MARTINDALE CO190 User manual

CO190 CARBON
MONOXIDE METER
INSTRUCTION
MANUAL
ALWAYS READ THESE INSTRUCTIONS BEFORE
PROCEEDING
Thank you for buying one of our products. For safety and a full understanding
of its benefits please read this manual before use. Technical support is
available from 01923 441717 and [email protected].
CONTENTS
1 Safety Information 1
1.1 Meaning of Symbols and Markings 1
1.2 Precautions 1
1.3 Effects on Health from CO Exposure 2
2 Introduction 3
2.1 Inspection 3
2.2 Description 3
2.3 Accessories 3
2.4 Battery Installation 3
3 Operation 4
3.1 Description of Press Buttons and CO190 Elements 4
3.2 Description of LCD symbols 5
3.3 Low battery indication 6
3.4 Power On/Off 6
3.5 Auto Power Off 6
3.6 Backlight 6
3.7 Unit of Measurement 6
3.8 Max Value Measurement 7
3.9 Hold Mode 7
3.10 SET alarm mode 7
3.11 Alarm Off 8
4 Maintenance 8
4.1 Battery Replacement 8
4.2 Calibration 9
4.3 Cleaning 9
4.4 Repair & Service 9
4.5 Storage Conditions 10
5 Warranty 11
Specifications
1. SAFETY INFORMATION
REMEMBER: SAFETY IS NO ACCIDENT
These instructions contain both information and warnings that
are necessary for the safe operation and maintenance of this
product. It is recommended that you read the instructions carefully
and ensure that the contents are fully understood. Failure to
understand and to comply with the warnings and instructions can
result in serious injury, damage or even death.
Particular attention should be paid to the Warnings, Precautions
and Technical Specifications.
Please keep these instructions for future reference. Updated
instructions and product information are available at:
www.martindale-electric.co.uk
1.1 Meaning of Symbols and Markings
Caution - refer to instructions
Equipment complies with relevant EU Directives
End of life disposal of this equipment should be in
accordance with relevant EU Directives.
1.2 Precautions
The CO190 must only be used by a skilled and competent person
who is familiar with the relevant regulations, the safety risks
involved and the consequent normal safe working practices, and
under the conditions and for the purposes for which it has been
constructed and specified.
12
Before use check the unit for cracks or any other damage. Make
sure the unit is free from dust, grease and moisture. Also check
any associated leads and accessories for damage. Do not use if
damaged.
The sensor in particular must be protected from exposure to water
or dust as contamination can alter the performance characteristics
of the unit. Always replace the CO190 in its storage case when not
in use.
Avoid severe mechanical shock or vibration and extreme
temperature.
To avoid corrosion from leaking batteries, remove the batteries when
the unit is not in use for an extended period.
1.3 Effects on Health from CO Exposure
The table below shows some effects on health due to prolonged
exposure to various concentrations of CO.
Level of CO ppm Effect on health
0-1 Normal background level
9 Maximum indoor air quality level
50 Maximum concentration for continuous exposure in
any 8 hour average level
200 Mild headache, fatigue, nausea and dizziness
400 Frontal headache, life threatening after 3 hours
800 Death within 2 hours
1600 Nausea within 20 minutes, death within 1 hour
12800 Death within 1 to 3 minutes

