Mark Gekko Vario User manual

MARK Save A Life GmbH
Gleinkerau 23
4582 Spital am Pyhrn
Österreich / Europa
Tel [phone] - 111
Fax [phone] - 111
[email protected]t
www.savealife.at
MARK Gekko Vario Instruction manual
Anchor point • Personal protective equipment (PPE) against falls from a height
EN 795: 2012 Class A1
TS 16415: 2013
English translation of the original German instruction manual
Keep for future reference
Version 1.3


NOTE
Making
your life
safer.
Dear Customer,
Thank you very much for buying this product. We have manufactured and tested it with
the utmost care, keeping to the strictest quality guidelines. In doing so, we have laid the
foundations for a safe product, but now it is over to you to make sure it is used correctly.
You must read this instruction manual carefully to ensure you are able to use the prod-
uct properly and safely. Always follow all hazard warnings and safety notices in the
relevant sections of these instructions.
You may only use this product if you are physically and mentally capable of doing so and
have read and understood this instruction manual.
Always keep the instruction manual, the installation report and the inspection report to-
gether with the other relevant product documents for future reference. If the instruction
manual and the inspection report are lost or have become unusable, you can download
the latest versions of these documents from www.savealife.at.
Do you have questions about this product? Do you have any requests or suggestions?
Just give us a call or send us an email!
Customer Service
MARK Save A Life GmbH
Gleinkerau 23
4582 Spital am Pyhrn
Austria/Europe
Tel. [phone]
Fax [phone]
[email protected]t
www.savealife.at
Manufacturer
MARK Save A Life GmbH, Gleinkerau 23, 4582 Spital am Pyhrn, Austria/Europe
Country of origin
Austria
Copyright
MARK Save A Life GmbH, Gleinkerau 23, 4582 Spital am Pyhrn, Austria/Europe

 FOR YOUR SAFETY 
1.1 Symbols used 5
1.2 Requirements of the user 6
1.3 Visual and functional inspection 6
1.4 Use 6
1.5 Storage and transport 7
1.6 Maintenance 7
1.7 Accidents - rescue plan 7
 PRODUCT DESCRIPTION 
2.1 Technical data 8
2.2 Labelling 8
2.3 Scope of delivery 8
2.4 Accessories 9
2.5 Redundancy 9
2.6 Rescue operations 9
2.7 Overload 9
2.8 Temperature range 9
 USE 
3.1 Intended use 10
3.1.1 Anchor device according to EN 795 Class A1 10
3.1.2 Multiple use 10
3.2 Anchor point 11
3.3 Service life and duration of use 11
 INSTALLATION 
4.1.1 Concrete 13
4.1.2 Brick 14
4.1.3 Wood 15
4.1.4 Steel 16
 TRANSPORT AND STORAGE 
 MAINTENANCE 
6.1 Repairs 17
6.2 Cleaning 17
 CHECKS 
7.1 Visual and functional inspection 18
7.2 Periodic inspections 19
 DISPOSAL 
 RESALE 
 ACCIDENTS 
10.1 Suspension trauma 20

Screw
Housing
Buckle
Base plate
Screw
Lock
Figure 1
Trained by MARK Save A Life. The competent per-
son is authorised to inspect the product for proper
function.
MARK Gekko, MARK Boa or another anchor device
that meets the applicable technical standards for
PPE against falls from a hight.
MARK Falcon, MARK Hawk, MARK Elephant,
MARK Elephant Hub or a descender/rescue device
that meets the applicable requirements of the
Regulation on PPE.
COMPETENT PERSON
ANCHOR DEVICE
DESCENDER/RESCUE DEVICE
DEFINITIONS
Where only male pronouns are used in the interest of making this document easier to
read, the intent is always to include both sexes.

