Masport P36-NG3 Quick start guide

Models:
P36-NG3
P36-LPG3
Owners&
Installation
PLEASEKEEPTHESEINSTRUCTIONS
FORFUTUREREFERENCE
Manual
01/16/04
LISTINGSANDCODEAPPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS 5262 and have been certified
by the Australian Gas Association
for installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised
service person.
918-015c
WARNING:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
informationconsultanauthorisedinstaller,
service agency or the gas supplier.
FORYOURSAFETY
Do not store or use gasoline or other
flammablevapoursandliquidsinthevicinity
of this or any other appliance.
Installation and service must be performed
byanauthorisedinstaller,serviceagencyor
the gas supplier.
P36 Gas Inbuilt
Head Office - Australia
54 Boundary Rd. Braeside
P.O. Box 553
Mordialloc 3195
Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
FORYOURSAFETY
What to do if you smell gas:
Donottrytolightanyappli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplierfromaneighbour's
phone. Follow the gas sup-
plier'sinstructions.
If you cannot reach your
gas supplier, call the fire
department.
Calais / Grenada

Masport P36-3 Gas Inbuilt
2
TO THE NEW OWNER:
Congratulations!
Youare the ownerof a state-of-the-artGas Fire by MASPORTLTD. The P36 hasbeen designed toprovide
you with all the warmth and charm of a wood fireplace at the flick of a switch. The model P36 has been
approved by the Australian Gas Association for both safety and efficiency. It promises to provide you with
economy,comfort andsecurity formany troublefree yearsto follow. Pleasetake amoment now to acquaint
yourself with these instructions and the many features of your Masport Fireplace.

Masport P36-3 Gas Inbuilt 3
TABLE OF CONTENTS
Operating Instructions
OperatingInstructions ...............................................27
LightingProcedure ....................................................27
ShutdownProcedure .................................................27
First Fire ...................................................................27
NormalOperatingSoundsof
GasAppliances ..................................................27
LightingPlateInstructions .........................................28
Maintenance
MaintenanceInstructions ..........................................28
GeneralFlueMaintenance ........................................28
Gold-PlatedorBrassLouvres....................................29
Gold Plated or Brass Trim .........................................29
LogReplacement ......................................................29
FireboxPaint.............................................................29
Glass Gasket............................................................29
DoorGlass................................................................29
Flush Glass ........................................................29
Bay Glass ..........................................................29
RemovingValve .........................................................30
InstallingValve ..........................................................30
PartsList
Replacement/SparePartsList...................................31
Warranty
Warranty ...................................................................39
Safety Label
SafetyLabel............................................................... 4
Installation
ImportantMessage .................................................... 5
BeforeYouStart ........................................................ 5
GeneralSafetyInformation ......................................... 5
InstallationChecklist .................................................. 5
LocatingYour GasFire .............................................. 6
ManufacturedHomeAdditionalRequirements ............ 6
Clearances................................................................. 6
MantelClearances ..................................................... 7
MantelLegClearances............................................... 8
FramingandFinishing................................................ 8
Unit Assembly Prior to Installation
TopStandoffAssembly........................................ 9
TopFacingSupport & Side Nailing Strip
Assembly...................................................... 9
FlueingIntroduction .................................................... 9
ExteriorFlueTerminationLocations ..........................10
Direct Flue System (Flex) .........................................11
Flueing-HorizontalTerminations ..............................12
Co Axial Flue System ...............................................13
VerticalTerminations ................................................14
HorizontalInstallations ..............................................16
VerticalTermination ..................................................17
System Data.............................................................18
GasLineInstallation..................................................18
AerationAdjustment..................................................18
Pilot Adjustment .......................................................18
PressureTesting .......................................................18
S.I.T.ValveDescription .............................................19
Optional Brick Panels ...............................................19
LogSetInstallation ...................................................19
FlushDoor-Standard ...............................................21
OptionalFlushTrim...................................................21
Louvres-Flush..........................................................21
OptionalBayDoor.....................................................22
OptionalBayTrim .....................................................22
Louvres - Bay ...........................................................22
HamptonCastFaceplate(optional) ...........................23
HamptonCastGrills(optional)...................................24
RemoteControl(optional)..........................................25
WallThermostat(optional) ........................................25
WiringDiagram .........................................................26

Masport P36-3 Gas Inbuilt
4
SAFETY LABEL
This is a copy of the label that accompanies
each P36 Zero Clearance Room Sealed Gas
Fireplace. We have printed a copy of the
contents here for your review. The label is
(AustraliaOnly)
located on the front inside base of the unit,
visible when the bottom louvre is open. DATA BADGE NOTE: Masport units are con-
stantly being improved. Check the label on the
unit and if there is a difference, the label on the
unit is the correct one.

