Markes International ACTI-VOC C-LFP-01 User manual

ACTI-VOC™
QUI-1086
Version 6
May 2021
www.markes.com
Instruction for use
Product reference:
ACTI-VOC low-ow pump kit C-LFP-01

Page 2 www.markes.com
QUI-1086
Contents
1. Introduction .............................................................3
1.1 Notices.......................................................................4
1.2 Disclaimer..................................................................4
1.3 Important safety warnings .......................................4
1.4 Important information ..............................................5
1.5 Warranty ....................................................................6
1.6 Technical support contact details ..........................6
1.7 Certications.............................................................6
1.8 EU declaration of conformity....................................7
2. Components.............................................................8
3. Calibration................................................................10
4. Sampling ..................................................................12
4.1 Personal/workplace monitoring...............................12
4.2 Indoor air monitoring ................................................13
5. Maintenance............................................................14
5.1 Battery .......................................................................14
5.2 Pump lter .................................................................15
5.3 Back-pressure adapter O-ring..................................16
5.4 6 mm o.d. tubes .......................................................17
6. Parts list ...................................................................17
6.1 Accessories ...............................................................17
6.2 Spare parts................................................................17
7.  Specications.......................................................18
8. Contact details ........................................................19

Page 3
QUI-1086
www.markes.com
1. Introduction
ACTI-VOC™ (part no. C-LFP-01) is a robust low-ow pump for sampling volatile organic
compounds (VOCs) onto sorbent tubes for subsequent analysis by thermal
desorption (TD). Being lightweight, compact and intrinsically safe, ACTI-VOC is ideal
for personal, workplace and indoor air monitoring.
ACTI-VOC is optimised for sampling onto TD tubes, and automatically compensates
for different impedances, ensuring constant ow rates whatever the sorbent
packing. This automatic compensation prevents the need for re-calibration when
switching between tubes during sampling, minimising down-time – this makes it
ideal for use in Markes’ MTS-32™ multiple tube sampler (part no. MTS-32).
ACTI-VOC is compatible with industry-standard thermal desorption tubes and 6 mm
o.d. tubes, and samples in the region of 20–200 mL/min. ACTI-VOC can also be
used to sample air or gas into Tedlar® bags, and works perfectly with Markes’
SafeLok™ tubes.
Each ACTI-VOC ships with:
■PTFE tubing and TD tube adapter
■Back-pressure adapter, for use with ows up to 100 mL/min
■CapLok™ tool
■Tools for ow adjustment and maintenance
■Mains charger
■Adapter for bag sampling
■Convenient carry-case
■Instruction for use.

Page 4 www.markes.com
QUI-1086
1.1 Notices
This manual was prepared exclusively for users of the Markes International ACTI-VOC
low-ow pump for TD applications. The material within this manual is proprietary
information, and is to be used only to understand, operate, and maintain the
instrument. By receiving this document, the recipient agrees that neither this
document nor the information disclosed within nor any part thereof shall be
reproduced or transferred, physically, electronically or in any other form, or used or
disclosed to others for manufacturing or for any other purpose except as specically
authorised in writing by the manufacturer.
1.2 Disclaimer
The seller assumes no responsibility whatsoever, to any party whosoever, for any
property damage, personal injury, or death received by or resulting from, in whole, or
in part, the improper use, installation, or storage of this product by the user, person,
rm, entity, corporation or party not adhering to the instructions and warnings in this
manual, or otherwise provided by the seller or from not adhering to all federal, state,
and local environmental and occupational health and safety laws and regulations.
The seller shall not be liable for direct, indirect, consequential, incidental or other
damages resulting from the sale and use of any goods and sellers’ liability
hereunder shall be limited to repair or replacement of any goods found defective.
This warranty is in lieu of all other warranties, expressed or implied, including but not
limited to the implied warranties of merchantability and tness for use or for a
particular purpose which are expressly disclaimed.
1.3 Important safety warnings
Make sure you follow the precautionary notices presented in this manual. Safety and
other special notices appear in boxes and include the following:
WARNING This is the general warning safety symbol and safety alert word to
prevent actions that could cause personal injury.
CAUTION Highlights actions that may cause product damage. We use it to
highlight information necessary to prevent damage to hardware,
software, invalid test results, or to information that is critical for optimal
system performance.
NOTE Emphasises important information about a specic task.

