Manchester Split-top Table Assembly Instructions
IMPORTANT
If you have difficulty assembling your Manchester Table or need customer service assistance.
Please call: Martin Universal Design, Inc. Customer Service Hot Line at 1-313-895-0700.
If you need additional parts, it is not necessary to contact your dealer, our Customer Service Rep.
will forward them to you immediately.
May 08- RPI
Parts List
Pg. 1
Part A - 1 piece Part B - 1 piece Part C - 1 piece
Part D - 1 piece
Part F - 1 piece
Part E - 1 piece Part G - 1 piece Part H - 1 piece
Part I - 1 piece Part J - 1 piece Part K - 4 pieces Part L - 1 piece
Part M
- 2 pieces
Part N - 10 pieces Part O - 4 pieces Part P - 3 pieces
Part Q - 2 pieces Part R - 3 pieces Part S - 14 pieces Part T- 4 pieces
6x30mm6x50mm 6x8mm
4x18mm 4x12mm4x30mm
Part U - 2 pieces Part V - 4 pieces Part W - 1 piece Part X- 1 piece
Part Y - 1 piece Part Z - 1 piece Part A1R - 1 piece Part A1L- 1 piece
Part B1 - 1 piece Part C1 - 1 piece Part D1 - 1 piece Part E1- 4 pieces
4x35mm

STEP 1] Assemble Drawer
Begin by taking the back panel of drawer (Part Y) and
inserting 1 plastic T-nut (part K) into each hole, making
sure the hole in the T-nut is lined up with the hole in the
edge of the back panel. See FIG A.
Manchester DRAWER Assembly
PLEASE NOTE:
Assemble the Drawer FIRST before assembling the base.
Once assembled, set drawer to side.
Assembled drawer to be used later
during assembly of table.
FIG A
KY
K
V
V
STEP 2] Assemble Drawer, cont’d.
Take the Drawer Front (Part Z) and insert the 4
Threaded Connector Pins (Part T). Use Phillips
Screwdriver to secure Threaded Connector Pins
into Drawer front.
See FIG B.
FIG B
STEP 3] Assemble Drawer, cont’d
Take the Sides of the Drawer (Parts A1R & A1L) and
insert the 2 T-nuts into the holes found on each side
panel, making sure the holes of the T-nuts line up with
the holes on the outer edge of the drawer sides.
See FIG C.
FIG C
T
Z
A1L
May 08- RPI
Pg.2

STEP 4] Assemble Drawer, cont’d
Attach sides of drawers (Parts A1L & A1R) to the Drawer
front (Part Z) by inserting Threaded Connection Pins
into the holes on the outside edge of the Drawers sides
(Parts A1L & A1R).
PLEASE NOTE: The Grooves in each side must be
lined up with each other to allow the drawer bottom
to be installed.
To secure, tighten the T-nuts found on the outer side of
the drawer sides. Turn the T-nuts until tight. See FIG D
K
STEP 5] Inserting Drawer Bottom
Slide the Drawer bottom (Part B1) into the grooves on the
sides of the drawers and into the front of the drawer.
NOTE: Brown side of drawer bottom is the bottom of
the drawer. White side up for inside drawer
bottom.
See FIG E
STEP 6] Completing Drawer Assembly
Complete Drawer Assembly by attaching the Drawer
back (Part Y) to the drawer by inserting the drawer bottom
into the groove on the drawer back. See FIG F
To secure Drawer Assembly, insert 2 each 4x35mm
screws (Part E1) into the drawer sides and tighten with
phillips screwdriver, as shown in FIG G
Manchester DRAWER Assembly
Z
A1L
FIG D
FIG E
Z
A1R
A1R
B1
B1
FIG F
FIG G
May 08- RPI
Pg. 3
A1R
B1
Z
Z
A1L

May 08- RPI
Pg. 4
STEP 7] Attaching Drawer Handle
Attach drawer handle (Part L) to drawer, using 2 each
4x18mm screws (Part Q). See FIG H
Insert screws (Part Q) through inside of drawer into ap-
propriate holes and tighten with phillips screwdriver. Hold
onto drawer handle while securing screws. See FIG I
Go back and double check all screws are tight on all
sections of drawer.
Set Drawer aside and begin table assembly.
Manchester DRAWER Assembly
Z
Z
L
Q
FIG I
FIG H

