Matrix 2016 3x console User manual

2016 3X CONSOLE
SERVICE MANUAL

CHAPTER 1: SERIAL NUMBER LOCATION ........................................................... 1
CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS
2.1 Electrical Requirements ............................................................................................. 2
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 Recommended Cleaning Tips .................................................................................... 3
3.2 Check for Damaged Parts ......................................................................................... 3
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.1 Console Description .................................................................................................. 4
4.2 Workout Setup Steps - Manual.................................................................................. 5
4.3 Workout Setup Steps - Level based programs.......................................................... 5
4.4 Workout Setup Steps - Fitness Test........................................................................... 6
4.5 Workout Setup Steps - Target Heart Rate ................................................................. 8
4.6 Workout Setup Steps - Constant Watts ..................................................................... 8
4.7 Workout Tracking Instructions.................................................................................... 8
4.8 USB Charging Instructions......................................................................................... 8
CHAPTER 5: MANAGER MODE
5.1 Manager Mode Overview ........................................................................................... 9
CHAPTER 6: ENGINEERING MODE
6.1 Engineering Mode Overview ...................................................................................... 12
CHAPTER 7: SERVICE MODE / TEST MODE
7.1 Service Mode Overview ............................................................................................. 13
7.2 Test Mode Overview................................................................................................... 14
CHAPTER 8: TROUBLESHOOTING
8.1 Electrical Diagram ...................................................................................................... 15
8.2 Error Codes List .......................................................................................................... 24
CHAPTER 9: PARTS REPLACEMENT GUIDE
9.1 Console Replacement..................................................................................................... 29
9.2 Handlebar Replacement ................................................................................................ 30
9.3 Testing the Unit ............................................................................................................... 34
CHAPTER 10: SPECIFICATIONS AND ASSEMBLY GUIDE
10.1 WiFi installation .............................................................................................................. 35
10.2 HURESA3X MYE TV Bracket Installation................................................................... 43
10.3 C3X MYE TV Bracket Installation ............................................................................... 47
10.4 Club Logo Installation ................................................................................................. 51
10.5 RF900/863 Receiver Installation................................................................................. 53
CHAPTER 11: SOFTWARE UPGRADE GUIDE
11.1 Software Upgrade Instructions for UCB...................................................................... 58
11.2 Software Upgrade Instructions for LCB ...................................................................... 59
TABLE OF CONTENTS

