Mase Generators IS 6.1 User manual

IS 6.1
Tipo modello
N° matricola
Codice
Rev.0 A.A. 09/08/2016
cod.43478
MANUALE USO, MANUTENZIONE E INSTALLAZIONE I
USE, MAINTENANCE AND INSTALLATION MANUAL GB

IS6.1
- 3
GB
GB

IS6.1
- 4
GB
GB
CONTENTS
DEFINITIONS USED................................................ 5
PRELIMINARY PRESCRIPTIONS ........................... 7
1 GENERAL INFORMATIONS............................ 6
1.1 Conform use .................................................... 8
1.2 Residualrisks................................................... 8
1.3 Safetysymbols ................................................. 9
1.4 Symbols on the generator group..................... 10
1.5 Safety labelinformations ................................ 11
1.6 Reference documents .................................... 15
1.7 Referenceregulationsandlegislativeprovisions .. 15
1.8 Marking.......................................................... 15
1.9 Identificationofthe generator unit ................... 15
2 GENERAL CHARACTERISTICS.................... 16
2.1 Composition of generator unit......................... 16
2.2 Command and control panel........................... 17
2.3 Table oftechnicalcharacteristics .................... 18
3 INSTALLATION............................................. 19
3.1 Generalhousingcharacteristics ...................... 19
3.2 Lifting ............................................................. 19
3.3 Anchoring the generator ................................. 19
3.4 Ventilation ...................................................... 19
3.5 Coolingwater circuit ....................................... 20
3.5.1Seawaterfeedsystem.................................... 20
3.5.2Components .................................................. 21
3.5.3Typicalinstallation .......................................... 22
3.5.4Exhaust system.............................................. 25
3.6 Fuelcircuit ..................................................... 26
3.6.1Fuelfilter ........................................................ 26
3.6.2Electric pump ................................................. 26
3.7 Electricalconnections ..................................... 27
3.7.1Batteryconnection.......................................... 27
3.7.2Controlpanelconnection ................................. 27
3.7.3A.C.connection. ............................................. 28
3.7.4Generator-networkswitching ........................... 29
3.7.5Emergencystop ............................................. 29
4 USING THE GENERATOR ............................ 30
4.1 Preliminary checks ......................................... 30
4.2 Fuelling .......................................................... 30
4.3 Starting the generator..................................... 31
4.4 Stoppingthe generator ................................... 31
4.5 Emergency stop ............................................. 32
5 SAFETY SWITCHES AND WARNING
SIGNALS ....................................................... 32
5.1 Engine protection module ............................... 32
5.2 Protectionagainst shortcircuits andoverload . 32
5.3 Control panel - alarm codes ............................ 33
6 MAINTENANCE ............................................. 34
6.1 Preamble........................................................ 34
6.2 Routine engine maintenance .......................... 34
6.3 Engine oil check ............................................. 34
6.4 Engine oil change........................................... 35
6.5 Oilfilter........................................................... 35
6.6 Replacing / cleaning the fuel pump filter.......... 36
6.7 Replacingthelinefuelfilter .............................. 36
6.8 Bleedingthe fuelsystem ................................. 37
6.9 Airfilter........................................................... 37
6.10 Drainingthe coolingsystem ............................ 37
6.11 Replacingthe zinc anode ................................ 37
6.12 Seawaterpumpmaintenance........................... 38
6.13 Checking/replacingthealternatorv-belt .......... 39
6.14 Alternatormaintenance ................................... 39
6.15 Batterymaintenance ....................................... 39
6.16 Listof recommendedspare parts ..................... 40
6.17 Periodsofinactivity ......................................... 40
6.18 Periodchecksandmaintenance ...................... 41
6.19 Anomalies, causes andremedies .................... 42
6.20 Howtoorderthespareparts............................ 42
7 TRASPORT, STORAGE, LIFTING,
HANDLING AND PACKAGING ...................... 43
7.1 Transport and storage .................................... 43
7.2 Lifting and handling of the packed
generator unit ................................................. 43
8 GUARANTEE AND RESPONSABILITY......... 44
8.1 Guarantee ...................................................... 44
8.2 Limits ofresponsability ................................... 44
9 DISPOSAL..................................................... 44
9.1 Disposalof the waste materials derivingfrom
maintenance and scrapping .......................... 44
10 WIRING DIAGRAMS...................................... 45
10.1 Wiring diagrams ............................................. 45