 LEGAL INFORMATIONEN 
11.1 Declaration of compliance 21
11.2 Exclusion of product liability 21
11.3 Copyright notice 21
11.4 Trademark notice 21
 DECLARATION OF CONFORMITY 
 INSTALLATION REPORT 
 INSPECTION REPORT 
DANGER
WARNING
CAUTION

 FOR YOUR SAFETY
Activities that require use of this product can often be dangerous and there are many
potential ways of using it incorrectly; however, it is not possible for us to state them all
here or even to come up with an exhaustive list.
This instruction manual contains information pertaining to the safety and function of
MARK Gekko Vario and its applications. However, the information and instruction here-
in are no substitute for experience, personal responsibility and knowledge, nor do they
release the user from his own individual risk.
You will find detailed safety regulations and related descriptions in this chapter and be-
fore the sections concerned. These safety instructions must be read and understood
before using this product. Do not hesitate to contact MARK Save A Life if anything is
unclear.
This is a state-of-the-art product that meets the applicable technical standards for PPE
and the requirements of the Austrian PPE Safety Regulation.
1.1 Symbols used
This instruction manual contains safety regulations in the following categories:
DANGER, WARNING, CAUTION and NOTE. Always observe these safety regula-
tions to prevent personal injury or damage to the product.
DANGER indicates an imminent hazard that will lead to very severe injury or death.
• To avoid very severe injury or fatal accidents, it is essential that you comply with all
safety notices bearing this hazard warning symbol.
WARNING indicates a potentially dangerous situation that could lead to severe
injury or death.
• To avoid potentially fatal accidents or serious injury, it is essential that you comply
with all safety notices bearing this hazard warning symbol.
CAUTION indicates a potentially dangerous situation that could lead to minor or
moderate injury.
• To avoid minor to moderate injury, it is essential that you comply with all safety notic-
es bearing this hazard warning symbol.
NOTE indicates a potentially detrimental situation that could lead to the product
or another object in its vicinity becoming damaged.
• Information about this product is also identified by the text NOTE. To avoid possible
product or material damage, it is essential that you follow all such notes.
NOTE


1.2 Requirements of the user
• Read the instruction manual carefully before you use this product.
You may only use this product once you have read and understood the instruction
manual.
• Only use this product as an anchor point for personal protective equipment.
• This product may only be used by two people simultaneously under certain circum-
stances.
• Only use this product if you are in good physical and mental health.
1.3 Visual and functional inspection
• The visual and functional inspection must be carried out by MARK Save A Life or a
competent person. MARK Save A Life oers ‘competent person' training.
• This product must be inspected for proper function before and after each use (e.g.
for any damage to the buckle).
• After it has been subjected to a heavy load (for instance, from a person falling when
attached to a rope fastened to the anchor point), the product must be properly
disposed of (e.g. by disconnecting and removing the buckle).
• If for any reason it seems unsafe to continue using this product (if the buckle is dam-
aged, for example), under no circumstances should it be used again; instead, dispose
of it properly and replace it with a new one.
• The inspection report must be completed in full. The details of every inspection must
be entered.
1.4 Use
• The product has an unlimited service life.
• Protect the product from sharp-edged objects, welding sparks, sources of fire, chem-
icals, oils, acids, etc.
• This product may only be used in conjunction with tested (certified) and approved
accessories that meet the applicable technical standards for PPE and the require-
ments of the Austrian PPE Safety Regulation (PSA-Sicherheitsverordnung).
• The product may only be sold on to a third party if it is supplied together with instruc-
tion manual in the relevant national language.
1.5 Storage and transport
• Always store this product in a clean and dry place, where it is protected from
mechanical hazards (e.g. sharp-edged objects) and the influence of chemicals (e.g.
acids, alkalis).
• Transport and store this product in the packaging supplied or equivalent packaging.
1.6 Maintenance
• If it is stored correctly and not subjected to a load, this product has an unlimited ser-
vice life. However, this service life may decrease drastically depending on the type of
use and external influences. This product may need to be replaced after just one use.
• Repairs to the product may only be carried out by MARK Save A Life.
• If this product has been subjected to a fall from a height, withdraw it from service.
• A competent person must inspect this product at least once a year. The result of the
inspection must be entered in the inspection report.
1.7 Accidents – rescue plan
• Suspension trauma can occur if a person falls whilst attached to a safety rope, has
to make a lengthy descent or is left ‘helplessly' hanging by a rope for a long period of
time.
• Before this product is used, a rescue plan must be drawn up that covers all rescue
measures for all possible emergency situations.
• Before each use, inspect the application area and the fall space; rectify, minimise or
make safe any hazards.


