Matrix R7XI-01 User manual

R7XI-01 BIKE
SERVICE MANUAL

CHAPTER 1: SERIAL NUMBER LOCATION ................................................................... 1
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
2.1 Read and Save These Instructions ........................................................................... 3
2.2 Electrical Requirements ............................................................................................ 4
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 Recommended Cleaning Tips ................................................................................... 5
3.2 Check for Damaged Parts ......................................................................................... 5
3.3 Care and Maintenance Instructions .......................................................................... 6
3.4 Touch Screen Care & Cleaning.................................................................................. 7
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.1 Console Description .................................................................................................. 8
4.2 Workout Setup Steps ................................................................................................. 9
CHAPTER 5: MANAGER MODE
5.1 Using Manager Mode ................................................................................................ 10
5.2 Manager Mode - General........................................................................................... 11
5.3 Manager Mode - Workout .......................................................................................... 14
5.4 Manager Mode - Setup Defaults................................................................................ 16
5.5 Manager Mode - Asset Management......................................................................... 18
5.6 Manager Mode - Weather .......................................................................................... 18
5.7 Manager Mode - TV ................................................................................................... 19
5.8 Manager Mode - Applications .................................................................................... 20
5.9 Manager Mode - Hardware ........................................................................................ 21
5.10 Manager Mode - Service............................................................................................ 22
CHAPTER 6: ENGINEERING MODE
6.1 Using Engineering Mode ........................................................................................... 23
6.2 Engineering Mode - General...................................................................................... 24
6.3 Engineering Mode - Workout ..................................................................................... 27
6.4 Engineering Mode - Setup Defaults........................................................................... 29
6.5 Engineering Mode - Network ..................................................................................... 30
6.6 Engineering Mode - Asset Management.................................................................... 31
6.7 Engineering Mode - Weather ..................................................................................... 32
6.8 Engineering Mode - TV .............................................................................................. 32
6.9 Engineering Mode - Applications................................................................................ 34
6.10 Engineering Mode - Hardware ................................................................................... 35
6.11 Engineering Mode - Service ....................................................................................... 36
6.12 Engineering Mode - Errors ......................................................................................... 36
CHAPTER 7: SERVICE MODE
7.1 Using Service Mode. .................................................................................................. 37
7.2 Service Mode - General ............................................................................................. 38
7.3 Service Mode - Workout............................................................................................. 41
7.4 Service Mode - Setup Defaults .................................................................................. 43
7.5 Service Mode - Update .............................................................................................. 44
7.6 Service Mode - Network............................................................................................. 45
7.7 Service Mode - Asset Management ........................................................................... 46
7.8 Service Mode - Weather ............................................................................................ 46
7.9 Service Mode - TV...................................................................................................... 47
7.10 Service Mode - Applications ....................................................................................... 48
7.11 Service Mode - Hardware........................................................................................... 49
7.12 Service Mode - Virtual Active ..................................................................................... 51
7.13 Service Mode - Management ..................................................................................... 51
7.14 Service Mode - Service .............................................................................................. 52
7.15 Service Mode - Errors ................................................................................................ 52
7.16 Service Mode - Netpulse ............................................................................................ 53
7.17 Matrix fitness 7xi series feature access codes........................................................... 54
TABLE OF CONTENTS