Masport P36-3 Gas Inbuilt 5
INSTALLATION
CHECKLIST
1) Locate appliance
a) Room location, page 6
b) Clearancesto Combustibles,pages6-8.
c) Mantle Clearances, page 7
d) Framing&Finishing Requirements,
page 8
e) Flueing Requirements, pages 9-17.
2) Assemble Top Standoffs and Top Facing
SupportandSideNailingStrips,page9.(NOTE:
must be done before installing unit into
fireplace.)
3) Install flue, pages 9-17.
4) Makegasandelectricalconnections.Testthe
pilot. Must be as per diagram. Page 18.
5) Install brick panels (optional), page 19.
6) Install log set where indicated on page 19.
7) Install Flush Door Front (Standard) and
optional Flush Gold Trim, page 21.
8) Install Optional Bay Front and optional Bay
Gold Trim, page 22.
9) Install Louvres (Flush or Bay), pages 21-22.
10)Install optional Remote Control, or Wall
Thermostat, page 26.
11)Final check.
Before leaving this unit with the
customer, the installer must ensure
that the appliance is firing correctly
and operation fully explained to
customer.
This includes:
1) Clocking the appliance to ensure the correct
firing rate (rate noted on label 30,000 Btu/h)
after burning appliance for 15 minutes.
2) Ifrequired, adjustingtheprimary airtoensure
thatthe flamedoes notcarbon. Firstallowthe
unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causes sooting or carboning that results in
damage is not the responsibility of the
manufacturer.
INSTALLATION
IMPORTANT:
SAVETHESEINSTRUCTIONS
TheP36-NGorP36-LPGRoomSealedFireplace
mustbeinstalled inaccordance withAG 601and
NZS52615261andtheseinstructions.Carefully
readalltheinstructionsinthismanualfirst.Consult
the"authorityhavingjurisdiction"todeterminethe
need for a permit prior to starting the installation.
Itistheresponsibilityoftheinstallertoensurethis
fireplaceis installedin compliancewithmanufac-
turer's instructions and all applicable codes.
BEFORE YOU START
NOTE:NOTINTENDEDASAFIREPLACEIN-
SERT.
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions,localgasfittingregulations,mu-
nicipal building codes, water supply regu-
lations, electrical wiring regulations, with
AG 601 (AGA gas installation code) NZS
5261 (New Zealand)
2) Installation and repair should be done
ONLY by an authorised person.
3) THISAPPLIANCEISNOTINTENDEDASA
FIREPLACEINSERT.DONOTCONNECT
TOMASONARY FLUE.
4) This appliance must be connected to
the specified flue and termination cap
to the outside of the building enve-
lope. Never flue to another room or
inside a building. Make sure that the
flue is fitted as per Flueing instruc-
tions.
5) Inspect the flueing system annually for
blockage and any signs of deterioration.
6) Flueingterminalsshallnotberecessed into
a wall or siding.
7) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
8) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9) Wear gloves and safety glasses for pro-
tection while doing required maintenance.
10)Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
11)Under no circumstances should this appli-
ance be modified. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
12)Installationandanyrepairstothisappliance
should be done by an authorised service
person. An authorised service person
should be called to inspect this appliance
annually. Make it a practice to have all of
your gas appliances checked annually.
13)Do not slam shut or strike the glass door.
14)Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
15)The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
INSTALLATIONANDREPAIRSHOULDBE
DONE BY A AUTHORISED SERVICE PER-
SON. THE APPLIANCE SHOULD BE IN-
SPECTED BEFORE USE AND AT LEAST
ANNUALLYBYANAUTHORISEDSERVICE
PERSON.MOREFREQUENTCLEANINGMAY
BE REQUIRED DUE TO EXCESSIVE LINT
FROMCARPETING,BEDDINGMATERIAL,
ETC. IT IS IMPERATIVE THAT CONTROL
COMPARTMENTS,BURNERSANDCIRCU-
LATING AIR PASSAGEWAYS OF THE AP-
PLIANCEBEKEPTCLEAN.
DUETOHIGHTEMPERATURES,THEAPPLI-
ANCESHOULDBELOCATEDOUTOFTRAF-
FIC AND AWAY FROM FURNITURE AND
DRAPERIES.
WARNING:FAILURETOINSTALLTHISAP-
PLIANCE CORRECTLY WILL VOID YOUR
WARRANTYANDMAY CAUSE ASERIOUS
HOUSEFIRE.
CHILDREN AND ADULTS SHOULD BE
ALERTEDTOTHEHAZARDSOFHIGHSUR-
FACETEMPERATURES,ESPECIALLYTHE
FIREPLACE GLASS, AND SHOULD STAY
AWAY TO AVOID BURNS OR CLOTHING
IGNITION.
YOUNGCHILDRENSHOULDBECAREFUL-
LY SUPERVISEDWHENTHEYAREINTHE
SAME ROOM AS THE APPLIANCE.
CLOTHING OR OTHER FLAMMABLE MA-
TERIALSHOULD NOTBE PLACED ONOR
NEARTHEAPPLIANCE.DONOTUSEAER-
OSOLS IN THE VICINITY OF THIS APPLI-
ANCE.

