AEx-100 Series Monitors are IP66 rated and can operate in extended temperature (-20~60°C)
environments, as well as locations where high brightness is a requirement. AEx-100 Series monitors
feature high brightness, sunlight readable displays (1000 Nits) via their optically bonded construction.
The AEx-100 Series feature Projected Capacitive Touch Screens, which allow for a more natural, intuitive
user touch experience compared to traditional analog-resistive touch screen terminals. Benefits of
projected capacitive touchscreens include multi-touch response (pinch and zoom functionality) and
personal tablet-like operation. Finally, projected capacitive touchscreens do not require calibration.

Operations Manual: AEx Series 6
Operations Manual: AEx Series 6
SPECIFICATIONS AND DIMENSIONAL OUTLINES
AT A GLANCE:
SPECIFICATIONS:
Connector Type
M12, with waterproof cover and tether chain*
Audio
N/A
Power
1 x M12 3-pin for DC power input (leads)*
Display Interface
1 x M12 12-pin for VGA*
USB
1 x M12 8-pin for 2 x USB 2.0 type A*
I/O Ports
On-Screen Display
1 x M12 8-pin for External OSD Controller Box
Type
Projected Capacitive
Interface
USB
Touch Screen
Light Transmission
90+%
Display Type
15.0” XGA TFT LCD
19.0” SXGA TFT LCD
Resolution
1024 x 768
1280 x 1024
Max. Color
262K
16.7M
Luminance (cd/m²)
1000
1000
Display
View Angle (H°/V°)
160/140
170/160
Contrast Ratio
800:1
1000:1
Backlight Lifetime (hrs)
50,000+
70,000+
Input Voltage
9-36 VDC
9-36 VDC
Input Current
0.63-2.53 A
1.34-5.37 A
Electrical
Input Power
22.8 W
48.3 W
Dimension
(W x H x D)
15.71 x 12.76 x 2.76 inches
[399 x 324 x 70 mm]
18.50 x 15.30 x 2.95 inches
[470 x 388.6 x 75 mm]
Net Weight
Approx. 18.74 lbs [8.5 kg]
Approx. 25.35 lbs [11.5 kg]
Mechanical
Construction
316 Stainless Steel Chassis
Mounting
VESA 100 x 100 mm
Operating Temperature
-4~140°F [-20~60°C]
Storage Temperature
-22~158°F [-30~70°C]
Relative Humidity
10 to 95% @ 40°C, non-condensing
Rating
IP66
Environmental
Certifications
ATEX / IECEx Zone 2 Ex ec ic IIC T4 Gc
ATEX / IECEx Zone 22 Ex tc IIIC T135°C Dc
Class I Division 2 Group A, B, C, D, T4
Class II Division 2 Group F, G, T135°C
Class III
ANSI/ISA 12.12-01-2013
CSA Std. C22 No213-1987, C22.2 No.61010
CE / FCC Class A / RoHS
Notes
* AEx units come provided with the following I/O cables; M12 waterproof connectors for PC side, other end of
I/O cable is corresponding specified connector type:
•1x USB 2.0 Type A
•1x VGA
•1x Power cable
•1x OSD (On-Screen Display) Controller
I/O cable length: 10’, Power cable length: 15’
Specifications subject to change without notice.
•CSA C1D2, C2D2, C3, ATEX / IECEx Zone 2, Zone 22
Certified for Use in Harsh Environments
•High Brightness Sunlight Readable (1000 Nits)
Optically Bonded TFT LCD
•Extended Operating Temperature (-20~60°C)
•316 Stainless Steel Chassis with IP66 Rating on All Sides
•Included 10’ External On-Screen Display Controller

Operations Manual: AEx Series 7
Operations Manual: AEx Series 7
DIMENSIONS: AEx-115PH
A
VESA 100 x 100 mm Screw Holes
B
M12 USB 2.0 Touch Connector
C
M12 VGA Connector
D
M12 External On-Screen Display
Controller
E
M12 VDC Power Connector

