MasterChef S480 User manual

S480 Barbecue
Assembly Manual
85-3064-8 (G43257) Propane
85-3065-6 (G43258) Natural Gas
1 YEAR LIMITED WARRANTY
Manual Revision #: 07302014 AT
TM
MC
ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012 ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
Assemble your grill immediately.
Missing or damaged parts claims must be submitted within 30 days of purchase date.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-855-453-2150.

DANGER
1. If you smell Gas:
a. Shut o gas to the appliance
b. Extinguish any open ame
c. Open lid
d. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your
re department
2. Requires two people to complete the
assembly process.
3. Beware of sharp edges.
WARNING
Failure to follow all of the Manufacturer’s
instructions could result in hazardous res,
explosions, property damage, or serious
personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if grill
was dealer assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this manual.
THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES
CAUTION
Read and follow all safety statements,
assembly instructions, use and care
directions before attempting to assemble
and cook.
WARNING
1. Do not store or use gasoline or other
ammable liquids or vapours in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
WARNING
IN DIRECT SUN, AND IN OPERATION,
YOUR BBQ’S STAINLESS STEEL AND
PAINTED STEEL PARTS CAN BECOME
VERY HOT.
CAUTION
Sharp edges. Wear gloves when assembling
your grill.
THIS BARBECUE IS FOR OUTDOOR USE ONLY
CONTACT CALL CENTRE IF ANY PARTS ARE MISSING
1-855-453-2150
INSTALLER OR ASSEMBLER/CONSUMER
This manual should be kept with the BBQ at
all times.
HEAVY ARTICLE NEEDS 2 TO LIFT
To ORDER non-warranty replacement parts or accessories, or to register your warranty,
please visit us on the web at
www.masterchefbbqs.com

1
HARDWARE PACK
1/4”-20UNC X13 Screw
X 20
ST4.2X8 Tapping Screw
X 6
Wheel Spacer
X 2
NO.10-24UNC X13 Screw
X 4
Hitch Pin
X 1
Washer (Wheel)
X 1
1 3
4 5 6
KEY # DESCRIPTION PART NUMBER QUANTITY
1 1/4”-20UNC X13 Screw 20120-13013-036 20
2 NO.10-24UNC X13 Screw 20124-10013-036 4
3 ST4.2X8 Tapping Screw 24200-42008-136 6
4 Wheel Spacer G305-0024-9088 2
5 Hitch Pin G306-0005-9088 1
6 Washer (Wheel) 40300-08000-036 1
TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• ¼” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
For correct hardware assembly, always position
the lock washer between the screw and the at
washer.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
Lock Washer
Flat Washer
Screw
BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.
Assemble the barbecue on a flat, clean surface. Grill is heavy. Two people are recommended
to complete assembly.
2

2
PARTS LIST PROPANE FOR 8530648 G43257
KEY # QUANTITY DESCRIPTION PART NO.
AA 1 Top lid assembly G432-9D00-01
AB 1 Thermometer and bezel G312-B201-01
AC 2 Lid handle brackets G352-0015-01
AD 1 Top lid handle G312-B203-01
AE 2 Lid bumpers-back G303-0038-01
AF 2 Lid bumpers-front G430-00B8-01
AG 2 Screws for lid G430-0024-02
BA 1 Burner box assembly G432-9R00-01
BB 4 Burner G432-B600-01
BC 1 Electrode set, main burner G439-0039-01
BD 3 Burner brace assembly G432-0078-01
BE 4 Flame tamer G430-0005-01
BF 3 Cooking grate G432-1800-01
BG 1 Warming rack G432-0001-01
CA 1 Control panel G432-9Q00-01
CB 1 Manifold assembly G432-9E00-01
CC 1 Regulator G511-0031-01
CD 4 Bezel, control knob G430-0027-02
CE 4 Control knob G312-B102-01
CF1 1 Electronic ignition assembly G409-0021-A2
CF2 1 Electronic ignition button G409-0030-01
CG 1 Grease cup hook G305-0043-01
CH 1 Grease cup G430-0033-02
CI 1 Heat shield G432-Q101-01
DA 1 Cart side panel, right G451-0D00-01
DB 1 Cart side panel, left G451-0C00-01
DC 2 Back Brace G432-E300-01
DD 1 Front panel G432-0033-01
DE 2 End caps G430-0023-01
DF 2 Wheel G210-0018-02
DG 1 Wheel axle G430-0007-02
DH 1 Match holder G401-0079-01
DI 1 Tank exclusion G432-5302-01
DJ 1 Gas Tank Support G307-0016-01
EA 1 Side shelf table, right G312-BL00-01
EB 1 Side shelf fascia, right G432-9S01-01
EC 1 Side shelf table, left G432-9U00-01
ED 1 Side shelf fascia, left G432-9C01-01
F1 1 Hardware pack G432-B057-01
F2 1 Assembly instructions G432-M057-01
F3 1 Safe use and care manual G432-M057-02

