101-1036: Mark 7® DecapSense APEX 10 /Evolution /
Revolution
Instruction Manual V 1.1
Read this manual completely. Understand all safety and operating instructions. Failure to
comply with the warnings and instructions may result in serious injury, illness or death.

2
DecapSense Evolution/Revolution User Manual Version 1.1
Package Contents
Please review these contents and inform us right away if you appear to be missing any of these items:
Item No.
Description
QTY
1
DecapSense –APEX10/EVO/Rev
1
2
8-32 x 5/16” Socket Cap Screw
2
3
Primer Offload Hose
1
1
2
3

DECAPSENSE EVOLUTION/REVOLUTION USER MANUAL VERSION 1.1
3
Set-Up Procedures:
1. Install sensor underneath station #2 using hardware included.
Figure 1: DECAPSense® with Hose Installed
Operating Instructions:
1. Locate DECAPSense underneath station #2.
2. Hook up the 3/8” Clear Tube to the bottom the DECAPsense to catch spent primers as they are
decapped.
3. Calibrate and run the machine as normal. On the “Sensors tab,” make sure DECAPSense® is enabled
(Highlighted Green.) See Figure #3. When a spent primer is not ejected the following notification box
will appear:
After you rectify the issue press “Ok” and proceed with normal operation.
2X 8-32 x 5/16” Cap
Screw
3/8” Clear Tube
DecapSense Assembly

4
DecapSense Evolution/Revolution User Manual Version 1.1
4. As with all sensors the DecapSense can be enabled or disabled on the Sensors Tab screen.
5. During operation the optical sensor may become dirty and require cleaning. The following notification
box MAY appear when cleaning is required:
6. Remove the case in station #2. Use an air can or compressed air and blast air down through the shell
plate and thru the sensor.

DECAPSENSE EVOLUTION/REVOLUTION USER MANUAL VERSION 1.1
5
Troubleshooting
Refer to the knowledge base section on our website under SUPPORT for troubleshooting articles relating
to setup and operation.
http://www.markvii-loading.com/knowledgebase
Please contact us for technical support
Phone: [phone]
Hours: 9:00am-4:30pm, ET, M–F
