MasterChef T360 User manual

T360 Barbecue
Assembly Manual
85-3052-6 (G30531) Propane
1 YEAR LIMITED WARRANTY
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
If pre-assembled, leave this manual with unit for
consumer’s future reference.
For product inquiries, parts, warranty and
troubleshooting support, please call 1-877-707-5463.
Manual Revision #: 22092012 PDAT

DANGER
1. If you smell Gas:
a. Shut o gas to the appliance
b. Extinguish any open ame
c. Open lid
d. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your
re department
2. Do not store or use gasoline or other
ammable vapours and liquids in the
vicinity of this or any other appliance.
3. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
4. Requires two people to complete the
assembly process.
5. Beware of sharp edges.
WARNING
Failure to follow all of the Manufacturer’s
instructions could result in hazardous res,
explosions, property damage, or serious
personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if grill
was dealer assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this manual.
THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES
CAUTION
Read and follow all safety statements,
assembly instructions, use and care
directions before attempting to assemble
and cook.
CAUTION
Sharp edges. Wear gloves when assembling
your grill.
THIS BARBECUE IS FOR OUTDOOR USE ONLY
CONTACT CALL CENTRE IF ANY PARTS ARE MISSING
1-877-707-5463
INSTALLER OR ASSEMBLER/CONSUMER
This manual should be kept with the BBQ at
all times.
HEAVY ARTICLE NEEDS 2 TO LIFT
To ORDER non-warranty replacement parts or accessories, or to register your warranty,
please visit us on the web at
www.masterchefbbqs.com

1
TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• ¼” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
Before assembling the barbecue, read these
instructions carefully.
Assemble the barbecue on a at, clean surface.
Grill is heavy. You should have at least two people
assemble the barbecue together.
Notes: Do not fully tighten all the nuts during
this initial stage.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
HARDWARE PACK
NO.10-24UNCX13 Screw
X 23
ST4.2X8 Tapping Screw
X 7
¼”-20UNC Wing Nut
X 2
Hitch Pin
X 5
Wheel Washer B
X 1
NO.10-24UNCX30 Screw
X 16
φ6.5 Fiber Washer
X 4
NO.8 Wing Nut
X 1
Wheel Washer A
X 1
NO.8-32UNCX10 Screw
X 2
φ5 Fiber Washer B
X 1
Bolt
X 4
Venturi Clip, Side Burner
X 1
NO.10-24UNCX50 Screw
X 12
φ5 Fiber Washer A
X 26
Wing Screw
X 1
Side Shelf Washer
X 4
1
5
9
13
17
21
2
6
10
14
18
3
7
11
15
19
4
8
12
16
20
KEY # DESCRIPTION PART NUMBER QUANTITY
1 ¼”-20UNC Nut 31220-13000-036 4
2 ¼”-20UNCX13 Screw 20120-13013-036 4
3 ¼”-20UNCX30 Screw 20120-13030-036 4
4 NO.10-24UNC Nut 31224-10000-036 42
5 NO.10-24UNCX13 Screw 20124-10013-036 23
6 NO.10-24UNCX30 Screw 20124-10030-036 16
7 NO.10-24UNCX50 Screw 20124-10050-036 12
8 NO.8-32UNCX10 Screw 20132-08010-036 2
9 ST4.2X8 Tapping Screw 24200-42008-136 7
10 φ6.5 Fiber Washer G431-0018-9000 4
11 φ5 Fiber Washer A G437-0050-9000 26
12 φ5 Fiber Washer B G437-0049-9000 1
13 ¼”-20UNC Wing Nut 33300-13000-032 2
14 NO.8 Wing Nut 33300-08000-032 1
15 Wing Screw G306-0025-9084 1
16 Bolt G306-0004-9188 4
17 Hitch Pin G306-0005-9088 5
18 Wheel Washer A G305-0024-9088 1
19 Side Shelf Washer A006-0006-9000 4
20 Venturi Clip, Side Burner G305-0057-9000 1
21 Wheel Washer B G305-0058-9088 1
¼”-20UNC Nut
X 4
¼”-20UNCX13 Screw
X 4
NO.10-24UNC Nut
X 42
¼”-20UNCX30 Screw
X 4