Masport P36-3 Gas Inbuilt
6
INSTALLATION
Clearances for Bay or Flush Front
NOTE: The minimum floor clearance must
be maintained from the top surface of the
carpeting, tile, etc.
Minimum Clearance from Top of Unit to:
Mantel* Minimum 7" (177mm)
Ceiling from top of unit. 32" (1016mm)
Side Wall Clearance
Bay or Flush Front 6" (152mm)
Barcelona Trim 8" (203mm)
Horizontal Flue Clearances
Top 2" (51mm)
Side 1-1/2"(38mm)
Bottom 1-1/2"(38mm)
Vertical Flue Clearances 1-1/4" (32mm)
Alcove Clearances**:
Max. Depth 36" (914mm)
Min. Width 48" 1219mm)
Min. Height 72" 1829mm)
* see mantle clearance instructions
(pages 7 & 8).
CLEARANCES
The clearances listed below are Minimum dis-
tances unless otherwise stated:
A major cause of chimney related fires is
failure to maintain required clearances
(air space) to combustible materials. It is
of the greatest importance that this fire-
place and flue system be installed only in
accordance with these instructions.
Clearance to Combustibles from:
Back 0" (0mm)
Side 0" (0mm)
Floor 0" (0mm)
Diagram 1
LOCATING YOUR
GAS FIRE
1) When selecting a location for your fire,
ensure that the clearances outlined on this
page are met.
2) Provide adequate clearances for servic-
ing.
3) The appliance must be installed on a flat,
solid, continuous surface (e.g. wood, met-
al, concrete). This may be the floor, or
raiseduponaplatformtoenhanceitsvisual
impact. If the appliance is going to be in-
stalled on carpeting, combustible linoleum
tileorothercombustiblematerialotherthan
wood flooring, the appliance must be in-
stalled on a metal or wood panel extending
the full width and depth of the appliance.
4) TheP36CoAxialFlueGasFireplacecanbe
installed in a recessed position or framed
out into the room as in A, B, C, D. See
Diagram1.
MANUFACTURED
MOBILE HOME
ADDITIONAL
REQUIREMENTS
1) Ensurethat structuralmembers arenotcut
or weakened during installation.
2) Ensure proper grounding using the #8
ground lug provided. See page 27.
A) Flat on Wall
B) Flat on Wall Corner
C) Recessed into Wall/Alcove
D) Corner
5) Thisappliance isListed forbedroom instal-
lations when used with a Listed Millivolt
Thermostat. Some areas may have further
requirements, check local codes before
installation.
6) The P36 Co Axial Flue Gas Fireplace is
approved for alcove installations, which
meet the clearances listed on this page.
7) We recommend that you plan your installa-
tion on paper using exact measurements
for clearances and floor protection before
actually installing this appliance. Have an
authorized inspector, dealer, or installer
review your plans before installation.
Note: For flue terminations see page 10.
WARNING
Fire hazard is an
extreme risk
if these clearances
are not adhered to.

Masport P36-3 Gas Inbuilt 7
Because of the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in Diagrams 1 & 2.
COMBUSTIBLE MANTELS
These drawings are to scale at 1:6 (one inch = 6 inches) Mantel can be installed anywhere in shaded area or higher using the above scale. Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour. Also the material from which the mantel is made from must be heat resistamt to 85oC.
Diagram 1 Diagram 2
INSTALLATION