3
EXPLODED DIAGRAM PROPANE FOR 8530648 G43257
BF
BE
BA
CA
AG
AE
AF
AC
BG
AB
AA
AD
CI
BC
CC
DF
DG
DA
DC
CD
EA
CG
CH
EB
DE
DH
DI
CB
DB
DD
DJ
BB
BD
CF2
CF1
EC
ED
CE
HARDWARE
PACK
F1
F2 F3
ASSEMBLY
MANUAL
SAFETY
AND CARE
MANUAL

4
PARTS LIST NATURAL GAS FOR 8530656 G43258
KEY # QUANTITY DESCRIPTION PART NO.
AA 1 Top lid assembly G432-9D00-01
AB 1 Thermometer and bezel G312-B201-01
AC 2 Lid handle brackets G352-0015-01
AD 1 Top lid handle G312-B203-01
AE 2 Lid bumpers-back G303-0038-01
AF 2 Lid bumpers-front G430-00B8-01
AG 2 Screws for lid G430-0024-02
BA 1 Burner box assembly G432-9T00-01
BB 4 Burner G432-B600-01
BC 1 Electrode set, main burner G439-0039-01
BD 3 Burner brace assembly G432-0078-01
BE 4 Flame tamer G430-0005-01
BF 3 Cooking grate G432-1800-01
BG 1 Warming rack G432-0001-01
CA 1 Control Panel G432-9Q00-01
CB 1 Manifold assembly G432-9G00-01
CC 1 Natural gas hose G501-0099-01
CD 4 Bezel, control knob G430-0027-02
CE 4 Control knob G312-B102-01
CF1 1 Electronic ignition assembly G409-0021-A2
CF2 1 Electronic ignition button G409-0030-01
CG 1 Grease cup hook G305-0043-01
CH 1 Grease cup G430-0033-02
CI 1 Heat shield G432-Q101-01
DA 1 Cart side panel, right G451-0D00-01
DB 1 Cart side panel, left G451-0C00-01
DC 2 Back Brace G432-E300-01
DD 1 Front panel G432-0033-01
DE 2 End Caps G430-0023-01
DF 2 Wheel G210-0018-02
DG 1 Wheel Axle G430-0007-02
DH 1 Match holder G401-0079-01
EA 1 Side shelf table, right G312-BL00-01
EB 1 Side shelf fascia, right G432-9S01-01
EC 1 Side shelf table, left G432-9U00-01
ED 1 Side shelf fascia, left G432-9C01-01
F1 1 Hardware pack G432-B057-01
F2 1 Assembly instructions G432-M057-01
F3 1 Safe use and care manual G432-M057-02

5
EXPLODED DIAGRAM NATURAL GAS FOR 8530656 G43258
BF
BE
BA
CA
AG
AE
AF
AC
BG
AB
AA
AD
CI
BC
CC
DF
DG
DA
DC
CD
EA
CG
CH
EB
DE
DH
CB
DB
DD
BB
BD
CF2
CF1
EC
ED
CE
HARDWARE
PACK
F1
F2 F3
ASSEMBLY
MANUAL
SAFETY
AND CARE
MANUAL