Page 5
QUI-1086
www.markes.com
1.4 Important information
WARNING Read and understand all applicable environmental health and safety
laws and regulations. Ensure complete compliance with all applicable
laws and regulations before and during use of this product.
WARNING Under no circumstances should this product be used except by qualied,
trained, technically competent personnel.
WARNING Do not remove, cover, or alter any label or tag on this product, its
accessories, or related products.
WARNING Do not operate this product should it malfunction, require repair, or have
a cracked or broken case.
WARNING Do not repair or modify this product, except as specied in this manual.
No user-serviceable parts are located within the case. Contact Markes
for service-related queries.
WARNING Use only parts specied by Markes when performing maintenance
procedures described in this manual.
WARNING Do not charge the battery in an explosive atmosphere.
CAUTION This product is intended for both indoor and outdoor use when protected
from splashed or wind-blown liquids. The unit is not waterproof, so never
submerge the unit in water. Pump failure or faulting may result.
CAUTION This product presents a possible static hazard. Do not rub the product
with a dry cloth.
CAUTION Use only the battery pack and chargers specied in this manual. Do not
insert any foreign objects into the contact slot. Shorting contacts will
blow the protective fuse.
CAUTION Do not operate the product with a dirty or blocked inlet lter or kinked
tubing. Pump failure or faulting may result.
CAUTION If the equipment is likely to come into contact with aggressive substances,
then it is the responsibility of the user to take suitable precautions that
prevent it from being adversely affected. Examples of aggressive
substances are acidic liquids or gases that may attack metals, or solvents
that may affect polymeric materials. Examples of suitable precautions
are regular checks as part of routine inspections or establishing from
material data sheets that it is resistant to specic chemicals.

Page 6 www.markes.com
QUI-1086
NOTE Both charger and battery become warm during charging.
1.5 Warranty
The manufacturer warranty for the ACTI-VOC is 12 months; this includes the battery.
NOTE The warranty becomes void if the cover is removed by anyone other than
a Markes-trained engineer.
1.6 Technical support contact details
In the rst instance please contact your supplier. If they are unable to resolve your
query, please contact Markes International on the details below.
Website: www.markes.com
E-Mail: suppor[email protected]
Telephone: [phone] (UK ofce)
[phone] (German ofce)
[phone] (US ofce (toll-free))
[phone] (China ofce)
1.7 Certications
WARNING Intrinsic safety certications become void by substitution of
components, unauthorised repair or alteration.

Page 7
QUI-1086
www.markes.com
1.8 EU declaration of conformity
LFS-113 is manufactured for Markes and sold as part of a low-ow pump kit (part no. C-LFP-01).
EU DECLARATION OF CONFORMITY
Sensidyne, LP
1000 112th Circle North, Suite 100
St. Petersburg, Florida 33716
Certificate No: 113 Issue 10 June 20th, 2018
The undersigned declares that the products named in this certificate meet the provisions of the relevant Union
harmonization legislation: EMC Directive 2014/30/EU for Electromagnetic Compatibility, RoHS Directive
2011/65/ EU for Restriction of Hazardous Substances in electrical equipment (category 11), Directive
2014/34/EU concerning equipment and protective systems intended for use in potentially explosive atmospheres
and US and Canadian Hazardous Location and Electrical Equipment Requirements. This declaration is issued
in the sole responsibility of Sensidyne, LP.
Product Type: Portable Air Sampling Pump
Product designation: LFS 113
800088-R LFS-113D Basic
800098-R LFS-113DC Clock
Manufacturer: Sensidyne, LP
Intended Use: Air Sampling
Quality Assurance Notification No: SIRA 03 ATEX M263 SIRA Certification Notified body Number: 0518
Quality Assessment Report: GB/SIRA/QAR08.0026/05
Notified Body(s): UL LLC
333 Pfingsten Road, Northbrook, IL
60062-2096 USA
Intrinsically Safe: UL File No. ALOC7. E118722 US and CAN, Class I, Zone 0, AEx ia IIC
UL 913, Eighth Edition
UL 60079-0, Sixth Edition
UL 60079-11, Sixth Edition
CSA C22.2 No. 60079-0, Third Edition
CSA C22.2 No. 60079-11:14
IEC 60079-0, Sixth Edition
IEC 60079-11, Sixth Edition
EN 60079-0:2013
RoHS Directive 2011/65/EU Technical documentation on file for the assessment of
electrical and electronic products.
EMC Directive 2014/30/EU TUV Report No. TP72128526.400
Conforms to: EN 61326-1:2013
EMI Verification TUV Report No. TP72128526.200
Conforms to: FCC Part 15, Class A & ICES-003 Class A
ATEX Directive 2014/34/EU UL Certificate No. DEMKO 17 ATEX 1899, Rev. 0
II 1 G Ex ia IIC T4 Ga Report No. 4787879539
Ambient température range is -20 ºC to +40 ºC Conforms to: EN 60079-0:2012 + A11:2013,
EN 60079-11:2012
IECEx UL Certificate No. 17.0056
UL File No. EXHZ.E495159
Conforms to: IEC 60079-0: 2011, Ed. 6.0
IEC 60079-11: 2011, Ed. 6.0
Signed: Date: 06/20/2018
Name: Lisa Diaz
Title: Manager: Quality Assurance /Regulatory Affairs Sensidyne, LP
Who is the natural and legal person with responsibility for the design, manufacture, packaging and labeling before the device is
placed on the market under his own name, regardless of whether these operations are carried out by the Manufacturer or on his
behalf by a third party.