Masport P36-3 Gas Inbuilt
8
INSTALLATION
Note: 40-1/2" (1029mm) is the minimum
height for flex termination.
Note: The unit does not have to be com-
pletely enclosed in a chase. The
clearance on top of the unit is 0" to
the standoffs so combustible
building materials can be laid di-
rectly on top of the standoffs. You
must maintain 1-1/2" (38mm) clear-
ance from the flue to combustible
materials for flex.
5) Use steel studs for framing where the
1-1/2" (38mm) clearance from the flue to
combustiblematerialcannotbemaintained,
e.g. front top header.
Diagram 2
MANTEL LEG
CLEARANCES
Combustible mantel leg clearances as per dia-
gram below:
FRAMING AND
FINISHING
1) Determine the total thickness of facing ma-
terial (e.g. drywall plus ceramic tiles) to
allow the finished surface to be flush with
the front of the unit. Total facing thickness
canvaryfrom1/2"(13mm)to1-1/4"(32mm)
thick.
Maximum38mmprojectionat51mmminimum
clearance.
3) For exterior walls, insulate the enclosure to
the same degree as the rest of the house,
apply vapour barrier and drywall, as per
local installation codes. (Do not insulate
the fireplace itself.)
4) The top of the unit must not be closer than
32" (813mm) to the ceiling.
Install Side Nailing Strips, Top Facing
Support, and Top Standoffs before unit
is slipped into position. See page 9 for
assembly details.
2) Frame in the enclosure for the unit with
framing material. The framed opening is
36-1/4" high x 36-1/4" wide x 12-3/4" deep
(921mmhighx921mmwidex324mmdeep).
Framing Dimensions
A B C D
36-1/4" 36-1/4" 12-3/4" 46"*
921mm 921mm 324mm 1168mm*
*'D'isMinimumheighttocombustiblematerials
including the Minimum 2" (51mm) Top clear-
ancetotheHorizontalFlue,seeflueclearanc-
es on page 6.

Masport P36-3 Gas Inbuilt 9
Screw Facing Material
Position Depth
A 1/2" / 13mm
B 7/8" / 22mm
C*1-1/4" / 32mm
"C" Screw Position:
For a facing material depth of 1-1/4"
(32mm), the top facing support must be
reversed.
UNIT ASSEMBLY
PRIOR TO
INSTALLATION
TheTopFacingSupport,theSideNailingStrips
and the 2 Top Standoffs must be correctly
positioned and attached to the top before unit
is slipped into position.
TopStandoffAssembly
The top standoffs are shipped in a flat position
and must be folded into shape and attached.
1) Remove the standoffs from the fireplace
top.
2) Take each standoff and bend into the cor-
rect shape. Bend up at the bend lines until
the screw holes in the standoff and the pre-
punched screw holes on the fireplace top
line up.
3) Attach the standoff securely to the top with
2 screws per standoff (on opposite cor-
ners).
Top Facing Support and
Side Nailing Strips
Determine the total thickness of facing material
(e.g. drywall plus ceramic tiles) to allow the
finished surface to be flush with the front of the
unit. Total facing thickness can vary from 1/2"
(13mm) to 1-1/4" (32mm) thick.
The Top Facing Support & Side Nailing Strips
canbemountedin3differentpositionsdepend-
ing on the thickness of the facing material.
*For "C" screw position the top facing support
is reversed.
1) Mount Top Facing Support using the 3
suppliedscrewsintothethreepre-punched
screwholeson thetopfrontof theunit.Use
holepositionsA,B,orCdependingonyour
facing depth.
2) Use the same screw hole position for the
Side Nailing Strips as was used for the Top
Facing Support. Attach each side nailing
strip using 3 screws.
FLUEING
INTRODUCTION
The P36 uses the "balanced flue" technology
Co Axial system. The inner liner flues products
ofcombustiontotheoutsidewhiletheouterliner
draws outside combustion air into the combus-
tionchambertherebyeliminatingtheneedtouse
heatedroomairforcombustionandlosingwarm
room air up the chimney.
Note: These flue pipes must not be con-
nected to any other appliance.
The gas appliance and flue system must be
flued directly to the outside of the building, and
never be attached to a chimney serving a
separate solid fuel or gas burning appliance.
Each Co Axial Flue gas appliance must use it's
own separate flue system. Common flue sys-
tems are prohibited.
Flues must be installed in accordance with
these instructions and with the specific instruc-
tions with each flue kit. Where required always
refer to either AG 601 or NZS 5261:2003.
INSTALLATION

Masport P36-3 Gas Inbuilt
10
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced flue terminals
or the flue terminals of outdoor appliances according
to AG 601 (AGA gas installation code) or NZS 5261 (New Zealand).
For vertical termination height refer to AG 601 or NZS 5261.
Minimum
Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other flue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)): see table below
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h Up to 50 MJ/h input Over 50 MJ/h input Over 150 MJ/h input
input to 150 MJ/h input
150 500 1000 1500
NOTES:
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest
par to of the terminal.
(III) Prohibited area below electricity meter or fuse box extends to ground level.
(IV)A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on
at least two sides and a free flow of air at the appliance is achieved.