1
1.1 SERIAL NUMBER LOCATION
CHAPTER 1: SERIAL NUMBER LOCATION
CONSOLE SERIAL NUMBER LOCATION
SERIAL NUMBER LOCATION

2
CHAPTER 2: IMPORTANT SAFETY INFORMATION
2.1 ELECTRICAL REQUIREMENTS
DEDICATED CIRCUIT AND ELECTRICAL INFO
A “Dedicated Circuit” means that each outlet you plug into should not have anything else running on that same circuit. The easiest way to verify
this is to locate the main circuit breaker box, and turn off the breaker(s) one at a time. Once a breaker has been turned off, the only thing that
should not have power to it are the units in question. No lamps, vending machines, fans, sound systems, or any other item should lose power
when you perform this test. Non-looped (isolated) neutral/grounding means that each circuit must have an individual neutral/ground connection
coming from it, and terminating at an approved earth ground. You cannot “jumper” a single neutral/ground from one circuit to the next.
ELECTRICAL REQUIREMENTS
For your safety and to ensure good unit performance, the ground on this circuit must be non-looped (isolated). Please refer to NEC article 210-21
and 210-23. Any alterations to the standard power cord provided could void all warranties of this product.
The 3x, 5x and 7xe bikes are designed to be self-powered and do not require an external power supply source to operate. Without an external
power supply, the console’s start-up time may be delayed. Add-on TV’s and other console accessories will increase the time needed for start-up.
An external power supply will ensure power is provided to the console at all times and is recommended when add-on accessories are used.
For units with an integrated TV (like the 7xe and 7xi), the TV power requirements are included in the unit. An RG6 coaxial cable with ‘F Type’
compression fittings on each end will need to be connected to the cardio unit and the video source. Additional power requirements are not needed
for the add-on digital TV (3x and 5x). For units with an add-on PCTV (3x and 5x), the TV power requirements are separate.
NOTE: ALL UNITS WITH VIRTUAL ACTIVE™ MUST BE POWERED!
110 V UNITS
All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of a 100-125 V, 60 Hz and a 15 A
“Dedicated Circuit”, with a non-looped (isolated) neutral/ground for power. This outlet should be a
NEMA 5-15R and have the same configuration as the plug. No adapter should be used with this
product. These bikes can be daisy-chained together with up to 4 units per 15 A dedicated circuit.
Matrix daisy-chain cord adapters are sold separately.
220 V UNITS
All Matrix 3x, 5x, 7xe and 7xi 220 V bikes require the use of a 216-250 V, 50 Hz and a 15 A
“Dedicated Circuit”, with a non-looped (isolated) neutral/ground for power. This outlet should be a
NEMA 6-15R and have the same configuration as the plug. No adapter should be used with this
product. These bikes can be daisy-chained together with up to 4 units per 15 A dedicated circuit.
Matrix daisy-chain cord adapters are sold separately.
North American power cord plugs shown.
Depending on your country, the plug type may vary.
220 NEMA 6-15P
PLUG
110 NEMA 5-15P
PLUG
GROUNDING INSTRUCTIONS
The unit must be grounded. If it should malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. The unit is equipped with a cord having an equipment-grounding conduc-
tor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances. If the user does not follow these grounding instructions, the user could void the Matrix limited warranty.
ADDITIONAL ELECTRICAL INFO
In addition to the dedicated circuit requirement, the proper gauge wire must be used from the circuit breaker box, to each outlet that will have the
maximum number of units running off of it. If the distance from the circuit breaker box to each outlet, is 100 ft (30.5 m) or less, then 12 gauge wire
should be used. For distances greater than 100 ft (30.5 m) from the circuit breaker box to the outlet, a 10 gauge wire should be used.
ENERGY SAVING / LOW-POWER MODE
All units are configured with the ability to enter into an energy saving / low-power mode when the unit has not been in use for a specified period
of time. Additional time may be required to fully reactivate this unit once it has entered the low-power mode. This energy saving feature may be
enabled or disabled from within the ‘Manager Mode’ or ‘Engineering Mode.
ADD-ON PCTV (3X AND 5X)
A 15 A or 20 A “Dedicated Circuit” with a non-looped (isolated) neutral/ground is required. Each PCTV requires at least 1.2 A of current. No more
than 12 PCTVs should be used for each 15 A circuit and no more than 16 PCTVs should be used for each 20 A circuit. The power outlet should
have the same configuration as the plug. No adapter should be used with this product. An RG6 coaxial cable with ‘F Type’ compression fittings
will need to be connected between the video source and each add-on PCTV unit. See the PCTV Manual for web connection requirements.
ADD-ON DIGITAL TV (3X AND 5X)
Additional power requirements are not needed for the add-on digital TV. An RG6 coaxial cable with ‘F Type’ compression fittings will need to be
connected between the video source and each add-on digital TV unit.
BATTERY CHARGING (3X AND 5X)
The bike saves its batter charge by moving into a shutdown mode whenever PEDAL FASTER appears on the display. If the user does not
maintain a pedal rate of 40 RPM or higher, a 30 second shutdown process begins. When the battery voltage is low, LOW BATTERY appears
on the display. This means it is time to recharge the battery. If the battery must be charged, use the optional power adapter charging unit. The
charger should be connected to the bike for a minimum of eight hours to ensure a thorough charge.

3
CHAPTER 3: PREVENTATIVE MAINTENANCE
3.1 RECOMMENDED CLEANING TIPS
DO NOT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems.
MAINTAIN LABELS AND NAMEPLATES. Do not remove labels for any reason. They contain important information. If unreadable or missing,
contact Matrix Fitness Systems for a replacement. 1-866-693-4863, www.matrixfitness.com
MAINTAIN ALL EQUIPMENT Preventative maintenance is the key to smooth operating equipment. Equipment needs to be inspected at regular
intervals. Defective components must be replaced immediately. Improperly working equipment must be kept out of use until it is repaired.
Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so. Matrix Fitness Systems will
provide service and maintenance training at our corporate facility upon request or in the field if proper arrangements are made.
3.2 CHECK FOR DAMAGED PARTS
In order to maximize life span, and minimize down time, all Matrix Fitness Equipment requires regularly
scheduled cleaning.
YOU WILL NEED:
- Mild dish soap and water mixture in a spray bottle (per manufacturers recommend ratio).
- Lint free 100% cotton cleaning cloths or Microfiber cleaning cloths.
DAILY:
1. Wipe down the unit after each use with a mild dish soap and water mixture. NOTE: Spray the soap/water mixture onto the cloth. NEVER
spray directly onto the equipment. We recommend that you do NOT allow customers to use spray bottles to clean the equipment. If the
cleaner is sprayed directly on the equipment or overspray is present, it may cause your equipment to rust and/or cause damage to console
overlays.
WEEKLY:
1. With a clean dry 100% lint free cloth and water/soap mixture, wipe down the entire console area including the hand grips and hand rails.