Operations Manual: AEx Series 8
Operations Manual: AEx Series 8
DIMENSIONS: AEx-119PH
A
VESA 100 x 100 mm Screw Holes
B
M12 USB 2.0 Touch Connector
C
M12 VGA Connector
D
M12 External On-Screen Display
Controller
E
M12 VDC Power Connector

Operations Manual: AEx Series 9
Operations Manual: AEx Series 9
I/O PORTS AND CABLES
The below section provides information on the I/O connectors and cables for your AEx-100 Series
Monitor. All connections at the monitor are M12 style; M12 connections are durable, rugged, and carry
an IP67 rating against dust and water intrusion. AEx- Series Monitors come with one of each of the
below cables (unless specified otherwise).
POWER INPUT (9-36 VDC):
Your AEx-100 Series Monitor comes with both a 1M (~3’) cable (7431-0134) as well as a 5M (~15’) DC
power input cable (7431-0129). 3’ DC power cable drawing shown above.
VGA:
VGA cable allows for connection to your PC, enabling the AEx-100 Series monitor to display the signals
from your PC VGA output device.

Operations Manual: AEx Series 10
Operations Manual: AEx Series 10
USB (TOUCH CONTROL OPERATION):.
To enable the AEx-100 Series’ touch functionality, this USB cable must be plugged into a USB 2.0 (or
better) port of your PC.
ON-SCREEN DISPLAY (OSD) CONTROLLER:
The On-Screen Display Controller is used to adjust the operational parameters of the OSD menu.

Operations Manual: AEx Series 11
Operations Manual: AEx Series 11
ON-SCREEN DISPLAY (OSD) OPERATION
Your AEx-100 Series Monitor has Power and On-Screen Display (OSD) buttons located on the On-
Screen Display Controller. If the monitor is powered on, but does not have an active connection to a
computer, the power indicator will illuminate RED. When there is an active PC connection, the power
indicator will illuminate GREEN.
The table below shows the buttons and their respective operations.
Button
Function with OSD menu active
Function with OSD menu inactive
Turns the power ON or OFF
Turns the power ON or OFF
This button scrolls left through
submenus. In a submenu, this button
increases the selected parameter value.
Adjust brightness value of the monitor
downward (decrease display brightness)
Scrolls right through submenus. In a
submenu, this button decreases the
selected parameter value.
Adjust brightness value of the monitor
upward (increase display brightness)
If an OSD menu parameter is highlighted,
pressing this button will select the
highlighted menu item/icon and enter the
parameter adjustment submenu.
If there is no highlighted parameter, this
button is used to exit the On-Screen
Display menu.
Enters the On-Screen Display menu.
Acts as the “Enter” key when selecting a
submenu.
Opens the input menu to allow change of
display input connection.
Auto Adjust
Menu/Enter
Up/Left
Down/Right
Power
Indicator
Power
Button

Operations Manual: AEx Series 12
Operations Manual: AEx Series 12
OSD MENU PARAMETERS AND OPTIONS
MAIN MENU
This is the initial OSD menu that shows up when the button is pressed.
PICTURE MENU
In the Picture menu, the following parameters can be adjusted:
•Backlight
•Brightness
•Contrast
•Sharpness
•(Exit to Main Menu)
DISPLAY MENU
In the Display menu, the following parameters can be adjusted:
•Auto Adjustment
•H Position (Horizontal)
•V Position (Vertical)
•Pixel Clock
•Phase
•(Exit to Main Menu)

Operations Manual: AEx Series 13
Operations Manual: AEx Series 13
COLOR MENU
In the Color menu, the following parameters can be adjusted:
•Gamma
•Color Temperature
•Color Effect
•(Exit to Main Menu)
ADVANCE MENU
In the Advance menu, the following parameter can be adjusted:
•Aspect Ratio
•(Exit to Main Menu)

