Max SN890CH2(CE) Installation and operation manual

SN890CH2(CE)
Pneumatic Nailer
OCT 2014
OPERATING & MAINTENANCE MANUAL
BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE
SAFETY WARNING AND INSTRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE.
WARNING

SN890CH2(CE)
ITEM
PART NO
MATERIAL
DESCRIPTION
ITEM
PART NO
MATERIAL
DESCRIPTION
1
KN12666
Steel
SCREW 5X12
60
KN12616
Rubber
MAGAZINE GUIDE A
2
KN12678
Rubber
EXHAUST GUIDE
61
KK29024
Stainless steel
COMPRESSION SPRING
3
KN12194
Steel
EXHAUST COVER
62
KN12590
Steel
CONTACT BOLT
4
KN12669
Steel
SCREW 6X28
63
KN12652
Rubber
O-RING 1A 1.5X5
5
KN70168
Aluminium
CYLINDER CAP UNIT
64
KN70171
Steel
CONTACT ARM B UNIT
6
KN12720
Stainless steel
COMPRESSION SPRING 2720
65
KN12672
Stainless steel
E-RETAINING RING 5
7
KN12627
Urethane
PISTON STOP
66
KN12624
Polyacetal
NAIL GUIDE B
8
KN12656
Aluminium
HEAD VALE PISTON
67
KN12722
Stainless steel
NAIL GUIDE A
9 KN12650 Rubber O-RING AS568-150 68 KN12716 Stainless steel NAIL COVER
10
KN12645
Rubber
O-RING AS568-142
69
KN12574
Steel
TAIL HANGER
11
KN70142
Stainless steel, rubber
CYLINDER CAP SEAL UNIT
70
CC49411
Steel, nylon
NUT M5
12 KN12613 Rubber O-RING 4.5X48.8 71 KN12715 Nylon TAIL COVER
13
KN70170
Magnesium, steel
MAIN PISTON UNIT
72
KN12667
Steel
SCREW 5X14
14
KN12628
Urethane
CYLINDER SEAL
73
KN12419
Stainless steel
NAIL STOPPER
15
KN12190
Polyacetal
CYLINDER RING
74
KN81072
Aluminium
MAGAZINE
16
KN12649
Rubber
O-RING 1AG100
75
GN12070
Steel
RUBBER WASHER 1.8X6X2
17
KN12648
Rubber
O-RING 1AG70
76
KN12719
Stainless steel
SPIRAL SPRING 2719
18
KN12634
Aluminium
CYLINDER
77
KN12661
Stainless steel
PARALLEL PIN 2661
19
KN12614
Rubber
CHECK PAWL
78
KN12714
Nylon
PUSHER HOLDER
20
KN12193
Rubber
BUMPER
79
KN12712
Steel
PUSHER
21
KN81069
Aluminium
FRAME
80
KN12662
Steel
PARALLEL PIN 2662
22
KN12205
Aluminium
NAME LABEL A
81
KN12622
Nylon
TRIGGER LOCK LEVER
23
KN12206
Aluminium
NAME LABEL B
82
KK23507
Stainless steel
COMPRESSION SPRING 3507
24
KN12671
Steel
SCREW 5X28
83
KN12621
Nylon
TRIGGER LOCK DIAL
25
CN35685
Nylon
END CAP FILTER SA-10
84
KN12723
Polyacetal
SPRING COLLAR
26
KN12436
Aluminium
END CAP
85
KN12573
Nylon
ARM COVER
27
EE31121
Steel
PLANE WASHER 1-5
86
CN31083
Rubber
DUST COVER HOOK
28
KN12643
Rubber
O-RING 1AP12
87
KN12655
Stainless steel
COMPRESSION SPRING 2655
29
KN12644
Rubber
O-RING 1AP20
89
FF21235
Steel
ROLL PIN 3X30
30
KN12636
Polyacetal
TRIGGER VALVE HOUSING
91
KN12420
Stainless steel
NAIL STOPPER B
31
KN12660
Stainless steel
PARALLEL PIN 2660
101
CN32246
Polyacetal
PILOT VALVE
32
KN12642
Rubber
O-RING 1AP6
102
KK24123
Stainless steel
COMPRESSION SPRING 2653
33
KN12646
Rubber
O-RING 1BP7
103
CN35128
Steel
TRIGGER VALVE STEM
34
KN12664
Polyacetal
PILOT VALVE
104
HN10100
Steel
CONTACT LEVER
35
KN12641
Rubber
O-RING 1AP9
105
HS10118
Polyacetal
TRIGGER
36
KN12654
Stainless steel
COMPRESSION SPRING 2654
106
HN10786
Stainless steel
ARM GUIDE PLATE
37
KN12658
Steel
TRIGGER VALVE STEM
107
KN12277
Steel
CONTACT ARM A GUIDE
38
KN12647
Rubber
O-RING 1B 1.4X2.5
108
KN12278
Nylon
ARM GUIDE
39
KN12637
Polyacetal
TRIGGER VALVE CAP
109
KN12276
Steel
CONTACT ARM A
40
KN12635
Steel
CONTACT LEVER B
110
KK33300
Stainless steel
TORSION SPRING 3300
41
KN12630
Steel
CONTACT LEVER A
111
KK23973
Stainless steel
COMPRESSION SPRING 3973
42
KN12401
Polyacetal
TRIGGER
112
KN12653
Stainless steel
COMPRESSION SPRING 2653
43
FF22402
Stainless steel
ROLL PIN 3X16
113
KN12405
Steel, stainless steel
RAFTER HOOK
44
HS10145
Nylon
SWITCH LEVER A
115
BB40027
Steel
SCREW 5X30
45
KN12620
Steel
SWITCH LEVER B
201
KN81070
TRIGGER VALVE KIT
46
CN34500
Stainless steel
SWITCH SPRING
202
KN81073
ARM GUIDE KIT
47
KK23129
Stainless steel
COMPRESSION SPRING 3129
203
KN81074
O-RING KIT
48
KK29025
Stainless steel
COMPRESSION SPRING 9025
204
KN81027
SEQUENTIAL TRIP KIT
49
KN12207
Nylon
ARM GUIDE
206
4009589
Polyethylene terephthalate
NAME LABEL
50
KN12618
Rubber
EXHAUST SEAL
207
4009573
Polyethylene terephthalate
CAUTION LABEL
51
KN12212
Steel
CONTACT ARM A
208
KN81035
RAFTER HOOK KIT
52
KN12651
Rubber
O-RING AS568-144
210
KN12420
Stainless steel
NAIL STOPPER B
53
KN12200
Polyacetal
ADJUST DIAL
211
KN81054
BODY HANGER KIT
54
KN12711
Steel
NOSE
212
KN12676
NAIL GUIDE C
55
KN12668
Steel
SCREW 5X10
213
BB40404
Steel
SCREW 5X16
56
HH12111
Rubber
O-RING 1AG45
57
KN12670
Steel
SCREW 8X28
58
KN12619
Steel
PLANE WASHER 5.1X12X1.2
59
KN12717
Rubber
MAGAZINE GUIDE B
October 2014