III
CHAPTER 8: TROUBLESHOOTING
8.1 Electrical Diagram ..................................................................................................... 55
8.2 LCB LED Indicators.................................................................................................... 59
8.3 LCB Wiring Connections............................................................................................ 60
8.4 Troubleshooting - Error 04A0..................................................................................... 61
8.5 Troubleshooting - Error 04B0..................................................................................... 62
8.6 Troubleshooting - Error 0248 ..................................................................................... 63
8.7 Troubleshooting - Error 02B4..................................................................................... 64
8.8 Troubleshooting - Error 02AB .................................................................................... 65
8.9 Troubleshooting - Error 01AC .................................................................................... 66
8.10 Troubleshooting - No Resistance Issues ................................................................... 67
8.11 Troubleshooting - Heart Rate Issues ......................................................................... 68
8.12 TV Troubleshooting - Seat adjustment issues ........................................................... 69
8.13 TV Troubleshooting - Overview.................................................................................. 70
8.14 TV Troubleshooting - Picture Fuzzy or Unclear......................................................... 71
8.15 TV Troubleshooting - TV Will Not Turn On ................................................................ 72
8.16 TV Troubleshooting - Entertainment Keypad Issues ................................................. 73
CHAPTER 9: PART REPLACEMENT GUIDE
9.1 Console Replacement..................................................................................................... 74
9.2 Handlebar Replacement ................................................................................................ 75
9.3 Cup Holder Replacement .............................................................................................. 76
9.4 Keypad / Overlay Replacement...................................................................................... 77
9.5 Console Mast Replacement............................................................................................ 79
9.6 Seat Pad Replacement................................................................................................... 80
9.7 Back Pad Replacement .................................................................................................. 81
9.8 HR Handlebar Replacement........................................................................................... 82
9.9 HR Grips Replacement................................................................................................... 83
9.10 Upper Seat Frame Replacement ................................................................................... 84
9.11 Lower Seat Frame Replacement.................................................................................... 85
9.12 Seat Adjustment Handle Replacement........................................................................... 87
9.13 Rear Shrouds Replacement .......................................................................................... 88
9.14 Pedal Replacement ........................................................................................................ 89
9.15 Front Shroud Replacement............................................................................................. 90
9.16 Lower Control Board Replacement ................................................................................ 91
9.17 Battery Replacement ...................................................................................................... 92
9.18 Drive Belt Replacement .................................................................................................. 93
9.19 Generator Belt Replacement .......................................................................................... 94
9.20 Generator Replacement.................................................................................................. 95
9.21 Pulley Axle Set Replacement ......................................................................................... 96
9.22 Crank Axle Set Replacement.......................................................................................... 98
9.23 Testing the Bike............................................................................................................... 99
CHAPTER 10: BIKE SPECIFICATIONS AND ASSEMBLY GUIDE
10.1 R7xi-01 Bike Specifications ........................................................................................ 100
10.2 Fasteners and Assembly Tools ................................................................................... 101
10.3 Assembly Instructions ................................................................................................ 102
10.4 Adjusting the Pedal Straps and Seat .......................................................................... 106
10.5 Leveling the Bike......................................................................................................... 107
10.6 TV Programming Instructions ..................................................................................... 108
10.7 Using Update Manager............................................................................................... 114
10.8 Netpulse & AM Setting SOP ...................................................................................... 118
CHAPTER 11: SOFTWARE UPGRADE GUIDE
11.1 Software Upgrade Procedure ..................................................................................... 130
TABLE OF CONTENTS

1
1.1 SERIAL NUMBER LOCATION
A serial number plate is located below the bottom of the console mast beneath a rubber boot. There is also a serial number tag on the middle
of the main frame pointed towards the floor.
CHAPTER 1: SERIAL NUMBER LOCATION

2
CONSOLE SERIAL NUMBER LOCATION
1.1 SERIAL NUMBER LOCATION - CONTINUED
CONSOLE SERIAL NUMBER LOCATION
CHAPTER 1: SERIAL NUMBER LOCATION

3
CAUTION! If you experience chest pains, nausea, dizziness,
or shortness of breath, stop exercising immediately and con-
sult your physician before continuing.
CAUTION! Any changes or modifications to this equipment
could void the product warranty.
2.1 READ AND SAVE THESE INSTRUCTIONS
To ensure your safety and protect the equipment, read all
instructions before operating the MATRIX R7xi Bike.
To ensure proper use of the Matrix R7xi Bike, make sure that all
users read this manual. Remind the users that before undertaking
any fitness program, they should obtain complete physical
examinations from their physicians. If, at any time while exercising,
the user experiences dizziness, pain, or shortness of breath,
nausea or feels faint, he or she must stop immediately.
* This bike is only to be used for its intended purpose described
in this manual. Do not use attachments that have not been recom-
mended by Matrix.
* Never drop or insert objects into any opening. Keep hands away
from moving parts. If the item cannot be reached, contact a Matrix
authorized dealer for assistance.
* Never operate the unit if it is damaged, not working properly, when
it has been dropped, or has been dropped in water.
* Keep hands and feet clear at all times from moving parts to avoid
injury.
* Do not use this product outdoors, near swimming pools or in areas
of high humidity.
* Do not operate where aerosol (spray) products are being used or
when oxygen is being administered.
* Do not use this product in bare feet. Do not wear shoes with heels,
leather soles, cleats, or spikes while exercising.
* Do not remove the side covers. Service should only be done by an
authorized service technician.
* Close supervision is necessary when used near children, invalids,
or disabled people.
* When the bike is in use, young children and pets should be kept at
least 3 meters / 10 feet away.
* Assemble and operate the bike on a solid, level surface.
* Never face backward while using the Matrix R7xi Bike.
* Use the stationary handlebars when mounting or dismounting the
bike.
* Do not wear clothing that might catch on any moving parts of this
bike.
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS

