Maxell Momicare MXTS-200CBL User manual

Cordless Low-frequency Pulse Massager
Just place it on
your skin!
Easy massage
◎Be sure to turn of f the power when removing the gel sheet. Failure to do so may result in a strong electric shock.
◎If you feel unwell while using the product, stop using it immediately and consult a doctor. Failure to do so may
result in an accident or poor health.
Safety precautions To use this produc t securely and safely,
be sure to read the User Manual thoroughly before use.
Danger Never use this product in combination with any of the electric medical equipment described below.
1) Self-contained medical equipment such as a pacemaker, 2) life-support electric medical equipment such as an articial
heart-lung machine, and 3) wearable electric medical equipment such as an electrocardiograph.
Failure to follow the above precautions may result in an accident or signicant bodily harm.
Warnings If any of the following conditions apply to you, consult a doctor before using this product.
1) Acute disease, 2) malignant tumor, 3) infectious disease, 4) pregnancy, menstruation, or immediately after having
given birth, 5) cardiac disorder, 6) body temperature of 38°C or higher (fever) [during acute onset of symptoms
(fatigue, chill, blood pressure change, etc.) and debilitating condition], 7) slight anemia, 8) abnormality (infection,
wound, etc.) in the skin of the area to be massaged, 9) abnormal blood pressure, 10) when requiring rest or when
feeling very ill, 11) acute [pain] disorder such as spine fracture, ligament rapture, or torn muscle, 12) perceptual
disorder due to severe peripheral circulatory failure such as diabetes, 13) particular feelings of physical discomfort
other than the above.
Failure to do so may result in an accident or poor health.
Effectiveness/
Efcacy
Relieves stiff shoulders, prevents paralyzed muscle from atrophying,
and provides effective massages. This product is for home use only.
Home-use low-frequency massage device Controlled medical device
◎Connection cable (sold separately)
MX TS-200CBL1P
JAN code: 4902580756666
Major specications
White
Product name
Model
Set contents
Cord length
Weight
Connection cable
MXTS-200CBL
Connection cable x 1
User manual
About 1.2 m
About 14 g
When you’re uncomfortable, just slap it on.
New “MOMICARE”,
the evolution of
convenient massage.
◎Massaging while working
◎Massaging during household tasks
◎Massaging while commuting or long-distance traveling by train
◎Massaging while relaxing at home
Cordless MOMICARE is convenient for massaging while
doing other things in any situation!
Maxell MXTS-MR200 Low-frequency Pulse Massager Catalog KK011-1803 Produced in March 2018
●The product shown in this catalog complies with the Restriction of Hazardous Substances (RoHS) in EU.
●The specications and design of the product shown in this catalog are subject to change without notice due to modication.
●The actual product may dif fer slightly from the photographs shown in this catalog, due to printing requirement s.
●The names, logos, and service marks contained in this catalog are trademarks or registered trademarks of Maxell and
other companies.
●The information contained in this catalog is accurate as of March 2018.
2018.3
Maxell MXTS-MR200 Low-frequency
Pulse Massager Catalog
For global environmental protection, this catalog uses vegetable-oil-based ink.
Contacts
Maxell Contact Us Search
■Maxell product dealer

MOMICARE includes
5 modes and
10 strength settings.
MOMICARE eases stiffness,
pain, and fatigue.
Simple and easy to use
Apply MOMICARE wherever it is needed
White
1-unit pack
I
MXTS-MR200W1P JAN code: 4902580756550
2-unit pack
I
MXTS-MR200W2P JAN code: 4902580756581
Pink
1-unit pack
I
MXTS-MR200P1P JAN code: 4902580756567
2-unit pack
I
MXTS-MR200P2P JAN code: 4902580756598
①MXTS-200GELW2P
MXTS-200GELP2P
MXTS-200GELB2P
②MXTS-200GELFW2P
③MXTS-200GELWW1P
JAN code: 4902580756611
JAN code: 4902580756628
JAN code: 4902580756635
JAN code: 4902580756659
JAN code: 4902580756642
Black
1-unit pack
I
MXTS-MR200B1P JAN code: 4902580756574
2-unit pack
I
MXTS-MR200B2 JAN code: 4902580756604
Major specications
Brand name
Model
Category
Medical device category
General name
Medical device ID number
Rated voltage of main unit
Maximum output current
Maximum output voltage
Power consumption
(while working)
Power consumption
(while charging)
Basic frequency
Rated time
Output pulse width
Charging time
MXTS Low-frequency Pulse Massager
MXTS-MR200
Equipment 78 Home-use Electric Massage Device
Controlled medical device
Home-use low-frequency massage device
229AKBZX00042000
3.7 V DC (lithium-ion battery)
Input: 100 VAC, 50 to 60 Hz, 0.4 W
Output: 5 V DC, 0.04 A
10 mA or less
About 42 V at maximum setting
About 0.1 W
About 0.2 W
About 1 to 100 Hz
About 15 minutes
200 µ seconds
Automatically turns off after about 15 minutes.
