Masimo Kite User manual

Operator's Manual
Kite®Supplemental Display

Masimo Corporation www.masimo.com 1
These operating instructions provide the necessary information for proper operation of all models of the Kite. There may be information provided in this
manual that is not relevant for your system. General knowledge of pulse oximetry and an understanding of the features and functions of Kite are
prerequisites for its proper use. Do not operate Kite without completely reading and understanding these instructions.
Notice: Purchase or possession of this device does not carry any express or implied license to use with replacement parts which would, alone or in
combination with this device, fall within the scope of one of the relating patents.
CAUTION: Federal (USA) law restricts this device to sale by or on the order of a physician.
For professional use. See instructions for use for full prescribing information, including indications, contraindications, warnings, and precautions.
Masimo Corporation
52 Discovery
Irvine, CA 92618, USA
Tel.: [phone]
Fax.: [phone]
www.masimo.com
EU authorized representative for Masimo Corporation:
MDSS GmbH
Schiffgraben 41
D-30175 Hannover, Germany
Patents: www.masimo.com/patents.htm
Kite®, Masimo®, ®, O3®, SedLine®, Radical-7®, Root®, and rainbow® are federally registered trademarks of Masimo Corporation.
Rad-97™ is a trademark of Masimo Corporation.
All other trademarks and registered trademarks are property of their respective owners.
© 2017 Masimo Corporation

Masimo Corporation www.masimo.com 3
Contents
About This Manual......................................................................................................................................................................................................................5
Product Description, Intended Use and Contraindications........................................................................................................................................................7
Product Description ...............................................................................................................................................................................................................7
Intended Use .........................................................................................................................................................................................................................7
Contraindications ..................................................................................................................................................................................................................7
Safety Information, Warnings and Cautions ..............................................................................................................................................................................9
Safety Warnings and Cautions...............................................................................................................................................................................................9
Performance Warnings and Cautions ....................................................................................................................................................................................9
Cleaning and Service Warnings and Cautions.....................................................................................................................................................................10
Compliance Warnings and Cautions ...................................................................................................................................................................................10
Chapter 1: Description..............................................................................................................................................................................................................11
Overview ..............................................................................................................................................................................................................................11
Chapter 2: Operation ................................................................................................................................................................................................................13
Navigating the Kite .............................................................................................................................................................................................................13
Add a Device ........................................................................................................................................................................................................................15
Modify/Remove Device ........................................................................................................................................................................................................ 17
View Device Data ................................................................................................................................................................................................................. 17
Kite Display.........................................................................................................................................................................................................................20
Disconnect/Change Device..................................................................................................................................................................................................23
Chapter 3: Troubleshooting .....................................................................................................................................................................................................25
Troubleshooting Kite ...........................................................................................................................................................................................................25
Chapter 4: Specifications .........................................................................................................................................................................................................27
Kite Host Device ..................................................................................................................................................................................................................27
Compatible Masimo Devices ...............................................................................................................................................................................................27
Chapter 5: Warranty Information.............................................................................................................................................................................................29
Contacting Masimo..............................................................................................................................................................................................................29
Index .........................................................................................................................................................................................................................................31

Masimo Corporation www.masimo.com 5
About This Manual
This manual explains how to set up and use Kite® Supplemental Display. Important safety information relating to general use of Kite appears in this
manual. Read and follow any warnings, cautions, and notes presented throughout this manual. The following are explanations of warnings, cautions, and
notes.
A warning is given when actions may result in a serious outcome (for example, injury, serious adverse effect, death) to the patient or user.
WARNING: This is an example of a warning statement.
A caution is given when any special care is to be exercised by the patient or user to avoid injury to the patient, damage to this device, or damage to other
property.
CAUTION: This is an example of a caution statement.
A note is given when additional general information is applicable.
Note: This is an example of a note.