Page 8 www.markes.com
QUI-1086
2. Components
Front view Back view
Figure 1: ACTI-VOC components
1 Air inlet: Located on the pump lter, this provides a built-in means of attaching
tubing for suction sampling.
2 Pump fIlter: A 10 μm nylon air inlet pump lter protects the pump assembly from
dirt.
3 Flow adjustment: Requires a at-bladed screwdriver (provided).
4 Battery check: This green LED (B) indicates that sufcient battery power is
available to run the pump for 8 hours under normal load conditions.
5 ON/OFF switch.
6 Fault indicator: This red LED (F) indicates a ow fault due to excessive back-
pressure or insufcient battery voltage to maintain ow. If ow changes exceed
5%, a fault icon appears. If a fault exceeds 30 seconds, the pump shuts down
and the display will show sample time.
7 Clock display: Shows the continuous run-time (in minutes, to two decimal
places), and will lock-in the sample time upon fault indication. The time will reset
to zero when the power switch is turned OFF and then back ON again.
➒1
➑2

3





4
75
6

Page 9
QUI-1086
www.markes.com
➑ Outlet port: Provides a receptacle for the bag sampling accessory. The screwcap
prevents dirt from entering the outlet port when not in use.
➒ Bag sampling accessory: Provides a means for lling air sampling bags.
 Base screws: Must remain tight and should be checked prior to beginning
sampling.
 Charging port: Used to connect a charger for recharging the internal battery.
 Belt clip.
 Internal rechargeable battery.
 Mode indicator: For service use only.
 Mode selector: For service use only.
 Hex key: For service use only.
 Back-pressure adapter: Gives the required minimum back-pressure the pump
needs for low-ow TD use. Use this in conjunction with the ⅛″ tubing with
standard ¼″ and 6 mm o.d. TD tubes for ows up to 100 mL/min.
 PTFE tubing and TD tube adapter: Use the adapter in place of the back-pressure
adapter when sampling onto SafeLok™ tubes or at ows greater than 100 mL/min.

Page 10 www.markes.com
QUI-1086
3. Calibration
Calibration (ow rate verication) must be performed before sampling to ensure the
pump is working efciently, and when setting the ow rate. As the pump is
constant-ow, you need only set the ow rate at the beginning of your sampling
period with the use of a calibration tube – you will not need to re-calibrate when
switching between tubes.
■Ensure the ACTI-VOC is fully charged.
■Attach the PTFE tubing () to the pump and push your sorbent tube for
calibration into the relevant adapter (Figure 2). The sampling arrow on the TD
tube should be pointing towards the pump.
NOTE Use the back-pressure adapter when setting ows up to
100 mL/min; use the PTFE tube adapter when setting ows in
excess of 100 mL/min.
Figure 2: PTFE tubing (A) with back-pressure adapter and (B) without back-pressure
adapter
A B

Page 11
QUI-1086
www.markes.com
Figure 3: Adjusting the ACTI-VOC ow
using the ow adjuster 3
■Connect the sampling end of the TD
tube to a suitable ow-measuring
device, e.g. digital owmeter (part no.
C-FLMTR).
■Turn on the owmeter and the pump,
and adjust the ow on the ACTI-VOC
using the at-bladed screwdriver
provided with the ACTI-VOC (Figure 3).
■ When the desired ow rate has been
reached, turn off the pump and
owmeter, and remove the sorbent tube
used for calibration from the adapter.
■ The pump is now ready for sampling.