WARNING
2.1 Technical data
• Tested to EN 795: 2012 Class A1 and TS 16415: 2013
• Stainless steel, colour: stainless steel
• Weight (without screws): 144g
• Width: 50mm
• Length: 90mm
• Height: 14mm
• Hole/screw spacing: 38mm
• Number of users: 1 person
2 people (depending on base and installation position,
see Table 4.1)
2.2 Labelling
• We recommend that you give your product an inventory number and enter it in the
inspection sheet.
• Do not remove any stickers or labels from your product!
 PRODUCT DESCRIPTION
Designation
EN test number
Year of manufacture
CE
Number of users Read instruction manual
2.3 Scope of delivery (see Figure 1)
1x MARK Gekko (base plate, housing, buckle)
2x screws/bolts (incl. nuts)
1x box
1x instruction manual incl. installation report and inspection report
2.4 Accessories
Must not be combined with non-tested or non-approved accessories.
• Only use this product in conjunction with tested accessories or those recommended
by MARK Save A Life that meet the applicable technical standards for PPE and the
requirements of the Austrian PPE Safety Regulation.
Classed as tested accessories:
Descender and rescue devices
Lifting devices
Retractable fall arrest blocks
Guided-type fall arresters on fixed anchor lines
Guided-type fall arresters on flexible anchor lines
Rescue overalls
Energy absorbers
Carabiners
Anchor points
Safety harnesses
Connectors
The accessories listed above can also be viewed at www.savealife.at. You can give us a
ring or send us an email too, we’d be delighted to advise you!
EN 341
EN 1496
EN 360
EN 353-1
EN 353-2
EN 1497
EN 355
EN 362
EN 795
EN 361
EN 354
2.5 Redundancy
Training is not an emergency situation. Generally speaking, a second safety device
should be employed for all exercises (redundancy). Unforeseeable events, technical
failure and human error can never be completely excluded! A second MARK Gekko can
fulfil the necessary redundancy function, for example.
2.6 Rescue operations
The anchor point must undergo a visual and functional inspection after each rescue
operation; only MARK Save A Life or a competent person may perform this inspection.
2.7 Overload
If anchor points have been subjected to stress from a fall or an overload, withdraw them
from future service.
2.8 Temperature range
This product can be used in a temperature range of -40°C to +150°C.


