Max MB-1000C-NA Reference guide

Binding Finisher
MB-1000C-NA
MB-1000C-EU
Installation Procedure
When installing this product, follow these instructions.
(Make sure to perform the actual work with at least 2 people.)
NOTE : THE FINISHER MUST BE INSTALLED BY A CUSTOMER SERVICE REPRESENTATIVE WHO HAS
COMPLETED THE TRAINING COURSES ON THE BASE COPIER AND THE UNIT.

Read this first
1
These Installation Procedure instructions use indications to help you safely perform
installation. The meaning of each indication is explained below.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Emphasizes essential information.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
WARNING
CAUTION
About indications

Ring opener
Rebinding board
Interface cable
Upper side cover
Lower side cover
Slope
Finisher door cover
Tapping screw 3x6
Spanner 24-19
Equipment/Accessories Equipment/Accessories
No. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Warranty/Guarantee card (NA only)
DFD docking bracket for upstream
DFD docking bracket for down
Operation manual
+Screw 4×6
Installation procedure
AC power cord
Cartridge label
Cartridge
CD (Operation manual)
1
1
1
1
1
2
1
11
1
1
1
1
1
7
1
1
1
1
1
Checking supplied items
7
11
19
10
1 2
4
6
5
18
9
8
13
16
12
3
17
14 15
2
* This is already installed
in the unit.
20
Safetyinformation
20 1
* NA only

Installation space
The dimensions in the diagram below indicate the minimum amount of space that is
necessary.
300mm
or
more
900mm
or
more
DOWN UP
(860mm)
3
If this unit is the last downstream unit, leave the space indicated below open.
UP
30mm or more

(2) Remove the included items.
(1) Remove the cover of the cardboard box.
Cut the plastic band and remove
the cover of the cardboard box.
(3) Remove the side cover of the cardboard box, and then remove the upper cover of
the cardboard box.
(4) Remove the tape at the top of the plastic cover, and then open and pull down the
plastic cover.
Remove all of the included items.
Remove the side cover of the
cardboard box.
Remove the upper cover of the
cardboard box
Directions for opening the cardboard box
4

(5) Cut the tape at the bottom 4 corners of the cardboard box and open the corners.
(6) Extend the length of the 4 casters at the bottom.
(7) Secure the casters into place.
When the base of the product is 100 mm from the base of the cardboard box, secure the
upper nut by rotating it anticlockwise.
Position after unboxing Extend the caster by rotating
the lower nut clockwise.
Use the supplied spanner to
loosen the upper nut by rotating it
clockwise. (View from the top)
100mm
5

(9) Remove the cardboard from the upper side.
(10) Place the supplied slopes at the 2 locations on the upper side indicated in the illustration.
Remove the cardboard from the
upstream side by cutting at the
locations indicated with dotted lines. There are no dotted lines on the actual
cardboard box.
Slope
(8) Remove the 2 pieces of cardboard packaging from the bottom center of the product.
There two locations are at the front and back.
Align the edge of the slope with the position indicated by the arrow.
6

(11) Lower the product from the upper side.
(12) Check that the heights of the entrance and exit are 860 mm from the floor.
Make sure to hold the product by the locations indicated with dotted lines.
If the heights are not 860 mm,
perform steps (6) and (7).
Perform adjustments based on the
floor of the installation area.
860mm
860mm
CAUTION
7

(3) Remove the tape.
(1) Remove the 2 brackets from the upstream side.
(2) Remove the bracket from below the right door.
Remove the 4 screws.
Remove the 4 screws.
Remove the 2 screws.
(4) Open the right door, and remove the bracket from the bottom of the right door.
Check that all connected devices are turned OFF, and that the power plug is disconnected from
the power outlet.
Directions for installing the Binding Finisher
Remove the 2 screws.
WARNING
8

(5) Open the doors and remove the tape and cushion.
(6) Attach the Upper side cover to the upper side.
· Remove the binder unit. (A)
· Remove each piece of tape.
· Open the door and pull out the
cartridge. (B)
· Remove the cushion inside.
· Tighten the upper-right screw first.
Tapping screw 3×6
A
B
9

(7) Attach the Lower side cover to the downstream side.
(8) Open the supplied cardboard box.
(9) Attach the DFD docking bracket for upstream to the bottom of the upper side.
Tighten the screws in the order indicated above.
Secure these 4 locations with
screws.
Insert this into the holes in the top. Hang it on the hooks.
Tapping screw 3×6
screw 4×6
Base
(1)
(3)
(4)
(2)
· Tighten the upper-right screw first.
10

(10) Insert the Cartridge label into the cartridge.
11

If there are devices connected to the downstream unit side (refer to the installation
manual of the downstream unit)
Secure these 3 locations with screws.
(1) If using a DFD-specification downstream unit, attach the DFD docking bracket for down to
the bottom of the downstream side.
(2) If using a Canon V-series FINISHER
(1)
(2) (3)
Tapping screw 4×6
Align the unit embossment and the holes of the FINISHER Door Cover, and secure the 3
locations with screws.
Tapping screw 3×6
Secure these 3 locations
with screws.
Align this with the holes in the embossment.
12
Insert this into the holes in the top. Hang it on the hooks.
Base

