Master MFG REVOLT SPOT KIT Instruction manual

HAVING TROUBLE? CALL SUPPORT AT: 320.340.6464
SPOT REVOLT KIT INSTALLATION SRK-AC
PARTS
Connect Battery Charger to
the open hole on the top of
the Revolt Battery Pack.
Plug the Battery Charger into
an appropriate outlet.
Charging ReVolt Battery Pack
1.
INCLUDED
COMPONENTS
NOTE:
THE REVOLT SERIES BATTERY PACK IS NOT CHARGED OUT OF THE
CARTON AND REQUIRES TWO HOURS TO FULLY CHARGE.
Revolt Battery Pack (1)
33-100512
Battery Charger (1)
33-100513
• Before Using The Battery Pack & Charger:
Read this operator’s manual and all labels on the
battery pack.
• Caution: To reduce risk of injury, ONLY CHARGE
REVOLT BATTERY PACK WITH REVOLT SERIES
CHARGERS. Other types of batteries may burst
causing personal injury and damage. Do not wire
a battery pack to a power supply plug or the DC
outlet of a vehicle. Batteries will be permanently
disabled or damaged.
• Avoid Dangerous Environments: Do not
charge battery pack in rain, snow, damp or wet
locations. Do not use battery pack or charger in
the presence of explosive atmosphere (gaseous
fumes, dust or flammable materials) because
sparks may be generated when inserting or
removing battery pack, possibly causing a fire.
• Charge In A Well Ventilated Area: Do not
allow smoking or open flames near charging
battery pack. Vented gases may explode.
• Do Not Burn Or Incinerate Battery Packs:
Battery packs may explode, causing personal
injury or damage. Toxic fumes and materials are
created when battery pack burns.
• Do Not Crush, Drop or Damage: Do not use a
WARNING
Read and understand all instructions. Failure to follow all instructions listed below,
may result in electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
battery pack or charger that has received a sharp
blow, been dropped, run over, or damaged in any
way.
• Do Not Disassemble: Incorrect reassembly
may result in the risk of electric shock, fire or
exposure to battery chemicals.
• Battery Chemicals Cause Serious Burns:
Never allow contact with skin, eyes or mouth. If
a damaged battery pack leaks battery chemicals,
use rubber or neoprene gloves to dispose of it.
If skin is exposed to battery fluids, wash with
soap and water, and rinse with vinegar. If eyes
are exposed to battery chemicals, immediately
flush with water for 20 minutes and seek medical
attention. Remove and dispose of contaminated
clothing.
• Do Not Short Circuit: A short circuited battery
pack may cause a fire, personal injury, and
product damage. A batter pack will short circuit if
a metal object makes a connection between the
positive and negative contact on a battery pack.
Do not place a battery pack near anything that
may cause a short circuit such as coins, keys or
nails in your pocket.
NOTE: Follow sprayer
assembly instructions
before you complete Revolt
assembly steps.
PARTS
Connect the Wire Harness to your Pump by pushing the two-pin
terminal connectors together.
Connects ReVolt Dock to Pump
2.
V
RE OLT

HAVING TROUBLE? CALL SUPPORT AT: 320.340.6464
SPOT REVOLT KIT INSTALLATION SRK-AC
3. PARTS
Slide Battery Pack into the open dock in the Weather Guard. A
click will be heard when properly attached.
NOTE: To release the Battery Pack from the Weather Shield
dock, press the Release Button on the back of the Battery Pack.
Connects Battery to Dock
PARTS
When ready for spraying, flip the Power Switch on the Battery
Dock.
Turns On Power to Pump
4.
NOTE: The Power Switch will
light up in the ON position. If
it doesn’t, the Battery Pack
will need to be fully charged.
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Pump Will Not Prime Out of Product Refill Supply Container
Pump Will Not Turn On Battery Not Connected Check Battery Connection
Low Voltage Check Voltage
Battery Pack Won't Charge
Battery Not Connected To
Charger
Connect Battery Pack To Charger Until Red LED Appears
Charger Not Plugged In Pluge Charger Into Working Outlet
Surronding Air Temperature
Too Hot or Cold
Move Charger & Battery Pack To Air Temperature of 40
Deg or Below 105 Deg
Bad Charger Replace Charger
Sprayer Won't Start
Battery Pack Not Installed
Properly
Check Battery Pack Installation
Battery Pack Not Charged Charge Battery Pack with Charger Until LED Light Is
Green
Power Switch Not Lighting Up
Battery Pack Not Installed
Properly
Check Battery Pack Installation
Battery Pack Not Charged Charge Battery Pack with Charger Until LED Light Is
Green
Battery Dock Not Working See If Battery Pack Is Fully Charged & Connect. If Not
Working, Issue Is With Dock.
Bad Charger Replace Charger
BREAKDOWN
B.
ID Part Description Qty
1 34-100000
Battery Mount -
15/25 Gallon Spot
Sprayers Only
1
2 33-100512 ReVolt Battery Pack 1