DANGER

WARNING
 USE
Activities that require use of this product can often be dangerous. Therefore, always ob-
serve the hazard warnings and safety notices in these instructions. Please contact us if
you have any doubts about anything or find the information dicult to understand.
3.1 Intended use
This product may only be used for people, i.e. to enable them to descend or be res-
cued,
or to protect them against falling from a height.
• This product may only be used for the purpose described in this instruction manual
and only in conjunction with tested (certified) and approved accessories that meet
the applicable technical standards for PPE and the requirements of the Austrian PPE
Safety Regulation. It must not be combined with other non-approved accessories, as
this could put your safety at risk.
Use
Using this product without first reading the instruction manual can result in acci-
dents that can lead to severe injury or even death.
• Read through the instruction manual carefully before you use this product.
• Please contact MARK Save A Life or a competent person if you have any doubts
about anything or find the information dicult to understand.
Inspection
Using this product without first inspecting it for damage and function can lead to
severe or fatal injury.
• Inspect this product for proper function before and after each use.
• If you think this product is no longer safe, you must not continue to use it.
This product can be used in a variety of ways in dierent situations. In order to master
all these possibilities, the user must be well briefed by a professional, competent person
who has been specifically trained in this product.
3.1.1 Anchor device according to EN 795 Class A1
The MARK Gekko anchor point is intended for use as an anchor device in conjunction
with personal protective equipment (PPE) recommended by MARK Save A Life.
3.1.2 Multiple use
The MARK Gekko anchor point is also suitable and approved for multiple use. If the
anchor point is removed carefully after having been used, it can then be reused later in
another location.
The anchor point must be inspected by a competent person before being installed
again.
The product must be re-installed according to the MARK Gekko Vario installation
instructions. Always create a corresponding installation report each time the product is
installed.
3.2 Anchor point
Attachment to the anchor point
If a person is not connected to the anchor point properly, then a fall from a height
can result in severe injury or even death.
• Inspect the anchor point at least once a year.
• Only use anchor points that meet the applicable technical standards for PPE and the
requirements of the Austrian PPE Safety Regulation.
Anchor points are needed in locations where people may fall from a height. The de-
signers or constructors of buildings or installations are responsible for positioning the
anchor points, which must be done according to the applicable statutory regulations,
standards and guidelines that apply.
The structural fabric of the building or installation must be suitable for the intended
load-bearing capacity. According to standards, the following (static) loads are introduced
into the structure via anchor points:
• Restraint system 4 kN
• Fall arrest system 10 kN
3.3 Service life and duration of use
In principle, this product has an unlimited service life. In practice, however, its duration
of use depends on several factors. Extreme operating conditions, environmental factors,
contamination, damage, storage and transport can all aect the service life of this
product.
The product features a fall indicator, which clearly shows whether the anchor device has
been subjected to the stress of a fall and must therefore be disposed of as per Point 8.
The visual and functional inspection described in Point 7.1 shows every user whether
the anchor device has been deformed by a previous fall and therefore can no longer be
used.
If the anchor point buckle will no longer engage easily in its home position or move
easily from its home position to its working position, then the anchor device has been
deformed by a previous fall and must no longer be used.
If it seems unsafe to continue using this product, you must not use it again under any
circumstances; instead, ensure it can no longer be used and replace it with a new anchor
point.

Installation in solid wood/engineered wood
Installation in concrete/reinforced concrete/hollow concrete/solid brick/sand-lime brick
Installation in steel
1. Drill holes
1. Drill holes
1. Drill holes 2. Install MARK Gekko Vario
2. Install MARK Gekko Vario
4. Install MARK Gekko
Vario
2. Clean holes 3. Fill holes with injection
mortar
Discard initial mortar
Screws:
talternating rotary mo-
tion when pressing
Caution: Do not over-tighten screws!
NOTE

 INSTALLATION
This product may only be installed in accordance with the instructions in these instruc-
tion manual and with the installation materials (screws, mortar) supplied by MARK
Save A Life . MARK Save A Life recommends it is installed by a specialist company.
4.1.1 Concrete
65Nm
Video instructions for correct assembly are provided and must be followed! It is neces-
sary to contact MARK Save A Life GmbH!
NOTE
If the substrate cannot be clearly identified, a pull-out test or a substrate test must be
carried out in accordance with EN 795 or TS 16415
WARNING

Hollow concrete Reinforced concrete
Certification EN 795 : 2012 class A1, TS 16415 : 2013 EN 795 : 2012 class A1, TS 16415 : 2013
Screws NIRO M10 A2-80
ø 10 x 160mm
NIRO M10 A2-80
ø 10 x 100mm
Drill Masonry drill
ø 12mm
Setting depth in the load-bearing
subsurface ≥80mm
Quality and installation base ≥C20/25 cracked reinforced concrete
Composite mortar Würth WIT-VM250, Fischer FIS AB 300T, Hilti HIT-HY 170
Remarks Clean the boreholes with a perforated brush and blow them out according to the
manufacturer’s instructions and instructions for use of the adhesive
Distance from edge ≥200mm ≥55mm
Installation base Drilled holes in concrete core
Deformation Maximum expected deformation due to
a fall from a height ≤50mm
Maximum expected deformation due to
a fall from a height ≤50mm
Permissible installation positions
Number of users: 1 person
Number of users: 2 persons