IS6.1
- 5
GB
GB
DEFINITIONS USED
Theterms used are currenttechnicalterms,and where considered necessarythe meaningis described
below
- Generator
An assembly of an internal combustion piston engine and an alternate current, synchronous, 2-4 pole, self-
excited generator,joined together to createa stationfor self-productionof electricalenergy.
- Usersystem
Composed of the power supply circuits of the user equipment, including the relevant sectioning, handling,
breaking, transformation, protection, etc. devices which do not formpart of the production, transmission and
distributionsystems.
- Category 1 electrical system
A systemwhere the rated voltage is greater than 50 V and smaller than 1000 V includingalternate current.
- Load
A set of numerical values of electrical and mechanical magnitudes which characterise the requirements
imposed on a rotary machine by an electrical circuit or by a mechanicaldevice at a certaininstant.
- Thermal switch
Main cut-out and breaking device made up of a switch which opens automatically by thermal effect.
- Differential switch
Main cut-out andbreaking device made up of a switch which opens automatically by differential effect.
- Skilled person
A person with technical know-how or sufficient experience to allow him to avoid the dangers inherent in
electricity.
- specialisedpersonnel
Apersonable to evaluate the jobassignedto himandrecognise thepossible dangers on the basis of training
atthetrainingcentres,withprofessionalexperienceandknowledgeoftheequipmentinquestionandofthepossible
dangers deriving inthe eventof negligentbehaviour.
- Supplier
Abody (e.g. manufacturer, agent, installer) whichsupplies the equipmentor services relating tothe machine.
- Control
Controlaction by which an output variable of the controlled system(controlled variable) is affectedby an input
variable of the controllingsystem inorder to achieve a certain goal.
- Manual control
Control where the change of a variable handled is produced by a person through manual intervention.
- Automaticcontrol
Controlwherethechangeofavariablehandledisproducedbyacontrollingdevice(automaticcontroller)without
the interventionof a person.
- Danger
Source of possible harm or damage to health.
- Protection
Guard or protectiondevice as safety measure to protect persons froma present or potentialdanger.
- Casing
Part intendedto assure protectionofthe equipmentagainst specific outsideinfluences andprotectionin every
senseagainstcontacts.

IS6.1
- 6
GB
GB
- Connection in bad state
The live parts are not fully coveredwithinsulationremovable by destructiononly, the connections are not secure
because of unstable tighteningof the parts and a development of oxide between the parts.
- Direct contact
Contact of persons or animals withlive parts.
- Control circuit
Circuit usedto control machine operation.
- Equipment
Generaltermwhich comprises materials, devices, equipment,accessories andsimilar used inconjunction with
anelectrical installation.

IS6.1
- 7
GB
GB
PRELIMINARY PRESCRIPTIONS
FIELD OF EMPLOYMENT:
THE GENERATOR IS PROPER FOR TO PRODUCE IN WAY AUTONOMOUS ELECTRIC ENERGY IN THE
LIMITS OF TENSION AND WATT DECLARED BY THE BUILDER
Consult this manual carefully before proceeding to the use and to any operation on the genset.
FAILURE TO RESPECT THE SPECIFICATIONS CONTAINED IN THIS USE AND MAINTENANCE MANUAL
WILL RESULT IN FORFEITURE OF THE GUARANTEE ON THE PRODUCT.
This manual was drawnupby themanufacturer andforms anintegral partof thegenerator equipment,definition
used as indicatedinDirective 98/37/EC; theinformationcontainedin the manualis addressedto allthe persons
involvedin the operating life cycleof the generator,andis necessary toinformboth thosewho effectively carry
out the different operations and those who coordinate the activities, to arrange the necessary logistics andto
regulate access to the place where the generator willbe installed andoperated.
This manual was drawn up by the manufacturer with the purpose of providing essential information and
instructionsforproper useandmaintenance inconditionsof safety.Itconstitutes anintegralpart ofthegenerator
equipment andmust carefully be protected from any agent which may damage it for the entire life cycle of the
generator. The manual must accompany the generator if transferred to another user or owner.
It is opportune to remember the supplied generator group needs installation.
The technician willrelease, at the endof the work, a declaration to the meaning of the normative applied.
The manual defines the purpose for which the generator was constructed and contains all the information
necessary to guarantee safe andproper use.
Constantobservanceoftheinstructionscontainedinthismanualguaranteesthesafetyoftheoperator,protection
against damage to persons or things, operating economy anda longer life of the generator.
The drawings are provided by way of example. Even if the generator in your possession differs from the
illustrations contained in this manual in elements of little significance, for example the colour, the safety of the
generator andthe information providedare nevertheless guaranteed.
To facilitate consultation,it has been dividedinto sectionsidentifying themain concepts; fora quicklook at the
topics, consult the index.
Ongoingimprovementanddevelopment oftheproductmay have ledto modificationstothe generatorwhichare
not included in this publication.
Whenever a problem concerning the generatororthispublication arises, consultmanufacturer forthe
latestinformationavailable.