Quick mode: Automatically turns off after about
7 minutes.
3 hours (at 10 to 35°C room temperature)
Main unit x 1
Gel sheet x 1
Protective sheet x 1
Power supply adapter x 1
USB cable x 1
User manual
Main unit x 2
Gel sheet x 2
Protective sheet x 1
Power supply adapter x 1
USB cable x 1
User manual
Main unit case: PC + ABS
Gel sheet: Acrylic gel
Main unit: 44 (height) x 44 (width) x
10.5 (depth) mm
Gel sheet: 61 (height) x 125 (width) x
0.5 (thickness) mm
About 25 g (main unit + gel sheet)
Set contents
(1-unit pack)
Set contents
(2-unit pack)
Material
Dimensions
(1 unit)
Weight (1 unit)
Major specications
Brand name
Model
Medical device category
General name
Medical device registration
number
Color
Set contents
Material
Dimensions
Weight
Standard Spot type Wide type
61 (height) x 125 (width) x
0.5 (thickness) mm
About 12 g (1 piece)
59 (height) x 190 (width) x
0.5 (thickness) mm
About 12 g (1 piece)
154 (height) x 180 (width) x
0.5 (thickness) mm
About 41 g (1 piece)
White/Pink/Black
Gel sheet x 2
White
Gel sheet x 2
Protective sheet x 1
User manual
Acrylic gel
White
Gel sheet x 1
A 15-minute massage course consisting mainly of “Knead” and
“Press” in addition to “Tap” and “Vibrate”.
Automatic
mode
-
1
A 7-minute massage course consisting of “Tap”, Vibrate”, “Knead”,
and “Press”. This course is appropriate for quickly easing fatigue.
Quick
mode
-
2
A massage course consisting of “Tap” and “Vibrate” to ease your
neck and shoulders. This course also eases upper arm fatigue.
Neck and shoulders
mode
-
3
A massage course consisting of “Tap”, “Vibrate”, and “Knead” to
ease lassitude, heaviness, and fatigue of waist.
Waist
mode
-
4
A massage course consisting of “Knead”, “Press”, and “Vibrate”
to ease thigh and calf fatigue.
Legs
mode
-
5
* Use the MXTS-200GEL series gel sheets as replacement sheets.
* When the strength level is set to 10 (maximum).
The number of repetitions varies according to mode.
MOMICARE employs a soft cushion gel sheet.
Product range
MOMICARE gives priority to ease of use
and safety.
Dedicated gel sheets* for each part of your body.
Cordless and rechargeable
◎Main unit
MOMICARE employs a frequency range of 1 to 100 Hz that provides highly effective treatment and minimal muscle fatigue.
①Standard ②Spot type ③Wide type
◎Replacement/dedicated gel sheets (sold separately)
* Spot type/Wide type
MXTS Gel sheet
MXTS-200GEL
General medical device
Inductor for home-use low-frequency pulse massager
40B2X10023000001
Neck Shoulders
Back Arms
Waist Legs
The cushion gel sheet has a smooth feel that makes it pleasant and
enjoyable to use. It can be removed and replaced, and multiple sheets
can be used – one for each family member.
We recommend using these when you want to intensively massage
the soles of your feet or massage a wide area such as your waist.
MOMICARE is a compact and cordless massage device with a built-in
lithium-ion battery.
A recharging power supply adapter and USB cable are included.
Once the battery is charged, you can use MOMICARE 7 times for
about 15 minutes*.
The connection cable (sold separately)
enables you to control MOMICARE by hand.
MOMICARE’s thoughtful design enables you to turn it on and set the
mode and strength by hand before attaching it where it is needed.
The body detection sensor automatically stops MOMICARE as soon as
the gel sheet leaves your skin.
Dedicated power supply
adapter (for charging)
Timer