Masimo Corporation www.masimo.com 7
Product Description, Intended Use and Contraindications
Product Description
Kite is a supplemental display for Masimo medical devices on the same network. Kite allows for remote display of system and parameter data generated
by Masimo devices.
The following devices can display data on Kite:
•Radical-7® (standalone)
•Root® with:
•Radical-7®
•Radius-7®
•SedLine®
•ISA™
•O3®
•Rad-97™
Intended Use
Kite is a supplemental display intended to be used to view data from a standalone patient monitoring device. Kite can be used in hospital or hospital-like
environments.
Contraindications
None

Masimo Corporation www.masimo.com 9
Safety Information, Warnings and Cautions
Note: Please refer to the Operator's Manual or Directions For Use for Kite host device.
Safety Warnings and Cautions
WARNING: Do not adjust, repair, open, disassemble, or physically modify the Kite host device. Injury to personnel or equipment damage could occur.
Return the Kite host device for servicing.
WARNING: If Kite fails any part of the setup procedures or electrical safety tests, remove the device from operation until qualified service personnel have
corrected the situation.
WARNING: Do not place the Kite host device where it may be accessible by patients.
WARNING: Do not use the Kite host device if it appears or is suspected to be damaged.
WARNING: Do not use unauthorized devices with Kite. Possible loss of performance and/or patient injury may result.
WARNING: Do not place the Kite host device in any position that might cause it to fall on the patient.
WARNING: Kite host device should only be used in clinical environments in which it is approved to prevent patient injury or damage.
WARNING: To protect against injury, follow the directions below:
•Avoid placing the device or accessories on surfaces with visible liquid spills.
•Do not soak or immerse the device in liquids.
•Use cleaning solutions only as instructed in this operator's manual.
Performance Warnings and Cautions
WARNING: Kite does not generate or manage alarms. The connected device's alarms, used in conjunction with clinical signs and symptoms, are the
primary sources for determining that an alarm condition exists.
CAUTION: Kite is not a primary display. Medical decisions should be made using data from the primary display of a device in conjunction with clinical
signs and symptoms.
CAUTION: Kite is intended to operate across the facility's network. Unanticipated failure or alteration of network components (including but not limited
to: disconnection or malfunctioning of a networking device/switch/router/ethernet cable) may result in loss of connectivity of Kite to other hospital
systems. Altering or making changes to the hospital network should be done with proper knowledge.
CAUTION: The Quality of Service (QoS) of connectivity to the Point-of-Care (POC) devices may be affected by:
•Network failure
•Increased number of connected devices on the network
•Modifications to the network
•Presence of devices provided with radio transmitters
•Improper network configuration on POC
•Signal priorities of the network
•Latency
CAUTION: Network performance may be affected by changes in the network including the addition of additional network devices.
CAUTION: To prevent tampering, the Kite host device should be located with responsible personnel.
CAUTION: Do not place the Kite host device on electrical equipment that may affect the device and prevent it from working properly.
CAUTION: To ensure proper system operation, always verify successful connection between POC devices and Kite.

Kite Safety Information, Warnings and Cautions
Masimo Corporation www.masimo.com 10
Cleaning and Service Warnings and Cautions
WARNING: Do not autoclave, pressure sterilize, or gas sterilize the Kite host device.
WARNING: Use cleaning solutions only as instructed in the Operator's Manual for the Kite host device.
Note: Modifications to Kite's settings, and those of any components connected thereto, should be made by qualified personnel only.
Note: Kite host device installation must be completed by Masimo or an authorized service department.
Compliance Warnings and Cautions
WARNING: Do not attempt to repair or modify any part of Kite host device doing so may void the warranty or the authorization to use the Kite host device.
WARNING: Disposal of product - Comply with local laws in the disposal of Kite host device and/or its accessories.
WARNING: When using devices with wireless features outside the United States, consideration should be taken to local government frequency allocations
and technical parameters to minimize the possibility of interference to/from other wireless devices.
WARNING: In accordance with international telecommunication requirements, the frequency band of 2.4 GHz and 5.15 to 5.25 GHz is only for indoor
usage to reduce potential for harmful interference to co-channel mobile satellite systems.
Note: Refer to the Kite host device's Operator's Manual or Directions For Use for Kite for FCC compliance information before use.

Masimo Corporation www.masimo.com 11
Chapter 1: Description
Overview
Kite is a supplemental display for system and parameter data generated by Masimo devices.
Note: For complete information on setup and use, refer to the Operator's Manual or Directions For Use for Kite host device.
Note: For proper operation, Kite host device and Masimo devices must be connected to the same network. For more information, contact your network
administrator.
Note: Kite is not a diagnostic tool.

Masimo Corporation www.masimo.com 13
Chapter 2: Operation
Navigating the Kite
To operate Kite on the connected display:
1. Select the icon to start Kite.
2. Once Kite starts, the login screen will be displayed. See Login on page 13.
Login
Login to Kite using a username and password credentials.
•Registration is required to use Kite. To register, see Create New User (Register) on page 14.
•For a forgotten username or password, a new account must be created by pressing/selecting Forgot your password? Register. The lost or
forgotten username or password cannot be recovered.