4.1.2 Brick 4.1.3 Wood
Solid brick
Certification EN 795 : 2012 class A1
Screws NIRO M10 A2-80
ø 10 x 160mm
Drill Masonry drill
ø 12mm
Setting depth in the load-bearing
subsurface ≥140mm
Quality and installation base ≥35 N/mm²
Composite mortar Würth WIT-VM250, Fischer FIS AB
300T, Hilti HIT-HY 170
Remarks BClean the boreholes with a perforated
brush and blow them out
Distance from edge ≥200mm
Installation base Drilled holes in the load-bearing brick
Deformation Maximum expected deformation due to
a fall from a height ≤50mm
Permissible installation positions
Number of users: 1 person
 
Solid wood
wall/ceiling
Certification EN 795 : 2012 class A1, TS 16415 : 2013
Screws Stainless-steel wood screws
NIRO A2-80, ø 10 x 100mm
Drill Wood drill bit
ø 6mm
Setting depth in the load-bearing
subsurface ≥80mm
Quality and installation base C24 (S10), ≥CLT 100
Remarks Pre-drill holes
ø 6mm / 60mm deep
Distance from edge ≥50mm
nstallation base Drill holes in solid wood
Deformation Maximum expected deformation due to
a fall from a height ≤50mm
Permissible installation positions
Number of users: 1 person
Number of users: 2 persons

NOTE
DANGER

4.1.4 Steel  TRANSPORT AND STORAGE
Always observe the information below to ensure safe transport and storage.
• Make sure that the packaging is dry and undamaged.
• Store this product in a clean and dry place, where it is protected from mechanical
hazards (e.g. sharp-edged objects) and the influence of chemicals
(e.g. acids, alkalis).
• Transport this product in the packaging supplied or equivalent packaging.
 MAINTENANCE
6.1 Repairs
Modifications to this product
Unauthorised repairs or extensions to the product, or tampering with it, can lead to
falls from a height and very serious accidents.
• Repairs (e.g. if screws are not seated securely in the installation base) may only be
performed by specialist companies.
• Only MARK Save A Life may modify this product or add to it.
If it seems unsafe to continue using this product, do not use it again under any circum-
stances; instead, have it inspected by MARK Save A Life or an authorised partner.
6.2 Cleaning
• Clean metal parts with a damp cloth.
• Never use chemical detergents.
Steel
Certification EN 795 : 2012 class A1, TS 16415 : 2013
Screws NIRO M10 A2-80
Length min. 35mm
Drill Metal drill bit
ø 11mm
Setting depth in the load-bearing
subsurface min. sheet thickness >3mm
Quality and installation base S 235 JR
Remarks Tightening torque
65 Nm
Distance from edge ≥25mm
Deformation Maximum expected deformation due to
a fall from a heigh ≤50mm
Permissible installation positions
Number of users: 1 person
Number of users: 2 persons