4
4.1 CONSOLE DESCRIPTION
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
e.g. A3X CONSOLE SHOWN
3X CONSOLE DESCRIPTION
The Matrix machine is inspected before it is packaged. It is shipped in
two pieces: the base and the console. Carefully unpack the unit and
dispose of the box material. Note: There is a thin protective sheet of
clear plastic on the overlay of the console that should be removed
before use.
A) WORKOUT KEYS: Simple program view and selection buttons.
B) GO: One Touch Start.
C) ENTER : Confirm each program setting.
D) BACK: Go to previous program setting.
E) NUMBER KEYPAD: Enter program settings.
F) UP/DOWN LEVEL: Adjust resistance level.
G) UP/DOWN INCLINE (A3X ONLY): Adjust incline level.
H) UP/DOWN TIME: Adjust workout time.
I) STOP: Ends workout and shows workout summary data.
J) COOL DOWN: Puts the console into Cool Down mode.
K) TOGGLE DISPLAY: Cycles between 3 or 4 rows of workout
information displayed in LED window. The console will
automatically cycle between the workout information if the
Toggle Display button is pushed and held down for 3 seconds.
ENTERTAINMENT BUTTONS
L) TV POWER: Turns connected TV on or off.
M) VOLUME UP/DOWN: Adjusts the volume output through
headphones.
N) MUTE: Mutes sound.
O) CC: Turns closed captioning on or off.
P) CHANNEL UP/DOWN: Change channels on the integrated
console TV.
Q) LAST CHANNEL: Cycle between the current channel and the
previous channel.
E) NUMBER KEYPAD: Enter channel number. Press to
confirm channel number.
A
G
AE HK
FPM
N
J
Q
I
O L
B
D C

5
4.2 WORKOUT SETUP STEPS - MANUAL 4.3 WORKOUT SETUP STEPS - LEVEL BASED PROGRAMS - CONTINUED
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
GO - Press to immediately begin a workout. Workout, resistance
level, and time will automatically go to default settings. Pressing
GO will not prompt user for age, weight, or level settings.
1) Start pedaling and press the GO key to begin your workout.
2) The display will read 3, 2, 1, Begin and then the program will
start.
MANUAL - Manual allows the user to input more information
while defining their own workout. Calorie expenditure will be more
accurate when inputting information in Manual than by pressing GO.
1) Start pedaling, press the MANUAL key. Then press ENTER.
2) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
3) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
5) Press GO, and then the display will read 3, 2, 1, Begin and then
the program will start.
FAT BURN - Fat burn is a level based program that is designed
to help users burn fat through various resistance level changes.
1) Start pedaling and press the Training Workouts. Then press
ENTER.
2) Select FAT BURN by using the UP or DOWN LEVEL keys and
press ENTER.
3) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
5) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
6) Press GO, then the display will read 3, 2, 1, Begin and then the
program will start.
4.3 WORKOUT SETUP STEPS - LEVEL BASED PROGRAMS
INTERVAL TRAINING - The Interval Training program is a
level based program that automatically adjusts the resistance of the
machine from low to high intensity settings at regular intervals.
1) Start pedaling and press the Training Workouts. Then press
ENTER.
2) Select Intervals by using the UP or DOWN LEVEL keys and
press ENTER.
3) Select Level by using the UP or DOWN LEVEL keys and press
ENTER.
4) Select Time by using the UP or DOWN LEVEL keys and press
ENTER.
5) Select Weight by using the UP or DOWN LEVEL keys and press
ENTER.
6) Press GO then the display will read 3, 2, 1, Begin and then the
program will start.