IS6.1
- 8
GB
GB
1 GENERAL INFORMATIONS
1.1CONFORM USE
The generator is suitable for independent productionof electrical energy withinthe voltage and wattage limits
declared by the manufacturer.
Any other use outside the already stated fieldof use is prohibited: the generator is intended for marine use.
The generator has been designed to operate independently (without operator) if not for sporadic checks.
The limits of use are:
- operatingtemperature: -10°C (14°F), +40°C (104°F)
- relative humidity: 30% - 90%
- the generator is suitable for marine operation.
Installations are subjectto approvalby manufacturer orby anauthorisedinstaller.
Arbitrary modifications to the machine are prohibitedfor safety reasons.
Original spare parts must be used on pain of losingmachine conformity.
Allthe operations that require dismantling of specialparts may only be carried out by technicians authorised by
the local dealer or the manufacturer.
Only manufacturer techniciansor personneltrained havethe necessary knowledge of the generator andthe
special equipmentas wellas the experience to carry out anyoperation inthemost economical andreliable way.
1.2 RESIDUAL RISKS
The generator has been designedtakinginto account the safety regulations set out in the EC directives and
standards; nonetheless, the followingresidual risks remain:
- injury caused by contact with hot parts during maintenance.
- injury caused by electrocution during maintenance on the electric panel.
- risks connected with long periods of exposure to the noise of the generator (with opencowling).
- risks due to contact with the generator lubricants during maintenance.
- risks due to the fire hazard the fuel represents.
Because of the typical intrinsic danger of the Generators, youare reminded that, although the generator has
beendesigned, constructed andtestedin accordance with the safety regulations, only proper andcarefuluse
can guarantee full safety; to this end, the various precautions to be takenduringuse of the Generator are
listedbelow.

IS6.1
- 9
GB
GB
SAFETY INSTRUCTIONS
The electromechanics equipments, included the generatingsets, switch, command electric equipments and
accessories, cancause damages to people and,if they are installed, usedor mainteined with not qualified
operations, they can put inserious danger the life of people. To avoid accidents is necessary to know the
potential risks andoperate with caution.Read and follow allthe precautions andthe instructions for the safety.
PRESERVE THESE INSTRUCTIONS.
The manual shows varied typologies of precautions andinstructions for the safety: Danger, Warning, Caution.
1.3 SAFETY SIMBOLS
Indicates that particular attention mustbe paid in order to prevent serious riskswhich could lead to death
or possible harm to the health of personnel.
Aconditionwhichmayoccurduringthelifetimeof aproduct,system orplantconsideredatriskregarding
damage topersons, property,the environment oreconomic loss.
Indicatesthatparticularattentionmustbepaidinordertopreventseriousconsequenceswhichcouldresult
in damage to tangible goods, such as the resources or the product.
Other symbols on this manual
Particularimportantinstructions
Indicates components and non inclusiveparts with the base configuration.
Carefully consult this manual before usingor carryingout any operation on the generator.
The routine maintenance operations, must be carried out by qualifiedpersonnel who have the appropriate
equipment and protections.