6
PROPANE MODEL ONLY.
NATURAL GAS MODEL WILL NOT
HAVE TANK EXCLUSION (DI) AS
SHOWN.
Note: You will need two people for this step.
Assemble the tank exclusion (DI) to the left and
right cart side panels (DB, DA), as shown.
Note: The left cart side panel (DB) will have
large holes on the end of the legs for
assembling the wheel axle (DG).
Note: the tank exclusion should sit in the
middle hole on the left and right side panel.
1
ASSEMBLY INSTRUCTIONS
YOU WILL NEED:
3
X 6
Front View
Close Up
Close Up
a. Assemble the front panel (DD) to the left and
right cart side panels (DB and DA) as shown.
2DB
DA
DI
DD
DB
DA
DI
A
B
b. Ensure that the slots on the tank exclusion (DI)
align with the slots on the front panel.
DI
DA

7
Note: Turn Cart assembly upside down.
a. Place wheel (DF) and wheel spacer (#4) onto
the wheel axle (DG). “Cone”side of wheel
should be against cart side panel, gure B.
b. Insert wheel axle assembly (DG) through wheel
axle hole in the front and rear of the left cart
side panel (DB), as shown.
c. To complete wheel assembly position the
wheel spacer (#4), wheel (DF), wheel washer
(#6) and hitch pin (#5), onto wheel axle (DG)
as shown.
d. Insert end caps (DE) into right cart side panel
(DA).
Assemble two back braces (DC) to the left and
right cart side panels (DB and DA) as shown.
3
4
ASSEMBLY INSTRUCTIONS
876
YOU WILL NEED:
YOU WILL NEED:
4
1
X 2
X 8
5
X 1
6
X 1
Close Up
Back View
DF
4
46
5
DF
DG
DD
A
DE
DD
DC
DC
DC
DB
Close upClose up
C
B
45
6

8
PROPANE MODEL ONLY.
Assemble the gas tank support (DJ) to left cart
side panel (DB).
Note: TWO PEOPLE required for this step.
Ensure that the regulator hose (CC) (Propane
models only) is hanging outside of cart.
Position the lid and burner box assembly (A&B),
onto the cart assembly (C), and assemble.
YOU WILL NEED:
ASSEMBLY INSTRUCTIONS
1
X 4
A B
+
C
A
B
Back View
Close up
DB
DJ
BA
5
6
DB
DJ
DB
CC

9
Assemble the control knobs (CE) onto the valve
stems of the manifold assembly (CB) located on
the control panel (CA).
TIP: Only assemble to brass nut.
ASSEMBLY INSTRUCTIONS
CE
CB
7
8
CA
RIGHT SIDE SHELF ASSEMBLY
a. Assemble the hardware to the burner box
assembly (BA) and control panel (CA).
Do not tighten.
A
Right side view
Close Up
B2
A1
A1
YOU WILL NEED:
1
X 1
A1
2
X 1
B2
BA
CA

10
ASSEMBLY INSTRUCTIONS
8b. Position the right side shelf assembly (EA and
EB) onto the hardware half-tightened in Step
8A, as shown in gure B and C.
D
E
B
EA
c. Tighten screws.
d. Assemble the right side shelf assembly (EA and
EB) to the control panel (CA) and the burner box
assembly (BA), as shown in gure E.
YOU WILL NEED:
C
EA
BA
CA
EB
1
X 3
A1
2
X 1
B2
Right side view
Back view, under right side shelf
Back view, under right side shelf
View, under right side shelf
EA
BA
EA
BA
CA
EB
A1
A1
A1
B2
BA
TIP: Only assemble to brass nut.