3
2. INTRODUCTION
2.1 Inspection
Examine the shipping carton for any sign of damage. Inspect the
unit and any accessories for damage. If there is any damage then
consult your distributor immediately.
2.2 Description
The CO190 has the following functions and features:
LCD display with backlight
Display hold
Auto power off
Alarm mode
Temperature measurement
Max value measurement
Hold mode
2.3 Accessories
The CO190 comes with the following accessories:
Storage case
4 x 1.5V AA LR6 batteries
Instructions
2.4 Battery Installation
Refer to Section 4.1 (Battery Replacement).
4
3. OPERATION
3.1 Description of Press Buttons and CO190 Elements
1 Sensor
2 LCD display
3
HOLD The user can hold the measured value displayed on the screen
4
MAX Stores the highest measured value
5 Turns the CO190 On/Off
6SET Set-up button for the CO alarm threshold
7Turns the backlight on/off
8°C / °F Changes the unit of measurement between C or F
9 Battery cover
5
3.2 Description of LCD symbols
Battery capacity indicator
Auto power off is active
MAX Maximum recorded reading is displayed
HOLD Hold mode is active
1888 CO level measured result
Beeper Off indication
Hi Alarm Level
ppm Unit indication
°C °F Temperature unit of measurement
-188.8 Temperature measured result
SET SET alarm
ALARM Alarm Indication
3.3 Low Battery Indication
If the symbol is displayed, the battery needs replacing as
measurement accuracy can no longer be guaranteed (See section
4.1 Battery Replacement).
3.4 Power On/Off
Press the button to switch on the meter. Hold the button for 3
seconds to switch off the CO190.
The CO190 will perform a self-test calibration check when powered
up. If the meter detects CO levels of 0-3ppm, the LCD will decrease
from the initial value to zero. During the self- test, the display counts
down from 60 to 0 and will beep when complete. If the CO190
passes the self-test, it will begin monitoring and shows a reading on
the display.
3.5 Auto Power Off
If the unit is inactive for a period of 30 minutes, the CO190 will
automatically power off.
To disable this function, press and hold the button while switching
on the CO190. The HOLD symbol will disappear from the LCD to
confirm the auto power off is disabled.
3.6 Backlight
Press the button to turn on the display backlight. It will
automatically turn off after 30 seconds if there is no further operation
of the unit.
3.7 Unit of Measurement
When the CO190 is switched on, it defaults to °C. Press the °C / °F
button to switch between Celsius (°C) and Fahrenheit (°F).
6

3.8 Max Value Measurement
Press the MAX button to enter the MAX mode. The CO190 will
simultaneously store the maximum value to the memory and is
updated with every new reading.
Pressing the MAX button will display the MAX indicator and the
maximum recorded value on the LCD. Press the MAX button
again and the indicator flashes and the current measured value is
displayed. To exit the MAX mode, press and hold the MAX button
for two seconds.
3.9 Hold Mode
To enter the HOLD mode, press the HOLD button while in
measurement mode. The HOLD symbol will appear on the LCD. To
exit display hold, press the HOLD button again.
3.10 SET Alarm Mode
The default alarm threshold is set to 35ppm. The alarm can be set
from 0 to 1000 ppm in this function. Press and hold the SET button
to enter the CO high alarm threshold mode. The ALARM , SET and
Hi symbols should be displayed on the screen with the current
alarm threshold value flashing. While holding the SET button, press
the °C / °F to increase the required alarm threshold or the MAX
button to decrease the value. When the required value is displayed
on the screen, release the SET button to save it. This value will be
stored until further changes are made to the alarm mode.
The alarm beeper gives audible indication, speeding up with CO
concentration and becoming a continuous tone above 200 ppm
(the recommended 15 minute exposure limit). Above 1000 ppm, the
7
alarm beeper sounds continuously with a high frequency tone. The
LCD will display OL to indicate an over range reading.
3.11 Alarm Off
Press and hold the button and then switch on the meter. The
mute beeper icon will appear on the display. To re-enable the
beeper, power off the CO190 and then switch it back on.
4. MAINTENANCE
4.1 Battery Replacement
The battery compartment is on the rear of the unit. To gain access,
undo the retaining screw and lift the cover away from the back of
the unit.
Replace with 4 new AA batteries (IEC LR6, NEDA 15A), observing
correct polarity. Replace the battery cover.
Note: Do not mix old and new batteries.
8
4.2 Calibration
To maintain the integrity of measurements made using your
instrument, Martindale Electric recommends that it is returned
at least once a year to an approved Calibration Laboratory for
recalibration and certification.
Martindale Electric is pleased to offer you this service.
Please contact our Service Department for details.
Email: [email protected]
Tel: [phone]
The CO190 should be regularly checked to ensure it is reading
correctly. Martindale recommends an annual recalibration and
regular checks with a test gas.
4.3 Cleaning
This instrument must be kept in a clean condition.
If contamination is found, clean with a damp soft cloth and if
necessary a mild detergent or alcohol. Do not use abrasives,
abrasive solvents, or detergents which can cause damage to the
unit. If a mild detergent is used, the unit should subsequently
be thoroughly cleaned with a water dampened soft cloth. After
cleaning, dry and allow to remain in a dry environment for 2 hours
before use.
4.4 Repair & Service
There are no user serviceable parts in this unit other than those
that may be described in section 4. Return to Martindale Electric
if faulty. Our service department will quote promptly to repair any
fault that occurs outside the guarantee period.
Before the unit is returned, please ensure that you have checked
the unit and batteries.
4.5 Storage Conditions 9
The instrument should be kept in warm dry conditions away from
direct sources of heat or sunlight, and in such a manner as to
preserve the working life of the unit. It is strongly advised that the
unit is not kept in a tool box where other tools may damage it.
10