IS6.1
- 10
GB
GB
Cod. 42653
Cod.42585
Cod. 42655
Cod. 42656
Cod. 41781
Cod. 42657
cod. 42118
Cod. 42654
Cod. 41763
1.4 SYMBOLS ON THE GENERATOR GROUP

IS6.1
- 11
GB
GB
1.5 SAFETY LABEL INFORMATIONS
• These labels warn the user of any danger which may cause serious injury.
Carefully read the meaning andthe precautions described in this manual.
• Ifthelabeldetaches orbecomes illegible, replace it witha new one whichcanbe requestedfromanauthorised
dealer.
Danger Symbols Description
HOT PARTS
Hot engine and exhaust system.
Can cause severe injuryor death.
Do not work on generator set untill it is allowed to cool.
Servicingexhaustsystem.
Hot parts can cause severe injury or death.
Do not touch hot engine parts. An engine becomes hot while running and exhaust
system components become extremely hot.
Hot coolant and steam. Before removing the pressure cap,stop the generator set
andallow it to cool. Then loosen the pressure cap to rilieve pressure.
ACCIDENTAL STARTING
Accidental starting. Can cause severe injury or death.
The generator is started froma remote controlpanel. In order to prevent accidental
starting, set the emergency switchto the (OFF) position.
Disconnect the negative pole fromthestarter battery.
Disabling generatorset. Accidentalstarting can cause severe injuryor death.
Before workingonthegeneratorset orconnectedequipment,disable thegeneraset
as follows:
1)Disconnect power to battery charger, if equipped.
2)Remove battery cables (remove negative (-)lead first).
3)Reconnect negative (-) leadlast whenreconnectingbattery.
Followtheseprecautionstopreventstartingofgeneratorsetbytheremotestart/stop
switch or by the onboard switch.
Hazardous voltage. Moving rotor.
Can cause severe injuryor death.
Operate generator set only with all guards and electrical enclosures in place.
MOVING PARTS
Rotating parts.
Can cause severe injuryor death.
Do not operate generator set without all guards, screens, andcovers in place.
PREVENTING FIRE
• Be sure to use the proper diesel fuel.
• Be sure to stop the engine before refueling.
•If you spill fuel, wipe off such spillage completely.
• Never place oil or other flammable materials (such as straws, withered
grass) close to the engine during running or shortly after shuttingit down.
• Check fuel oil and engine oil for leakage from their piping lines to cause
fires.

IS6.1
- 12
GB
GB
PREVENTING FIRE
Can cause severe injuryor death.
•Start
• Start the engine only from a starter switch without any loador in neutral posi-
tion of the clutch of machine unit.
The machine unit suddenly starts to move or generates power to cause serious
personal injury.
• Keep the machine unit sufficiently away from a building and flam-
mable materials during engine running. It may cause fires due to hot
exhaust gas and engine body.
• Keep sparks, open flames or any other formof ignition(match, cigarette,
etc.) away whenfueling / refueling. Fire andor an explosion may result.
FIRE
Can cause severe injuryor death.
In case of fire, do not open the chest
Extinguish the generator fire and immediately unload the whole content of the
portable extinguisher through the hole indicatedby the label.
EXHAUST SYSTEM
Carbonmonoxide.
Can cause severe injuryor death.
The exhaust system must be leakproof and routinely inspected.
Carbonmonoxidesymptoms.
Carbonmonoxide can cause severe nausea, fainting, ordeath.
Carbon monoxide is a poisonous gas witch is present in exhaust gases.
Inspectingexhaustsystem.
Carbonmonoxide can cause severe nausea, fainting, ordeath.
In addiction to routine exhaust system inspection,install a carbon monoxide
detector.
Consultyourboatbuilderordealerforapproveddetectorinstallation.Inspect your
detector before each generator set use. Test the carbon monoxide detector
function per the manufacter’s instructions and keep it operationalat alltimes.
Installingexhaust system.
Carbonmonoxide can cause severe nausea, fainting, ordeath.
In addiction to routine exhaust system inspection,install a carbon monoxide
detector.
Use the followingprecautions when installing andoperating generator set.
Do not install exhaust outlet where exhaust can be drawn in throught
portholes,vents,or airconditioners.
Ifthe generatorsetexhaust discargeoutletisnear thewaterline,watercouldenter
the exhaust discharge outlet andclose or restrict the flow of exhaust.
Danger Symbols Description