(1) Remove the screw from the DFD docking bracket.
(2) Connect the unit to the upstream unit.
(3) Lock the connector and secure it.
Remove the screw. Pull it forward.
Push the lever all the way inward. Secure it with a screw.
Connecting the Binding Finisher to the upstream unit
13

(4) From behind the unit, connect the power cord and the cable for the upstream unit.
Check that the ground fault breaker switch is set to the right position, and connect the power cord.
Connect the power cord.
Secure these 2 locations
with screws.
Connection with
upstream unit
Connection with
downstream unit
Object/part No. technical data
Power Supply Cord (for EU)
Detachable SVT type, maximum 4.5 m long,
minimum 125V, 10A. One end terminates in
parallel-blade (NEMA 5-15P) attachment plug,
other end in appliance coupler.
CAUTION
The soket-outlet shall be installed near the equipment and be easily accesible.
14

If there is any downstream finishing unit after the Max binder, it is imperative
that you perform the following procedure.
(1) Press the power switch to turn on the power and close the front door.
(3) If "Pass Code?" is displayed, press the SET key, enter 5050 for the number area currently
displayed as 0000 by using the arrow keys, and press the SET key.
(4) Press the up and down arrow keys to select "Bypass Speed", and press the SET key.
If the cursor is displayed in the number area, enter values based on the downstream unit by
using the arrow keys, and press the SET key. (The unit of speed is mm/sec.)
Adjust the bypass speed setting depend on the main printer device.
Refer to “LCD Display and Special operation” in the service manual for more information
on connectable devices and the value of the bypass speed.
LCD
Set this to the up
position.
(2) Press the left key when "Bind", "Bypass" or "Punch" is displayed in the operation panel's LCD.
15

(7) Press the ESC key 2 times, and check if "Bind", "Bypass" or "Punch" is displayed in the LCD
to complete the procedure.
CAUTION
Input values by following the settings of the downstream unit.
· To update the software version, refer to the service manual.
·If the punch location and the ring location are not aligned, refer to the side register adjustment in
the service manual.
(5)Press the up and down arrow keys to select “Bypass Type?” and press the SET key.
(6) Press the up and down arrow keys to select “Non-DFD” and press the SET key. If this is set
to any other selection you will get a message on the varioPRINT UI “Check Max Binder”
If the center of the upstream unit transfer and the center of the Binding Finisher transfer are
unaligned, paper jams or binding problems may occur. Perform the following check and
adjust the unaligned equipment.
How to Check the Alignment
(1) If the Binding Finisher is the unit fartherst downstream, go to (3).
(2) Separate the unit on the downstream side and check from the downstream side of the Binding
Finisher.
(3) When using the Binding Finisher's "Bind" or "Punch" to print or bind, the paper should be visible
as in the illustration below. (The mark for A4 size paper is on the left and the mark for LT size
paper is on the right.)
When using A4 paper, if the edge of the paper is off of the center baseline by two marks, as in the
illustration below, the center of the transfer is off of the baseline by 4 mm, towards the back.
Center baseline
Center baseline
LT size paper mark A4 size paper mark
16

17
How to Adjust the Alignment
(1) Separate the upstream unit and the Binding Finisher. (See page 13.)
(2) Remove screw 1from the DFD docking bracket and loosen screws 2, 3, and 4.
(3) Slide the DFD docking bracket to the back side and the front side, and align it with the center.
(4) Tighten 3 screws (screw 2, 3, and 4), and see page 13 to connect the unit to the upstream
unit.
As a screw will be
leftover, be sure to
keep it in storage.
2
3
4
2
3
4
1
If the Binding Finisher is set up to eject finished documents to the right
With some copiers, the Binding Finisher can be set up to eject finished documents to the right.
This requires changes to parts and the control software.
Documents ejected to the left Documents ejected to the right
After
changes

― 18 ―
The Bypass mode cannot be used when the Binding Finisher is set up to eject finished
documents to the right.
Caution
Comparison of specifications
Document ejection direction
Incoming sheet rate
Internal feeding rate
(Bypass)
Internal feeding rate
(Binding/Punching)
Upstream unit
Max. supported printing
speed
Downstream unit
Available
modes
Bypass
Binding
Punching
Document ejection to left
To left
920
105
950-1600
1030
Stacker
None or finisher
To right
920
105
1030
Stacker
None
Document ejection to right
mm/s
ppm
mm/s
mm/s

― 19 ―
Parts for conversion to document ejection to the right
Parts to be changed out or added
Safety precaution
The Finisher must be installed by a customer service representative who has
completed the training courses on the base copier and the unit.
Right side cover
Docking bracket
Docking bracket
Top transfer guide
Bottom transfer guide
Add because FB is farthest downstream unit
Change because upstream unit is on other side
Install because documents are transferred in opposite direction
Install because documents are transferred in opposite direction
Right side cover
Top transfer guide
Bottom transfer guide
Part Note
