MasterCraft TBD User manual

IMPORTANT:
Read and understand this instruction manual
thoroughly before using the product.
4V SCREWDRIVER
INSTRUCTION
MANUAL
054-2439-8

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
3
TABLE OF CONTENTS
Technical Specifications 4
Safety Guidelines 5
Key Parts Diagram 9
Operating Instructions 10
Maintenance 13
Troubleshooting 14
Parts List 15
Warranty 16
NOTE:
If any parts are missing or damaged, or if you have any questions,
please call our toll-free helpline at 1-800-689-9928.
SAVE THESE INSTRUCTIONS
• This manual contains important safety and operating instructions. Read all
instructions and follow them with use of this product.
TABLE OF CONTENTS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-2439-8 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Rated voltage 4 V d.c.
Max torque 5 N.m
No-load speed 200 RPM
Min charging time 3 hr
Max. input voltage and current 5V, 0.6A
Chuck size 1/4” (6.4 mm)

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
5
SAFETY GUIDELINES:
WARNING!
Safety symbols in this Instruction Manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warnings do not,
by themselves, eliminate any danger, nor are they substitutes for proper accident prevention
measures.
WARNING!
This Safety Alert Symbol indicates caution, warning, or danger. Failure to obey a safety
warning can result in serious injury to yourself or others. To reduce the risk of injury, fire, or
electric shock, always follow the safety precautions.
KNOW YOUR TOOL
To operate this tool, carefully read this Instruction Manual and all labels affixed to the screwdriver
before using. Keep this instruction manual available for future reference.
IMPORTANT
This tool should only be serviced by a qualified service technician. For more information, call the toll
free helpline at 1-800-689-9928.
READ ALL INSTRUCTIONS THOROUGHLY.
SAVE THESE INSTRUCTIONS.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions, illustrations and specifications provided with
this power tool. Failure to follow all instructions listed below may result in electric shock,
fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
6
model no. 054-2439-8 | contact us 1-800-689-9928
• Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
ELECTRICAL SAFETY
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of an GFCI reduces the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious personal
injury.
• Use personal protective equipment. Always wear eye protection. Protective equipment
such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch or energizing power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
7
• Do not let familiarity gained from frequent use of tools allow you to become complacent
and ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or remove the battery pack,
if detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result in a
hazardous situation.
• Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situations.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
• Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
• When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects that can make a
connection from one terminal to another. Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
8
model no. 054-2439-8 | contact us 1-800-689-9928
• Do not use a battery pack or tool that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause explosion.
• Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
SERVICE
• Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service of battery packs should only be performed by
the manufacturer or authorized service providers.
ADDITIONAL SAFETY GUIDELINES FOR THE SCREWDRIVER
• Hold the power tool by insulated gripping surfaces, when performing an operation
where the fastener may contact hidden wiring. Fasteners contacting a “live” wire may
make exposed metal parts of the power tool “live” and could give the operator an electric shock.
• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
V ..................... Volts
A ..................... Amperes
Hz ................... Hertz
W .................... Watts
min ................. Minutes
or d.c .............. Direct current
n0................... No-load speed
…/min or …min-1 ................... Revolutions or reciprocations per minute
RPM ............... Revolutions per minute
.............. WARNING – To reduce the risk of injury, user must read instruction manual.
.............. WARNING – To reduce the risk of injury always wear eye protection.
.............. WARNING – To reduce the risk of injury always wear ear protection.
• For best results, your battery tool should be charged, stored and used in a location
where the temperature is more than 5°C (41°F) but less than 40°C (104°F). Do not store
outside or in vehicles.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
9
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
PACKAGE CONTENTS:
Cordless Screwdriver, USB cable, 10 screwdriver bits, nylon holster and instruction manual
KEY PARTS DIAGRAM
No. Description No. Description
1 Bit holder 4 USB socket
2 LED light 5 Rotation selector
3 Trigger switch 6 Battery level
KEY PARTS DIAGRAM
WARNING!
• Remove the screwdriver from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• Do not allow familiarity with the screwdriver to cause a lack of alertness. A fraction of a second of
carelessness is enough to cause severe injury.
FPO
1 6 5
2 3
4

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-2439-8 | contact us 1-800-689-9928
10
OPERATING INSTRUCTIONS
CHARGING (fig 1)
1. Insert one side of the USB cable (included) into the
USB socket on the screwdriver.
2. Connect the other side of the USB cable to the
computer’s USB port or a USB charger for a wall
socket (sold separately).
BATTERY LEVEL (fig 2)
This screwdriver is equipped with a battery level
which is used to display the remaining capacity of
the battery. Press the trigger switch to display the
LED lights. One light (red) means low charge; two
lights (red + yellow) mean middle charge; three
lights (red + yellow + green) mean full charge.
LED LIGHT (fig 3)
The LED light, located on the front of the screwdriver,
will illuminate when the trigger switch is depressed
and will automatically turn off after the trigger
switch is released. This provides additional light on
the surface of the workpiece for operation in lower
light situations.
OPERATING INSTRUCTIONS
fig 1
fig 2
fig 3
USB socket
Battery
level
LED light