DANGER
NOTE
 
 CHECKS
Inspection
Using this product without first inspecting it for damage can lead to severe or fatal
injury.
• Inspect this product for proper function before and after each use.
• If you think this product is no longer safe, you must not continue to use it.
The inspection by MARK Save A Life or a competent person only applies on the condition
that, prior to the inspection:
• This product has not been subjected to stress from a fall.
• No components have been adapted or modified.
• This product was not exposed to temperatures below -40 °C or above +150 °C.
• No metal components have fallen on to a hard surface from a height of over 2m.
7.1 Visual and functional inspection
• An inspection must be carried out at least once a year by a competent person.
• The visual and functional inspection requires no involvement from external
testing authorities.
Test loads do not need to be attached.
• Check all parts for damage.
• Check that the product labels are legible.
• If the inspection indicates that it may be unsafe to continue using the product, you
must not use it again under any circumstances; instead, ensure it can no longer be
used (see Point 8) and replace it.
1. Move buckle out of
lock
3. Fold buckle down
after use
2. Fold buckle up into
working position
4. Move buckle into
lock
The MARK Gekko anchor point has been designed for tough working environments. To
preserve the product’s service life and performance, it needs to be handled carefully and
should undergo periodic inspections.
7.2 Periodic inspections
The result of this inspection must be entered in the inspection report.
The frequency of the inspection will depend on how often and how intensely the
product is used, as well as on the operating environment. If the product is subjected
to extremely heavy stress, the inspection must be performed more than once a year.
 DISPOSAL
When do you have to dispose of this product?
• If MARK Save A Life or a competent person has established that it would be unsafe
to continue using the product.
• If the visual and functional inspection has identified defects.
• If the buckle will no longer engage in the lock.
• If it seems unsafe to continue using the product.
• If there is deformation (e.g. caused by a fall or a heavy load).
• If there is damage (tears, cracks, etc.)
• If it no longer reflects the state of the art.
Dispose of this product in such a way that it cannot possibly be re-used or misused (e.g.
by disconnecting and removing the buckle).
Dispose of this product in an environmentally friendly manner, according to national
regulations and standards.
 RESALE
• To ensure it can be used correctly and safely, this product may only be re-sold to-
gether with the instruction manual and the inspection report.
• The purchaser must always have the instruction manual and inspection report availa-
ble in its respective ocial national language. This is the seller's responsibility.
 ACCIDENTS
The information below is designed to help you avoid accidents, but is no substitute for
experience, personal responsibility and knowledge, nor does it release you from your
own individual risk.
• An emergency plan must be drawn up that covers all rescue measures for any emer-
gency situation that may arise.
• Before each use of this product, inspect the application area and the fall space, and
minimise or make safe any hazards.

DANGER
As time passes
 
We recommend the following products to combat suspension trauma:
MARK Mammoth MARK Mammoth High-Vis
10.1 Suspension trauma
Suspension trauma
Suspension trauma (orthostatic shock) can occur if a person falls whilst attached
to a fall arrest system, has to make a lengthy descent or is left ‘helplessly' hanging
by a rope for a long period of time. Suspension trauma can cause lifelong damage to
health and can even be fatal.
• Make sure that the casualty is rescued quickly.
• Administer the correct first aid.
Initial signs of suspension trauma:
• Paleness
• Sweating
• Shortness of breath
• Initially, a rise in pulse and blood pressure
• Impaired vision
• Dizziness
• Nausea
• Later, a drop in pulse and blood pressure
Suspension trauma is a medical emergency.
• Call the emergency services immediately.
• Free the casualty from his suspended position as quickly as possible.
• Place the casualty on the floor (in a sitting or squatting position) with the upper body
elevated.
• Release the straps and any tight clothing.
• Always pay attention to the casualty’s circulation and breathing.
If the casualty is suspended in the fall arrest system but able to move, he should kick
one foot firmly against the bottom of the other and point the toes of the bottom foot
upwards, before switching feet. This will keep the blood circulating, albeit only for a
short time (a few minutes)! (Source: BG/GUV-I 869)
 LEGAL INFORMATION
• Do not remove any stickers or labels from this product.
• We recommend that you give this product an inventory number and enter it in the
inspection report.
11.1 Declaration of compliance
The manufacturer, MARK Save A Life GmbH, Gleinkerau 23, 4582 Spital am Pyhrn,
hereby declares that the product described below (‘MARK Gekko Vario’)
• complies with the safety regulations for personal protective equipment PPE (EU
Directive 89/686/EEC in the latest version) and has been designed according to the
following standards
EN 795: 2012 Class A1
• is identical to the PPE that was tested by the accredited and notified testing and
inspection authority and safety testing laboratory Allgemeine Unfallversicherungsan-
stalt, Adalbert-Stifter-Straße 65, 1200 Vienna, with number
PB 2017-4938
• has gone through the quality assurance system of the accredited and notified
testing and inspection authority and safety testing laboratory Allgemeine Unfallver-
sicherungsanstalt, Adalbert-Stifter-Straße 65, 1200 Vienna, with
ID number 0511
11.2 Exclusion of product liability
We accept no liability for direct, indirect or accidental consequences, nor any type of
damage arising from the use of this product or from incorrect information provided
by the competent inspector or installation engineer on the inspection report or the
installation report.
11.3 Copyright notice
The layout, graphics, pictograms and photographs, as well as all other text and image
content found in this instruction manual are protected by copyright.
11.4 Trademark notice
All trademarks are the property of their respective owners.