6
4.4 WORKOUT SETUP STEPS - FITNESS TEST
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
-- Below for HURESA3x only
FITNESS TEST -The Cooper Fitness Test measures cardiovascular fitness and proves an estimated sub-maximal VO2 result. It is based
on power output according to ACSM standards and was developed by the Cooper Institute© (www.cooperinstitute.org). User RPMs must
remain between 60-80 RPM during the test. The test will end when the user can no longer maintain this speed. Use of a heart rate strap is
optional but provides more data.
The test starts at a low intensity level and gradually increases in intensity (difficulty) every 2 minutes. As it increases, the user must maintain
60-80 RPM to advance to the next level. The test could take upwards of 30+ minutes for very fit individuals. Once the test ends a recovery
period (cool down) will begin and the user's results are calculated and displayed. Results are based on the number of stages completed.
Incline will not be adjustable during the test.
1) Start pedaling and press the FITNESS TEST key. Then press ENTER.
2) Select Age by using the UP or DOWN LEVEL keys and press ENTER.
3) Select Gender by using the UP or DOWN LEVEL keys and press ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press ENTER.
5) Press GO, then the display will read 3, 2, 1, Begin and then the program will start.
6) Once the workout is complete, the display will read the results of the Fitness Test.
STAGES COMPLETED:
1 Well Below Average
2 Well Below Average
3 Below Average
4 Below Average
5 Average
6 Average
7 Above Average
8 Above Average
9+ Well Above Average

7
4.4 WORKOUT SETUP STEPS - FITNESS TEST - CONTINUED
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
-- Below for C3x only
FITNESS TEST (WFI) - The WFI (Wellness Fitness Initiative) protocol is a test used by firefighters in a series of intervals lasting a
maximum of 16 minutes, where the speed is increased every minute until the Target Heart Rate is exceeded for 15 seconds. When the test
is complete, the display provides a summary of VO2max, Highest SPM, Elapsed Time, and Target Heart Rate. The test requires constant
monitoring of the user's heart rate, so the use of a telemetric heart rate strap is highly recommended.
CPAT
The Candidate Physical Ability Test (CPAT) is a new minimum requirement for the position of Firefighter. The job of a Firefighter is one of
the most physically demanding jobs in North America. Participants wear a 50-pound (22.68-kg) vest to simulate the weight of self-contained
breathing apparatus (SCBA) and firefighter protective clothing. An additional 25 pounds (11.34 kg), using two 12.5-pound (5.67-kg) weights that
simulate a high-rise pack (hose bundle), is added to your shoulders for the stair climb event. The candidate must maintain 60 SPM (steps per
minute) for 3 minutes.
FITNESS TEST (SUBMAXIMAL) - The Submaximal test measures cardiovascular fitness and provides an estimated Sub-maximal
VO2 max result. This assessment is a 4 stage test lasting 3-5 minutes where the speed is increased until your Heart Rate is between 115 - 150
bpm for 2 of the stages. When the test is complete, a Fitness Rating is displayed as High, Good, Average, Fair, or Low along with your age and
VO2 max. The test requires constant monitoring of the user's heart rate, so the use of a telemetric heart rate strap is highly recommended.
1) Start pedaling and press the FITNESS TEST key. Then press ENTER.
2) Select Age by using the UP or DOWN LEVEL keys and press ENTER.
3) Select Gender by using the UP or DOWN LEVEL keys and press ENTER.
4) Select Weight by using the UP or DOWN LEVEL keys and press ENTER.
5) Press GO, then the display will read 3, 2, 1, Begin and then the program will start.
6) Once the workout is complete, the display will read the results of the Fitness Test.
FITNESS RATING NORMS (V02 MAX)
AGE 20-29 30-39 40-49 50-59 60+
MEN
HIGH 51.4+ 50.4+ 48.2+ 45.3 42.5+
GOOD 51.3-46.8 50.3-44.6 48.1-41.8 45.2-38.5 42.4-35.3
AVERAGE 46.7-42.5 44.5-41.0 41.7-38.1 38.4-35.2 35.2-31.8
FAIR 42.4-39.5 40.9-37.4 38.0-35.1 35.1-32.3 31.7-28.7
LOW 39.4 OR
LESS
37.3 OR
LESS
35.0 OR
LESS
32.2 OR
LESS
28.6 OR
LESS
WOMEN
HIGH 44.2+ 41.0+ 39.5+ 35.2+ 35.2
GOOD 44.1-38.1 40.9-36.7 39.4-33.8 35.1-30.9 35.1-29.4
AVERAGE 38.0-35.2 36.6-33.8 33.7-30.9 30.8-28.2 29.3-25.8
FAIR 35.1-32.3 33.7-30.5 30.8-28.3 28.1-25.5 25.7-23.8
LOW 32.2 OR
LESS
30.4 OR
LESS
28.2 OR
LESS
25.4 OR
LESS
23.7 OR
LESS

