Instruction Manual
MODEL R4G/R4GT series
Rev 0.6
-LCk Option (CC-Link)
B/N 217.9.230 *217.9.230*

Trademarks
◆Company names and product names in this document are the trademarks or registered
trademarks of their respective companies.
Note
◆All rights reserved.
◆
No part of this publication may be reproduced, stored in a retrieval system, or transmitted,
in any form, or by any means, mechanical, electronic, photocopying, recording, or
otherwise, without the prior written permission of Matsusada Precision.
◆
No patent liability is assumed with respect to the use of the information contained herein.
Moreover, because Matsusada Precision is constantly striving to improve its high-quality
products, the information contained in this manual is subject to change without notice.
Every precaution has been taken in the preparation of this manual. Nevertheless,
Matsusada Precision assumes no responsibility for errors or omissions.
Neither is any liability assumed for damages resulting from the use of the information
contained in this publication.
Warranty
◆For details, refer to the following website.
https://www.matsusada.com/support/manufacturer_warranty.html

R4G/R4GT series -LCk option
Contents
Page
1Outline...............................................................................................................................1
2CC-Link .............................................................................................................................2
2-1 Specification of the CC-Link ...........................................................................................2
2-2 Installation of the CC-Link and construction the network................................................2
2-3 CSP+ File .......................................................................................................................3
2-4 Setting the CC-Link ........................................................................................................3
2-5 Indicator .........................................................................................................................3
3How to set the CC-Link operation......................................................................................4
3-1 How to set the CC-Link mode for R4G/R4GT ................................................................4
3-1-1 Set the mode to the CC-Link mode .........................................................................4
3-1-2 Setting the station number ......................................................................................5
3-1-3 Setting the baudrate................................................................................................6
3-1-4 Applying the settings ...............................................................................................6
3-2 Confirming start-up of the CC-Link for R4G/R4GT .........................................................7
3-3 Communicating with the master .....................................................................................7
3-4 Controlling with the CC-Link [usage example]................................................................8
3-4-1 Starting up R4G/R4GT............................................................................................8
3-4-2 Completing the initial setting ...................................................................................9
3-4-3 Setting the voltage / current ..................................................................................10
3-4-4 Turning the output ON...........................................................................................12
3-4-5 Confirming the monitor value ................................................................................13
4Communication data .......................................................................................................15
4-1 Outline of the communication data (slave → master)...................................................15
4-1-1 RX bit data (slave → master) ................................................................................19
4-1-2 RWr word data (slave → master) ..........................................................................22
4-2 Outline of the communication data (master → slave)...................................................24
4-2-1 RY bit data (master → slave) ................................................................................27
4-2-2 RWw word data (master → slave).........................................................................29
4-3 R4G/R4GT Model correspondence table .....................................................................36
5Troubleshooting...............................................................................................................37
5-1 Inquiries........................................................................................................................37

1 Outline
1
R4G/R4GT series -LCk option
Outline
This document is the communication specification when the CC-Link option is used for the
R4G/R4GT SERIES.
Refer to the instruction manuals shown below for the basic operation and the like of R4G.
R4G/R4GT SERIES instruction manual
R4G/R4GT SERIES optional instruction manual

2 CC-Link
2
R4G/R4GT series -LCk option
CC-Link
Specification of the CC-Link
Specification of the CC-Link is shown below.
Item
Specification
Version
Ver.1.10
Number of
occupied stations
2 stations occupied
Communication
speed
10M / 5M / 2.5M / 625k / 156kbps
Connector
MSTB 2,5/ 4-ST-5,08 AU
(an equivalent product is included)
Connection cable
CC-Link Ver. 1.10 compatible cable
(Shielded, 3-core twisted pair cable)
Terminating
resistor
110 Ω ± 5% 1/2 W
Installation of the CC-Link and construction the network
(1) How to install the CC-Link
Prepare the connector and cable that are listed in the specification of the CC-Link
(section 2-1).
Wiring of the connector shall be as follows.
CC-Link cable side
(1) DA (Positive RS485 RxD/TxD)
(2) DB (Negative RS485 RxD/TxD)
(3) DG (Signal Ground)
(4) SLD (Cable Shield)
(2) Constructing the network
The R4G/R4GT SERIES can be used as the slave station (remote device station).
In the CC-Link, the station number of the master station is fixed at 0 (zero), and the
slave stations are connected in the multi-drop configuration.
In order to mitigate signal reflection and prevent signal disturbance, install the
terminating resistor at the end of the network.
For other details, refer to the “CC-Link Cable Wiring Manual” (issued by CLPA).
① ② ③ ④