Masport P36-3 Gas Inbuilt 11
FLUEING
Direct Flue System (Flex)
Horizontal Terminations Only
These flueing systems, in combination with the P36 Room Sealed Gas Fireplace, have been tested and listed as a Direct Vent type flue system
by the Australian Gas Association. The location of the termination cap must conform to the requirements in the Flue Terminal Locations diagram
on page 10.
Direct Flue (Flex) System Termination Kit (Part # 946-515) includes all the parts needed to install the P36 with a maximum run of
1.2m.
1) 175mm dia. flexible liner (1200mm length)
2) 100mm dia. flexible liner (1200mm length)
3) spring spacers (4)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" Drill Point, Stainless Steel (4)
If longer runs are needed, the Direct Flue
system (Flex) # 946-516 includes all the parts
needed to install the P36 with a maximum 3.0m
run.
1) 175mm dia. flexible liner (3.0m length)
2) 100mm dia. flexible liner (3.0m length)
3) spring spacers (7)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" Drill Point, Stainless Steel (4)
Notes:
1) Liner sections should be continuous without any joints or seams.
2) Only Flex pipe purchased from Masport may be used for Flex installations.
3) If you are installing the P36 into a Masport Mantel Kit, use the minimum horizontal vent height (centre-line of 1029mm).
Remember to include the mantel base in your calculations and to maintain the 32mm clearance (38mm with Flex) to the
underside of the mantel top.
INSTALLATION

Masport P36-3 Gas Inbuilt
12
INSTALLATION
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
MASPORT DIRECT FLUE SYSTEM
(LPG & NG)
The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90oelbow (two 45o elbows equal one 90o
elbow).
Masport Flex Vent
4" (102mm) inner diameter
6-7/8" (175mm) outer diameter
• Maintain clearances to combustibles as listed on pages 6 to 8.
• Horizontal flue must be supported every 3 feet (0.9 meters).
NOTE: If you are installing the P36 into a Masport Mantel Kit, use the minimum horizontal flue height (centre-line of
40-1/2"(1029mm)). Remember to include the mantel base in your calculations and to maintain the 3" (76mm) clearance to
the underside of the mantel top.
A flue guard should be used when-
everthetermination is lowerthan the
specified minimum or as per local
codes.
Note: Masport Co Axial Flue System
(Flex) is only approved for hor-
izontal terminations.
Total flue length CANNOT be
longer then 3 meters.

Masport P36-3 Gas Inbuilt 13
INSTALLATION
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
MASPORT CO AXIAL FLUE SYSTEM
(LPG & NG)
The diagram below shows examples of horizontal termination arrangements using two 90oelbows (two 45o elbows equal one 90oelbow).
Note: 1) A maximum of two 90oelbows are permitted.
2) A minimum of 6 ft. (1.8m) vertical from base of unit is required if two 90oelbows are used.
3) Minimum distance between elbows is 2 ft. (0.6m).
4) Determine the permitted range of horizontal termination arrangements by using chart on page 12
and deducting 3 ft. (0.9m) from the maximum horizontal distance for the second 90oelbow.
• Maintain clearances to combustibles as listed on pages 6 to 8.
• Horizontal flue must be supported every 3 feet (0.9 meters).
A flue guard should be used whenever the
terminationislowerthanthespecifiedminimum
or as per local codes.
If length "B" is increased, length "A" must
be decreased by a corresponding amount.

Masport P36-3 Gas Inbuilt
14
FLUEING ARRANGEMENTS - VERTICAL TERMINATIONS
The P36 is approved for a 23 ft. (7.0m) vertical, with a maximum 12 ft. (3.7m) horizontal offset using
two 90oelbows (two 45o elbows equal one 90oelbow), as per diagram 1.
The P36 is approved for a 37 ft. (11.3m) straight vertical, including a 20" (0.5m) horizontal offset using
two 90oelbow (two 45o elbows equal one 90oelbow), as per diagram 2.
• Flue must be supported at offsets
• Maintain clearances to combustibles.
Note: Masport Co Axial Flue System (Flex) is only approved for horizontal terminations.
Diagram 1
Diagram 2
INSTALLATION

Masport P36-3 Gas Inbuilt 15
INSTALLATION
The P36 is approved for a 37 ft. (11.3m) straight vertical, as per the diagram 3.
The shaded area in diagram 3 shows all allowable combinations of straight
vertical and offset to vertical terminations. Maximum two 45oelbows allowed.
• Flue must be supported at offsets
• Maintain clearances to combustibles as listed on pages 6 to 8.
Diagram 3