 DECLARATION OF CONFORMITY
 
 INSTALLATION REPORT
INSTALLATION REPORT
MARK Gekko Vario anchor point
Version (for technical details, see pp. 13–16)
Hollow concrete Solid wood
Reinforced concrete Engineered wood/
≥CLT
Solid brick Steel
To inspect Inspected/OK
Installation base
Fixed
With sucient static load-bearing capacity
Installation
Specified distance from edge observed
Prescribed screw-in depth acc. to instruction manual observed
Specified screws used
Any insulating layers or plaster coats taken into account
Photographs taken
MARK Gekko Vario
Securely anchored in installation base
No corrosion
No cracks
No deformation
Buckle can be opened by tapping it.
Buckle engages in the lock with little force.
Instruction manual
Available in full
Client
Responsible
party/contact
Signature,
company stamp
Contractor
Responsible
party/contact
Signature,
company stamp
Product MARK Gekko Vario anchor point Installation date
Batch number
(acc. to delivery note)
Comments:
Inventory number
Complete the installation report carefully!
Keep the installation report for future reference as per BauKG §8 !


 INSPECTION REPORT
2021 2022 2023 2024 2025 2026 2027 2028 2029 2030
1
2
3
4
5
6
7
8
9
10 
11 
12 
13 
Customer: Signature customer:
MARK Save A Life GmbH, Gleinkerau 23, A-4582 Spital am Pyhrn, [phone], [e-mail]
INSPECTION PROTOCOL/Visual inspection
Anchor point MARK Gekko Vario
Annual inspection
Remarks: Signature qualified person: Date of inspection: month/year
Anchor point is in proper condition
and can be used
Installation
Annually
Buckle folds back and locks again without increased effort
The anchor point is damaged or no longer functional and was made inoperative (by removing the buckle). The anchor point must be replaced. No corrosion at the anchor point visible No cracks or tears at the anchor point visible No deformation at the anchor point detectable
(If points 1-11 are checked, 12 can be checked as well - otherwise 13)
Result of the visual inspection
All screws checked for tightness
This product must be inspected at least once a year by a qualified person. Depending on the environment and intensity of use also more often. The inspection is subject to following conditions: The product has been
installed according to the user manual provided by the manufacturer, components of this product have not been modified or altered and it has not been exposed to temperatures below -40 °C or above + 150 °C. Fill in the inspection protocol carefully and keep it stored according to legal requirements.
Installation protocoll complete Substructure firm and stable Buckle can be folded out by tapping Photo record of installation available
Anchor point available and product identification readable
User manual available
Layout plan with position of anchor devices:
NOTES


MARK Save A Life GmbH
Gleinkerau 23
4582 Spital am Pyhrn
Österreich / Europa
Tel: [phone]
Fax: [phone]
[e-mail]
www.savealife.at
Subject to technical modifications. The
latest version shall always apply.
We only guarantee that our materials
are in perfect working order.
All rights reserved. It is only permitted
to make changes to, reprint or photo-
graphically reproduce this document,
in whole or in part, with the express
consent of MARK Save A Life GmbH,
Gleinkerau 23, 4582 Spital am Pyhrn,
Austria.