2 CC-Link
3
R4G/R4GT series -LCk option
CSP+ File
Please download a CSP+ file from a home page of CLPA.
It is included in files with the document name “Miscellaneous”. (As of May 18, 2017)
If you have any other questions, please contact CLPA.
Setting the CC-Link
(1) Setting the station number
Assign the station number of your choice from the front panel of the R4G/R4GT
SERIES (section 3-1-2).
(2) Setting the baudrate
Assign the speed of your choice from the front panel of the R4G/R4GT SERIES
(section 3-1-3).
The speed can be selected from what is listed in the specification of the CC-Link
(section 2-1).
Indicator
There are two LED indicators on the CC-Link module.
Connection port of the CC-Link connector
(1) Run LED
(2) Error LED
Details of indicator operation
Status
(1) Run LED
(2) Error LED
Off
When network is not connected or
power is OFF
When there is no error or
power is OFF
Green
When network is connected
-
Red
Major error detected
Major error detected
Red, Flickering
-
CRC error detected
Red, Flashing
-
Change in station number or speed
is detected
(1)
①
②
③
④
(2)

3 How to Set CC-Link Operation
4
R4G/R4GT series -LCk option
How to Set CC-Link Operation
How to set the CC-Link mode for R4G/R4GT
The following settings are necessary to use R4G/R4GT in CC-Link mode.
[Procedure]
Set the mode to the CC-Link mode
Display the menu screen by Power ON the device while pressing the SET switch on the front
panel.
Rotate the VOLTAGE dial, and change the screen to the CC-Link setting screen.
Rotate the CURRENT dial, and turn ON the CC-Link mode.
CURRENT
Dial
(Change ON/OFF)
VOLTAGE
Dial
(Change menu)
Press button
Press down button
Dial rotation

3 How to Set CC-Link Operation
5
R4G/R4GT series -LCk option
Setting the station number
Rotate the VOLTAGE dial, and change the screen to the STAT setting screen.
Rotate the CURRENT dial, and select the station number (1-63).
CURRENT
Dial
(Change Station)
CURRENT
Dial
(Change Station)
CURRENT
Dial
(Change Station)

3 How to Set CC-Link Operation
6
R4G/R4GT series -LCk option
Setting the baudrate
Rotate the VOLTAGE dial, and change the screen to the BPS setting screen.
Rotate the CURRENT dial, and select the baudrate (0.156/0.625/2.5/5/10 Mbps).
Applying the settings
1. Confirm that the screen does not display “dEF,” and long press the LOCK button (exit the
menu screen).
→ In this case, if the screen display is “dEF,” the settings will return to default settings.
2. Switch ON the power once again.
→ The CC-Link settings will be applied after the device is re-started.
CURRENT
Dial
(Change Baudrate)
CURRENT
Dial
(Change Baudrate)

3 How to Set CC-Link Operation
7
R4G/R4GT series -LCk option
Confirming start-up of the CC-Link for R4G/R4GT
After setting the CC-Link, check the front panel of R4G/R4GT after power ON.
REMOTE lamp is ON: The device is operating normally under the CC-Link network.
REMOTE lamp blinks: There is an error such as detached cable, wrong station number or
speed, etc.
REMOTE lamp is OFF: The device is not operating under the CC-Link mode (check section
3-1).
Communicating with the master
After confirming establishment of the CC-Link, set the initial setting completion flag (RY(n+3)8) in
the master.
If the remote READY status (RX(n+3)B) in R4G/R4GT is at “Hi,” the setting is done.
[Precautions]
The setting will be applied to all bit area at the timing when the initial setting completion is
established in the master.
For example, when the operation command bit RY(n+1)7 is set at enabled (1), and when the
operation command bit RY(n+1)6 is set at output (1), output will begin at the timing when the
initial setting completion RY(n+3)8 is set at complete (1).
When setting the initial setting completion RY(n+3)8 at complete (1), do so after carefully
confirming that the value status of other areas is at the intended value.