4
2.2 ELECTRICAL REQUIREMENTS
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
DEDICATED CIRCUIT AND ELECTRICAL INFO
A “Dedicated Circuit” means that each outlet you plug into should not have anything else running on that same circuit. The easiest way to verify
this is to locate the main circuit breaker box, and turn off the breaker(s) one at a time. Once a breaker has been turned off, the only thing that
should not have power to it are the units in question. No lamps, vending machines, fans, sound systems, or any other item should lose power
when you perform this test.
Non-looped (isolated) neutral/grounding means that each circuit must have an individual neutral/ground connection coming from it, and
terminating at an approved earth ground. You cannot “jumper” a single neutral/ground from one circuit to the next.
ELECTRICAL REQUIREMENTS
For your safety and to ensure good unit performance, the ground on this circuit must be non-looped (isolated). Please refer to NEC article 210-
21 and 210-23. Any alterations to the standard power cord provided could void all warranties of this product.
The 3x, 5x and 7xe bikes are designed to be self-powered and do not require an external power supply source to operate. Without an external
power supply, the console’s start-up time may be delayed. Add-on TV’s and other console accessories will increase the time needed for start-
up. An external power supply will ensure power is provided to the console at all times and is recommended when add-on accessories are used.
For units with an integrated TV (like the 7xe and 7xi), the TV power requirements are included in the unit. An RG6 coaxial cable with ‘F Type’
compression fittings on each end will need to be connected to the cardio unit and the video source. Additional power requirements are not
needed for the add-on digital TV (3x and 5x). For units with an add-on PCTV (3x and 5x), the TV power requirements are separate.
NOTE: ALL UNITS WITH VIRTUAL ACTIVE™ MUST BE POWERED!
110 V UNITS
All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of a 100-125 V, 60 Hz and a 15 A
“Dedicated Circuit”, with a non-looped (isolated) neutral/ground for power. This outlet should be a
NEMA 5-15R and have the same configuration as the plug. No adapter should be used with this
product. These bikes can be daisy-chained together with up to 4 units per 15 A dedicated circuit.
Matrix daisy-chain cord adapters are sold separately.
220 V UNITS
All Matrix 3x, 5x, 7xe and 7xi 220 V bikes require the use of a 216-250 V, 50 Hz and a 15 A
“Dedicated Circuit”, with a non-looped (isolated) neutral/ground for power. This outlet should be a
NEMA 6-15R and have the same configuration as the plug. No adapter should be used with this
product. These bikes can be daisy-chained together with up to 4 units per 15 A dedicated circuit.
Matrix daisy-chain cord adapters are sold separately.
North American power cord plugs shown.
Depending on your country, the plug type may vary.
GROUNDING INSTRUCTIONS
The unit must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce
the risk of electric shock. The unit is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. If the user does
not follow these grounding instructions, the user could void the Matrix limited warranty.
ADDITIONAL ELECTRICAL INFO
In addition to the dedicated circuit requirement, the proper gauge wire must be used from the circuit breaker box, to each outlet that will have
the maximum number of units running off of it. If the distance from the circuit breaker box to each outlet, is 100 ft (30.5 m) or less, then 12
gauge wire should be used. For distances greater than 100 ft (30.5 m) from the circuit breaker box to the outlet, a 10 gauge wire should be
used.
ENERGY SAVING / LOW-POWER MODE
All units are configured with the ability to enter into an energy saving / low-power mode when the unit has not been in use for a specified period
of time. Additional time may be required to fully reactivate this unit once it has entered the low-power mode. This energy saving feature may be
enabled or disabled from within the ‘Manager Mode’ or ‘Engineering Mode.

