Martin Universal Design Alyssia Craft Table with Tray User manual

A
F
K
P
U
B
G
L
Q
V
C
H
M
R
W X Y
D
I
N
S
E
J
O
T
QTY: 1
Top
Allen Wrench Wrench
QTY: 1
QTY: 1
QTY: 8
QTY: 2
QTY: 2
QTY: 2
QTY: 2
QTY: 4
QTY: 1
QTY: 1
QTY: 1
QTY: 2
QTY: 2
QTY: 1
QTY: 1
QTY: 1
QTY: 2
QTY: 24
QTY: 1
QTY: 2
QTY: 1
QTY: 4
IMPORTANT
If you have difculty assembling your table, or need customer service
assistance, please call: Martin Universal Design, Inc. customer service
hotline at 1-313-895-0700, or email at [email protected]. If
you need additional parts, it is not necessary to contact your dealer. Our
Customer Serice Representative will forward them to you immediatly.
PARTS LIST = Table Components = Fasteners and Tools
Phillips head screwdriver not included.
Alyssia Craft Table with Tray
U-CC83BST
Legs Left/Right Upper Support Left/Right Upper Support Rear Support Bar
Front Support Bar
Cup Holder
6x55mm Bolts
Small Washer
Lower Support Braces
6x50mm Bolts Nut 5x14mm Screws Large Washers
Tilt Mechanism Knobs Pencil Ledge
Metal Shelf
Tilt Bracket
Metal Tray Plastic Tray
QTY: 2 QTY: 2
5mm Spacer4x12mm Screw

Q
Q
P
P
P
P
S
M
T
N
B
B
C
D
F
F
G
E
Step 1
A) Assemble legs (Part B ) with crossbar (Part G ) using 4 ea. 6x55mm Bolts (Part P ).
B) See Fig 1 - Insert left/right upper supports (Part C & D ) into leg. Tighten both legs
(Part B ) using plastic knobs (Part N ), and Large washers (Part T )
C) Assemble crossbar (Part E ) to both arms using 4 ea. 6x55mm bolts (Part P ).
D) Assemble front crossbar (Part F ) using 2 ea. 6x50mm bolts(Part Q ).
E) See Fig 2 - Attach tilt brackets (Part M ) to crossbar (Part F ) using 2 ea. 5x14mm
screws (Part S ).
Fig 1
Fig 2

Q
S
S
S
M
F
UY
L
T
LR
A
A
A
I
Step 2
A) Place table upside down on the top (Part A ). Make sure predrilled holes line up
according to the diagram.
B) See Fig 1 - Attach tilt mechanisms (Part L ) into predrilled holes on table top (Part A
) using 4 ea. 5x14mm Screws (Part S ) for each mechanism.
C) See Fig 2 - Attach tilt mechanism to the right and left arms using 5mm spacers (Part
Y ), large washers (Part T ), small washers (Part U ) 1 ea. 6x50mm bolts (Part Q ) and
nuts (Part R ).
D) See Fig 3 - Slide the metal tray (Part I ) to the edge of table top (Part A ) and attach
using 6 ea. 5x14mm Screws (Part S ).
E) See Fig 4 - Attach crossbar (Part F ) using tilt brackets (Part M ) and 4 ea. 5x14mm
screws (Part S ). Make sure to line up holes on brackets to predrilled holes on the table
top (Part A )
Fig 1
Fig 2
Fig 3
Fig 4

X
A
K
G
H
I
J
O
Step 3
Step 4
A) Attach metal shelf (Part H ) to lower crossbar (Part G ) between legs, by tapping it into
the grooves.
B) Place cup holder (Part K ) and plastic tray (Part J ) into metal side tray.
A) Attach pencil edge (Part O ) using 2 ea. 4x13mm screws ( Part X ) to the table top.

TILT ADJUSTMENT:
To adjust the tilt of your table top, grab the back edge of the table top and lift
the top with [2] hands to the maximum tilt and then back down to your desired
position. NOTE: You must lift the table top all the way up before lowering it to the
desired tilt level.
NOTE: If the top does not seem to move smoothly - this means you are NOT
holding the top balanced with both hands. Make sure your hands are positioned
evenly. This will make the adjustments easier.
In order to lower the table top, life it all the way up to its maximum height which
allows the tilt mechanisms to release from their locked position. To avoid damaging
the table top, DO NOT attempt to lower the table top by forcefully pushing down
on the top when its in a locked position.