3 How to Set CC-Link Operation
8
R4G/R4GT series -LCk option
Controlling with the CC-Link [usage example]
Using the MELSEC CC-Link Ver.2 Controller board / DeviceMonitor tool, and setting the voltage
at 12.34 V and the current at 1 A in R4G18-5, the procedure to set the output ON is described
below.
The procedure shown below is when R4G/R4GT is used under station number 1.
Starting up R4G/R4GT
Switch ON the power of R4G/R4GT after setting it in CC-Link mode, and connect the CC-Link
cable.
(1) When start-up under the CC-Link is complete, RX38 will turn ON (1).
(1)

3 How to Set CC-Link Operation
9
R4G/R4GT series -LCk option
Completing the initial setting
Enter the value in the bit area (RY).
(1) Set all RY bit area at 0 (zero).
(2) Set the RY38 bit for initial setting completion at 1.
Confirm the value in the bit area (RX).
(1) When the initial setting is complete, RX38 will turn OFF (0), and RX3B will turn ON (1).
(2) Since R4G/R4GT is operating in CC mode, RX11 is at CC (1).
(3) Since R4G/R4GT is remotely operated, RX17 is at Remote (1).
(1)
(2)
(1)
(2)
(3)
(1)

3 How to Set CC-Link Operation
10
R4G/R4GT series -LCk option
Setting the voltage / current
Enter the value for data classification 1 in the “word area” (RWw).
(1) Enter the voltage set value, 1234 (12.34 V), in RWw0.
Enter the current set value, 1000 (1 A), in RWw1.
Enter the ON delay time set value, 0 (zero), in RWw2.
Enter the OFF delay time set value, 0 (zero), in RWw3.
Enter the overvoltage protection value, 1800 (18 V), in RWw4.
Enter the overcurrent protection value, 5000 (5 A), in RWw5.
Enter 0 (zero) into RWw6 and RWw7, since they are not used.
Enter the value in the bit area (RY).
(1) Set the data classification (RY08 through RY0B) in the “word area” at data 1 (0000).
(2) Set the command data RY00 and RY01 at write setting data (01).
(3) Set the command execution RY04 at start command (1).
(1)
(1)
(2)
(3)

3 How to Set CC-Link Operation
11
R4G/R4GT series -LCk option
Confirm the value in the bit area (RX).
(1) After the command execution is complete, the command response RX04 will change to
command processing complete (1).
(2) To write the setting data for the command that had its processing completed, RX00 and RX01
will change to write setting data (01).
(3) Since data classification will be 1 for the data classification that had its processing completed,
RX08 through RX0B will be at data classification 1 (0000).
Enter the value in the bit area (RY).
(1) When the command response RX04 becomes command processing completed9+ (1), set the
command execution RY04 at stopped (0).
(1)
(2)
(3)
(1)

3 How to Set CC-Link Operation
12
R4G/R4GT series -LCk option
Turning the output ON
Enter the value in the bit area (RY).
(1) Enter operation command enabled (1) for operation command selection RY17.
(2) Enter output (1) for operation command RY16.
Confirm the value in the bit area (RX).
(1) When R4G/R4GT is in the output status, RX10 will be at output in process (1).
(1)
(2)
(1)