Page 12 www.markes.com
QUI-1086
4. Sampling
The following sampling workows are recommended for TD applications, where the
pump has been calibrated before use as described in Section 3.
4.1 Personal/workplace monitoring
■Uncap your pre-conditioned TD tube for sampling, using the CapLok tool
provided.
■Place the pump, ⅛″ tubing, appropriate adapter and sample tube on the worker
as shown (Figure 4A), ensuring the sampling arrow on the TD tube is pointing
towards the pump. The tube can be held in position with a penclip (part no.
C-CL010).
■Turn on the pump using the at-bladed screwdriver provided (Figure 4B) and
leave to sample for a given time. Be aware that different analytes will have
different retention volumes on a given sorbent.
■After the sampling period has passed, turn off the pump (Figure 4C) and record
the sample time. This is displayed on the ACTI-VOC in minutes to the nearest
0.01 minutes.
Figure 4: Using ACTI-VOC for personal monitoring
A
B C

Page 13
QUI-1086
www.markes.com
■Remove the TD tube from the tubing adapter and cap with long-term storage
caps (C-CF020). You should do this by nger-tightening each cap, and then
quarter-turning with the CapLok tool provided.
■See CapLok tool ‘how-to’ video for further information.
■Calculate the total air volume sampled using the following formula:
Total air volume (L) = Sample ow rate (mL/min) × Sample time (min)
1000
■Your tube is now ready for analysis, and your pump can be used for additional
samples at the same ow rate.
4.2 Indoor air monitoring
■Uncap your pre-conditioned TD tube for sampling, using the CapLok
tool provided.
■Place the pump, ⅛″ tubing, appropriate adapter and sample tube on a level
surface in the atmosphere of interest (Figure 5A), ensuring the sampling arrow
on the TD tube is pointing towards the pump.
■Turn on the pump using the at-bladed screwdriver provided (Figure 5B) and
leave to sample for a given time. Be aware that different analytes will have
different retention volumes on a given sorbent.
■After the sampling period has passed, turn off the pump (Figure 5C) and record
the sample time. This is displayed on the ACTI-VOC in minutes to the nearest
0.01 minutes.
■Remove the TD tube from the tubing adapter and cap with long-term storage
caps (C-CF020). You should do this by nger-tightening each cap, and then
quarter-turning with the CapLok tool provided.
■See CapLok tool ‘how-to’ video for further information.
■Calculate the total air volume sampled using the following formula:
Total air volume (L) = Sample ow rate (mL/min) ×
Sample time (min)
1000
■Your tube is now ready for analysis, and your pump can be used for additional
samples at the same ow rate.

Page 14 www.markes.com
QUI-1086
5. Maintenance
5.1 Battery
ACTI-VOC uses rechargeable nickel-metal-hydride (NiMH) batteries that must be fully
charged and properly maintained to obtain the maximum run time. The battery is
rated at 4.8 V (720 mA h).
WARNING Do not charge the battery in an explosive atmosphere.
CAUTION All NiMH batteries lose charge when not in use. If the battery pack has
not been charged for 3–4 days, recharge it before use. NiMH batteries
stored for extended periods should be recharged every 1–2 months to
avoid complete discharge.
CAUTION Make certain the charger plug is fully inserted into the port on the
battery pack.
CAUTION Ensure the ACTI-VOC is fully charged each time as partial charging can
reduce the battery capacity over time.
CAUTION The charger can be damaged by line transients and overvoltage.
Although this is not a common problem, long-term reliability can be
improved by use of a surge/overvoltage protector.
CAUTION Do not short battery terminals, as this will blow the internal fuse.
NOTES Both charger and battery pack become warm during charging.
AB C
Figure 5: Using ACTI-VOC for indoor air monitoring