11
ASSEMBLY INSTRUCTIONS
CF2
+-
9
10
ELECTRONIC IGNITION ASSEMBLY
a. Remove the ignition battery cover (CF2) and
the plastic nut from the electronic ignition box
(CF1).
b. Position the electronic ignition box (CF1)
through the opening in the right side shelf
fascia (EB) and secure using the plastic nut.
c. Insert one “AA“ battery into the battery
compartment (CF1) with the positive end
facing outward, as shown. Securing using the
ignition battery cover (CF2).
* Battery not included.
d. Insert the main burner electrode (BC) and
the ground wire into the Electronic Ignition
Assembly (CF1).
Note: the ground wire and main burner
electrode wire connection points are the same.
Ensure that the wire is pushed in rmly.
CF1
Battery
Plastic Nut
LEFT SIDE SHELF ASSEMBLY
a. Assemble the hardware to the burner
box assembly (BA) and control panel (CA).
Do not tighten.
YOU WILL NEED:
1
X 1
A1
2
X 1
B2
Left side view
View under right side shelf
View under right side shelf
Close Up
B2
A1
A1
Ground Wire
CF1
BC
CA
A
BA
CA
EA
EB
EB
TIP: Only assemble to brass nut.

12
ASSEMBLY INSTRUCTIONS
10 b. Position the left side shelf (EC and ED) onto
the hardware half-tightened in Step 10A, as
shown in gure B and C.
c. Tighten screws.
d. Assemble the left side shelf assembly (EC and
ED) to the control panel (CA) and the burner
box assembly (BA), as shown in gure E.
View, under left side shelf
EC
BA
ED
B
E
EC
D
C
YOU WILL NEED:
1
X 3
A1
2
X 1
B2
ED
CA
BA
EC
BA
EC
BA
Left side view
Back view, under left side shelf
Back view, under left side shelf
A1 A1
A1 B2
CA
TIP: Only assemble to brass nut.

13
ASSEMBLY INSTRUCTIONS
11
A
Place the ame tamers (BE) into the burner box
assembly (BA).
Place the cooking grates (BF) into the burner box
assembly (BA).
BF
BE
12
Close up, front view
Close up, back view
BE
BE
B
C
BA
BA

14
ASSEMBLY INSTRUCTIONS
To assemble the warming rack (BG), insert the
stationary wire into the holes on the sides of
the lid. Insert warming rack pivot legs into the
holes on the inside of the burner box assembly
(BA), as shown.
14
BG
Stationary Wire
Hang the grease cup hook (CG) from the bottom
of the burner box (BA), and place grease cup (CH)
into position.
PROPANE MODEL SHOWN
CAUTION
Failure to assemble grease cup hook and grease
cup will cause hot grease to drip from the
bottom of the BBQ burner box, with the risk of
re, property damage, or personal injury.
CG
CG
CH
CI
CH
Pivot Legs
View from underneath burner box
Close up
Close up
A
B
13
BA
BA
BG

15
ASSEMBLY INSTRUCTIONS
16 NATURAL GAS MODELS ONLY
Attach the natural gas hose (CC) to the
manifold (CB), as shown.
ATTENTION
In order to complete installation of your natural
gas BBQ a 1/2” or 3/8” adapter may be required
to connect your BBQ’s natural gas hose to your
home gas supply. Contact your natural gas
supplier to purchase the necessary part.
View, under left side shelf
CB
CC
15 PROPANE MODEL SHOWN
FOR NATURAL GAS MODEL,
FOLLOW STEP 16.
Position the 20lb propane tank into the notches
located on the bottom of the left cart side panel
(DB). Position the gas tank support (DJ) onto the
tank collar. Attach the regulator coupling nut
(CC) to the propane tank valve.
ATTENTION
LP Cylinder is sold separately.
Use only LP tanks that are equipped with an
OPD (Overll protection device). Fill and leak
check before attaching to the BBQ hose and
regulator. See Safe Use and Care Manual, leak
test procedure for more information
CAUTION
Cylinder valve must face to the front of cart
once the tank is attached.
Failure to install cylinder correctly may allow
gas hose to be damaged in operation, resulting
in re.
WARNING
Always keep LP cylinder in upright position
during use, transport and storage.
WARNING
When assembling regulator onto LP cylinder,
ensure that the regulator is assembled below
the support bar, as shown.
CC
DJ

TM
MC
Visit www.masterchefbbqs.com
to complete product registration
Master Chef® Customer Service
1-855-453-2150
Trileaf Distributions Trifeuil
Toronto, Ontario M4S 2B8
