GBC Magnapunch 2.0 User manual

Magnapunch 2.0
Heavy Duty Punch
INSTALLATION & OPERATION MANUAL
MANUAL DE INSTALACIÓN Y FUNCIONAMIENTO
MANUEL D’INSTALLATION ET D’UTILISATION
Document Number: 80120510 Rev. A
Do not duplicate without written permission from ACCO Brands.

Magnapunch 2.0 – Installation and Operating Instructions
Page i
ACCO Brands reserves the right to make changes
to this publication and to the products described in
it without notice. All specifications and information
concerning products are subject to change without
notice. Reference in this publication to information or
products protected by copyright or patent does not
convey any license under the rights of ACCO Brands
or others. ACCO Brands assumes no liability arising
from infringements of patents or any other rights of
third parties.
This publication is copyrighted © 2011 by ACCO
Brands. All rights reserved.
© 2011 ACCO Brands. All rights reserved. ACCO® is a registered trademark of
ACCO Brands. GBC® is a registered trademark of General Binding Corporation.
80120510 Rev. A 11-2011
ACCO Brands Canada
5 Precidio Court
Brampton, ON L6S-6B7
800.263.1063
www.gbccanada.com
ACCO Mexicana
Neptuno #43, Colonia Nueva Industrial Vallejo
Delagacion Gustavo A. Madero, CP 07700
México, DF. (55) 1500-5578
www.gbc.com.mx
Co n v e n t i o n s Us e d in t h i s
Ma n U a l
The Magnapunch 2.0 features menu driven operation
from an LCD user interface. Menu selections and
commands appear in bold. For example:
On the Language Setup menu, press UP or DOWN
to scroll to the desired language.

Page ii
Magnapunch 2.0 – Installation and Operating Instructions
1. Safety 1-1
General Safeguards ................................................1-1
Die Set Cautions .................................................1-2
Electrical..................................................................1-2
For 230 Volt Machines Only................................1-2
GBC Technical Service .......................................... 1-3
Safety Label Locations .......................................... 1-4
2. Warranty 2-1
Limited 90-Day Warranty ........................................2-1
3. Specifications 3-1
Punching Dimensions ........................................ 3-2
FCC Class A Notice ............................................... 3-4
Canada Class A Notice - Avis Canada, Classe A .. 3-4
Modifications.......................................................... 3-4
4. Installation 4-1
GBC Technical Service .......................................... 4-1
Prior to Installation ................................................. 4-1
Installation .............................................................. 4-1
Testing................................................................ 4-1
5. Feature guide 5-1
Power ..................................................................... 5-1
ON/OFF Switch.................................................. 5-1
Fuse ................................................................... 5-1
Power and Foot Pedal Connectors.................... 5-1
Punching Throat..................................................... 5-1
Lift Picker ............................................................... 5-2
User Interface......................................................... 5-2
LCD .................................................................... 5-2
Push Buttons ..................................................... 5-2
Edge Guide and Tabletop Trigger .......................... 5-2
Edge Guide ........................................................ 5-2
Tabletop Trigger ................................................. 5-3
Punching Table....................................................... 5-3
Chip Drawer ....................................................... 5-3
Die Set ............................................................... 5-3
Foot Pedal.......................................................... 5-3
6. Operation 6-1
User Interface......................................................... 6-2
Navigation.......................................................... 6-2
First Time Setup................................................. 6-2
Operation ............................................................... 6-3
Home Screen ..................................................... 6-3
Menu .................................................................. 6-4
Usage Instructions............................................. 6-4
Help + Tips......................................................... 6-5
Notification Screens .......................................... 6-5
Changing the Interchangeable Die Sets ................ 6-6
Removing Die Sets ............................................ 6-6
Installing Die Sets .............................................. 6-6
Removing Punch Pins........................................ 6-7
Job Setup............................................................... 6-7
Using the LCD User Interface............................ 6-7
Testing the Job .................................................. 6-9
Punching Operation ..............................................6-10
Punching the Job..............................................6-10
Punch Activation ...................................................6-11
Foot Pedal.........................................................6-11
Tabletop Trigger ................................................6-11
Punching Tips ......................................................6-12
Paper.................................................................6-12
Plastic Covers...................................................6-12
Chip Drawer ......................................................6-12
Hole Quality...........................................................6-13
7. Operator Maintenance 7-1
Caring for the Magnapunch 2.0 ..............................7-1
Die Set Maintenance .........................................7-1
Cleaning the Magnapunch 2.0............................7-1
Troubleshooting ......................................................7-2
Notes 7-3
Ta b l e o f Co n T e n T s