Operations Manual: AEx Series 14
Operations Manual: AEx Series 14
INPUT MENU
In the Input menu, the following parameters are shown:
•Auto Select
•VGA
•DP (DisplayPort)
•DVI
•(Exit to Main Menu)
Note: AEx-100 Series Monitors use VGA Input only.
AUDIO MENU
In the Audio menu, the following parameters are shown:
•Volume
•Mute
•(Exit to Main Menu)

Operations Manual: AEx Series 15
Operations Manual: AEx Series 15
OTHER MENU
In the Other menu, the following parameters can be adjusted:
•Reset
•Menu Time
•OSD H Position
•OSD V Position
•Language
•Transparency
•Rotate
•(Exit to Main Menu)
INFORMATION MENU
The Information menu provides information of the current PC connection. Selecting Exit will exit the OSD
menu.

Operations Manual: AEx Series 16
Operations Manual: AEx Series 16
MOUNTING OPTIONS
The AEx-100 Series offer VESA mounting as an option. VESA 100 x 100mm threaded inserts are
located on the rear of the unit. Use M4 threaded mounting screws included with the VESA mounting
hardware to mount the AEx-100 Series as illustrated in the figure below.
Use VESA mounting hardware suitable for your intended application; Maple Systems is not responsible
for damage to unit, mounting surface, or to other components caused by improper mounting.
PC CONNECTION
You will need to connect your AEx-100 Series unit to a PC. Use the included VGA and USB Cables to
connect your monitor and PC. When connected to a computer running a Windows®8.x or 10 Operating
System, there are no additional drivers required for operation. Your MON6000AP Series monitor uses
standard Windows®HID (Human Interface Device) Drivers.
CONNECTING YOUR MONITOR TO A PC
1. Be sure all equipment is powered off.
2. Connect one end of your power cable to the power connector on the monitor, and the other end to
the VDC output of your power supply.
3. Connect the M12 connector of the VGA cable to the input connector on the monitor, the other end
to the VGA connector on your PC.
4. If touch operation from the monitor is desired, plug the “rectangular end” of the included USB cable
to a USB port of your PC.
5. Apply power to your monitor and PC. Your monitor should now be displaying your PC desktop.

Operations Manual: AEx Series 17
Operations Manual: AEx Series 17
AEX-800 SERIES PANEL PC
OVERVIEW
The AEx-800 Series Industrial Projected Capacitive Panel PC is available in 15.0” and 19.0” screen sizes.
The AEx-800 Series Panel PCs are constructed of 316 Stainless Steel and are ideal for use in hazardous
locations thanks to their CSA Class I, Division 2, Class II Division 2, Class III, and ATEX/IECEx Zone 2,
Zone 22 certifications.
AEx-800 Series Panel PCs are powered by Intel® Celeron™ N2900 Quad-Core Processors, running at
1.83GHz. They come with 8GB of onboard DDR3L 1333MHz RAM, and have both a 128GB 2.5” MLC
SATA III SSD as well as a 64GB mSATA MLC SSD.
The AEx-800 Series Panel PCs are IP66 rated and can operate in extended temperature (-20~60°C)
environments, as well as locations where high brightness is a requirement. AEx-800 Series Panel PCs
feature high brightness, sunlight readable displays (1000 Nits) via their optically bonded construction.
The AEx-800 Series feature Projected Capacitive Touch Screens, which allow for a more natural, intuitive
user touch experience compared to traditional analog-resistive touch screen terminals. Benefits of
projected capacitive touchscreens include multi-touch response (pinch and zoom functionality) and
personal tablet-like operation. Finally, projected capacitive touchscreens do not require calibration.

