Markilux planet flex User manual

Overview
markilux
markilux planet fix / planet flex
Operation manual
GB
2
1
3
4
Table of contents
markilux operating instructions
Page
1. Reading the instructions 3
2. Engagement and slewing range, markilux planet flex (optional) 3
17-10-2018 7062205 TK + QS
planet fix with markilux awning planet flex with markilux awning

3
markilux.com
2. Engagement and slewing range, markilux planet flex (optional)
markilux planet fix / planet flex
Operating instructions
S
N
W
O
300°
F2
60°
V
H
L
R
The markilux planet flex has a specified engagement range of 300°. To use the possible shade area optimally, no objects may
hinder the markilux planet flex as it slews!
1. Reading the instructions
2. Bring the markilux planet into the
required position with the handle.
Read the operating instructions and all the documentation pertaining to the product (handover protocol, important guidelines,
etc.) carefully and completely before using the product. Separate instructions exist for the folding-arm awnings!
Attention!
V = Front
H = Rear
R = Right
L = Le
3. Lower the handle to lock the turning
mechanism again.
1. Li the handle to release the lock.
