Matsusada Precision DRJ Series Installation guide

1
DRJ series
Basic Instruction Manual
1. Introduction
This manual summarizes the main features of the DRJ
series. Detailed descriptions and precautions are
provided in the instruction manual. The product
generates high-voltage and high-energy. Since such
high-voltage or high-energy may result in dangerous
situations such as death or serious injury due to electric
shock, read through the instruction carefully before
using the product. Use the product after understanding
how to use it properly. Please note that we will not be
held responsible for any damage or loss caused by not
following the warnings, cautions, and procedures
described in the manual.
Instruction Manual on the Web
The latest instruction manual and driver(s) are
available on our website.
You can also access our website with
the QR code on the right.
If the download is unavailable, please
contact our sales representative.
Keep the manual with you so that you can read it
whenever you want.
https://www.matsusada.com/product/
Table of Contents:
1. Introduction ........................................................
1
2. Accessories .......................................................
1
3. For Safe Use of the Product ..............................
2
4. Initial Inspection .................................................
4
5. External View .....................................................
4
6. Simple Descriptions from Power-on to Output ...
5
7. Main Features ....................................................
5
8. Switch Indications..............................................
6
9. Protection Features ........................................
7
10. Pin Assignment for Remote Control Connector ......
7
11. Troubleshooting ..............................................
8
2. Accessories
After unpacking the box, check the following
accessories are enclosed with the unit. Contact our
sales representative if you find different items, missing
items, or damaged items in the package.
<Accessories>
□
Basic Instruction Manual (This one)
1 ㍶
□
Output terminal cover
1 pc
□
Remote connector cover
1 pc
□
AC input cable
1 pc
□
CO-Opt cable (for -LGob option)
1 pc
□
Cable for option
(for –LMss,-LPhv,-LPhw,-L1p3ws)
1 pc
*172.9.064*
B/N: 172.9.064 Rev 0.0

2
3. For Safe Use of the Product
Symbols
Symbols are used in the manual and product, which
indicate precautions to be observed for safe use.
Understand these symbols first and then read the
manual thoroughly.
Some symbols below are not used in products.
Indicates a potentially hazardous
situation, which, if not avoided, may result
in serious injury or death.
Indicates a potentially hazardous
situation, which, if not avoided, may result
in minor or moderate injury or in property
damage.
Indicates danger/warning/caution. Refer to the
instruction manual when this symbol appears on
the unit.
Indicates the possible danger of electric shock
under specific conditions, which may result in
serious injury or death.
High Temperature Caution:
Indicates the possible danger of injury by high
temperature under specific conditions.
Indicates general prohibitions, including warnings.
Indicates what must be followed.
Protective earth terminal (ground terminal for
preventing electric shock)
Indicates the possible danger of death if you drink
it and burns or blindness if it attaches.
Indicates the possible danger of exposure to
radiation.
Frame or chassis terminal
Ground terminal
Power ON
Power OFF
Standby
Bistable push button switch ON
Bistable push button switch OFF
Alternative Current
Understand the risks.
The Product generates high-voltage and high-energy.
The product is designed for electrical engineers or the
equivalents who install, wire, and operate it.
Read the instruction manual thoroughly before use and
familiarize yourself with the proper use and danger of
the product.
Make sure to allow only specific people to handle
the product.
Make sure to allow only the following people to handle
the product:
1. who are electrical engineers or the equivalents
and have already familiarized themselves with the
proper use and danger of the product, or
2. who are electrical engineers or the equivalents
and have already been trained by the
above-mentioned people, or
3. who work under the supervision of the
above-mentioned people.
If people other than those listed above install, wire, or
operate the product, it may cause electric shock,
burnout, or injury.
Do not open or remove the case or panel of the
product.
Do not disassemble, repair, or modify the product by
yourself. High-voltage is applied to the inside of it.
Otherwise, it may cause electric shock, fire, or
malfunction.
Moreover, if you do it, the safety and functions are not
covered with the warranty.
The product does not suit to install and use in
places where children may be present.
The product is designed to be installed in places such
as factories or laboratories. Do not install and use it
where children may be present.
Make sure to ground it.
When the product has a protection ground terminal or
GND terminal, make sure to ground it.
When the AC line input of it is an inlet type, connect the
attached power cable or a power cable suitable for your
area to an outlet with the ground. Otherwise, it may
result in electric shock or fire.
Regarding power cable
When a power cable is enclosed or attached to the
product, do not use it for other products.
When no power cable is enclosed with the product,
prepare the power cable suitable for the usage
environment and area by yourself.
Regarding the connection of power cable
Electrical engineers or the equivalents who have
already been familiarized with the proper use and
danger of the product should connect the power cable
to the AC input by referring to the instruction manual.
Regarding products that have acquired the safety
standard, check the page describing the over-voltage
categories too.

