Max-Ability Pressalit 3000 User manual

Shower table 3000 –Operation and maintenance manual en
Bruseleje 3000 –Brugs- og vedligeholdelsesvejledning dk
Duschliege 3000 –Gebrauchs- und Pegeanleitung de
Table de douche 3000 –Manuel d’utilisation et d’entretien fr
Douchebrancards 3000 –Gebruiks- en onderhoudshandleiding nl
Duschbrits 3000 –Bruks- och underhållsanvisning sv
Dusjstellebord 3000 –Bruks- og vedlikeholdsveiledning no
Camilla de ducha 3000 -Instrucciones de uso y mantenimiento es
洗澡床 3000 - 操作和维护手册 中文
 –3000

www.max-ability.com
Pressalit 3000
User Manual
Fixed Height Changing Table
Child
R8435313301: Graphite Gray
R8435313299: Sapphire Blue
(replaces R8523)
Adult
R8435318301: Graphite Gray
R8435318299: Sapphire Blue
(replaces R8528)
MAX-Ability, Inc.
800.577.1555 [email protected]
rev Apr 2021

www.max-ability.com
800.577.1555 [email protected]
The guarantee covers faults or defects in material or manufacture within a period
of 5 years. Products are subject to minor technical modifications and design
deviations. E.&O.E.
Find more product information by clicking here or go to
max-ability.com/product/pressalit-care-3000-adult-changing-table/

3
Content
Mounting instruction ........................................... 3
Operational signage ............................................ 3
General safety .................................................. 4
Symbols used in this manual..................................... 5
Specific safety .................................................. 5
Product label................................................... 6
Intended use ................................................... 7
Intended operator profile ................................... 7
Intended user profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operating environment..................................... 7
Versions ....................................................... 8
Operating instructions .......................................... 9
Head support ................................................. 10
Cleaning...................................................... 11
To remove limescale....................................... 12
Disinfection................................................... 12
Maintenance.................................................. 13
Service inspection ........................................ 13
Trouble-shooting .............................................. 14
Technical data................................................. 14
Disposal and recycling ......................................... 15
Mounting instruction
A mounting instruction is included with the product. It can also
be downloaded from www.pressalit.com.
Operational signage
An operational signage can be downloaded from
www.pressalit.com.
800.577.1555 [email protected]
www.max-ability.com

4
General safety
!CAUTION
• Please comply with these instructions to avoid the product becoming
damaged or destroyed.
• Do not perform repairs, disassembly, or assembly operations,
extensions, re-adjustments or modifications to this product. These
must be carried out by Pressalit or by persons authorized by Pressalit
only.
• Never allow children to operate this product unless under supervision.
The product is not intended for play.
• Never use the product if it is defective or damaged. Do not use a
defective product before it has been repaired.
!WARNING
• Read and understand the manual completely before use. Keep the
manual close to the unit.
• Comply with this manual to avoid accidents involving serious personal
injury.
• Never use or handle this product in other ways than are specified in
this manual, as this can put your safety at risk and cause damage to the
product.
• Make sure that everyone who is to install or use the product and its
systems has the necessary information and access to this manual.
NOTICE
• The information in this manual is based on correct fitting of the
product in accordance with our Assembly instruction.
• Pressalit cannot be held liable if the product is used in any way which
differs from that described in the guide.
• We reserve the right to amend this manual without prior notice.
www.max-ability.com
800.577.1555 [email protected]

5
Symbols used in this manual
The following symbols are used in this manual as well as the associated
documentation supplied with the product.
Specific safety
!WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
!CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practices.
IMPORTANT
IMPORTANT indicates important information about handling and use of
the product.
NOTICE
NOTICE is used to address practices not related to personal safety.
Hand injury warning
!CAUTION
•
•
www.max-ability.com
800.577.1555 [email protected]
Never leave a person lying on the changing table without supervision.
Always be careful when moving a person to and from the table.

6
①Production date
②Article number
③GS1-128 barcode
④Maximum rated load
⑤Name and address of manufacturer
⑥Product weight
⑦Consult manual for use
⑧
This product is CE-marked in accordance with the European
Medical Device Directive 93/42/EEC, including amendments
incorporated in Directive 2007/47/EEC. A declaration of conformity
can be found at www.pressalitcare.com
Pressalit A/S, Pressalitvej 1
DK-8680 Ry [phone]
www.pressalit.com
REF




YYYY-MM-DD RZZZZYYYXXX-X
(01)0XXXXXXXXXXXXX(10)YYMMDD
①②③
④⑤⑥⑦⑧
Product label
800.577.1555 [email protected]

7
Intended use
This product is intended for bathing a person who is unable to stand up or sit
down. The person is lying horizontally on the table.
Intended operator profile
The product is to be used by personnel trained in health care and trained in
washing a person in their care.
Intended user profile
The product can be used by all - adults, children, young, old, whose weight
does not exceed the maximum load of 200 kg.
Operating environment
For indoor use in a wet environment, such as a bathroom or wash room.
The product is intended to be used at room temperature, in private homes,
nursing homes and hospitals under normal working conditions.
Product label placement ①.
1
NOTICE
.
Salt and chloride have a corrosive effect on the products components and
will cause a decrease in the life expectancy of the product. The damaging
effects can, however, be reduced if the product is showered with tap water
on a daily basis.
800.577.1555 [email protected]

8
Versions
R8435313
R8435318
www.max-ability.com
800.577.1555 [email protected]
(replaces R8523)
(replaces R8528)

9
Operating instructions
Take care to avoid injury to
hands when in the vicinity of
closing mechanical parts 1.
Support the shower table using your hand or body when folding it down, to
avoid the risk of damage.
The built-in gas cylinders make it easy to fold the shower table up against the
wall after use.
1
1
www.max-ability.com
800.577.1555 [email protected]