Magnapunch 2.0 – Installation and Operating Instructions
Page iii

Page 1-1
Magnapunch 2.0 – Installation and Operating Instructions
Your safety, as well as the safety of others is
important. Before you install or use the Magnapunch
2.0, read and follow all the safety notices carefully
in this chapter. In this instruction manual, and on
the Magnapunch 2.0, you will find important safety
notices regarding the Magnapunch 2.0. Read all
of the instructions and save these instructions for
further use.
The safety alert symbol precedes each
safety notice in this manual. The symbol indicates a
potential personal safety hazard to you or others.
This safety alert symbol indicates a potential
electrical shock. It warns you not to open the
Magnapunch 2.0 and expose yourself to hazardous
voltage.
The following warnings are found on the
Magnapunch 2.0.
This safety notice means that you could be seriously
hurt or killed if you open the Magnapunch 2.0 and
expose yourself to hazardous voltage. Do not open
the Magnapunch 2.0. There are no user serviceable
parts inside. Refer service to qualified service
personnel.
This safety notice means that a
fire or risk of electrical shock
could result from using an
improper fuse. For continued
protection against fire or risk of
electrical shock, replace only
with the same type and rating
fuse.
WaRninGs
Do not attempt to service or repair the•
Magnapunch 2.0.
Do not open the Magnapunch 2.0. There are•
no serviceable parts inside. Refer service to
qualified service personnel.
Do not connect the Magnapunch 2.0 to an•
electrical supply or attempt to operate the
Magnapunch 2.0 until you have completely
read these instructions. Maintain these
instructions in a convenient location for future
reference.
To guard against injury, the general safety•
precautions must be observed when installing
and using the Magnapunch 2.0.
Ensure the Power switch is in the OFF position•
when the Magnapunch 2.0 is not in use.
Consider the work area. A cluttered work area•
can lead to accidents. The Magnapunch 2.0
must be placed on a sturdy level table surface.
Allow sufficient access to the front, back, and
sides of the Magnapunch 2.0. Keep the work
area well lit.
Failure to observe these warnings could result in
severe bodily damage or death.
Ge n e R a l sa f e G U a R d s
Do not use the Magnapunch 2.0 for other than•
its intended purposes.
Do not defeat or remove electrical and•
mechanical safety equipment such as
interlocks, shields, and guards.
Do not insert objects unsuitable for punching•
or expose the equipment to liquids.
Use only GBC Magnapunch 2.0•
interchangeable Die Sets with the
Magnapunch 2.0.
Before you operate this Magnapunch 2.0, it is•
important that you read and understand the
entire contents of these instructions.
1. sa f e t y

Magnapunch 2.0 – Installation and Operating Instructions
Page 1-2
die se t Ca U t i o n s
CAUTIONS:
Possible pinch point hazard. When installing Die•
Sets into your Magnapunch 2.0, always keep
fingers and body parts out of the Magnapunch
2.0’s Die Set slot and away from all areas of the
Die Set except for the finger groove in the Die
Set’s handle. Failure to observe these precautions
may result in injury.
Possible Die Set damage. Make certain that all•
punch pins are fully and properly seated in the Die
Set before inserting the Die Set. Failure to ensure
that all punch pins are fully seated could result in
damage to the Die Set and Magnapunch 2.0.
el e C t R i C a l
The Magnapunch 2.0 should be connected only to
a source of power as indicated in these instructions
and on the nomenclature plate located on the rear of
the Magnapunch 2.0. Contact an electrician should
the attachment plug provided with the Magnapunch
2.0 not match the receptacles at your location.
WARNING: Do not attempt to service or repair
the Magnapunch 2.0. Failure to observe this warning
could result severe personal injury or death.
Make sure the power switch is in the Off position
when the Magnapunch 2.0 is not in use.
Disconnect the plug from the receptacle and contact
your dealer or distributor, or GBC Technical Service
when one or more of the following has occurred.
The power supply cord or attachment plug is•
damaged.
Liquid has been spilled into the Magnapunch•
2.0.
The Magnapunch 2.0 is malfunctioning.•
The Magnapunch 2.0 does not operate as•
described in these instructions.
CAUTION: The receptacle must be located
near the Magnapunch 2.0 and must be easily
accessible.
Disconnect the attachment plug from the receptacle
to which it is connected and keep the power
supply cord in your possession while moving the
Magnapunch 2.0.
fo R 230 vo l t Ma C h i n e s on l y
CAUTION: When choosing a detachable
line cord for use with your Magnapunch 2.0, always
observe the following.
The cordset consists of three parts;•
attachment plug, cordage, and appliance
inlet. Each of these components must have
European regulatory approvals for safety.
The following minimum electrical ratings•
for the specific cordset are published for
safety purposes. Do not use cordsets that
do not meet the following minimum electrical
requirements.
Plug: 10 amperes, 250 volts, 50/60 Hz,
European safety approved.
Cordage: Type HO5VV-F3G0.75, harmonized
( HAR ). The symbols indicate cordage
approved to appropriate European standard.
Note, HAR may be substituted by the approval
mark of the European Safety agency which
approved the cordage. An example would be
VDE .
Appliance Connector: 10 amperes, 250 volts,
50/60 Hz, European safety approved, Type IEC
320.
The cordset shall not exceed 3 meters in
length. A cordset with component electrical
ratings greater than the minimum specified
electrical ratings may be substituted.