8
4.5 WORKOUT SETUP STEPS - TARGET HEART RATE
4.6 WORKOUT SETUP STEPS - CONSTANT WATTS
TARGET HEART RATE - The Matrix H5x-05 Bike comes with
standard digital contact heart rate sensors and are POLAR telemetry
compatible. The heart rate control workout mode allows the user to
program their desired heart rate zone, and the bike will automatically
adjust the level based upon the user's heart rate. The heart rate
zone is calculated using the following equation: (220-Age)8%=target
heart rate zone. The user must wear a POLAR telemetric strap or
continually hold onto the contact heart rate grips for this workout.
Locate the metal sensors on the handlebars of the bike. Notice
that there are two separate pieces of metal on each grip. You must
be making contact with both pieces of each grip to get an accurate
heart rate reading. You can grab these sensors in any program to
view your current heart rate.
1) Start pedaling and press the HEART RATE key. Then press
ENTER.
2) Select Age by using the UP or DOWN LEVEL keys and press
SELECT.
3) Select Target HR Percentage by using the UP or DOWN LEVEL
keys and press SELECT.
4) Select Time by using the UP or DOWN LEVEL keys and press
SELECT.
5) Select Weight by using the UP or DOWN LEVEL keys and press
SELECT.
6) Press GO, then the display will read 3, 2, 1, Begin and the
program will start.
CONSTANT WATTS - Constant Watts is a unique program
that allows you to vary your cadence or RPM and the bike's
resistance level will adjust accordingly to your selected goal. The
quicker you pedal, the less resistance for the goal selected.
1) Start pedaling and press the CONSTANT WATTS key. Then
press ENTER.
2) Select Watts by using the UP or DOWN LEVEL keys and press
SELECT.
3) Select Time by using the UP or DOWN LEVEL keys and press
SELECT.
4) Select Weight by using the UP or DOWN LEVEL keys and
press SELECT.
5) Press GO, then the display will read 3, 2, 1, Begin and the
program will start.
CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.7 WORKOUT TRACKING INSTRUCTIONS
3x consoles equipped with xID workout tracking allow users to
login and record their workouts by entering their xID and 4-digit
passcode.
4.8 USB CHARGING INSTRUCTIONS
The USB port on the 3x console now supports device charging.

9
CHAPTER 5: MANAGER MODE
5.1 MANAGER MODE OVERVIEW
1) To enter Manager Mode, press number key "ENTER, 1, 0, 0, 1, ENTER" on the number keypad. Manager Mode will appear on the display.
2) To scroll through the list of options in Manager Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the display.
3) To select a custom setting, press the ENTER key when the desired setting is shown.
4) To change the value of the setting, use the UP and DOWN LEVEL keys.
5) To confirm and save the value of the setting, press the ENTER key.
6) To exit the setting without saving, press the BACK key.
7) Press and hold the STOP key for 3-5 seconds to return to normal operation.
Group Model Item1 Item2 Default
Value
Values/Range Unit Notes
Workouts HURESAC Maximum
Time
60 4~99 Minutes Sets the total run time of any program.
HURESAC Default Time 20 4~MAX Minutes Workout time when GO is pressed or when no time is
selected during program set up.
HURESAC Default Level 1 1~10 Starting resistance when GO is pressed or when no
resistance is selected during program set up.
HURESAC Pause Time 5:00 0:30/1:00/2:00/
3:00/4:00/5:00
Minutes :
Second
This option controls the default pause time.
C Maximum
Level
20 10~25 Set the level which is the max usable speed.
User HURESAC Age 30 10-100 This option controls the default user's age.
HURESAC Weight 150lb/
68kg
50lb/23kg ~
400lb/182kg
This option controls the default weight.
HURESAC Default
Height
72/ 83 36/91~96/244 Default height of user.
HURESAC Gender Male Male/Femal Determines the gender of the user when not selected
during program set up.
Data &
Time
HURESAC Data 2015/01/01 This option sets the current date of the machine.
HURESAC Time RTC time This option sets the current time of the machine.
HURESAC Time Zone 21 1~78 This option sets the time zone (See Table 1).
Speed HURESAC Unit Standard Standard/Metric This option sets speed unit is standard (Mile) or
Metric.
Software HURESAC Version UCB Current software version of UCB.
LCB-MCUB Current software version of LCB-MCUB.
LCB-MCUA
(option)
Current software version of LCB-MCUA.
Language Sets the language for the console.
WiFi Current software version of WiFi.
Bootloader Current software version of bootloader.
HURESAC Update UCB UCB software update.
LCB-MCUB LCB-MCUB software update.
LCB-MCUA
(option)
LCB-MCUA software update.
Language Language software update.
HURESAC Auto Update Disable/
Enable
Enable This option controls the auto software update function
is Disabled or Enabled.
Time 1:00 AM HH:MM Automatically software updated time.
Check
Update
Manually check remote update. Auto updating console
software from DAPI if it has the latest version.
General HUREA Accumulate
Distance
0 0~999999 Mile/Km Total distance for all programs. Hold UP and DOWN
LEVEL keys for 3 seconds to clear record.
HURESAC Accumulate
Time
0 0~999999 Hours Total time for all programs displayed in hours.Hold
UP and DOWN LEVEL keys for 3 seconds to clear
record.
SC Accumulate
Floors
0 0~999999 Floors Total floors for all programs. Hold UP and DOWN
LEVEL keys for 3 seconds to clear record.