Kite Chapter 2: Operation
Masimo Corporation www.masimo.com 14
Create New User (Register)
To create a new user (register), perform the following procedure:
1. Press/select Forgot your password? Register on the Login screen. See Login on page 13.
2. Enter a Username.
3. Enter a Password to be used with this user name.
4. Enter the password again in the Confirm Password field.
5. Enter MasimoKite7283 (case sensitive) into the Key field.
6. Press/select the Register button to complete the new user registration.
Logout
To log out of Kite:
1. While viewing the Parameter screen of a particular device, press/select the Menu icon in the upper-right corner of the screen.
2. Select Disconnect.

Kite Chapter 2: Operation
Masimo Corporation www.masimo.com 15
3. When the Device screen displays, press/select the Menu located at upper-right corner of the screen.
4. Select Logout.
5. After logging out, the Login screen is displayed. See Login on page 13.
Add a Device
The device to be added must be on the same network (wired or wireless) as the Kite host device.
Note: If the device is not on the same network, it can be added, but Kite will not be able to connect it to view the parameters monitored by that device
until both Kite and the device are connected to the same network.
To add a new device, perform the following procedure:
1. Press/select the Add Device button, located at the top of the Device screen.
2. The device's Details screen displays.

Kite Chapter 2: Operation
Masimo Corporation www.masimo.com 16
3. Give the device a desired label or identifier in the Name field.
4. Enter the IP address from the device. If using a Wi-Fi connection, use the Wi-Fi IP address; if using an Ethernet connection, use the Ethernet IP
address. Refer to the Operator's Manual for the device for instructions on locating the IP address.
5. Select the model of the device to be connected from the Device Type drop-down menu (Radical-7 shown in this example).
6. If a Secured Connection is needed, see Using a Secured Connection on page 16.
7. If a Secured Connection is not used, press/select the check mark in the bottom-right corner of the screen to add the device.
8. The device will be added to the Device screen.
9. To view the device on Kite, see View Device Data on page 17.
Using a Secured Connection
To add a Secured Connection for a device, perform the following procedure:
1. After selecting the Device type, enable Secured Connection.
2. Press/select Client Certificate (.bks) and use the Browse function of Kite to select the .bks file.
Note: The exact location of the file may vary.

Kite Chapter 2: Operation
Masimo Corporation www.masimo.com 17
3. Enter the password provided by Masimo.
4. Press/select the check mark in the bottom-right corner of the screen to add the device.
5. The device is added to the Device screen.
6. To view the device on Kite, see View Device Data on page 17.
Modify/Remove Device
To modify device details or remove a device from Kite, from the Device screen, press/select and hold on the selected device to view the Device Details
screen. See View Device Data on page 17.
Modify Device Details
1. Change the device details as desired.
2. When complete, select the check mark at the lower right corner of the screen to save the changes and exit the device Details screen and return
to the Device Screen.
Remove a Device
1. While viewing the device Details screen, select the trash can icon in the upper right corner of the screen.
2. When prompted to "Delete Device?", select OK or Cancel.
3. When OK is selected, the device is removed and Kite returns to the Device Screen.
View Device Data
Available devices setup to display on Kite appear on the Device screen.
If a device is not available, add a device by pressing/selecting the Add Device button , located at the bottom right corner of the Device screen. See Add
a Device on page 15.
1. Press/select the device to connect.
2. If the device is successfully connected to the same network as Kite, the device parameters display. See Kite Display.
•If Kite displays "Please enter the key displayed on the device" before connecting, see Pairing Key on page 18.
•If the device cannot connect, Kite continues to attempt a connection until Cancel is pressed/selected.

Kite Chapter 2: Operation
Masimo Corporation www.masimo.com 18
Pairing Key
If the device requests a pairing key to connect to Kite, perform the following procedure:
Note: Some devices may not display a pairing key. Refer to the device Operator's Manual. Root is shown in the following example.
1. Kite requests a pairing key to connect with the device.
2. The Kite Pairing key displays on the device screen. This is the number to enter on Kite.
Note: If the Kite pairing key window is closed, go to the Kite settings on the device to view the paring key. Refer to the device Operator's
Manual.