Page 1-3
Magnapunch 2.0 – Installation and Operating Instructions
GBC te C h n i C a l se R v i C e
To order replacement accessories, service, parts,
or an Equipment Maintenance Agreement, please
contact GBC Technical Service and Support at:
United States
GBC Technical Service and Support – 3rd Floor
ACCO Brands
300 Tower Parkway
Lincolnshire, IL 60069
www.gbcconnect.com
1-800-723-4000
Canada
ACCO Brands Canada
5 Precidio Court
Brampton, ON L6S-6B7
www.gbccanada.com
[e-mail]
1-800-463-2545
Mexico
ACCO Mexicana
Neptuno #43, Colonia Nueva Industrial Vallejo
Delagacion Gustavo A. Madero, CP 07700
México, DF. (55) 1500-5578
www.accomexico.mx/index.php
(5525) 1500-5741
Other Sources
For service facilities in other regions, please visit:
www.gbcconnect.com/contact_us.aspx
Also use your mobile phone to scan the QR code
on the side of the Magnapunch 2.0 for a list of
authorized service providers.

Magnapunch 2.0 – Installation and Operating Instructions
Page 1-4
sa f e t y la B e l lo C a t i o n s
Magnapunch 2.0 Safety Label Locations.Figure 1.

Page 2-1
Magnapunch 2.0 – Installation and Operating Instructions
2. Wa R R a n t y
li M i t e d 90-da y Wa R R a n t y
ACCO Brands USA LLC, 300 Tower Parkway,
Lincolnshire, IL 60069 (in Canada, ACCO Brands
Canada Inc., 5 Precidio Court, Brampton, ON
L6S-6B7; and in Mexico, ACCO Mexicana, S.A. de
C.V. Av., Circuito Industrial Norte #6 Parque Industrial
Lerma 52000, Lerma Edo. De México) (each,
respectively, “ACCO Brands”) warrants to the original
purchaser that this Magnapunch 2.0 ACCO Brands
product is free from defects in workmanship and
material under normal use and service for a period of
90 days after purchase.
ACCO Brands’ obligation under this warranty is
limited to replacement or repair, at ACCO Brands’
option, of any warranted part found defective by
ACCO Brands without charge for material or labor.
Any replacement, at ACCO Brands’ option, may be
the same product or a substantially similar product
that may contain remanufactured or refurbished
parts. This warranty shall be void in the following
circumstances:
(i) if the product has been misused,
(ii) if the product has been damaged by negligence
or accident, or
(iii)if the product has been altered by anyone other
than ACCO Brands or ACCO Brands’ authorized
agents.
For warranty execution, please contact ACCO
Brands at:
1-800-541-0094 or www.gbcconnect.com in the
USA
800-263-1063 or www.gbccanada.com in Canada
(55) 1500-5578 or www.gbc.com.mx in Mexico
TO THE EXTENT ALLOWED BY APPLICABLE
LAW, THIS WARRANTY IS IN LIEU OF ALL OTHER
EXPRESSED WARRANTIES. REPRESENTATIONS
OR PROMISES INCONSISTENT WITH OR
IN ADDITION TO THIS WARRANTY ARE
UNAUTHORIZED AND SHALL NOT BE BINDING ON
ACCO BRANDS. TO THE EXTENT PERMITTED BY
APPLICABLE LAWS, ANY IMPLIED WARRANTIES
(IF APPLICABLE) ARE LIMITED IN DURATION
TO THE DURATION OF THIS WARRANTY.
SOME STATES AND JURISDICTIONS DO NOT
ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU. TO THE
EXTENT PERMITTED BY APPLICABLE LAW, IN
NO EVENT SHALL ACCO BRANDS BE LIABLE
FOR ANY SPECIAL, INCIDENTAL, PUNITIVE,
EXEMPLARY, CONSEQUENTIAL OR SIMILAR
DAMAGES, WHETHER OR NOT FORESEEABLE.
SOME STATES AND JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF
SPECIAL, INCIDENTAL, PUNITIVE, EXEMPLARY,
CONSEQUENTIAL, OR SIMILAR DAMAGES, SO
THE ABOVE EXCLUSION OR LIMITATION MAY NOT
APPLY TO YOU.
FOR CONSUMERS WHO HAVE THE BENEFIT
OF CONSUMER PROTECTION LAWS OR
REGULATIONS IN THEIR JURISDICTION OF
PURCHASE OR, IF DIFFERENT, IN THEIR
JURISDICTION OF RESIDENCE, THE BENEFITS
CONFERRED BY THIS WARRANTY ARE IN
ADDITION TO ALL RIGHTS AND REMEDIES
CONVEYED BY SUCH CONSUMER PROTECTION
LAWS AND REGULATIONS.
To the extent permitted by law, this warranty is
not transferable and will automatically terminate if
the original product purchaser sells or otherwise
disposes of the product.
This warranty gives you specific legal rights. Other
rights, which vary from jurisdiction to jurisdiction,
may exist. In addition some jurisdictions do not allow
(i) the exclusion of certain warranties, (ii) limitations
on how long an implied warranty lasts and/or (iii) the
exclusion or limitation of certain types of costs and/
or damages, so the above limitations may not apply.