IS6.1
- 13
GB
GB
EXHAUST SYSTEM
Carbonmonoxide.
Group generator use.
Carbonmonoxide can cause severe nausea, fainting, ordeath.
Carbon monoxide is an odorless, colorless,tasteless, non irritating gas,able to, if
inhaled only also for brief time to provoke the death.
Beespecially carefulifoperatingthegenerator setwhenmooredor anchored under
calmconditions as gases may accumulate.
Ifoperatingthegeneratorsetdockside,moortheccraftsothattheexhaustdischarges
onthelee side(thesideshelteredfromthewind).Alwaybeawareofothers-makesure
your exhaust is directed away fromother boats andbuildings.
HAZARDOUS VOLTAGE / ELECTRICAL SHOCK
Hazardous voltage. Moving motor.
Can cause severe injuryor death.
Operate generator set only with all guards and electrical enclosures in place.
Grounding generatorset.Hazardousvoltagecan causesevereinjuryordeath.
Electroconduction is possible whnever electricity is present. Open main circuit
breakers of all power source before servicingequipment. Configure the installation
to electrically groundthe generator set andalectrical circuits when in use.
Nevercontactelectricalleadsorapplianceswhenstandinginwateroronwetground,
as the chance of electroconduction increases under such conditions.
Disabling generator set.
Hazardous voltage can cause severe injury ordeath.
To disable the generating set from load, turn off the the automatic switch of the line
or disconnect the output cables fromthe commutationswitch and block the final part
ofcables.Hazardous voltageto loadduringanispectioncoldcause severedamages
to people andto equipment. Donot use the emergency buttoninstead the automatic
switch of the line.
Battery short circuit.
Explosion can cause severe injury or death. Short circuits can cause severe
damagestopeopleand/orequipment.Disconnectthebatterybeforedoinginstallation
operations o generator set maintenances. Remove all jewels before doing
maintenance on the maintenance.
Remove negative (-) lead first when disconnecting battery. Reconnect negative (-)
lead lastwhen reconnectingbattery.
Never connect negative battery lead (-)to positive lead (+)of startingsolenoid.
Danger Symbols Description

IS6.1
- 14
GB
GB
Danger Symbols Description
BATTERY
Do not touch the electrolitic battery acid
Sufficient ventilation of the battery area.
• Keepthe area around the battery wellventilated, paying attention to keep
sparks, open flame and any other formof ignition away. Duringengine running or
chargingbattery, hydrogengas is produced fromthe battery and
can be easily ignited.
Battery acid. Sulfuric acid in batteries can cause severe injury or death.
Sulfuric acidin battery cancause permanent damage to eyes, burn, skin,and hole
in clothing.
Always wear splash-proof safety googles when workingnear the battery. If battery
acidis splashedin the eyes or skin,wash immediatelythe affectedarea with large
quantity of clean water. Seek immediate medical aid incase of eyes contact.
Do not intentionally make the battery sparkby short-circuiting to check its
remainingcharge. It will cause fires.
If the battery electrolyte frozen, recharge the battery after warming upto
thaw it.
SAFETY CLOTHING
Do not expose your skin to high pressure fuel spray
Be careful so as not to bringyour skin in contact with highpressure fuel spray
from broken fuel injection pipe to penetrate your skin to cause inflamed.
If exposing to the spray should occur, obtain prompt medical treatment.
Beware of dirt from air blowing
Wear protective equipment such as goggles to protect your eyes when
blowingcompressed air or steam. Dust or flyingdebris can hurt eyes.