STEP 1] Assembly Base of Table
Begin by assembling the base by taking the left side
(part A) and attaching the three cross supports (part
C, D & E) using 1 each 6x50mm hex bolts (part N) into
each hole found on the outside side edge of Part A and
lining that hole up with the hole in the end of each cross
support. Tighten hex bolt with Allen Wrench (part C1).
SEE FIG 1,2 & 3
PLEASE NOTE: The Black square caps as shown in
FIG 1 indicate the top side of Parts A & B
PLEASE NOTE: DO NOT OVERTIGHTEN HEX BOLT
to cause frame to bend.
Pg. 5
FIG 3
Manchester Split-top Table Assembly Instructions
A
C
N
A
D
N
FIG 1
FIG 2
NAD
E
This is what your partial assembled base should now
look like. See FIG 4.
D
E
C
A
STEP 2] Assembly Base of Table, cont’d
FIG 4
May 08- RPI
Attach cross support (part D) to Side A
FIG 2.
Attach cross support (part E) to Side A
FIG 3.

Pg. 6
May 08- RPI
Manchester Split-top Table Assembly Instructions
Repeat with right side (part B) by attaching the other end
of the three cross supports (part C, D & E) using 1 each
6x50mm hex bolts (part N) into each hole found on the
outside side edge of Part A and lining that hole up with
the hole in the end of each cross support. Tighten hex
bolt with Allen Wrench (part C1). SEE FIG 5,6 & 7
PLEASE NOTE: The Black square caps as shown
in FIG 1 indicate the top side of Parts A & B
PLEASE NOTE: DO NOT OVERTIGHTEN HEX BOLT
to cause frame to bend.
B
C
N
N
B
D
FIG 6
FIG 7
This is what your partial assembled base should now
look like. See FIG 8.
Attach cross support (part D) to Side A
FIG 6.
Attach cross support (part E) to Side A
FIG 7.
FIG 5
N
B
E
FIG 8
STEP 3] Assembly Base of Table, cont’d
STEP 4] Assembly Base of Table, cont’d

Pg. 7
May 08- RPI
Manchester Split-top Table Assembly Instructions
Attach lower wider Cross Support (part F) to lower
portion of base by lining up the two holes on each end
of Part A & B with the two holes found in each end of
Part F. Secure by using two each 6x50mm Hex Bolts
in each end.
SEE FIG 9.
PLEASE NOTE: DO NOT OVERTIGHTEN HEX BOLT
to cause frame to bend.
B
F
N
FIG 9
STEP 5] Attach Lower Cross support
If you assembled the base correctly, the assembled
base should now look like FIG 10.
STEP 6] Assembly Base of Table, cont’d
FIG 10
F
B
A
This step involves attaching the Tilt Mechanism (Part
J) to the Base. Find the 2 holes on top side of cross
support (part D). Secure Tilt Mechanism to this cross
support using 2 each 6x30mm Hex Bolts (Part O) & 2
each Hex Nuts (Part U). The Nuts are to be positioned
on the underside of cross support D. Use wrench (part
D1) to hold nuts while tightening down Hex bolts. See
FIG 11 & FIG 11B for proper positioning.
PLEASE NOTE: The elbow of the Tilt Mechanism is
to be pointed to the rear of the table Base.
See below for Photo that shows this.
STEP 7] Attach Tilt Mechanism to Base
FIG 11
FIG 11B
This is the underside
of Part D
Front of Table
Rear of Table
Elbow of the Tilt Mechanism
faces the rear of the table
J
D
D
E
J