Magnapunch 2.0 – Installation and Operating Instructions
Page 2-2

Page 3-1
Magnapunch 2.0 – Installation and Operating Instructions
Item Specification
Punch Pattern
Plastic Binding•
Plastic Color Coil, GBC and•
Industry standard 4:1 (C4)
Plastic Color Coil, 5:1 (C5)•
Twin Loop Wire, 2:1 (W2)•
Twin Loop Wire, 3:1 (W3)•
VeloBind•
SureBind•
3 or 4 Hole Binding•
Maximum number of sheet punch capacity for 20 lb. (75 g/m2) bond.
39
29
29
29
34 (round) 29 (square)
34 (round) 29 (square)
49
49
34
Dimensions
Width•
Height•
Depth•
18.5 in. (47.0 cm)
12.0 in. (30.5 cm)
20.0 in. (50.8 cm)
Weight
Machine•
Shipping•
94 lbs. (42.4 kg)
116 lbs. (52.6 kg)
Electrical Requirements
Fuse (F1 T1A 250V)•
Voltage•
Current•
Power•
U.S. Receptacle•
US Model
20A, 250V
115 VAC
5.6 Amperes maximum, 50/60
Hz
644 W
NEMA 5-15R
Refer to the nomenclature
plate located on the rear of the
Magnapunch 2.0 for the specific
electrical rating applicable to the
unit.
Europe Model
20A, 250V
230 VAC
3.5 Amperes maximum, 50/60 Hz
805 W
YP-24 R
Refer to the nomenclature plate located
on the rear of the Magnapunch 2.0 for the
specific electrical rating applicable to the
unit.
Noise Level 94dB when punching maximum pages of media.
Under 2003/10/EC on the minimum health and safety requirements regarding
the exposure of workers to the risks arising from physical agents (noise), the
following sound pressure levels require the following action by employers:
80dB employers must make hearing protection available to workers.•
85dB a hearing protection warning sign must be displayed.•
87dB individual hearing protection shall be used by workers.•
Motor 1/4 HP
3. speCifiCations
Dimension Reference.Figure 2.
Width
Depth
Height
Height
Width Depth