3 How to Set CC-Link Operation
13
R4G/R4GT series -LCk option
Confirming the monitor value
Confirm the value for data classification 1 in the “word area” (RWr).
Enter the value in the bit area (RY).
(1) Set the data classification (RY08 through RY0B) in the “word area” at data 1 (0000).
(2) Set the command data RY00 and RY01 at read setting data (11).
(3) Set the command execution RY04 at start command (1).
Confirm the value in the bit area (RX).
(1) After the command execution is complete, the command response RX04 will change to
command processing complete (1).
(2) To read the setting data for the command that had its processing completed, RX00 and RX01
will be at read setting data (11).
(3) Since data classification will be 1 for the data classification that had its processing completed,
RX08 through RX0B will be at data classification 1 (0000).
(1)
(2)
(3)
(1)
(2)
(3)

3 How to Set the CC-Link Operation
14
R4G/R4GT series -LCk option
Confirm data classification 1 in the “word area” (RWr).
(1) The output voltage value can be confirmed in RWr0.
The output current value can be confirmed in RWr1.
The voltage set value can be confirmed in RWr2.
The current set value can be confirmed in RWr3.
The overvoltage protection set value can be confirmed in RWr4.
The overcurrent protection set value can be confirmed in RWr5.
RWr6 is not used.
The error code can be confirmed in RWr7.
(1)

4 Communication Data
R4G/R4GT series -LCk option
Communication Data
Outline of the communication data (slave → master)
Bit data 2 stations (32 bit * 2 stations = 64 bit)
Device No.
RX
Outline
RXn0
Command data
01: Write setting data
11: Read setting data
RXn1
RXn2
RXn3
RXn4
Command response
0: Stopped
1: Command processing complete
RXn5
RXn6
RXn7
RXn8
Data classification in the word area (*1)
0000: Data 1 0001: Data 2
…
1110: Data 15 1111: Data 16
RXn9
RXnA
RXnB
RXnC
RXnD
RXnE
RXnF
RX(n+1)0
Output status
0: Output off 1: Output on
RX(n+1)1
CV/CC status
0:CV 1:CC
RX(n+1)2
Output stop by the integrated current value
(*2)
00: No stoppage 01: Stop output
10: Stop output and HOLD
RX(n+1)3
RX(n+1)4
Output stop by operation time (*2)
00: No stoppage 01: Stop output
RX(n+1)5
RX(n+1)6
RX(n+1)7
Local / Remote
0: Local 1: Remote
RX(n+1)8
Output shutoff status
0: Output enabled 1: Shutoff activated
RX(n+1)9
Overvoltage protection
0: No protection 1: Activated protection
RX(n+1)A
Overcurrent protection
0: No protection 1: Activated protection
RX(n+1)B
RX(n+1)C
RX(n+1)D
RX(n+1)E
RX(n+1)F
Interlock switch status
0: Interlock off 1: Interlock on

4 Communication Data
16
R4G/R4GT series -LCk option
Bit data 2 stations (32 bit * 2 stations = 64 bit)
Device No.
RX3
Outline
RX(n+2)0
Multiset
00:OFF 01: Multi A
10: Multi B 11: Multi C
RX(n+2)1
RX(n+2)2
Delay trigger
0:OFF 1:ON
RX(n+2)3
Pulse sequence
0:OFF 1:ON
RX(n+2)4
Lamp mode
00:OFF 01:CVCC
10:CV 11:CC
RX(n+2)5
RX(n+2)6
RX(n+2)7
RX(n+2)8
RX(n+2)9
RX(n+2)A
RX(n+2)B
RX(n+2)C
RX(n+2)D
RX(n+2)E
RX(n+2)F
RX(n+3)0
System reserved
System reserved
RX(n+3)1
RX(n+3)2
RX(n+3)3
RX(n+3)4
RX(n+3)5
RX(n+3)6
RX(n+3)7
RX(n+3)8
Initial processing request flag
00: No initial request
01: Initial request active
RX(n+3)9
Initial setting completion flag
00: Initial setting not complete
01: Initial setting complete
RX(n+3)A
Error status flag
00: No error 01: Error present
RX(n+3)B
Remote READY status
00: Remote not possible
01: Remote possible
RX(n+3)C
System reserved
System reserved
RX(n+3)D
RX(n+3)E
RX(n+3)F