10
CHAPTER 5: MANAGER MODE
5.1 MANAGER MODE OVERVIEW - CONTINUED
Group Model Item1 Item2 Default Value Values/Range Unit Notes
Language HURESAC Default
Language
English Sets the language for the console. Select
between English, Spanish, German, Italian,
French, Dutch, Portuguese Swedish, Finnish,
Turkish and Polish.
HURESAC Erase EEPROM Erase language data in EEPROM.
Logo HURESAC Default Logo Matrix This option allows the user to select the
screen header from a list..
HURESAC Import Logo Import logo from USB to console.
HURESAC Erase EEPROM Erase all logo data in EEPROM
Machine HURESAC Type This option selects the current model.
HURESAC Serial Number Console Prefix+(Type)
+YYMM00000
YY-MM-xxxxx Serial Number input is available for both the
Console and Frame.
Type: B~Z (A not display).
Frame Prefix+(Type)
+YYMM00000
YY-MM-xxxxx
HURESAC Out of Order OFF ON/OFF This option allows the club to show the unit "out
of order" if an error is present.
HURESAC Beeper ON ON/OFF Sets console beeper sound on / off.
HURESAC Headphone Jack Notification Enable Enable/Disable This option controls the headphone Jack insertion
times warning function is disabled or enabled.
Times to
waring
30000 1000~1000000 This option controls the headphone Jack insertion
times warning function is disabled or enabled.
HURESAC USB Port Protection Enable Enable/Disable This option controls the USB port protection is
disabled or enabled.
HURESAC Keypad Stuck
Check
Enable Enable/Disable This option controls the keypad stuck check is
disabled or enabled.
Notification Enable Enable/Disable This option controls the Keypad/overlay error
notification is disabled or enabled.
TV HURESAC Power OFF ON/OFF OFF: Turn off TV power after reset
ON: Don't turn off TV power after reset
HURESAC Input Source OFF OFF/TV/PCTV/
Remote TV/CAB
Sets the audio of the console to the type of TV
attached.
HURESAC Default Volume a. input default (DF: 15/Range1~15)
b. Max (DF: 32/ Range: 1~32)
c. Output Default (DF: 13/Range:1~Max)
Remote TV support a/b/c item, others only
support c.
Internet HURESAC Enable/Disable Sets the internet function (WiFi) is disabled or
enabled.
HURESAC MAC ID MAC ID data.
HURESAC IP Automatically detects the available IP address
and displays it.
HURESAC AP MODE OFF ON/OFF Sets console wireless module is an access
point (AP) or not.
HURESAC Signal Strength (Current Status) Disconnected/25%
/50%/75%/100%
This option shows the current WiFi signal
strength.
HURESAC Export setting Export internet setting (Wifi) to USB.
HURESAC Import setting Import internet (Wifi) setting from USB.
HURESAC Reset Reset internet connected data. SSID/password
Factory Default Restore.
ErP HURESAC Erp Time OFF OFF~ 30
(Minutes)
Minute Console will enter ErP mode if user does not
touch the screen or press any key pad for couple
minutes.