5
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 RECOMMENDED CLEANING TIPS
In order to maximize life span, and minimize down time, all Matrix Fitness Equipment requires regularly
scheduled cleaning.
YOU WILL NEED:
- Mild dish soap and water mixture in a spray bottle (10:1 water to soap ratio).
- Lint free 100% cotton cleaning cloths or Microfiber cleaning cloths.
- Vacuum / Shop Vac with extendable hose and soft brush attachment.
- Computer screen or LED / LCD cleaner.
- Corrosion Block (available from Matrix - part # ZMS4001374).
DAILY:
1. Wipe down the unit after each use with a mild dish soap and water mixture. NOTE: Spray the soap / water mixture onto the cloth.
NEVER spray directly onto the equipment. We recommend that you do NOT allow customers to use spray bottles to clean the equipment. If
the cleaner is sprayed directly on the equipment or over spray is present, it may cause your equipment to rust and / or cause damage to con-
sole overlays.
2. With a clean dry 100% lint free cloth and water / soap mixture, wipe any dust or dirt from the out of the seat wheel track (Figure A).
WEEKLY:
1. With a clean dry 100% lint free cloth and water / soap mixture, wipe down the entire frame so it is free of dust, dirt, and sweat.
2. With a clean dry 100% lint free cloth and water / soap mixture, wipe down the entire console area including the hand grips and hand rails.
3. Use a computer screen cleaner or LCD / LED to clean the touch portion of the console (see Section 3.4).
MONTHLY:
1. Vacuum under and around the Bike. If you need to move it, unplug the unit first.
2. Apply Corrosion Block to the metal part of the iPod cable.
DO NOT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems.
MAINTAIN LABELS AND NAMEPLATES. Do not remove labels for any reason. They contain important information. If unreadable or missing,
contact Matrix Fitness Systems for a replacement. 1-866-693-4863, www.matrixfitness.com
MAINTAIN ALL EQUIPMENT Preventative maintenance is the key to smooth operating equipment. Equipment needs to be inspected at regular
intervals. Defective components must be replaced immediately. Improperly working equipment must be kept out of use until it is repaired.
Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so. Matrix Fitness Systems will
provide service and maintenance training at our corporate facility upon request or in the field if proper arrangements are made.
3.2 CHECK FOR DAMAGED PARTS
FIGURE A

6
3.3 CARE AND MAINTENANCE INSTRUCTIONS
CHAPTER 3: PREVENTATIVE MAINTENANCE
In order to maximize life span, and minimize down time, all MATRIX equipment requires regular cleaning, and maintenance items performed on
a scheduled basis. This section contains detailed instructions on how to perform these items and the frequency of which they should be done.
Some basic tools and supplies will be necessary to perform these tasks which include (but may not be limited to):
* Metric Allen wrenches
* #2 Phillips head screwdriver
* Adjustable wrench
* Commercial Pedal wrench (available from Matrix - part # ZMS4001254)
You may periodically see addendums to this document, as the Matrix Technical Support Team identifies items that require specific attention, the
latest version will always be available on the Matrix web site at www.matrixfitness.com.
DAILY MAINTENANCE ITEMS
1) Look and listen for loose fasteners, unusual noises, and any other indications that the equipment may be in need of service.
2) Attempt to wobble the unit from side to side and front to back. Level if needed (see Section 10.5).
WEEKLY MAINTENANCE ITEMS
1) Check the pedal straps for damage.
2) Clean the grooves on the foot pedals.
MONTHLY MAINTENANCE ITEMS
1) Frequently vacuum the floor beneath the unit to prevent the accumulation of dust and dirt which can affect the smooth operation of the unit.
2) Check that the pedal and crank assembly are tight with no free play or wobble in them. Make sure to use a commercial grade pedal wrench to
get the pedals as tight as possible.
3) Check the condition of the seat upholstery. Make sure that the seat adjustment mechanism is operating correctly.
4) Check the seat for looseness. Tighten the seat rollers if needed (see Section 8.13).
YEARLY MAINTENANCE ITEMS
1) Remove the front shrouds and check the belt for damage, alignment, and proper tension.

7
3.4 TOUCH SCREEN CARE & CLEANING
CHAPTER 3: PREVENTATIVE MAINTENANCE
TOUCH SCREEN CARE AND CLEANING
* The touch screen requires very little maintenance. We recommend that you periodically clean the touch screen surface with a clean dry 100%
lint free cloth and water / soap mixture or a computer or LCD / LED screen cleaner.
* It is very important to avoid using any other chemical on the touch screen.
* Always dampen the cloth and clean the screen. Do not spray the water / soap mixture on the screen itself, the drips can seep into the display
or stain the bezel.
* After cleaning, make sure the surface is dry. There should not be any left over solvent to seep into the display.
* It is very important to handle the touch screen with care. Do not use excessive force when cleaning.
* Do not use any sharp materials to clean the touch screen surfaces.
* Do not use high pressure air, water, or steam to clean the touch screen surface.