2
PARTS LIST PROPANE FOR 8530526 G30531
KEY # QUANTITYDESCRIPTION PART NO.
AA 1 Top Lid Assembly G305-0R01-01
AB 2 Upper Hinge G206-0002-03
AC 1 Lid Handle G305-0090-01
AD 2 Lid Bumper G560-5002-01
BA 1 Burner Box Assembly G305-0S01-01
BB 2 Lower Hinge G206-0010-03
BC 1 Burner G305-AD00-01
BD 1 Flame Tamer G305-0078-01
BE 1 Cooking Grate G305-0006-01
BF 1 Warming Rack G305-0080-01
CA 1 Control Panel G305-0T01-01
CB 1 Manifold Assembly G305-0V00-01
CC 4 Control Knob G432-0090-01
CD 1 Ignitor G206-0301-01
CE 1 Grease Cup Hook G305-0043-01
CF 1 Grease Cup G430-0033-02
CG 1 Regulator G305-0056-01
DA 2 Upper Leg Support Bars G305-0600-01
DB 1 Cart Leg, Right, Front G305-0017-01
DC 1 Cart Leg, Right, Rear G305-0018-01
DD 1 Cart Leg, Left, Front G305-0019-01
DE 1 Cart Leg, Left, Rear G305-0020-01
DF 1 Burner Box Support, Left G305-0030-02
DG 1 Burner Box Support, Right G305-0031-02
DH 1 Side Brace G305-0700-01
DI 1 Heat Shield G210-0012-01
DJ 1 Front Panel G305-0U00-01
DK 2 Back Brace G305-0010-01
DL 3 Tank Exclusion G434-0056-01
DM 2 Support Bracket G305-0021-01
DN 2 End Caps, Cart legs G208-0012-01
DO 2 Wheel G206-0025-01
DP 1 Wheel Axle G305-0059-01
DQ 1 Tank Retainer Clip G306-0020-01
DR 1 Match Holder G401-0079-01
EA 1 Side Shelf, Right E201-0009-02
EB 1 Right Side Shelf Bracket, Front G305-0082-01
EC 1 Right Side Shelf Bracket, Rear G305-0083-01
ED 1 Side Burner Table, Left G305-0X00-01
EE 1 Left Side Shelf Bracket, Front G305-0033-01
EF 1 Left Side Shelf Bracket, Rear G305-0034-01
EG 1 Side Burner Drip Pan G307-0024-01
EH 1 Side Burner G434-5500-02
EI 1 Side Burner Electrode Wire G305-0084-01
EJ 1 Side Burner Cooking Grate G307-0022-01
EK 1 Side Burner Valve G305-0068-01
F1 1 Hardware Pack G305-B031-01
F2 1 Assembly Manual G305-M031-01
F3 1 Safe Use and Care Manual G451-M018-01

3
EXPLODED DIAGRAM PROPANE FOR 8530526 G30531
BF
DM
AA
AC
DB
EJ
EH
CE
EG
DO
DP
DR
DK
F1
HARDWARE
PACK
ASSEMBLY
MANUAL
SAFETY
AND CARE
MANUAL
F2 F3
DN
EB
BC
CC
EI
DA
ED
EF
EE
CC
DD
DQ
DE
DH
DI
DF
DG
DJ
EC
CD
EA
DA
CC CC
BE
BD
CG
EK
BB
AB AD
CF
BA
CB
CA
DK
DL
DC

4
Attach the Support Bracket (DM) to the bottom
of the left Cart Legs (DD & DE), as shown. Ensure
that the hardware is assembled through the
third hole from the bottom of the Cart Legs.
Insert left Cart Legs (DD & DE) into the Upper
Leg Support Bar (DA), as shown.
Attach Side Brace (DH) to left front Cart Leg (DD)
using hardware, as shown in gure B.
1
ASSEMBLY INSTRUCTIONS
DH
DA
DD
DE
Close Up
2
YOU WILL NEED:
YOU WILL NEED:
16
4
17
6
X 2
X 1
X 2
X 1
DD
DM
DE
DM
DE
DD
DA
DE
B
A

5
Assemble the Front Panel (DJ) to the left and
right front Cart Legs (DB & DD), as shown.
Insert right Cart Legs (DB & DC) into the Upper
Leg Support Bar (DA), as shown. Secure the
Right, Front Cart Leg (DB) to the Upper Leg
Support Bar (DA) using hardware, as shown.
Attach the Support Bracket (DM) to the bottom
of the right Cart Legs, as shown.
3
4
ASSEMBLY INSTRUCTIONS
DA
DM
DB
DJ
DC
DC
YOU WILL NEED:
YOU WILL NEED:
4
4
6
7
X 3
X 4
X 3
X 4
DB

