MARKLIFE P50 User manual
MARKLIFE
P50 LABEL PRINTER MANUAL
CONTENTS
Packing List
Introduction
Getting Started
Install and Setup Marklife APP
Create and Print your own label
Marklife APP Features
Trouble Shooting Guide
Print head/Rubber-covered roll cleaning
Warning
Notes
Warranty
01
02
05
08
12
20
21
23
24
25
26
01
02
03
04
05
06
07
08
09
10
11
PACKING LIST
MARKLIFE
P50 LABEL PRINTER MANUAL
Printer*1 Type C cable*1
Use Manual * 1
(includes instructions, warranties and certificate)
1
INTRODUCTION
2 3
Product Model: P50
Printing width: 20mm~50mm
Print accuracy: 203DPI
Bluetooth: 4.0
Battery capacity: 1200mAh
Charging time: less than 3 hours
Battery life: continuous printing length greater than 150 meters
Battery lifespan:charge and discharge times: more than 500 times
Printing life: more than 50km;
This label maker is only suitable for printing thermal label paper. For
better printing quality, it is recommended to use label paper from our
shop.
If the label maker is not used for a long time, in order to ensure the
battery life, it needs to be charged regularly.
The print head needs to be cleaned with alcohol cotton for a long time;
Note: Consumers shall use
the power adapter thathas
obtained China Compulsory
Certification andmeet the
standard requirements.
USB
On/off button
Basic parameters
4
On/Off button
Turn on P50 label maker: Press and hold the On/Off button until the
button green light appears.
Label calibration: Press the On/Off button twice in quick succession
the P50 label maker will come out with a label for label calibration.
Turn off P50 label maker: Press and hold the On/Off button until the
button light is off.
The P50 label maker power off automatically if you do not use it for
20 minutes.
Light status description
Green light: Fully charged / In normal use status.
Red light: Charging /Paper shortage/Overheat/Cover opening
Red light Flashing: Low Power, Low battery will cause unclear
printing, please charge it in time.
Orange light: Firmware is upgrading. Just wait till firmware
upgrading is finished and restart.
Blue light: Bluetooth is connected and in normal use status.
Blue light Flashing: Bluetooth is not connected.
GETTING STARTED
5
Step 1: Put in labels
1. Open the cover of the paper bin by holding the switch handles and
lifting the lid upwards.
2. Take out the spool and take off the movable plate. Load the paper
on the spool, put the movable plate back, and adjust its suitable size,
make sure the movable plate is fixed to avoid printing distortion.
3. Make sure the sticker side is facing down while Loading the paper,
Close the cover with some paper left outside of the cutter.
4. Turn on: Press and hold the On/Off button
until the button a green light appears.
67
INSTALL AND SETUP MARKLIFE APP
8
APP Download
Search“Marklife" in the App Store
For Apple phones, please search for "Marklife" in the Apple App Store
to download the APP.
For Android phones, please search "Marklife" in Google Play to get it.
9
APP Installation
To install and set up the Marklife APP, just follow the on-screen
instructions that step you through the setup process, including access
rights settings for support.
APP Bluetooth connectivity, custom label storage, and local custom
text printing function.
11
Connect P50 to APP
Turn on your label maker: Press and hold the On/Off button until the
button green light appears.
Turn on Bluetooth on your phone.
Open the Marklife APP.
Click Visitor Mode, our APP supports visitor mode, which means
you can use the app without registering. You can also register or
log in through a third-party account.
Click the "Unconnected" button, find your P50 label maker name,
and click to Connect it.
NOTE: Please make sure to connect the device from the app side. It
will be failed if you connect from the phone Bluetooth section.
10
CREATE AND PRINT YOUR OWN LABEL
12
Follow these steps to print out the labels you want:
Go to Create label>Select Label Type>Gap Label>Quick size
selection>Text, and edit your label content following the guidelines
below.
After you finish the content design, click Print>Check the preview
page>Print.
NOTE:
-Label calibration needs to be done each time the bin is opened
before printing, otherwise the label content will be printed off-set.
-Make sure to select the corresponding label paper type and size
before printing. Selecting an inappropriate paper type and size may
result in printing errors or wasted paper.
P50 Label Maker comes with a roll of Gap Label, size 40*30mm.
13
14 15
16
Double click "Double click Edit" to edit your text you can drag the text
box to adjust the text location. Choose the text size, font, and left and
right alignment, or directly drag the text box to complete the
adjustment of the text position. You can also add some stickers,
Graffiti, Dates, Lines, Shapes, and Numbers.P50 label machine also
supports printing pictures, Excel, Code, QR code, and OCR.
After finishing the text font settings, click Print to enter the print
preview page. On the print preview page, you can add the number of
copies to be printed at one time and the direction of printing, we
recommend the default print direction.
17
18 19
After the printing is completed,tear off the label starting from one side
of the label to the other side, which is easier and more labor-saving.
MARKLIFE APP FEATURES
20
Label content editing
Marklife APP supports bold font, italic, line spacing, and word
spacing adjustment. Even support adding pictures of text type or
sketch type, borders, stickers, dates, QR codes generated by the
label maker, graffiti, and consecutive serial numbers.
This printer supports photos & sketches printing.
You can use the excel importing function after login in.
Cloud Template
You can also find a template from“cloud template” with the same size
and the same appearance as the label you’re using to create a label.
If you choose a template that does not match the size and the
appearance of the label you are using, it will result in a failed print.
TROUBLE SHOOTING GUIDE
21
If your problem is not found in the table below, you can shut down
and reboot to try again.
Any questions, welcome to send an email to us, we will be happy to
serve you!