Operations Manual: AEx Series 18
Operations Manual: AEx Series 18
SPECIFICATIONS AND DIMENSIONAL OUTLINES
AT A GLANCE:
SPECIFICATIONS:
CPU
Intel®Celeron™N2930 Quad-Core 1.83GHz Processor
System Chipset
SoC
System
System Memory
Onboard DDR3L 8 GB 1333 MHz
Connector Type
M12, with waterproof cover and tether chain*
USB
1 x M12 8-pin for 2 x USB 2.0 type A*
Serial
1 x M12 8-pin for RS-232/422/485, DE-9, COM1 (default RS-232)*
Audio
N/A
Graphics
1 x M12 12-pin for VGA*
LAN
2 x M12 8-pin for RJ-45*
Power
1 x M12 3-pin for DC power input (leads)*
I/O Ports
Remote Power Switch
N/A
Type
Projected Capacitive
Interface
USB (Internal)
Touch Screen
Light Transmission
90+%
Display Type
15.0” XGA TFT LCD
19.0” SXGA TFT LCD
Max. Resolution
1024 x 768
1280 x 1024
Max. Color
262K
16.7M
Luminance (cd/m²)
1000
1000
View Angle (H°/V°)
160/140
170/160
Contrast Ratio
800:1
1000:1
Display
Backlight Lifetime (hrs)
50,000+
70,000+
Internal Storage Device
1 x 128 GB 2.5” SATA III, MLC SSD
1 x 64 GB mSATA MLC SSD
Storage
SD Card Slot
N/A
Input Voltage
9-36 VDC
9-36 VDC
Input Current
1.12-4.48 A
1.83-7.31 A
Electrical
Input Power (max.)
40.3 W
65.8 W
Dimensions (W x H x D)
15.71 x 12.76 x 2.76 inches
[399 x 324 x 70 mm]
18.50 x 15.30 x 2.95 inches
[470 x 388.6 x 75 mm]
Net Weight
Approx. 21.61 lbs [9.8 kg]
Approx. 27.12 lbs [12.3 kg]
Mounting
VESA 100 x 100 mm
Mechanical
Construction
316 Stainless Steel Chassis
Operating Temperature
-4~140°F [-20~60°C]
Storage Temperature
-22~158°F [-30~70°C]
Relative Humidity
10 to 95% @ 40°C, non-condensing
Rating
IP66
Environmental
Certifications
ATEX / IECEx Zone 2 Ex ec ic IIC T4 Gc
ATEX / IECEx Zone 22 Ex tc IIIC T135°C Dc
Class I Division 2 Group A, B, C, D, T4
Class II Division 2 Group F, G, T135°C
Class III
ANSI/ISA 12.12-01-2013
CSA Std. C22 No213-1987, C22.2 No.61010
CE / FCC Class A / RoHS
Operating System
Microsoft Windows
Microsoft WIndows©10 IoT Enterprise 2019 LTSC 64-bit (PKEA)
Notes
* AEx units come provided with the following I/O cables; M12 waterproof connectors for PC side, other end
of I/O cable is corresponding specified connector type:
•1x DE-9
•1x VGA
•1x USB 2.0 Type A
•2x RJ-45
I/O cable length: 10’, Power cable length: 15’
Specifications subject to change without notice.
•CSA C1D2, C2D2, C3, ATEX / IECEx Zone 2, Zone 22
Certified for Use in Harsh Environments
•High Brightness Sunlight Readable (1000 Nits) Optically
Bonded TFT LCD
•Extended Operating Temperature (-20~60°C)
•316 Stainless Steel Chassis with IP66 Rating on All Sides
•Microsoft Windows®10 IoT 2019 Operating System

Operations Manual: AEx Series 19
Operations Manual: AEx Series 19
DIMENSIONS: AEx-815PH
A
VESA 100 x 100 mm Screw Holes
B
M12 VDC Power Connector
C
M12 LAN Connector
D
M12 USB 2.0 Connector
E
M12 COM1 Connector
F
M12 LAN Connector
G
M12 VGA Connector

Operations Manual: AEx Series 20
Operations Manual: AEx Series 20
DIMENSIONS: AEx-819PH
A
VESA 100 x 100 mm Screw Holes
B
M12 VDC Power Connector
C
M12 LAN Connector
D
M12 USB 2.0 Connector
E
M12 COM1 Connector
F
M12 LAN Connector
G
M12 VGA Connector