11
CHAPTER 5: MANAGER MODE
5.1 MANAGER MODE OVERVIEW - CONTINUED
Time Zone
Country Code Country Code Country Code Country Code
Asia/Kabul 1 America/Chicago 21 Asia/Jerusalem 41 Pacific/Apia 61
America/Anchorage 2 America/Monterrey 22 Asia/Seoul 42 Asia/Bangkok 62
Asia/Kuwait 3 Asia/Shanghai 23 Atlantic/South Georgia 43 Asia/Singapore 63
Asia/Muscat 4 Africa/Nairobi 24 America/Denver 44 Africa/Harare 64
Asia/Baghdad 5 Australia/Brisbane 25 America/Chihuahua 45 Asia/Colombo 65
America/Halifax 6 Europe/Minsk 26 Asia/Rangoon 46 Asia/Taipei 66
Australia/Darwin 7 America/Sao Paulo 27 Asia/Novosibirsk 47 Australia/Hobart 67
Australia/Sydney 8 America/New York 28 Africa/Windhoek 48 Asia/Tokyo 68
Asia/Baku 9 Africa/Cairo 29 Asia/Kathmandu 49 Pacific/Tongatapu 69
Atlantic/Azores 10 Asia/Yekaterinburg 30 Pacific/Auckland 50 America/Indianapolis 70
America/Edmonton 11 Pacific/Fiji 31 America/St Johns 51 America/Phoenix 71
Atlantic/Cape Verde 12 Europe/Riga 32 Asia/Irkutsk 52 Asia/Vladivostok 72
Asia/Yerevan 13 Asia/Tbilisi 33 Asia/Krasnoyarsk 53 Australia/Perth 73
Australia/Adelaide 14 Europe/London 34 America/Santiago 54 Africa/Lagos 74
America/Costa Rica 15 America/Godthab 35 America/Tijuana 55 Europe/Berlin 75
Asia/Almaty 16 Africa/Monrovia 36 Europe/Paris 56 Asia/Tashkent 76
America/Cuiaba 17 Europe/Istanbul 37 Europe/Moscow 57 Pacific/Guam 77
Europe/Belgrade 18 Pacific/Honolulu 38 America/Argentina/Buenos Aires 58 Asia/Yakutsk 78
Europe/Belgrade 19 Asia/Calcutta 39 America/Bogota 59
Pacific/Guadalcanal 20 Asia/Tehran 40 America/La Paz 60
Table 1 - Time Zone list

12
6.1 ENGINEERING MODE OVERVIEW
CHAPTER 6: ENGINEERING MODE
1) To enter Engineering Mode, press number key "ENTER, 2, 0, 0, 1, ENTER" on the number keypad. Engineer Mode will appear on the
display.
2) To scroll through the list of options in Engineering Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the
display.
3) To select a custom setting, press the ENTER key when the desired setting is shown.
4) To change the value of the setting, use the UP and DOWN LEVEL keys.
5) To confirm and save the value of the setting, press the ENTER key.
6) To exit the setting without saving, press the BACK key.
7) Press and hold the STOP key for 3-5 seconds to return to normal operation.
Group Model Item1 Item2 Default
Value
Values/Range Unit Notes
Error Codes HURESAC Disable/Enable Enable Disable/Enable This option displays the error code history
on the unit.
DAPI HURESAC Server Production Dev/QA/Staging/
Production
Minutes :
Second
Dev
unsecure domain: dev.dls.jfit.co port: 80
SSL domain: dev-dls.jfit.co port: 443
QA
unsecure domain: qa.dls.jfit.co port: 80
SSL domain: qa-dls.jfit.co port 443
Staging
unsecure domain: staging.dls.jfit.co port: 80
SSL domain: staging-dls.jfit.co port 443
Production
unsecure domain: dapi-ls.jfit.co port: 80
SSL domain: dapi-ls.jfit.co port: 443
SSL ON ON/OFF This option controls the internet
transmission with SSL (Secure Sockets
Layer) or not.
Calibration A Auto
Calibration
This option is to calibrate the elevation
parameters.
AElevation Tuner Original Incline Tuner of A5x
Safety C Setting 100 4~500 The acting speed adjusted of old control
zone (capacitance sensor).
C Switch ON->5X,
OFF->3X
ON/OFF The function of control zone is enabled or
disabled.
Software HURESAC Back Up To backup current software into EEPROM.
Recovery To recover software from EEPROM.