8
4.1 CONSOLE DESCRIPTION
The R7xi has a fully integrated touch screen display. All information required for workouts is explained on screen. Exploration of the interface is
highly encouraged. The information explaining how to program for various workouts will give an explanation about the contents of each screen.
GO: One touch Start.
STOP: Ends workout and shows workout summary data.
COOL DOWN: (displayed on-screen during workout): Puts unit into Cool Down mode. Cool Down time is dependent on the length of the workout.
Workouts 19 minutes and shorter will have a cool down length of 2 minutes. Workouts 20 minutes and longer will have a cool down length of 5
minutes.
R7XI ENTERTAINMENT ZONE
iPOD®: Will take the user directly to the iPod screen to allow for iPod control and playlist selection.
VOLUME UP / DOWN: Adjusts the volume output through the headphone jack of the integrated console TV or iPod output.
NUMBER KEYPAD: Allows for easy TV channel selections.
CHANNEL UP / DOWN: Allows for channel selection.
DISPLAY MODE: Allows user to cycle through console display options, iPod, TV, or profile display.
LAST CHANNEL: Allows the user to cycle between the current channel and the previous channel viewed.
CC/MUTE: Mutes sound and turns closed captioning on or off.
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION

9
4.2 WORKOUT SETUP STEPS
To set up a workout, press the touch screen over the program you would like to use and then follow the prompts to begin your workout.
GO - Press to immediately begin a workout. Workout, resistance level, and time will automatically go to default settings. Pressing GO will not
prompt user for age, weight, or level settings.
MANUAL - Manual allows the user to input more information while defining their own workout. Calorie expenditure will be more accurate when
inputting information in Manual than by pressing GO.
FAT BURN - Fat burn is a level based program that is designed to help users burn fat through various resistance level changes.
ROLLING HILLS - The Rolling Hills program is a level based program that automatically adjusts the resistance level to simulate real terrain.
INTERVALS - The Intervals program is a level based program that automatically adjusts the resistance of the machine from low to high
intensity settings at regular intervals.
RANDOM - Random is a level based workout that randomly adjusts the resistance of the machine.
TARGET HEART RATE - The Matrix R7xi bike comes with standard digital contact heart rate sensors and are POLAR telemetry compatible.
The heart rate control workout mode allows the user to program their desired heart rate zone, and the bike will automatically adjust the level based
upon the user's heart rate. The heart rate zone is calculated using the following equation: (220-Age)8%=target heart rate zone. The user must
wear a POLAR telemetric strap or continually hold onto the contact heart rate grips for this workout.
Locate the metal sensors on the handlebars of the bike. Notice that there are two separate pieces of metal on each grip. You must be making
contact with both pieces of each grip to get an accurate heart rate reading. You can grab these sensors in any program to view your current heart
rate.
FITNESS TEST -The Cooper Fitness Test measures cardiovascular fitness and proves an estimated sub-maximal VO2 result. It is based on
power output according to ACSM standards and was developed by the Cooper Institute© (www.cooperinstitute.org). User RPMs must remain
between 60-80 RPM during the test. The test will end when the user can no longer maintain this speed. Use of a heart rate strap is optional but
provides more data.
The test starts at a low intensity level and gradually increases in intensity (difficulty) every 2 minutes. As it increases, the user must maintain
60-80 RPM to advance to the next level. The test could take upwards of 30+ minutes for very fit individuals. Once the test ends a recovery period
(cool down) will begin and the user's results are calculated and displayed. Results are based on the number of stages completed. Incline will not
be adjustable during the test.
STAGE COMPLETE:
1 Well Below Average
2 Well Below Average
3 Below Average
4 Below Average
5 Average
6 Average
7 Above Average
8 Above Average
9+ Well Above Average
CONSTANT WATTS - Constant Watts is a unique program that allows you to vary your cadence or RPM and the bike's resistance level will
adjust accordingly to your selected goal. The quicker you pedal, the less resistance for the goal selected.
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION