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
11
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
ROTATION SELECTOR (fig 4)
Move the rotation selector forwards for clockwise
rotation; move the rotation selector backwards for
anticlockwise rotation; set the rotation selector in the
middle position to lock the screwdriver from rotating.
TRIGGER SWITCH (fig 5)
To turn the screwdriver on, depress the trigger
switch. To turn it off, release the trigger switch.
INSTALL/REMOVE A BIT (fig 6)
1. Insert the bit into the magnetic bit holder.
2. Gently pull on the bit to check that it is properly
fitted and does not come loose.
3. To remove the bit, just simply pull out the bit from
the bit holder.
OPERATING INSTRUCTIONS
fig 4
fig 5
fig 6
Rotation
selector
Trigger
switch
Bit holder
Forwards
Backwards

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
12
model no. 054-2439-8 | contact us 1-800-689-9928
SCREWDRIVING OPERATION
Do not force the screwdriver and never attempt to enlarge a hole by pushing sideways. Allow the tool to
do the job.
1. Install a suitable bit.
2. Move the rotation selector forwards for clockwise rotation.
3. Apply just enough pressure to keep the bit engaged on the screw and press the trigger switch to tighten
the screw.
4. Move the rotation selector backwards for anticlockwise rotation.
5. Keep the bit engaged on the screw and then press the trigger switch to loosen the screw.
OPERATING INSTRUCTIONS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
13
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
MAINTENANCE
BEFORE EACH USE
1. Check for damaged, missing, or worn parts.
2. Check for loose screws, misalignment or binding of moving parts, or any other condition that may affect
the operation.
3. If abnormal vibration or noise occurs, turn the tool off immediately and have the problem corrected before
further use. Set the rotation selector in the middle position to lock the screwdriver from rotating before
cleaning or performing any maintenance.
PREPARING THE BATTERY TOOL FOR RECYCLING
To preserve natural resources, please recycle or dispose of batteries properly.
This product contains lithium-Ion batteries. Local, state, or federal laws may
prohibit disposal of lithium-Ion batteries in ordinary trash. Consult your local
waste authority for information regarding available recycling and/or disposal
options.
MAINTENANCE
WARNING!
• Do not let brake fluids, gasoline, petroleum-based products, penetrating oil, etc., come into contact with
plastic parts. These substances contain chemicals that can damage, weaken, or destroy plastic.
• When servicing, use only identical replacement parts. The use of any other parts may create a hazard or
cause damage to the product.
• Use only accessories that are recommended for this screwdriver by the manufacturer. Accessories that
may be suitable for one tool may become hazardous when used with another tool.
• To ensure safety and reliability, all repairs should be performed by a qualified service technician.
FPO

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-2439-8 | contact us 1-800-689-9928
14
TROUBLESHOOTING
Problem Possible Causes Solution
The tool doesn’t work. The battery is depleted. Recharge the battery.
If the problem remains unsolved after performing the checks described above, call the toll-free helpline
at 1-800-689-9928.
TROUBLE SHOOTING

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
15
EXPLODED VIEW
No. Part No. Description No. Part No. Description
1 0542439801 Rubber Cover 9 0542439809 Switch Trigger
2 0542439802 Tapping Screw 10 0542439810 Tapping Screw
3 0542439803 Working Light Cover 11 0542439811 Spring
4 0542439804 LED Light Cover 12 0542439812 Tapping Screw
5 0542439805 Gear Box Assembly 13 0542439813 R/L Button
6 0542439806 Housing 14 0542439814 R/L Washer
7 0542439807 Housing 15 0542439815 Electric Assembly
8 0542439808 Tapping Screw 16 0542439816 Battery Cell
If any parts are missing or damaged, or if you have any questions, please call the Toll-free Helpline,
at 1-800-689-9928.
PARTS LIST

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-2439-8 | contact us 1-800-689-9928
16
This Mastercraft product is guaranteed for a period of 3 years from the date of original retail
purchase against defects in workmanship and materials, except for the following components:
a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from
the date of original retail purchase against defects in workmanship and materials;
b) Component B: Accessories, which are guaranteed for a period of 1 year from the date of original retail
purchase against defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if returned to us with proof
of purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear the
cost of any repair or replacement and any costs of labour relating thereto.
These warranties are subject to the following conditions and limitations:
a) a bill of sale verifying the purchase and purchase date must be provided;
b) this warranty will not apply to any product or part thereof which is worn or broken or which has become
inoperative due to abuse, misuse, accidental damage, neglect or lack of proper installation, operation or
maintenance (as outlined in the applicable owner’s manual or operating instructions) or which is being
used for industrial, professional, commercial or rental purposes;
c) this warranty will not apply to normal wear and tear or to expendable parts or accessories that may be supplied
with the product that are expected to become inoperative or unusable after a reasonable period of use;
d) this warranty will not apply to routine maintenance and consumable items such as, but not limited to, fuel,
lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids, tune-ups or adjustments;
e) this warranty will not apply where damage is caused by repairs made or attempted by others (i.e. persons
not authorized by the manufacturer);
f) this warranty will not apply to any product that was sold to the original purchaser as a reconditioned or
refurbished product (unless otherwise specified in writing);
g) this warranty will not apply to any product or part thereof if any part from another manufacturer is
installed therein or any repairs or alterations have been made or attempted by unauthorized persons;
h) this warranty will not apply to normal deterioration of the exterior finish, such as, but not limited to,
scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical cleaners;
and
i) this warranty will not apply to component parts sold by and identified as the product of another company,
which shall be covered under the product manufacturer’s warranty, if any.
WARRANTY

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
17
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor
the manufacturer shall be liable for any other expense, loss or damage, including, without limitation,
any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or
inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other rights, which may vary from
province to province. The provisions contained in this warranty are not intended to limit, modify, take
away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or federal
legislation.
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8
WARRANTY