IS6.1
- 15
GB
GB
KVA
Hz
Cos.Ø
V V
A A
Degrees of protection IP
°C
m
Performance class
year of manifacture
Rated power factor
Rated voltage
declared frequency
Mass Kg
Class of insulation
Temp. max of use
Altitude max. of use
Rated current
Rated power 3F
Code Serial n°
1
2
5
4
14
67
89
10 11
12
13
15
16
3
1.6 REFERENCE DOCUMENTS
The instructions for use provided with each generator
are made up ofa collection of documents of whichthis
manual represents the General Part. The following
documents are normally provided separate.
a CE declarationof conformity.
bInstructionmanualforuse andmaintenanceof
the generators,(this manual).
cEngine use and maintenance manual.
dListofServiceCentres.
eWarrantycertificate.
fWarranty card.
gEPA certificate (Engine manufacturing)
1.7 REFERENCE REGULATIONS AND LEGISLATIVE PROVISIONS
The generatorgroups, destinedto the countries of the
EuropeanCommunity,areconformingto the applicable
ECdirectives,andtheyareprovidedofaECDeclaration
of Conformity.
EN 12601: Reciprocatinginternal combustionengine
driven generating sets.
98/37/EC and subsequent amendments:
Essential machine requirements for safety and health
protection(“Machine”directive).
73/23/EC and subsequent amendments contained in
thedirective93/68/EC:Guaranteeofsafetyofelectrical
material intended for use within certain voltage limits,
(“LowVoltage”Directives).
EN60204.1: Electrical equipment of machines.
1.8 MARKING
The generator identification plate carries all the
identification data conforming to ISO 8528 and in
accordance with the provisions for EC marking for
thosecaseswhererequired. Belowisafacsimileofthe
identification plate fixed onthe hull of eachgenerator.
1.9 IDENTIFICATION OF THE GENERATOR UNIT
1 - Machine name
2 - Machine code
3 - Serial number
4 - Rated power
5 - Declaredfrequency
6 - Ratedpower factor
7 - Ratedvoltage
8 - Ratedcurrent
9 - Degree of protection
10 - Class of isolation
11 - Temperature max. of use
12 - Altitude max. of use
13 - Performance class
14 - Year of construction
15 - Manufacturer - Adress
16 - Weight
The machine code number, the serial number
and the year of construction must always be
indicated when contacting the manufacturer
for information, order of spare parts, etc..

IS6.1
- 16
GB
GB
12
5
6 3
9
7
8
19
10
24
18 21
20
17 11
14 13
16
12 15
25
27
26
25 26 15
25
2 GENERAL CHARACTERISTICS
Thegeneratorshavebeendesignedforuseinthemarine
field, using highly reliable 3000/3600 rpm air/water-
cooleddieselengines.Particularattentionhasbeenpaid
to the degree of protection against external agents,
engine protection andprotection of the electrical parts
against overload or overheating, adopting automatic
systems able to stop the generator in the event of
malfunctioning.
Thegeneratorisparticularlyquietthankstoaninternally
insulatedsoundproofcasingandanadvancedsoundproof
systemforcombustionsmokeexhaust.
Thealternatorsusedarethesynchronousself-energized
type.
2.1 COMPOSITION OFGENERATOR UNIT
Thegeneratorunitisessentiallycomposedbythefollowing
components.
1 - Fixed frame
2 - Upper openable cowling
3 - Front openablecowling
4 - Electricconnectioncowling
5 - Anchorage stirrup
6 - Emergency button
7 - Exhaust gas andcoolingwater connection
8 - Seawaterintakeconnection
9 - Tankintakeconnections
10 - Engine air filter
11 - Check / refill oil cap
12 - Oilextractionpipe
13 - Oilfilter
14 - Expansionvase
15 - Seawaterpump
16 - Fuel pump
17 - Fuelfilter
18 - Engine hightemperaturesensor
19 - Mixer hightemperaturesensor
20 - Startingmotor
21 - rpmregulation screw
22 - Battery connection lead(+)
23 - Battery connection lead(-)
24 - Battery chargeralternator
25 - Zinc anode
26 - Water/waterradiator
27 - Water extraction pipe

IS6.1
- 17
GB
GB
56
2
9 87
4
1
3
2.2 COMMAND AND CONTROL PANEL (STANDARD VERSION)
Each generator is fitted with an instrument panel for
commands andcontrols with the followingcomponents:
1) Emergency button
2) Generalmagnetothermalswitch
3) Engine protection module
4) Display
5) START/ STOPswitch
6) START/Preheatingswitch
7) ScrollUP navigation menu
8) ScrollDOWNnavigationmenu
9) OKpushbutton