6
5Assemble the two Back Braces (DK) to the left
and right rear Cart Legs (DC & DE), as shown.
ASSEMBLY INSTRUCTIONS
DJ
DK
DC
DK
YOU WILL NEED:
4 6
X 8 X 8
DE
Attach the three Tank Exclusion rails (DL) to the
Front Panel (DJ) and the lower Back Brace (DK),
as shown. Secure using hardware.
Close Up
Back view
Back view
6
YOU WILL NEED:
9
X 3
DJ
DK
DK
DK
DJ
DE
DC
DL
DC
DE
DL

7
7
ASSEMBLY INSTRUCTIONS
NOTE: Turn cart assembly upside down.
Place Wheel (DO) onto the Wheel Axle (DP).
“Cone” side of wheel should be against cart leg,
as shown in gure B.
Insert Wheel Axle (DP) through wheel axle hole
in the front and rear, of the left Cart Legs (DD &
DE), as shown. The wheel axle hole is the second
hole from the bottom of the left Cart Legs (DD
& DE). To complete wheel assembly, position
the Wheel Washer B (#21), Wheel (DO), Wheel
Washer A (#18) and Hitch Pin (#17), onto Wheel
Axle (DP).
DP
DO
DD DE
YOU WILL NEED:
YOU WILL NEED:
17 18 21
X 1 X 1 X 1
DO
Close Up
8CA
DG
DF
DF
CA
DG
18
21
17
Close Up
a. Assemble only the rear left Burner Box
Support (DF), and the rear right Burner Box
Support (DG) rst. The angled edge of the
Burner Box Supports (DF & DG) should be
positioned towards the front of the unit.
b. Assemble the Control Panel (CA) together
with the front left and right Burner Box
Support (DF & DG).
TIP: One person should align the Burner Box
Supports (DF & DG) and the Control Panel
(CA), while the second person assembles the
hardware.
Only tighten all hardware once correct
assembly has been veried.
4 7
X 8 X 8
Angled edge
A
B

8
ASSEMBLY INSTRUCTIONS
a. Position the Manifold Assembly (CB) through
the back of the Control Panel (CA), and
assemble.
b. Assemble the Igniter (CD) through the front of
the Control Panel (CA), as shown.
a. Assemble the Heat Shield (DI) to the Side
Brace (DH), as shown.
b. Insert the Tank Retainer Clip (DQ) into the Side
Brace (DH), as shown and secure using a wing
nut.
YOU WILL NEED:
5
X 3
B
B
A
A
DI
DI
DH
DH
DQ
CA
CA
CB
CD
9
10
YOU WILL NEED:
YOU WILL NEED:
4
15
5
X 2
X 1
X 2
Back view

9
ASSEMBLY INSTRUCTIONS
11 a. Assemble the Burner (BC) into the Burner Box
Assembly (BA), with the burner venturi tubes
facing forward, as shown.
b. Assemble hardware into Burner Box Assembly
(BA), as shown.
NOTE: This hardware will be used in a later step
to support the Flame Tamer (BD).
BA
BA
BC
BA
BC
BC
YOU WILL NEED:
YOU WILL NEED:
5
6
11
411
X 2
X 4
X 2
X 4 X 4

10
ASSEMBLY INSTRUCTIONS
11
A
B
BA
DF
BA
BC
CD
DG
CC
CA
CB
DG
BC
c. Position the Burner Box Assembly (BA) onto
the Burner Box Supports (DF & DG), as shown
in gure A.
ATTENTION: Before assembling, ensure the
Burner (BC) engages the Manifold Assembly
valves (CB).
Attach the Burner Box Assembly (BA) to the
Burner Box Support (DF & DG), as shown in
gure B.
d. Attach the Burner Electrode Wire to the Igniter
(CD), as shown.
e. Position the Control Knobs (CC) onto Valve
stems (CB).
YOU WILL NEED:
45 11
X 4 X 4 X 4

11
ASSEMBLY INSTRUCTIONS
12 a. Assemble the front and rear right Side Shelf
Brackets (EB & EC) to the right Side Shelf (EA),
as shown.
b. Assemble the right Side Shelf (EA) to the
Upper Leg Support Bar (DA), as shown.
c. Assemble the front and rear left Side Shelf
Brackets (EE & EF) to the left Side Burner Table
(ED) using two screws, as shown in gure C.
d. Turn the left Side Burner Table (ED) over and
use two screws to nish assembly of the front
and rear, left Side Shelf Brackets (EE & EF), as
shown in gure D.
BA
EF
ED
EE
EF
ED
EE
A
B
C
D
YOU WILL NEED:
YOU WILL NEED:
1
9
2
19
3
X 2
X 4
X 2
X 4
X 2
EC
EB
EA
EA
DA
YOU WILL NEED:
YOU WILL NEED:
5
5
X 2
X 2