Page 15
QUI-1086
www.markes.com
The battery pack has an estimated life of 300–500 charge–discharge cycles,
depending on use. The table below shows the estimated battery life based on
usage level.
Pump usage Estimated battery life
High (40–60 hours per week) 1–1½ years
Medium (20–39 hours per week) 1½–2½ years
Low (<20 hours per week) 2½ years
Contact Markes to discuss battery replacement.
5.2 Pumplter
A 10 μm nylon air inlet pump lter protects the pump assembly from dirt. Under
normal operating conditions, the pump lter should be changed after approximately
six months or 250 hours of operation, or when needed.
CAUTION Failure to change the lter as it becomes dirty will decrease the pump’s
back-pressure capability and performance range.
To change the pump lter, follow the instructions below:
■ Blow all dust and debris from around the pump lter 2.
■ Grasp the knurled edge of the pump lter and rotate anticlockwise.
■ Check the new pump lter to make sure that the sealing O-ring is present on the
internal boss.
■ Install the new pump lter onto the pump,
rotating the knurled edge clockwise
(Figure 6).
CAUTION Do not overtighten the pump lter.
See Section 6.2 for the relevant part number.
Figure 6: ACTI-VOC with pump lter

Page 16 www.markes.com
QUI-1086
5.3 Back-pressure adapter O-ring
The back-pressure adapter connects the TD tube to the pump using an O-ring seal. It
is recommended that this O-ring is replaced every twelve months, or whenever it is
noticeably damaged.
The replacement process is as follows:
NOTES You will require a replacement O-ring (part no. U-COV10), an O-ring
extraction tool (part no. SER Z-0351), an O-ring insertion tool (part no.
SERZ-0285) and a pair of tweezers.
■Use the O-ring extraction tool to hook out the O-ring (Figure 7A), taking care not
to scratch the groove in which the O-ring is seated, or to damage the white PTFE
insert behind.
■Take the replacement O-ring and compress it slightly into an oval shape
(Figure 7B). Pinch with tweezers and insert halfway into the back-pressure
adapter.
■Use the O-ring insertion tool to push the replacement O-ring into the groove
(Figure 7C).
■Run the O-ring insertion tool around the inner diameter of the O-ring to ensure it
is free from distortions.
Figure 7: Changing the back-pressure adapter O-ring.
A B C

Page 17
QUI-1086
www.markes.com
5.4 6 mm o.d. tubes
The O-ring in the back-pressure adapter can be replaced with a smaller i.d. O-ring to
allow for use with 6 mm o.d. tubes.
To change the O-rings, see Section 5.3. The O-rings required are supplied with the
ACTI-VOC (part no. U-COV45).
6. Parts list
6.1 Accessories
Part number Description
SERZ-1076 Air inlet pump filter assembly
SERZ-1070 Bag sampling accessory
SERZ-0351 O-Ring extraction tool
SERZ-0285 O-Ring insertion tool
SERLFP-5002 Spare charger
SERZ-1097 PTFE tubing and TD tube adapter
SERLFP-5003 Back-pressure adapter
U-COV10 O-Ring, low-emission, size 10, pk 10
U-COV45 O-Ring, low-emission, 5.92 mm i.d., pk 10
Part number Description
C-FLMTR Digital flowmeter
C-CPLOK CapLok tool
C-CL010 Penclip, pk 10
6.2 Spare parts
Contact Markes to discuss battery replacements and additional pump maintenance.

Page 18 www.markes.com
QUI-1086
7. Specications
Dimensions
■Width: 63.5 mm (2.50″)
■Height: 34.9 mm (1.38″)
■Length: 117.5 mm (4.63″)
Weight
■Main unit: 340 g (12 oz)
Operating range
■20–200 mL/min
Pressure range
■Back-pressure up to 25″ H2O
Flow control
■5% of set point or ±3 mL/min, whichever is greater
Battery type
■Rechargeable nickel-metal-hydride battery pack
Battery output
■4.8 V, 720 mA h
Charging
■Internal (external with adapter)
Operating temperature
■–20°C to 45°C (–4°F to 113°F)
Storage temperature
■–40°C to 45°C (–40°F to 113°F)
Charging temperature
■0°C to 45°C (32°F to 113°F)

Page 19
QUI-1086
www.markes.com
Additional features
■Flow fault indication LED
■Battery check LED
■Belt clip
■Dual ltration system
■External ow adjust
■Elapsed timer clock module – LCD display
■Automatic instant-fault shutdown function
■RFI shielding
8. Contact details
For technical support, please contact your supplier in the rst instance. If they are
unable to resolve your query, please contact Markes International’s service
department:
E: [e-mail]
T: [phone]
W: www.markes.com
For an instructional product video, please visit:
chem.markes.com/ACTI-VOC
Scan the code to
watch the video

QUI-1086
L-0181 (190521-6)
ACTI-VOC™, CapLok™, MTS-32™ and SafeLok™ are trademarks
of Markes International. Tedlar® is a trademark of DuPont™.
