Max-Ability Pressalit 2000 User manual


Pressalit 2000 / 2100
Fixed Height Changing Table
User Guide
Model 2000
(Mesh Cover)
SKU: R8425218000
EAN: 5708590372167
Model 2100
(Coated Canvas)
SKU: R8425418000
EAN: 5708590372174
MAX-Ability, Inc.
[email protected]
800 577-1555

3
REF R8425218
R8425418
Pressalit A/S, Pressalitvej 1
DK-8680 Ry [phone]
www.pressalit.com
REF
++
++
==
YYYY-MM-DD RZZZZYYYXXX-X
(01)0XXXXXXXXXXXXX(10)YYMMDD
xxx kg
xxx lbs
xxx kg
xxx lbs

4
mm
inch
1800
300
86
0
70.87
11.81
33
.86

5
en
Content
Mounting instruction ........................................... 5
Operational signage ............................................ 5
General safety .................................................. 6
Symbols used in this manual..................................... 7
Specific safety .................................................. 7
Intended use ................................................... 8
Intended operator profile ................................... 8
Intended user profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating environment..................................... 8
Contraindications for use ................................... 8
Biocompatibility................................................ 8
Operating instructions .......................................... 9
Cleaning...................................................... 10
Zipping the cover onto the frame................................ 11
Maintenance.................................................. 12
Maintenance inspection ................................... 12
Product label.................................................. 13
Trouble-shooting .............................................. 14
Technical data................................................. 14
Disposal and recycling ......................................... 15
Original instructions
Mounting instruction
A mounting instruction is included with the product. It can also be
downloaded from www.pressalit.com.
Operational signage
An operational signage can be downloaded from
www.pressalit.com.

6
en
General safety
!CAUTION
• Please comply with these instructions to avoid the product becoming
damaged or destroyed.
• Do not perform repairs, disassembly, or assembly operations,
extensions, re-adjustments or modifications to this product. These
must be carried out by Pressalit or by persons authorized by Pressalit
only.
• Never allow children to operate this product unless under supervision.
The product is not intended for play.
• Never use the product if it is defective or damaged. Do not use a
defective product before it has been repaired.
!WARNING
• Read and understand the manual completely before use. Keep the
manual close to the unit.
• Comply with this manual to avoid accidents involving serious personal
injury.
• Never use or handle this product in other ways than are specified in
this manual, as this can put your safety at risk and cause damage to the
product.
• Make sure that everyone who is to install or use the product and its
systems has the necessary information and access to this manual.
NOTICE
• The information in this manual is based on correct fitting of the
product in accordance with our Assembly instruction.
• Pressalit cannot be held liable if the product is used in any way which
differs from that described in the guide.
• We reserve the right to amend this manual without prior notice.

7
en
Symbols used in this manual
The following symbols are used in this manual as well as the associated
documentation supplied with the product.
Specific safety
!
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
!
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practices.
IMPORTANT
IMPORTANT indicates important information about handling and use of the
product.
NOTICE
NOTICE is used to address practices not related to personal safety.
Hand injury warning
!CAUTION
• Never leave a person lying on the shower table without supervision.
• Always be careful when moving a person to and from the shower table.

8
en
Intended use
This product is intended for showering a person who is unable to stand up or sit
down. The person is lying horizontally on the table.
Intended operator profile
The product is to be operated by personnel trained in health care and trained in
washing a person in their care.
Intended user profile
The product can be used by all - adults, children, young, old, whose weight does
not exceed the maximum load of 175 kg / 385 lbs.
Operating environment
For indoor use in a wet environment, such as a bathroom or wash room. The
product is intended to be used at room temperature, in private homes, nursing
homes and hospitals under normal working conditions.
Contraindications for use
It is not recommended that pregnant women use this product.
It is not recommended that patients with infusion or insulin pump, inflammatory
skin diseases or patients in feverish conditions use this product.
Patients with cardiac insufficiency, cardiovascular diseases, craniocere bral injury,
open wounds, feed or drain lines (e.g. catheter, drainage tube) may use this
product only after consulting with the attending physician.
Biocompatibility
The materials in contact with the skin of the patient or the operator during the
showering procedure have been tested for their content of harmful substances
according to ISO 10993 Biocompatibility, and are therefore considered suitable
for this purpose.
NOTICE
Any serious incident that has occurred in relation to the product should be
reported to the manufacturer and the health authorities.