IS6.1
- 18
GB
GB
2.3 TECHNICAL CHARACTERISTICS TABLE
(1) Limited - time running power (LTP) ISO 8528-1
It is the maximum power that, under the environment conditions established by the norm ISO 3046/1, the generator group it is able to disburse for
a maximum of 500 hours for year, of which a maximum of 300 hours among the interval of maintenance prescribed by the builder. It is accepted
the operation to this power conditions the duration of the group.
An overload of the 10% is admitted only for regulation.
(2) Prime power (PRP) ISO 8528-1
It is the available maximum power for a variable power cycle that the generator group is able to disburse for a boundless number of hours for year
among the interval of maintenance prescribed by the builder and under the environment conditions established by the norm ISO 3046/1. The middle
power during a period of 24 hours, doesn't have to exceed 80% of the PRP.
An overload of the 10% is admitted only for regulation.
MAX POWER (LTP)
1
6.1 kW
CONTINUOUS POWER (PRP)
2
5.6 kW
POWER FACTOR (Cos
F
)
1
RATED VOLTAGE
230
V
RATED FREQUENCY
50
Hz
GRADE OF PROTECTION
IP 23
MAX TEMP. OF USE
40 - 104
°C - °F
MIN TEMP. OF USE
-5 - 23
°C - °F
MAX ALTITUDE OF USE
1000 - 3280
m - ft
MAX TILT OF USE
(PERIODICAL 3 min) 30°
MAX TILT OF USE (CONTINUOUS) 25°
SEA WATER PUMP FLOW
25 - 6,6
L/min - gal/min
L
650 - 25,6
mm - in.
DIMENSIONS
W
468 - 18,4
mm - in.
H
555 - 21,8
mm - in.
MASS
165 - 364
kg - lbs
TYPE
4 STROKE
MANUFACTER
KUBOTA
MODEL
Z 482
DISPLACEMENT 479 - 29,2 cm3 - in3
MAX POWER
11,1 - 8,2
HP - kW
n° OF CYLINDERS
2
RATED SPEED
3000
rpm
SPEED CONTROL
CENTRIFUGAL / MECCANICAL
INDUCTION SYSTEM
NATURAL
FUEL
DIESEL
INJECTION SYSTEM
INDIRECT
FUEL FEEDING PUMPS
ELECTRIC
MAX PREVALENCE FUEL PUMP
700 - 27,5
mm - in.
FULL LOAD CONSUMPTION 2,6 - 0,7 L/h - gal/h
COOLING
WATER / WATER (INTERCOOLER W/A)
LUBRIFICATION SYSTEM FORCED
OIL SUMP CAPACITY 2,1 - 0,5 L - gal
ELECTRIC PLANT
12
(negative pole to ground)
V
STARTING
ELECTRIC
STARTING MOTOR 12 - 0,7 V - kW
STARTING BATTERY 12 - 45 V - Ah
BATTERY CHARGER 12 - 10 V - A
STOPPING SYSTEM
STOP SOLENOID VALVE
TYPE
SYNCHRONOUS, SELF-REGULATED
n° OF POLES
2
MAX CURRENT
26,5
A
ISOLATION CLASS
H
VOLTAGE REGULATOR
CAPACITOR
VOLTAGE STABILITY
A
10%
FREQUENCY STABILITY
A
5%
COOLING
AIR / WATER
MODEL IS 6.1
GENERAL FEATURES
ALTERNATOR
ENGINE