Category
Abnormal
light
Display
Bluetooth
Label
Calibration
Item NO. Question Answer (Possible causes and solutions)
Why does it
show a red light?
a. Paper shortage: Replace the label ;
b. Overheat: Turn off the printer and wait for it to
cool down before using it again.
Low Power:Charge the printer
Debugging mode has been entered: Shut down
and then restart.
A.Please connect it from the“ Marklife” App, not
from the Phone Bluetooth section.
B.Cell phone Bluetooth is not open, open the
Bluetooth.
C.Printer Bluetooth failure when the red light
flashes rapidly, refer to item 2.
D. Printer Bluetooth is occupied by another cell
phones.
E.The Android mobile APP needs to obtain
location permission before it can search for
nearby printers.
a.Turn on the label maker, press the 0n/0ff button
twice in quick succession, the a label maker will
come out with a label for the label Calibration.
b.The calibration is OK if the end of the label is right
next to the label exit, if only part of the label comes
out, please press the button again for re-calibration.
Why is the
red light
flashing?
Why does it
show an orange
light?
Why does the
printer connect
fail
How to
do Label
Calibration
1
2
3
4
5
22
Category
Print
Fail
Stop
Printing
Item NO. Question Answer (Possible causes and solutions)
Why is the printed
label blank
Why the printing
is blurry and
incomplete
Why is the
printed content
not centered?
Why did the
printer suddenly
stop printing
a.The printing paper is placed upside down.
Replace the paper in the correct orientation
b.Paper issue: Replace another label paper, do
label calibration and print
a. Low Power. the red light is flashing: Charge
the printer.
b. Didn' t do label calibration before printing Do
label calibration and print again.
c.Poor quality printing paper, replace a new roll
of labels. Print head issue: Check whether there
is any done on the print head. If it is, wipe and
clean the print head with an alcohol swab In the
shutdown state.
a.Not calibrate the label before printing: calibrate
it before starting to print.
b.The model setting of the printer in the APP
does not match the printer used, reselect the
model.
c. If the label size set in the APP does not match
the actual label, reset the size, and try printing
again.
d.Confirm whether the font is too large beyond
the printing range, adjust the font size, and try
again.
In order to ensure the reliability of the printer, the
printer is designed with various self-protection,
including“out of paper”, "paper bin open”, "low
power”, etc. Please deal with the the situation
according to the related solution.
6
7
8
9
PRINT HEAD/RUBBER-COVERED ROLL CLEANING
23
If any issue below happens, please clean the print head/Rubber
-covered roll :
Blurry printing
Loud noise when feeding the paper
There is glue residue or dust sticking to the printhead.
Cleaning procedures:
1. Turn off the printer,
2. Wait for the roll to cool off completely after printing. Open the
cover and find the printhead;
3. Clean the dust or smudge with an alcoholic cotton ball (drained)
or exclusive printer cleaning pen (needs to be purchased).
4. Wait 5-10 minutes to make sure the alcohol has been volatilized
before turning on the printer.
WARNING
24
1) Please make sure there is no debris in the paper bin before use, otherwise,
the print head may be damaged during printing. If there is any dirt, please clean
the paper bin and print the head with alcohol.
2) Please turn off the power immediately when the label maker is go wrong.
3) There is a complex circuit inside the label maker and please do not
disassemble the label maker yourself.
4) Please do not squeeze, mechanical vibration, shaking the label maker.
5) Do not use the label maker near flammable materials such as gas stations and
fuel depots.
6) Please charge the battery in a cool, ventilated room. Do not expose the label
maker and USB cable to high temperatures, high humidity or put them in water to
avoid short circuits, causing the battery to heat up, smoke, deformation, damage,
or even an explosion. If the label maker and USB cable are connected to melt to
water or other liquids, disconnect the power immediately. When you find that the
label maker or power adapter smoke or smell, please unplug the power adapter
immediately and pay attention to avoid being burned.
7) Do not disassemble or modify the label maker, and strictly forbid charging with
a damaged power cord, otherwise it will lead to electric shock, fire, and label
maker damage.
NOTES
25
1) Please keep this product and accessories in a safe place out of the reach of
children to prevent danger.
2) Please do not disassemble the printer by yourself. When the the machine is
printing, please do not open the paper bin cover.
After printing is finished, the print head is still in a high temperature state, please
do not touch it to avoid burns.
3) When charging the printer and power adapter should be placed in room
temperature ventilation.
4) Please use a clean soft cloth to gently sassafras printer, prohibit the use of
dissolved substances, with corrosive chemicals and cleaning agents, such as
benzene, thinner.
5) Make the power adapter, please make sure that the printer powered off. Too
high an ambient temperature or too low an ambient temperature will result in
lower print quality.
6) Contact after-sales customer service when the battery cannot meet the
performance requirements.
7) Please use our original printing paper, otherwise it may lead to poor print
quality or even damage the printer.
8) The time of printing last on thermal paper is related to the quality of the
thermal printing paper.
9) If you want to print receipts for long-term preservation, please Use long-lasting
thermal printing paper.
10)If you use a power adapter to supply power, you should purchase a power
adapter that has obtained CCC certification to meet the standard requirements.
WARRANTY
26
From the date of purchase, this product print head warranty is 3 months, the rest
of the parts warranty is 12 months.
Warranty service is not available for the following cases during the warranty
period.
1)Out of warranty.
2)Unauthorized disassembly and repair or unauthorized modification.
3)Damage or scratches caused by man-made and other force.
4)Damage caused by accident, or use of other branded components or low
quality consumables.
5)Printer failure or damage due to incorrect installation and use.
6)Printer failure or damage caused by the use of the product in a working
environment not specified by the product.
7)Printer failure or damage due to improper use (beyond workload, etc.) or
maintenance (moisture, etc.).
Table of contents