Masport P36-3 Gas Inbuilt
16
Diagram 3
HORIZONTAL
INSTALLATIONS
Install the flue system according to the
manufacturer's instructions included
with the components.
1) Set the unit in its desired location. Check to
determine if wall studs or roof rafters are in
the way when the flueing system is at-
tached. If this is the case, you may want to
adjust the location of the unit. Rough in the
gas preferably on the right side of the unit
andtheelectrical(junctionblockisontheleft
side) on the left.
2) Putabeadofsiliconeinsidetheoutersection
of the adapter and a bead of Mill-Pac on the
inner collar. Slip the adapter over the exist-
ing inner and outer flue collar and fasten to
the outer collar only with the 3 supplied
screws (drilling pilot holes will make this
easier). Level the fireplace and fasten it to
the framing using nails or screws through
the nailing strips.
3) Assemble the desired combination of pipe
and elbows to the appliance adaptor and
twist-lock for a solid connection.
Note: Apply sealant "Mill-Pac" to inner
pipe and high temperature silicone
sealant to outer pipe.
a) Horizontal runs of flue must be support-
ed every three feet. Wall straps are
available for this purpose.
4) Mark the wall for a 10" x 10" square hole.
Thecenterof thesquarehole shouldline up
withthecenterlineofthehorizontalpipe.Cut
and frame the 10 inch square hole in the
exterior wall where the flue will be terminat-
ed. If the wall being penetrated is construct-
ed of non-combustible material, i.e. mason-
ry block or concrete, a 7"(178mm) diameter
(7-1/2"(191mm) diameter for flex) hole is
acceptable.
Note:
a) Thehorizontalrunoffluemustbe
level, or have a 1/4 inch rise for
every 1 foot of run towards the
termination.Neverallowtheflue
to run downward. This could
cause high temperatures and
may present the possibility of a
fire.
b) Thelocationofthehorizontalfluetermi-
nation on an exterior wall must meet all
local and national building codes, and
mustnotbe blockedorobstructed. For
External Flue Terminal Locations, see
diagram on page 10.
5) The arrow on the flue cap should be
pointing up. Insure that the 1-1/2" clear-
ances to combustible materials are main-
tained. Install the termination cap, see dia-
gram 3.
The four wood screws provided should be
replaced with appropriate fasteners for
stucco, brick, concrete, or other types of
sidings.
Note: If installing termination on a siding
covered wall, a vinyl siding stand-
off or furring strips must be used
to ensure that the termination is
not recessed into the siding.
6) Beforeconnecting thehorizontal runof flue
pipe to the flue termination, slide the Wall
Thimble over the flue pipe.
Diagram 1
INSTALLATION
7) Slide the appliance and flue assembly to-
wards the wall carefully inserting the flue
pipe into the flue cap assembly. It is impor-
tant that the flue pipe extends into the flue
cap sufficient distance so as to result in a
minimum pipe overlap of 1-1/4 inches. Se-
cure the connection between the flue pipe
and the flue cap by attaching the two sheet
metal strips extending from the flue cap
assemblyintothe outerwallofthe fluepipe.
Use the two sheet metal screws provided
toconnectthestripstothepipesection.See
Diagram2.
8) Install wall thimble in the center of the 10"
square and attach with wood screws. See
Diagram3.
Diagram 2