11
5. WARRANTY AND LIMITATION OF LIABILITY
This Martindale product is warranted to be free from defects in
material and workmanship under normal use and service. The
warranty period is 2 years and begins on the date of receipt by the
end user. This warranty extends only to the original buyer or end-
user customer, and does not apply to fuses, disposable batteries,
test leads or to any product which, in Martindale’s opinion, has been
misused, altered, neglected, contaminated, or damaged by accident or
abnormal conditions of operation, handling or storage.
Martindale authorised resellers shall extend this warranty on new and
unused products to end-user customers only but have no authority to
extend a greater or different warranty on behalf of Martindale.
Martindale’s warranty obligation is limited, at Martindale’s option, to
refund of the purchase price, free of charge repair, or replacement of
a defective product which is returned to Martindale within the warranty
period.
This warranty is the buyer’s sole and exclusive remedy and is in lieu
of all other warranties, expressed or implied, including but not limited
to any implied warranty of merchantability or fitness for a particular
purpose. Martindale shall not be liable for any special, indirect,
incidental or consequential damages or losses, including loss of data,
arising from any cause or theory.
Since some jurisdictions do not allow limitation of the term of
an implied warranty, or exclusion or limitation of incidental or
consequential damages, the limitations and exclusions of this warranty
may not apply to every buyer. If any part of any provision of this
warranty is held invalid or unenforceable by a court or other decision-
maker of competent jurisdiction, such holding will not affect the validity
or enforceability of any other provision or other part of that provision.
Nothing in this statement reduces your statutory rights.
Specification
CO190 Carbon
Monoxide Meter
All specified accuracies are at 23°C
Temperature coefficient:
0.1 x (specified accuracy) per °C
(0-22°C, 24-50°C)
Measurement ranges:
Carbon monoxide: 0 to 1000ppm
Temperature: -20°C to 70°C (-4°F to 158°F)
Carbon Monoxide
Range Accuracy
0-1000 ppm ±5% reading or ± 5 ppm (whichever is greater)
Temperature
Range Accuracy
-20°C to 70°C ±0.8°C
-4°F to 158°F ±1.5 °F
General
Digital display: 4 digit, 30mm, liquid crystal display
Sampling rate: twice per second
Sensor type: electrochemical carbon monoxide gas sensor
Temperature sensor type: thermistor
Resolution: 1ppm, 0.1°C/0.1°F
Response time: (at T90 in slowly moving air)
carbon monoxide: 60 seconds
temperature: 10 seconds
Specification
CO190 Carbon
Monoxide Meter
Power: 4 x 1.5V, AA alkaline batteries (IEC LR6, NEDA 15A)
Battery Life: 200 hours continuous approx.
Auto power off: after approx. 30 minutes
Dimensions: 190 (L) x 65 (W) x 45 mm (H)
Weight: 235g approx.
Includes: 4 x 1.5V AA alkaline batteries and instructions
ENVIRONMENTAL
Temperature & Humidity
(Operating): 0°C to 50°C (32°F to122°F) 10-90% R.H.
(Storage): -20°C to 70°C (-4°F to 158°F) 0-80% R.H.
EMC
Conforms to BS EN 61326-1
O18th Edition Testers
OAccessories
OCalibration Equipment
OContinuity Testers
OElectricians’ Kits
OEnvironmental Products
OFull Calibration & Repair Service
OFuse Finders
ODigital Clamp Meters
ODigital Multimeters
OLabels
OMicrowave Leakage Detectors
OMotor Maintenance Equipment
OMultifunction Testers
ONon-trip Loop Testers
OPat Testers & Accessories
OPhase Rotation Testers
OProving Units
OSocket Testers
OThermometers & Probes
OTest Leads
OVoltage Indicators
OSpecialist Metrohm Testers (4 & 5kV)
OSpecialist Drummond Testers
Check out what else you can get from Martindale:

Martindale Electric Company Limited
Tel: [phone] Fax: [phone]
E-mail: [email protected]
Website: www.martindale-electric.co.uk
© Martindale Electric Company Ltd. 2018
Registered in England No. 3387451. Rev 1 LIT190