IS6.1
- 19
GB
GB
555
[21.85"]
650
[25.57"] 468 [18.43"]
505
[19.90"]
465
[18.31"]
521
[20.51"]
537
[21.14"]
56.5
[2.22"] 56.5 [2.22"]
405
[15.94"] 50
[1.98"]
50
[1.98"]
619
[24.37"]
15.5
[0.61"] 15.5
[0.61"]
Ø14
[Ø0.55"]
Ø9
[Ø0.35"]
1
2
3
mm
[in.]
3 INSTALLATION
The generator may only be installed by qualified
technicians. Malfunctioning due to improper
installation may cause injury or death.
3.1 GENERATOR HOUSING CHARACTERISTICS
- The generator must be installed in a sufficiently
ventilated room able to assure the small amount of air
required for engine combustion.
-The roommust beacoustically separatedand isolated
from the living quarters.
- The generator must be positionedinsucha way as to
facilitate normalmaintenance operations.
- It is advisable to installthe generator in the
propulsion engine room provided that it meets the
above conditions.
- The air must be clean.
-The airtemperature inthe place of installation must be
between -5°C(23°F) and +40°C(104°F).
- The relative humidity must not exceed 50% at a
maximum temperature of +40°C (104°F). Relative
humidity of 90% at +20°C (68°F) and 100% at +25°C
(77°F)is permissible.
3.2 LIFTING
To lift the generator place the hook inthe hole (ref.1)
Always take these precautiona when lifting the
generator:
- Do not swing suspended loads.
- Never leave the load unattended.
- Lower the generator to the groundvery slowly.
- Always maintain the safety distance.
All the lifting operations must be carried out by
personnel specialised in this type of work, such as
truckdrivers, cranedrivers, slingers.
Theoperatorisconsideredresponsibleforusingthe
correctmachine slingingand liftingtechnique.
3.3ANCHORING THE GENERATOR
Forfixingthe generator setpredispose anadapted plinth
to sustain the weight andvibrations of the generator.
Proceed then to the perforation of the plinth following
the indications in (ref.2).
3.4 VENTILATION
Thegenerator is equippedwithan internalforced cooling
systemthrough a water/air exchanger.
The amount of air required for combustion is
aspiratedthrough the intake locatedonthebase (ref.3):
Therefore, always checkthat this intake is
free of any obstruction.

IS6.1
- 20
GB
GB
12
3.5 COOLING WATER CIRCUIT
The generator engine is cooled by an open-circuit
systemin whichseawater circulates.
At the time of installation, a seawater feed circuit
must be arranged for cooling, and an exhaust system
for the combustiongas and water mixture.
3.5.1 SEAWATER FEED SYSTEM
Two water intake systems are normally adopted on
boats:
-Direct intake system(ref.1).
-Systemwithbaffle (ref.2).
Manufacturer recommends using the direct intake
system (ref.1), since it prevents intake of pressurised
waterinto theintake ducts, instead generatinga vacuum
easily overcome by the water pump head of the
generator.
Do not fit any type of protection cap on the direct
intake system.
The system with baffle (ref.2), on the other hand, may
cause the following problems:
a- If mounted withthe slots facingthe bow:
In this case, during navigation and with the generator
off, pressure is created in the water intake duct, which
maycause the systemto fillupuntilreachingthe exhaust
port, thus making it possible for water to enter the
cylinders.
b- If mounted with the slots facingthe stern:
In this case, duringnavigation a vacuummay be created
in thewater intakeduct suchas to inhibitthewaterpump
to activate the cooling system or such as to limit the
flow rate withconsequentoverheatingofthe generator.

IS6.1
- 21
GB
GB
5
2
1
3
4
6
Exhaustmanifold
3.5.2 COMPONENTS
Ifthe generatorisinstalledat aheight over1m (3,3ft)
above the waterline, a check valve (ref.2) must be
fitted after the seawater intake to prevent the water
circuit from emptying out when the engine is off. If
the circuit is empty, the water pump impeller may
be damaged during starting.
For the same reason, when starting the generator
for the first time, manually prime the intake pipe
leading from the valve to the pump.
- 1/2"direct seawaterintake (ref.1).
- 1/2" ball cock (main system) (ref.3).
- 1/2" ballcock (system bleeding) (ref.4).
Serves to drain the cooling system of the generator
for general maintenance or for long periods of
inactivity.
- Water filter(inspectable) (ref.5).
It protects effectively thecooling circuit against intake
of mud, sand and seaweed.
Thefilter meshmust bethe fine type, itis advisable
to use the type with 2-470  m (micron) pitch.
Differentsizeswould notallow goodfilter efficiency.
- Antisiphon valve (ref.6): this valve brings the cooling
circuit to atmospheric pressure whenthe engine is off,
preventing the siphonage phenomenon.
It must be used when the base of the generator is
under the water line, and must be positioned at least
500mm (1.6ft) above sea level.
The drain pipe of the antisiphon valve must be
positioned under the valve thus preventing water
from accumulating in the pipe which must always
remain empty to allow air to pass through it when
the generator is switched off.
Itis advisable to runthe drainpipe through the bilge,
as small amounts ofwater may flow from it during
normal operation.
Two holeshave been made inthe casingto connect
the antisiphonvalve (ref.6).
Anti-siphonvalve
Water / water
exchanger