Manchester Split-top Table Assembly Instructions
Attach Drawer support guide (Part G) to base cross
supports (part C & E) using 2 each 6x30mm Hex bolts.
Tighten with Allen Wrench. See FIG 12.
PLEASE NOTE: Make sure the Drawer Support
guide is facing the right as in FIG 12.
STEP 8] Attach Drawer support guide
Attach 2 Hinges (Part M) to front edge Cross support
(Part E) by lining up holes in hinge and holes in cross
support E using 3 each 4x12mm screws (Part S) per
hinge. Tighten with phillips screwdriver. SEE FIG 13.
PLEASE NOTE: Make sure that the Hinge is
positioned as in FIG 13B
STEP 9] Attach Hinges to base
FIG 12
E
G
Drawer
Support
Guide
G
E
FIG 13
M
Hinges
need to be
attached as
shown at
right.
E
Front edge of base
FIG 13B
Align holes in hinges to holes in top and align holes in
tilt mechanism (Part J) to threaded holes in top.
See FIG 14
STEP 10] Attaching Base to Top
Line up holes in
hinge with holes
in top
Line up holes in
tilt mechanism
and T-nuts in top
Pg. 8
May 08- RPI
FIG 14
J

After lining up holes, attach tilt mechanism (Part J) to
top with 2 each 6x8mm Hex Bolts (Part P). Tighten with
Allen Wrench. See FIG 15.
STEP 11] Attach Tilt Mechanism to Top
Pg. 9
May 08- RPI
Attach the 2 Hinges (Part M) to the top by using 3 each
4x12mm screws (Part S) per hinge. Tighten with
phillips screwdriver.
See FIG 16.
STEP 12] Attach Hinges to Top
WARNING:
Turn table upright with TWO PEOPLE - DO NOT ATTEMPT to turn assembled table
onto its legs with only one person. Then continue with assembly
Manchester Split-top Table Assembly Instructions
PLEASE NOTE:
Before attaching Drawer Stop (Part X), the Drawer
must be installed FIRST!
To do so, slide drawer onto drawer glides
See FIG 17.
STEP 13] Attach Drawer Stop
FIG 15
FIG 16
FIG 17
J
M

After sliding Drawer into table, you need to install the
drawer stop (Part X). This can be a bit tricky.
You need to position the Drawer Stop (Part X) as shown
in FIG 18 and FIG 18b, then from underneath, secure
the drawer stop with a 6x8mm Hex Bolt (Part P). Tighten
with the allen wrench.
STEP 14] Attaching Drawer Stop, cont’d
Pg. 10
May 08- RPI
Manchester Split-top Table Assembly Instructions
FIG 18
P
X
FIG 18b
FIG 19
If installed correctly, the Drawer will not be able to be
pulled all the way out of the table.
See FIG 19.
DX
P

NOTE: The photo at the left show the table laying
top down on the carpeted floor and standing above
the table looking downward.
Slightly lift the table up and slide the side shelf (Part
H) underneath the drawer section, making sure to line
up the Side shelf so that the edges are flush and even
with the edge of the table top. See FIG 20
Continue with attachment of side shelf
on next page.
STEP 15] Attaching Side Shelf
Pg. 11
May 08- RPI
Manchester Split-top Table Assembly Instructions
WARNING:
To Install the SIDE SHELF, the Table must be turned back over onto its Table Top.
Use 2 People to turn Table over onto the Table Top, making sure it is placed on a
protected surface like a carpeted floor.
Drawer Bottom
Table Top
Drawer
Bottom
Table Top
Side Shelf
Line up the Side shelf so that
the edge of the shelf is flush
with the edge of the table top.
Indicated by the white line.
FIG 20

Once Side Shelf is positioned correctly, secure shelf
using 3 wood 4x30mm screws (Part R) in the holes
indicated in FIG 21. Use a Phillips Screwdriver to
secure.
DO NOT OVER TIGHTEN - This will cause the
screws to be loose.
STEP 16] Attaching Side Shelf
Manchester Split-top Table Assembly Instructions
4444 Lawton Avenue, Detroit, MI 48208 USA • Tel:[phone]/Fax:[phone]
Email: [email protected] • visit us at www.MartinUniversalDesign.com
May 08- RPI
Pg. 12
Secure with
screws in the
indicated holes
WARNING:
Your Table needs to be turned back onto its legs. Use 2 people to carefully turn the
table back over onto its legs.
Attach Pencil Ledge (Part W) to the front edge of table
top, using 2 each 4x12mm screws (Part S) as shown
in FIG 22.
STEP 17] Attaching Pencil Ledge
FIG 21
FIG 22
W
Side view of pencil
ledge after properly
installed on table top
Proper Assembled Table should now look like
Photo at Right.
To Tilt Table Top, lift on back edge of table top,
from flat position and lift until desired position.