Masport P36-3 Gas Inbuilt 17
INSTALLATION
OffsetChart
7) Ensure flue is vertical and secure the base
of the flashing to the roof with roofing rails,
slide storm collar over the pipe section and
seal with a mastic.
8) Install the vertical termination cap.
Note: Any closets or storage spaces,
which the flue passes through
must be enclosed.
Diagram 3
Diagram 1
Diagram 2
Note: Apply sealant "Mill-Pac" to inner
pipe and high temperature sili-
cone sealant to outer pipe.
VERTICAL
TERMINATION
1) Maintain the 1-1/2" clearances
(air spaces) to combustibles
when passing through ceilings,
walls, roofs, enclosures, attic
rafter, or other nearby com-
bustible surfaces. Do not pack
air spaces with insulation.
Checkpages14-15forthemax-
imum vertical rise of the flueing
system and the maximum hor-
izontal offset limitations.
2) Set the gas appliance in
its desired location. Drop
a plumb bob down from
the ceiling to the position
of the appliance flue exit,
and mark the location
where the flue will penetrate the ceiling.
Drill a small hole at his point. Next, drop a
plumb bob from the roof to the hole previ-
ouslydrilledintheceiling,andmarkthespot
where the flue will penetrate the roof.
Determine if ceiling joists, roof rafters or
other framing will obstruct the flueing sys-
tem. You may wish to relocate the appli-
ance or to offset, as shown in Diagram 2 to
avoid cutting load bearing members.
3) A Firestop spacer must be installed in the
floor or ceiling of every level. To install the
Firestop spacer in a flat ceiling or wall, cut
a 10 inch square hole. Frame the hole as
shown in Diagram 3 and install the firestop.
4) Assemble the desired lengths of pipe and
elbows. Ensure that all pipes and elbow
connections are in the fully twist-locked
position and sealed.
5) Cut a hole in the roof centered on the small
drilled hole placed in the roof in Step 2. The
hole should be of sufficient size to meet the
minimumrequirementsforclearancetocom-
bustibles of 1-1/2". Slip the flashing under
the shingles (shingles should overlap half
the flashing) as per Diagram 4.
Diagram 4: The upper half of the flashing is
installed under the roofing material and not
nailed down until the chimney is installed.
This allows for small adjustments.
6) Continue to assemble pipe lengths.
Note: If an offset is necessary in the attic
to avoid obstructions, it is impor-
tant to support the flue pipe every
3 feet, to avoid excessive stress
on the elbows, and possible sep-
aration. Wall straps are available
for this purpose (Diagram 2).
Galvanized pipe is desirable above the roof-
line due to its higher corrosion resistance.
Continue to add pipe sections through the
flashing until the height of the flue cap meets
theminimumheightrequirementsspecifiedin
Diagram5or localcodes. Notethatforsteep
roof pitches, the vertical height must be
increased. A poor draft, or down drafting
canresultfrom high windconditionsnear big
trees or adjoining roof lines, in these cases,
increasing the flue height may solve the
problem.

Masport P36-3 Gas Inbuilt
18
INSTALLATION
PRESSURE TESTING
The manifold pressure is controlled by a regu-
lator built into the gas control, and should be
checked at the pressure test point.
Note: To properly check gas pressure,
both inlet and manifold pressures
should be checked using the valve
pressure ports on the valve.
1) Makesurethevalveisinthe"OFF"position.
2) Loosen the "IN" and/or "OUT" pressure
tap(s), turning counterclockwise with a
1/8" wide flat screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" ID hose.
4) Light the pilot and turn the valve to "ON"
position.
5) The pressure check should be carried out
with the unit burning and the setting should
be within the limits specified on the safety
label.
P36-NG3SystemData
For 0 to 4500 feet altitude
Burner Inlet Orifice Sizes: #37( 2.65mm)
Max. Input Rating 33mj
Min. Input Rating 20mj
Supply Pressure min.1.25kPa
Manifold Pressure
(High) 0.9kPa
Electrical: 240 V A.C. System.
Circulation Fan: variable speed 130 CFM.
Log Set: Ceramic fibre, 7 per set.
Flue System:
Masport Direct Flue System (Flex)
P36-LPG3SystemData
For 0 to 2000 feet altitude
Burner Inlet Orifice Sizes: #52 (1.6 mm)
Max. Input Rating 31mj
Min. Input Rating 18mj
For 0 to 4500 feet Altitude:
Supply Pressure min2.75kPa
Manifold Pressure
(High) 2.7kPa
Electrical: 240 V A.C. System.
Circulation Fan: variablespeed130 CFM.
Log Set: Ceramic fibre, 7 per set.
PILOT ADJUSTMENT
Periodically check the pilot flames. Cor-
rect flame pattern has three strong blue
flames: 1 flowing around the thermopile,
1 around the thermocouple and 1 flowing
across the burner (it does not have to be
touching the burner).
Note: If you have an incorrect flame pat-
tern, contact your Masport dealer
for further instructions.
Incorrect flame pattern will have small,
probably yellow flames, not coming into
proper contact with the rear burner or
thermopile or thermocouple.
AERATION
ADJUSTMENT
The air shutter can be adjusted. Open the air
shutter for a blue flame or close for a yellower
flame.Theburneraerationisfactorysetbutmay
needadjustingduetoeitherthelocalgassupply
or altitude. This adjustment is performed by the
gas fitter.
Minimum Air Shutter Opening:
8 mm NG
Full Open LPG
CAUTION: Carbon will be produced if air
shutter is closed too much.
Note: Any damage due to carboning re-
sulting from improperly setting the
aeration controls is NOT covered
under warranty.
Closed-Tallyellow
Open-ShortBlue
GAS LINE
INSTALLATION
The gas line can be brought through either the
right or the left side of the appliance. The gas
valve is situated on the right hand side of the
unit and the gas inlet is on the right hand side
of the valve.
Note: If the gas line is being installed
from the left side, be sure to leave
room to accommodate servicing
of the fan.
The gas line connection may be made of rigid
pipe, copper pipe or an approved flex connec-
tor. (If you are using rigid pipe, ensure that the
valve can be removed for servicing.) Since
somemunicipalitieshaveadditionallocalcodes
it is always best to consult with your local
authoritiesandtheAG601 orNZS 5261instal-
lation code.
When using copper or flex connectors use
only approved fittings. Always provide a union
sothatgaslinescanbeeasilydisconnectedfor
servicing. Flare nuts for copper lines and flex
connectorsareusually consideredto meet this
requirement.
Important: Always check for gas leaks
with a soap and water solution or gas
leak detector. Do not use open flame for
leak testing.
SYSTEM DATA