Magnapunch 2.0 – Installation and Operating Instructions
Page 3-2
pU n C h i n G di M e n s i o n s
Punch Pattern Maximum Punch Length Number of Punch Pins Center to Center Hole
Spacing
Plastic binding 14 in. (356 mm) 25 0.5625 in. (14.29 mm)
Plastic Color Coil, GBC 4:1 (C4) 14 in. (356 mm) 55 0.2475 in. (6.29 mm)
Plastic Color Coil, industry
standard 4:1 (C4)
14 in. (356 mm) 55 0.25 in. (6.35 mm)
Plastic Color Coil, 5:1 (C5) 14 in. (356 mm) 69 0.20 in. (12.70 mm)
Twin loop wire 2:1 (W2) 14 in. (356 mm) 27 0.50 in. (12.70 mm)
Twin loop wire 3:1 (W3) 14 in. (356 mm) 41 0.3333 in. (8.47 mm)
ProClick 3:1 square 12 in. (305 mm) 34 0.3333 in. (8.47 mm)
VeloBind®15 in. (381 mm) 14 1.0 in. (25.40 mm)
SureBind®14 in. (356 mm) 12 Varies
3 or 4 hole binding Varies Up to 7 or 4 Varies

Page 3-3
Magnapunch 2.0 – Installation and Operating Instructions

Magnapunch 2.0 – Installation and Operating Instructions
Page 3-4
fCC Cl a s s a no t i C e
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful•
interference.
This device must accept any interference•
received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation
of this equipment in a residential area is likely to
cause harmful interference in which case the user
will be required to correct the interference at his own
expense.
Canada Cl a s s a no t i C e - avis
Canada, Cl a s s e a
This Class A digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
Mo d i f i C a t i o n s
Any modifications made to this device that are not
approved by ACCO Brands Corporation may void the
authority granted to the user by the FCC and/or by
Industry Canada to operate this equipment.
Toutes modifications apportées à ce dispositif et
non approuvées par ACCO Brands Corporation
annuleront le droit accordé à l’utilisateur par le FCC
et/ou par Industrie Canada de faire fonctionner cet
équipement.

Page 4-1
Magnapunch 2.0 – Installation and Operating Instructions
WARNING: Do not attempt to service or repair
the Magnapunch 2.0. Failure to observe this warning
could result in severe personal injury or death.
Disconnect the plug from the receptacle and contact
GBC Technical Service when one or more of the
following has occurred.
The power supply cord or attachment plug is•
damaged.
Liquid has been spilled into the Magnapunch•
2.0.
The Magnapunch 2.0 is malfunctioning.•
The Magnapunch 2.0 does not operate as•
described in these instructions.
GBC te C h n i C a l se R v i C e
United States
1-800-723-4000
Canada
1-800-463-2545
Mexico
(5525) 1500-5741
Other Sources
For service facilities in other regions, please visit:
www.gbcconnect.com/contact_us.aspx
Also use your mobile phone to scan the QR code
on the side of the Magnapunch 2.0 for a list of
authorized service providers.
pRioR t o in s t a l l a t i o n
Inspect the packaging and Magnapunch 2.0 for
damage. Shipping damage should be brought to the
immediate attention of the delivering carrier.
The Magnapunch 2.0 weighs 94 lbs. (42.4 kg). Two
people are required to lift and move the punch.
in s t a l l a t i o n
To unpack the Magnapunch 2.0:
Cut the plastic shipping straps and the packing1.
tape.
Remove the Magnapunch 2.0 from the shipping2.
carton. Use the cut outs in the cardboard base
pad to indicate where to place your hands.
To set up the Magnapunch 2.0 for the first time:
Place the Magnapunch 2.0 on a stable flat1.
surface capable of supporting the weight of the
Magnapunch 2.0. An additional work surface
near the Magnapunch 2.0 is recommended for
items to be punched.
The Magnapunch 2.0 should be located near the2.
electrical power with sufficient space behind and
above it to allow for ventilation. Adequate space
above the punch is required to open the top lid
and for staging the paper to be punched.
Connect the attachment plug provided with the3.
Magnapunch 2.0 to a suitably grounded outlet
only. Avoid connecting other equipment to the
same branch circuit to which the Magnapunch
2.0 is connected, as this may result in nuisance
tripping of circuit breakers or blowing fuses.
Connect the Foot Pedal to the rear of the4.
Magnapunch 2.0 and place the Foot Pedal on the
floor within easy reach of your foot.
te s t i n G
After the Magnapunch 2.0 has been properly
installed, it must be tested to ensure proper
operation.
Notes:
The first time the Magnapunch 2.0 is•
powered-up, a setup screen appears. Select
the language and then measurement units.
Language setup screen.Figure 3.
A Die Set must be installed before running the•
Magnapunch 2.0.
To test the Magnapunch 2.0:
Punch 10 sheets of 20 lb. (75 g/m1. 2) bond paper
in one lift.
Punch five sheets of 20 lb. (75 g/m2. 2) bond paper
to check for a clean hole punch.
If using a PB Die Set, Punch 10 sheets of 20 lb.3.
(75 g/m2) bond paper at each back gauge setting
to ensure three distinct positions.
4. in s t a l l a t i o n