3
Do not process or damage power cables
It may result in electric shock or fire.
Regarding the input voltage
Check the page describing the input terminals and
input voltage in the instruction manual.
Do not provide any voltage out of the specifications.
Regarding the fuse
The product builds in a protective fuse. In the case
where a fuse holder is arranged outside of the product,
you can replace it by yourself. Refer to the instruction
manual to replace it.
In the case where a fuse holder is not arranged outside
of the product, you cannot replace it by yourself.
In this case, do not open the case or panel of the
product and contact us.
The product is designed for indoor use.
Use the product indoors only, not outdoors. Even
indoors, do not use it if there is a possibility of water
leakage, flooding, or snow covering.
Regarding operating temperature and humidity
Use the product within the range of the specifications
describing in the instruction manual.
Do not use it in a place where the ambient temperature
exceeds the specified range or a closed place.
Do not install the product in places where
condensation may occur.
Doing so, insulation deteriorates and it may cause
electric shock, fire, or malfunction.
Do not place anything on top of the product.
Doing so, they may fall or tumble from it.
Do not put anything into the product.
Do not put foreign objects such as metal or liquid into
the product through air inlets, air outlets, or other
openings. Otherwise, it may result in electric shock, fire,
or malfunction.
Operate the product with the right hand.
Use only your right hand to operate the product and
keep your left hand away from it, which can reduce the
risk of electric current flowing through the left hand to
the vital organs of the body in the event of an electric
shock.
Do not touch the wiring/load connected to the
output and any terminals/connectors during the
operation or just after turning output off.
Very high-voltage is on the terminals and connectors
during the operation and even just after the output is
turned off. Touching them may result in serious injury or
death by electric shock.
The terminals here mean all terminals like input and
output terminals and terminals for communications and
remote controls.
Turn off the product before touching the
wiring/load connected to the product and any
terminals/ connectors on the product and cut it off
from the AC input.
Before touching the terminals/connectors and
wiring/load, turn off the product and unplug the AC
input cable from the outlet or turn off the AC input
breaker. Then, check there is no voltage remained
using a tester.
Since the output and sense terminals are connected to
condensers in it, there is high-voltage remained on
them even just after it is turned off.
In order to avoid electric shock, ground the terminals to
discharge using a short circuit grounding apparatus and
check the voltage again.
The terminals here mean all terminals like input and
output terminals and terminals for communications and
remote controls.
Level the product out to use for good heat
dissipation.
Do not install the product upside down or sideways. If
not, the inner heat dissipation will be insufficient.
It may result in smoke or fire due to components
deterioration.
Do not install the product in a place where cold air
directly blows to it.
It may result in electric leakage or burnout due to
condensation.
Do not install or use the product in a place where
corrosive gases or liquids exist in the atmosphere
or conductive dust particles such as iron powder
can enter through the air inlet/outlet.
Deterioration or short-circuiting of its internal parts may
cause leakage of electricity, smoke, burnout, fire, or
malfunction.
Do not install the product in a dusty place.
Accumulating dust in the air inlet will make hard to cool
it down it, it may result in malfunction.
In that case, remove dust immediately.
Do not block the air inlet and outlet.
Secure 30 cm space at least around the openings.
If they are blocked, the product cannot show the rated
performance due to the internal temperature increase.
Moreover, components deteriorate and it may result in
smoke or fire.
Remove wiring to and from the product when work
like welding near it is done.
Do not wipe the equipment with a dust cloth wet
with chemicals (thinner or the like) or water.
Doing so, it may result in an electric shock, electric
leakage, or burnout due to water getting inside.
Regarding fan replacement
When products equip a fan, it has a lifetime. It will be
worn out and deteriorated with the time passed and its
operation may become unstable. Also, its lifetime
greatly varies depending on the usage environment
such as temperature, humidity, dust. It requires to be
replaced at regular intervals to extend the lifetime. For
the replacement, contact us.
(It requires a replacement charge separately. Do not
replace it by yourself, as there is a risk of electric
shock.)

4
4. Initial Inspection
After unpacking, check its external appearance for any abnormalities.
Check the front panel, rear panel and chassis for scratches, dents, or other damages caused by handling or transportation.
Moreover, check whether or not the encoder or dial on the front panel works correctly as well.
If you find any abnormalities, contact the carrier and us.
5．External View
Front Panel:
Rear Panel:
(1) POWER switch
(2) OUTPUT LED
(3) OUTPUT switch
(4) Display
(5) REN LED
(6) LOCK LED
(7) RANGE LED
(8) Control key switch
(9) Numerical setting rotary encoder
(10) Outlet
(11) Air inlet
(1)
(2)
(4)
(3)
(5)
(6)
(7)
(10)
(11)
(8)
(9)
(a) (b) (c)
(d) (e) (f)
(g) (h) (i)
(a) RANGE key
(b) DC/AC key
(c) VLT/FRQ key
(d) PROTECT key
(e) Left key
(f) Right key
(g) DISPLAY key
(h) MEMOERY key
(i) ENT/LOCK key
Control key switch
(2)
(3)
(1)
(5)
(4)
(1) AC input inlet
(2) Cable holder
(3) Output terminal block
(4) Digital interface
(5) Remote control connector
DISPLAY