10
1
Click
Click
To pull the safety rail up:
Turn the locking knob ①
Turn the knob one way or
another to release the safety
rail.
Lift the safety rail upwards
until you hear a click
indicating that it is locked.
To fold the safety rail away:
Turn the locking knob ① Turn the knob one way or another to release the
safety rail. Push the safety rail back to the underside of the table until you hear
a click indicating that is is locked.
NOTICE
If the locks does not release when turning the release knob, gently lift the
rail, to take the weight off the locking mechanism. This will ensure the
release of the locks.
800.577.1555 [email protected]

11
The end pad can be used as a head support for
increased comfort.
Use the cut-out grip ① to lift the pad. Fold the
metal bracket ② down to hold the pad in the
upright position.
The end pads are interchangeable and can be
placed at either end of the table.
1
2
Head support
!CAUTION
Never let a person lie on the shower table without
the pads in place. The tray under the pads is
for water collection only. It is not to be used as
a bathtub. Risk of user injury and damage to
product.
1
www.max-ability.com
800.577.1555 [email protected]

12
Cleaning
Clean the shower table after each use. Use ordinary soapy water. Rinse off
with fresh water and dry with a soft cloth.
Do not leave the pads soaked in water. Remove the pads and dry the water
collection tray ①. Use the cut-out grips ②when lifting the pads.
1
IMPORTANT
• Do not use an autoclave or other type of steam cleaner.
• Avoid aggressive cleaning agents containing acids or chloride.
• Never spray the shower table directly with a high pressure cleaner.
• Avoid use of aggressive, abrasive, corrosive or chloride-based cleaning or
disinfecting products.
2
2
2
2
www.max-ability.com
800.577.1555 [email protected]

13
To remove limescale
To remove limescale marks on the aluminium parts, use 3 parts 30%
household vinegar to 7 parts water and afterwards wipe the parts with a cloth
wrung out in clean water.
In countries with relatively high levels of lime in the water supply, it may be
necessary to remove limescale deposits from the aluminium parts using a
de-scaling agent such as acetic acid. Test this first on an area that is not visible
when the table is in use.
Disinfection
When using the shower table for multiple patients, it is necessary to both
clean and disinfect the shower table between uses on different patients to
prevent the risk of cross infection.
!CAUTION
Always read the material safety data sheet (MSDS) and supplied
instructions of the cleaning, disinfecting or de-scaling agent and
comply with instructions for safe use, dilution, rinsing, drying,
handling and storage of the agent.
www.max-ability.com
800.577.1555 [email protected]

14
Maintenance
Expected service life of the shower table is 10 years, provided that
maintenance is carried out as described below:
It is recommended that maintenance inspection is done one a year.
Maintenance inspection
• Check the hinges ①on the
table and the safety rail ②.
Tighten if necessary.
• Check the pads ③for damage
and replace if necessary.
1
1
2
2
3
4
• Check the drain pipe
connections ④, and check
and clean the water trap (if
fitted).
www.max-ability.com
800.577.1555 [email protected]
Verify your purchase details before carrying out repairs so you don’t void your warranty:
We guarantee all product components against manufacturing defects for five years, and
parts repair/labor for one year, from the invoice date. In most instances the affected parts
are replaced, not repaired.
Parts damaged due to improper product assembly, installation, or procedure; lack of
recommended maintenance including cleaning; or lost after delivery cannot be included in
this warranty.

15
Trouble-shooting
Symptom Cause Action
does not stay in
upright position.
One or more gas
cylinders are defective. .
The water does not
run out of the water
collection tray.
Adjustment screws too
high or too low.
Adjust the adjustment
screws 1.
Technical data
Max load
Materials Powder-laquered stainless steel
Aluminium
Plastics
Mattress surface: Polyurethane foam
Dimensions
(width x length)
R8435313: 967 x 1410 mm / 38.07 x 55.51 inches
R8435318: 967 x 1910 mm / 38.07 x 75.19 inches
Weight R8435313: 58,31 kg / 128.55 lbs
R8435318: 64,10 kg / 141.31 lbs
1
440 lbs
www.max-ability.com
800.577.1555 [email protected]
The changing table
Contact MAX-Ability.

16
Disposal and recycling
The unit contains reusable materials. There are no known hazards or risks
associated with disposal of the product. All components can be discarded
after having been cleaned and disinfected.
When disposing of the product, we recommend that it be disassembled and
broken down into different waste groups for recycling or combustion.
The following table provides information on the recycling and handling of the
product.
Recyclable
components Material
Aluminium Aluminium is theoretically 100% recyclable without
any loss of its natural qualities. It requires only 5% of
the energy used to produce primary aluminium. The
quality of recycled aluminium is so high that it can
be used again and again, even in the case of anodised
products as the anodised layer is a natural part of the
aluminium.
Steel Steel can be recycled by being re-melted and included
as a secondary material in the production of new
steel.
PVC and
polystyrene
Hard PVC is granulated and re-melted.
Use plastic sorting and recycling systems where they
are locally available, otherwise incinerating plastic
has the added benefit of generating energy, which can
be used for, for example, combined heat and power
production.
Polyurethane Like other plastics, polyurethane can be recycled in
two primary ways: mechanical recycling, in which the
material is reused in its polymer form, and chemical
recycling that takes the material back to its various
chemical constituents.
www.max-ability.com
800.577.1555 [email protected]