10
1) To enter Manager Mode, press "ENTER, 1, 0, 0, 1, ENTER" on the number keypad and Manager Mode will appear on the display.
2) Manager Mode is divided into 9 tabs, located on the left side of the screen. They are General, Workout, Setup Defaults, Asset Management,
Weather, TV, Applications, Hardware and Service.
3) Choose a tab by touching the screen over the desired tab.
4) Each of the tabs has options that will appear once you have chosen that particular tab.
5) Press the "HOME" button or the EMERGENCY STOP to exit Manager Mode..
5.1 USING MANAGER MODE
CHAPTER 5: MANAGER MODE

11
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Accumulated Time Total time on the unit since production. Cannot be modified.
Accumulated Distance Total distance on the unit since production. Cannot be modified.
Serial Number - Console This option displays the serial number of the console, not
editable (see Service Mode to change serial numbers).
Cannot be modified.
Serial Number - Frame This option displays the serial number of the platform, not
editable (see Service Mode to change serial numbers).
Cannot be modified.
MANAGER MODE
General
5.2 MANAGER MODE – GENERAL – TAB 1
CHAPTER 5: MANAGER MODE

12
CHAPTER 6: MANAGER MODE
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Date & Time This option sets the current date and time of the machine. N/A
MANAGER MODE
General
5.2 MANAGER MODE - GENERAL – TAB 2
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Screen Timeout This option sets the machine show the
workout time of the machine.
Maximum: 120 sec
Maximum: 15 sec
Software Versions Software versions. Cannot be modified.
MANAGER MODE
General
5.2 MANAGER MODE - GENERAL – TAB 3

13
CHAPTER 5: MANAGER MODE
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Language Setup Sets the language used on the console. English (US), English (UK),
German, French, Italian,
Spanish, Dutch, Portuguese,
Korean, Israeli, Swiss, Russian,
Finnish, Taiwanese, Chinese, or
Japanese.
MANAGER MODE
General
5.2 MANAGER MODE – GENERAL – TAB 4

14
5.3 MANAGER MODE - WORKOUT – TAB 1
CHAPTER 5: MANAGER MODE
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Maximum Workout Time This option allows the club to set the
maximum workout duration limits during
peak and non peak hours.
Maximum: 120 Minutes
Minimum: 10 Minutes
Maximum Workout Calories This option allows the club to set the
maximum workout duration limits during
peak and non peak hours.
Maximum: 10000
Minimum: 50
Maximum Workout Distance This option allows the club to set the
maximum workout duration limits during
peak and non peak hours.
Maximum: 31.1 mi
Minimum: 0.1 mi
Pause Time This option controls the default pause time. Maximum: 10 Minutes
Minimum: 1 Minutes
Max Level This option controls the default program
level.
Maximum: 25
Minimum: 1
Min Cooldown Time This option allows the club to set the
minimum cool down duration limits during
peak and non peak hours.
Maximum: 5 Minutes
Minimum: 1 Minutes
MANAGER MODE
Workout

15
5.3 MANAGER MODE - WORKOUT – TAB 2
CHAPTER 5: MANAGER MODE
MANAGER MODE
Workout
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Max Cooldown Time This option allows the club to set the
maximum cool down duration limits during
peak and non peak hours.
Maximum: 10 Minutes
Minimum: 5 Minutes
Max Cooldown Adjustment Time This option allows the club to set the
maximum cool down adjustment time
duration limits during peak and non peak
hours.
Maximum: 20 Minutes
Minimum: 5 Minutes

16
5.4 MANAGER MODE - SETUP DEFAULTS – TAB 1
CHAPTER 5: MANAGER MODE
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Level This option controls the default program
levels.
Maximum: 20
Minimum: 1
Age This option controls the default user's age
used in the target heart rate calculations.
Maximum: 99
Minimum: 10
Weight This option controls the default weight
used in the calorie calculations. Displayed
in native units (pounds or kilograms).
79~401 lbs
Gender This option sets the user's gender as
either male or female.
Male or Female
Default Workout Time This option controls the default program
time.
Maximum: 60
Minimum: 5
Default Workout Calories This option controls the default program
calories.
Maximum: 5000
Minimum: 50
MANAGER MODE
Setup Defaults

17
5.4 MANAGER MODE - SETUP DEFAULTS – TAB 2
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Default Workout Distance This option controls the default program
Distance.
Maximum: 12.4
Minimum: 0.1
Default Web Brower Page This option controls the default machine Web
Brower Page.
N/A
Show Sliders In Workout This option controls the default Sliders bar of
True or False.
True or False
MANAGER MODE
Setup Defaults
CHAPTER 5: MANAGER MODE