5
6. Simple Descriptions from Power-on to Output
7. Main Features

Protection function
Output short circuit, Overvoltage, Overcurrent, Overpower, Input voltage abnormal,
Overtemperature, Power failure

Remote control function
Remote switch ON/OFF, Switching between voltage ranges, Switching between
frequencies, Switching between voltages

Other features
Door switch, Fault status output, preset function
Connecting Input/Output wiring and Start-up
Setting the range
Shift the cursor position for voltage/frequency by pressing
the [VLT/FRQ] key at AC output mode.
Move the blinking cursor with the right or left direction key to
set the value with the numerical setting encoder.
Press the [OUTPUT] switch to turn the output on.
* The OUTPUT LED is lit while the output is on.
Setting the DC/AC output mode
Starting the output
Check that the input/output and signal lines are wired
correctly according to the instruction manual.
* Make sure to ground the GND in the AC input inlet.
Check the display that the monitor screen appears
when turning on the [POWER] switch.
Set the output mode by pressing the [DC/AC] key.
Setting the output voltage/frequency
Set the output voltage range by pressing the [RANGE] key.
* Lo range: 100V, Hi range: 200V

6
8. Switch indications
To changes output monitoring, press the DISPLAY key
Output voltage/current monitoring
Output voltage/frequency monitoring
（AC mode）
Output voltage/power monitoring

7
9. Protection Features
10. Pin Assignment for Remote Control Connector
* PIN5 and PIN 10 are connected inside the product.
REMOTE
PIN 7LD door switch
PIN 6
FAULT status output common
PIN 5Program return
PIN 4NC
PIN 3NC
PIN 2Frequency program input
PIN 1Voltage program input
NC PIN
8
Local/remote switching for frequency
PIN 9
Signal return PIN10
FAULT status output PIN11
NC PIN12
NC PIN13
13
1
25
14
Local/remote switching for voltage range PIN25
NC PIN24
NC PIN23
Local/remote switching voltage programPIN22
LS remote switch input PIN21
Local/remote switching PIN20
PIN14 NC
PIN15
NC
PIN16
NC
PIN17
NC (Power failure protection enable/disable in -LN)
PIN18
Voltage range switching
PIN19 NC
Protection
Limit value for fault detection
MODEL
DRJ 500
Power
500VA
Input voltage Protection
≦about AC80V , about AC140 to 170V , ≦about AC270V
AC mode
Over Voltage
Protection OVP
range
Lo
0 to 157.5V
Hi
0 to 315V
Over
Current
Protection
OCP
RMS
range
Lo
0 to 5.25A
Hi
0 to 2.62A
DC mode
Over Voltage
Protection OVP
range
Lo
0 to 222.7V
Hi
0 to 445.4V
Over
Current
Protection OCP
range
Lo
0 to 2.36A
Hi
0 to 1.18A
Over power protection OPP
0 to 525VA
Changing range while generating
output
Lo(100V) →Hi(200V) 、Hi(200V) →Lo(100V)
Changing AC/DC while generating
output
AC →DC 、DC →AC
Changing +/- while generating output
＋→－、－→＋
Door Switch (LD)
OPEN
Remote Switch (LS)
OPEN

8
11. Troubleshooting
If you think a failure has occurred, first turn off the product and disconnect the input power. Make sure that no
voltage is on the input/output terminals, and then check the input/output wiring. They are not always a failure in the
following cases, check the product once again before requesting our services.
Problem
Items to check
"No output"
or "the output does not meet
the preset value."
☐
☐
☐
☐
☐
☐
☐
Is the input voltage within the specifications? Is the wiring correct?
Is the remote switch LS (PIN 21) and signal common (PIN 10) in the remote control
connector on the rear panel connected?
Is the door switch LD (PIN 7) and signal common (PIN 10) in the remote control
connector on the rear panel connected?
Is the voltage setting minimized?
Is the setting for limit, OCP, or OPP minimized?
Is the OVP setting correct?
Is the LOCK function activated?
"Breaker trip"
☐
☐
☐
Have you replaced the original screws of the housing with different ones?
(The replaced screws may have cut into the internal circuits.)
Is the breaker's base capacity sufficient?
Is the input or output wiring wrongly connected to its terminal?
"Output voltage fluctuates or
cannot be controlled"
☐
Is the peak current over the rated current?
"Output current is too low."
"Protection is activated when
the load is on."
☐
☐
☐
Is the setting of RANGE correct?
Is the peak current over the rated current?
Is the inrush current over the rated current?
Revision History:
Rev. No.
Rev. date
Revised contents
0.0
2023/08
First edition