12
ASSEMBLY INSTRUCTIONS
12 e. Assemble the left Side Burner Table (ED) to the
Upper Leg Support Bar (DA), as shown.
DA
ED
a. Assemble the Side Burner Valve Assembly (EK)
to the Side Burner Table (ED).
b. Position the Side Burner (EH) through the
opening in the Side Burner Drip Pan (EG).
Make sure the Side Burner (EH) engages the
Side Burner Valve (EK), and assemble, as shown
in gure C.
ED
EH
EG
ED
EK
EH
EK
EK
13
YOU WILL NEED:
8
X 2
YOU WILL NEED:
1 23
X 2 X 2 X 2
YOU WILL NEED:
12 14
X 1 X 1
A
B
C

13
13 c. Connect the Side Burner (EH) to the Side
Burner Valve (EK), using the venturi clip #20, as
shown.
d. Attach the end of the Side Burner Electrode
Wire (EI) to the Igniter (CD), as shown in gure
B. Ensure that the wire is pushed in rmly.
e. Place the Side Burner Cooking Grate (EJ) into
position on the Side Burner Shelf (ED).
f. Position the Side Burner Control Knob (CC)
over the Side Burner Valve Stem (EK).
ED
CD
EJ
ED
CC
EK
EH
ED
EK
20
EI
EH
CD
YOU WILL NEED:
20
X 1
ASSEMBLY INSTRUCTIONS
A
B
C

14
14 Assemble the Lower Hinge (BB) on the back of
the Burner Box Assembly (BA), as shown.
ASSEMBLY INSTRUCTIONS
BA BB
BB
Assemble the Upper Hinge (AB) to the Top Lid
Assembly (AA).
15 AA
AB
YOU WILL NEED:
YOU WILL NEED:
4
4
5
5
11
11
X 4
X 4
X 4
X 4
X 8
X 8
AB

15
16
ASSEMBLY INSTRUCTIONS
a. Assemble the Lid Handle (AC) to the Top Lid
Assembly (AA).
AC
YOU WILL NEED:
YOU WILL NEED:
13 10
X 2 X 4
AA
17
AB
AA
AA
AB
BA
BB
BB
BA
BB
To assemble the Top Lid Assembly (AA) to the
Burner Box Assembly (BA), position the Upper
Hinge (AB) in between the Lower Hinge (BB),
position hardware and lock into place using the
Hitch Pins (#17).
16 17
X 2 X 2
AB
AB
AB

16
18 Position the Flame Tamer (BD) into the Burner
Box Assembly (BA).
Note: The Flame Tamer (BD) should be placed
onto the hardware assembled in step 11b.
Position the Cooking Grate (BE) into the Burner
Box Assembly (BA).
ASSEMBLY INSTRUCTIONS
BE
To assemble the Warming Rack (BF), insert the
stationary wire into the holes on the sides of the
lid. Insert Warming Rack (BF) pivot legs into the
holes inside of the Burner Box Assembly (BA), as
shown.
19
BF
BA
BA
BD
Stationary wire
Pivot legs

17
20
ASSEMBLY INSTRUCTIONS
Hook the Grease Cup Hook (CE) to the bottom of
the Burner Box Assembly (BA), as shown. Place
the Grease Cup (CF) into the Grease Cup Hook
(CE).
BA
CE
CE
21
DM
a. Loosen the wing nut from the Tank Retainer
Clip (DQ). Set bottom of the tank into notches
located on the left Support Bracket (DM).
Position Tank Retainer Clip (DQ) onto tank collar
and tighten wing nut.
Close up
CF
CF
DQ
CG
Close Up
A

18
21
ASSEMBLY INSTRUCTIONS
b. Attach the Regulator coupling nut (CG) to the LP
cylinder valve.
ATTENTION
LP Cylinder is sold separately. Use only
LP tanks that are equipped with an
OPD (Overll protection device). Fill
and Leak check before attaching to the
BBQ hose and regulator. See Safe Use
and Care Manual, leak test procedure
for more information.
WARNING
Always keep LP cylinder in upright
position during use, transport and
storage.
Close Up
B