Magnapunch 2.0 – Installation and Operating Instructions
Page 4-2

Page 5-1
Magnapunch 2.0 – Installation and Operating Instructions
po W e R
on/off sW i t C h
Use the ON/OFF switch to turn the Magnapunch
2.0 on and off. Press the ON/OFF switch to the I
position to turn the Magnapunch 2.0 On. Press
the ON/OFF switch to the Oposition to turn the
Magnapunch 2.0 Off.
fU s e
One fuse protects the Magnapunch 2.0 and its
electrical components from current that is higher
than the Magnapunch 2.0 is rated for.
CAUTION: For continued protection against
fire or risk of electrical shock, replace only with the
same type and rating fuse.
To replace a fuse, insert a flat blade screwdriver
into the fuse cover, push, and then turn counter-
clockwise. Replace the fuse, insert into the fuse
holder, and turn it clockwise.
5. fe a t U R e G U i d e
Magnapunch 2.0 Identification.Figure 4.
This chapter helps you identify the main components of the Magnapunch 2.0.
po W e R a n d fo o t pe d a l Co n n e C t o R s
Connections on Back of Magnapunch 2.0.Figure 5.
The Power Cord plugs into a standard US 115 VAC
NEMA 5-15R (European 230 VAC YP-24 10 to 16
Amp) wall outlet.
pU n C h i n G th R o a t
The Punching Throat is where the media’s edge to be
punched is inserted during the punching process.
NOTE: Do not force more media into the throat than
will fit easily.
PowerFoot Pedal Service port
Fuse
ON/OFF switch
Chip Drawer
User Interface
Punching Table
Edge Guide and
Tabletop Trigger
Die Set
Lift picker
Punching Throat

Magnapunch 2.0 – Installation and Operating Instructions
Page 5-2
li f t pi C k e R
Raise the lid of the Lift Picker to stack media that has
been punched or that is to be punched.
Magnapunch 2.0 with Media in Lift Picker.Figure 6.
Us e R in t e R f a C e
The User Interface (UI) consists of an LCD and four
buttons below the LCD. The LCD displays system
messages and provides access to operational
functions. The push buttons below the LCD are used
to navigate through the menus, select items, and
commit commands.
Start Up Screen.Figure 7.
lCd
The LCD provides continuous status of the
Magnapunch 2.0 and includes step by step
instructions on how to use your Magnapunch 2.0.
pU s h BU t t o n s
The Push Buttons relate to the commands at the
bottom of the LCD. The action of the button may
change depending on the menu on the LCD.
ed G e GU i d e a n d ta B l e t o p
tR i G G e R
Edge Guide and Tabletop Trigger.Figure 8.
ed G e GU i d e
The Edge Guide sets the position for a variety of
punching patterns and paper sizes.
Turn the Edge Guide handle 1/4 turn
counter-clockwise to unlock. Move the Edge Guide
to line up with the desired setting on the Die Set and
then turn the handle clockwise 1/4 turn to lock the
Edge Guide in place.
Edge Guide Unlocked.Figure 9.
Edge Guide
adjustment handle Tabletop Trigger

Page 5-3
Magnapunch 2.0 – Installation and Operating Instructions
ta B l e t o p tR i G G e R
The Tabletop Trigger is incorporated into the Edge
Guide. The Tabletop Trigger is used to automatically
punch without the use of the Foot Pedal. The
Tabletop Trigger is activated on the Home screen of
the User Interface.
Push the stack of media into the Throat and then
slide to the left against the Trigger to activate the
punch.
pU n C h i n G ta B l e
The Punching Table is where you lay the media to be
punched. Place the media on the Punching Table,
push the media into the Throat, and then slide to the
left.
Ch i p dR a W e R
The Chip Drawer collects the paper chips from
the punched media. When the Chip Drawer is full,
a message on the LCD UI alerts you to empty the
drawer.
die se t
The Magnapunch 2.0 offers thirteen different Die
Sets to match the punching requirements for your
documents. To change a Die Set, refer to “Changing
the Interchangeable Die Sets”.
fo o t pe d a l
The Foot Switch is activated on the Home Screen.
When media is inserted into the Punching Throat
and pushed against the Edge Guide, press the Foot
Pedal to activate the punch.
Foot Pedal.Figure 10.

Magnapunch 2.0 – Installation and Operating Instructions
Page 5-4