9
en
To pull the safety rail up:
Release the lock 2and pull the
safety rail 3from the underside
of the table, and swing it
upwards. The safety rail will
automatically lock into position.
3
2
2
2
To fold the safety rail away: Release the lock 2and swing the safety rail
down to the underside of the table. The safety rail will automatically lock into
position.
Take care to avoid injury to
hands when in the vicinity of
closing mechanical parts.
Support the table using
your hand or body when
folding it down, to avoid
the risk of damage.
The built-in gas cylinders
make it easy to fold the
table up against the wall
after use.
Operating instructions
7 kg
15 lbs

10
en
Cleaning
Clean the shower table after each use. Use ordinary soapy water. Rinse off with
fresh water and dry with a soft cloth.
IMPORTANT
• Do not use an autoclave or other type of steam cleaner.
• Avoid aggressive cleaning agents containing acids or chloride.
• Never spray the nursing bench directly with a high pressure cleaner.
• Avoid use of aggressive, abrasive, corrosive or chloride-based cleaning
or disinfecting products.
The frame with the cover
can be removed for
cleaning. It can be zipped
off and washed in regular
washing machine at max
70o C.
Dry the water collection
tray.
!CAUTION
Never let a person lie on the shower table without
the cover in place. The tray under the cover is
for water collection only. It is not to be used as a
bathtub. Risk of user injury and damage to product.

11
en
Zipping the cover onto the frame
When the cover has been removed for washing, it must be zipped back onto the
frame again.
Zip all zippers approximately 5 cm
(2 inches).
Continue to zip the four zippers
gradually in a clockwise or
counterclockwise direction.
This will ensure that the cover is
mounted correctly on the frame.
①
②
④
③

12
en
Maintenance
Expected service life of the shower table is 10 years, provided that maintenance is
carried out as described below:
It is recommended that maintenance inspection is done one a year.
Maintenance inspection
• Check the hinges ①on the
table and the safety rail ②.
Tighten if necessary.
• Check the cover ③for
damage and replace if
necessary.
1
1
2
2
3
4
• Check the drain pipe
connections ④, and check
and clean the water trap (if
fitted).

13
en
①Production date
②Article number
③Medical device
④Batch code
⑤GS1-128 barcode
⑥Name and address of manufacturer
⑦Maximum user weight
⑧Max load
⑨Consult manual for use
⑩This product is CE-marked in accordance with the European
Medical Device Regulation 2017/745. A declaration of conformity
can be found at www pressalit com.
Pressalit A/S, Pressalitvej 1
DK-8680 Ry [phone]
www.pressalit.com
REF
⑥⑦⑧⑨⑩
①②③④⑤
++
++
==
YYYY-MM-DD RZZZZYYYXXX-X
(01)0XXXXXXXXXXXXX(10)YYMMDD
xxx kg
xxx lbs
xxx kg
xxx lbs
Product label

14
en
Trouble-shooting
Symptom Cause Action
The shower table does
not stay in upright
position.
One or more gas cylinders
are defective.
Contact MAX-Ability.
The water does not
run out of the water
collection tray.
Adjustment screws too
high or too low.
Adjust the adjustment
screws 1.
Technical data
Max load 175 kg / 385 lbs
Materials Powder laquered stainless steel
Plastics (PVC, Polystyrene)
Weight R8425218, R8425418: 14,32 kg / 31.57 lbs
1

15
en
Disposal and recycling
The unit contains reusable materials. There are no known hazards or risks
associated with disposal of the product. All components can be discarded after
having been cleaned and disinfected.
When disposing of the product, we recommend that it be disassembled and
broken down into different waste groups for recycling or combustion.
The following table provides information on the recycling and handling of the
product.
Recyclable
components Material
Steel Steel can be recycled by being re-melted and included as
a secondary material in the production of new steel.
PVC and
polystyrene
Hard PVC is granulated and re-melted.
Use plastic sorting and recycling systems where they are
locally available, otherwise incinerating plastic has the
added benefit of generating energy, which can be used
for, for example, combined heat and power production.
Polyurethane Like other plastics, polyurethane can be recycled in
two primary ways: mechanical recycling, in which the
material is reused in its polymer form, and chemical
recycling that takes the material back to its various
chemical constituents.