Masport P36-3 Gas Inbuilt 19
OPTIONAL
BRICK PANELS
1) Undo the bottom 2 door latches and open
and remove glass door. Remove logs.
Note: The logs must not be in the unit.
2) Insert the back brick panel first by carefully
slipping it between the back wall of the
firebox and the rear log bracket.
6) When finished reading manometer, turn off
the gas valve, disconnect the hose and
tighten the screw (clockwise) with a 1/8"
flat screwdriver. Note: Screw should be
snug, but do not over tighten.
S.I.T.VALVEDESCRIPTION
1) Gas cock knob
2) Manual high/low adjustment
3) PilotAdjustment
4) Thermocouple Connection - option
5) Outlet Pressure Tap
6) Inlet Pressure Tap
7) PilotOutlet
8) Main Gas Outlet
9) Alternative TC Connection Point
3) Put the side panels in next. Slide them in
fromthe frontandpush themflatup against
the wall. Be very careful not to scratch
them on the firebox hardware.
4) Install the 2 brick retaining clips, one on
each side.
INSTALLATION
LOG SET
INSTALLATION
Read the instructions below carefully and
refer to the diagrams. If logs are broken
do not use the unit until they are replaced.
Broken logs can interfere with the pilot
operation.
The gas log kit (Part # 512-930) contains the
following pieces:
a) 02-49 Rear Log 902-236
b) 02-55 Middle Left Log 902-237
c) 02-50 Front Left Log 902-242
d) 02-53 Center Left Log 902-239
e) 02-51 Front Bottom Log 902-241
f) 02-54 Center Right Log 902-238
g) 02-52 MiddleRightLog 902-240
h) Embers 902-156
i) Vermiculite 902-179/21
NOTE: If you will be installing the optional
Brick Panels, install the Brick Pan-
els prior to installing the logs.
1) Carefully remove the logs from the box and
unwrap them. The logs are fragile, handle
with care - do not force into position.
2) Sprinkle the vermiculite around the firebox
base.
Vermiculite Vermiculite Vermiculite
The "02" refer numbers (i.e. 02-49) are
molded into the rear of each log.
3) PlacetheLog 02-49onthe rearlog support
pins with the flat side to the back.

Masport P36-3 Gas Inbuilt
20
INSTALLATION
9) Place Log 02-52 between Logs 02-51 and
02-49andon the indentationonLog 02-54.
The bottom right end sits behind the rear
grate tab.
Log indentation
Photo shows rear grate tab.
Log 02-51 was removed to show
the positioning of Log 02-52.
Rear
Grate
Tab
02-52
02-49
02-51 02-54
02-52
02-54
5th Grate Tab
Rear Bracket
Front Brackets
Notch
02-55
02-50
02-54
5) Position Log 02-53 across the cutouts in
Logs 02-49 and 02-51 with the notch on the
left side of the log fitting into the 2nd grate
tab.
Cutouts
2nd Grate Tab
02-53
02-49
02-51
02-49
02-51
02-53
02-49
02-51
02-53
02-55
02-53
02-50
02-55
02-53
02-50
02-55
02-53
02-49
02-51
02-53
02-51 02-54
Notch
Bracket
Bracket
02-49
02-51
02-49
02-51
4) Place Log 02-51 on the front right side of
theburner.Pushthebackofthelogagainst
the2 bracketswith thenotchonthebottom
right side of the log fitting into the right side
of the grate.
6) Place the bottom left front edge of Log
02-55againsttherearbracketontheburner
tray and rest the log on the cutout on
Log 02-53.
7) Sit Log 02-50 on the front left side of the
burner.Pushthebackofthelogagainstthe
2 front brackets with the notch on the
bottom of the log fitting into the first grate
tab.
8) Position Log 02-54 across the cutouts in
Logs 02-51 and 02-53. The notch in the
bottomrightendfittingagainstthe5thgrate
tab.