13
7.1 SERVICE MODE OVERVIEW
CHAPTER 7: SERVICE MODE / TEST MODE
1) To enter Service Mode, press number key "ENTER, 3, 0, 0, 1, ENTER" on the number keypad. Engineer Mode will appear on the display.
2) To scroll through the list of options in Service Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the
display.
3) To select a custom setting, press the ENTER key when the desired setting is shown.
4) To change the value of the setting, use the UP and DOWN LEVEL keys.
5) To confirm and save the value of the setting, press the ENTER key.
6) To exit the setting without saving, press the BACK key.
7) Press and hold the STOP key for 3-5 seconds to return to normal operation.
Group Model Item1 Item2 Default Value Values/Range Unit Notes
Accumulate HURESAC Distance Current value 0~999999 Manually sets the Accumulated
Distance.
HURESAC Time Current value 0~999999 Manually sets the Accumulated
Time.
SC Floors Current value 0~999999 Manually sets the Accumulated
Floors.
Log HURESAC Error Display None Error0~Error10
/ None
Shows the last 10 errors.
Reset Reset error log..
Headphone Jack
Sensor
Insert Counts Current Value 0~999999 Insert headphone jack counts..
Reset NO NO-YES Reset headphone insert counts.
Configuration HURESAC Export to USB Export engineer parameters to a
USB device.
Import from USB Import engineer parameters from
a USB device.
Factory Default HURESAC Reset NO NO-YES Reset engineering default
to factory value.
Asset
management
HURESAC Disable/Enable Disable Disable/Enable This option controls the AM
function is Disabled or Enabled.
Club ID This option records the club ID
of the fitness facility.
xID Login HURESAC Enable/Disable Disable Disable/Enable This option controls the xID login
function is Disabled or Enabled.

14
7.2 TEST MODE OVERVIEW
CHAPTER 7: SERVICE MODE / TEST MODE
1) To enter Test Mode, press number key "ENTER, 5, 0, 0, 1, ENTER" on the number keypad. Engineer Mode will appear on the display.
2) To scroll through the list of options in Test Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the display.
3) To select a custom setting, press the ENTER key when the desired setting is shown.
4) To change the value of the setting, use the UP and DOWN LEVEL keys.
5) To confirm and save the value of the setting, press the ENTER key.
6) To exit the setting without saving, press the BACK key.
7) Press and hold the STOP key for 3-5 seconds to return to normal operation.
Group Model Item1 Item2 Default
Value
Values/
Range
Unit Notes
Display HURESAC Press the ENTER key repeatedly to
check each set of LEDs on the display
sequentially.
Keypad HURESAC Press any key and the display should
show the corresponding message.
C-SAFE HURESAC Press the ENTER key to test CSAFE.
Headphone Jack HURESAC Press the ENTER key to test the insert
headphone jack counts.
Language Test HURESAC Press the ENTER key to test language
string change.
ErP HURESAC Auto/5/10/30/60 Scond Press the ENTER key and choice ErP
time to test ErP function.
CZ IR Frequency C Press the ENTER key to test IR sensor
frequency of control zone.

15
8.1 ELECTRICAL DIAGRAMS
CHAPTER 8: TROUBLESHOOTING
HURES3X-02-C/A3X-03-C ELECTRICAL BLOCK
DIAGRAM

16
CHAPTER 8: TROUBLESHOOTING
8.1 ELECTRICAL DIAGRAMS - CONTINUED
C3X-02-C ELECTRICAL BLOCK DIAGRAM

17
CHAPTER 8: TROUBLESHOOTING
8.1 ELECTRICAL DIAGRAMS - CONTINUED
H/P GROUND WIRE (HURES3X-02-C/A3X-03-C)
Pause sensor wire (HuresaC3x-C)
USB WIRE (HURES3X-02-C/A3X-03-C)
PAUSE SENSOR WIRE (HURES3X-02-C/A3X-03-C)

18
QUICKLY KEY WIRE (C3X-02-C)
CHAPTER 8: TROUBLESHOOTING
8.1 ELECTRICAL DIAGRAMS - CONTINUED
TKP
QUICKLY KEY WIRE (HURES3X-02-C/A3X-03-C)
