MaxiCosi Luna User manual

Instruction
Manual
IMPORTANT KEEP
THIS BOOKLET IN THE
PLACE PROVIDED AT
THE BACK OFTHE
CHILD RESTRAINT
Instructions applicable for:
Luna
Luna Pro
Scan QR code to view
video instructions
Suitable from
6 MONTHS
TO 8 YEARS
(approximately)
Luna
Forward facing
car seat
Luna Pro

Remove
Slack
Pull
Push
Harness straps in green zone
14
Attach
Pull
16
13
17
2 3
Place on the back seat
of the vehicle in-line
with a top tether strap
anchorage point
Pull the vehicle seat belt across the back
and through to the other side. Ensure belt is
behindtrim
To select upright
position, swing the
recline arm back under
the seat
Thread the vehicle seat
belt through forward
facing belt path
2
Store strap in storage
pocket
129
click
5
3
10
67
11
8
4
Quick Setup with Seatbelt
Select recline position
by swinging the recline
arm back
Forward Facing Mode
1
Loosen the top tether
Remove slack from top
tether
Fasten the vehicle belt
and listen for the click
Remove slack Attach the top tether
strap
Scan QR code to
view online video
instructions
Place child in the
restraint
15
click
Engage harness buckle
The shoulder straps
must be in the slots
which are nearest to
the child’s shoulders
but not more than
25mm below the
child’s shoulders.
Tighten the harness Double check shoulder
height markers

4 5
Contents
Welcome to the
Maxi-Cosi family!
Congratulations on the purchase of your brand new
Maxi-Cosi Car Seat. Please take the time to read through
these instructions carefully.
Our vision at Maxi-Cosi is to help parents as their families grow, and like an embrace that carries
a child before they can walk, we’ve helped millions of families at the start of their new life.
It was over 40 years ago that we launched Europe’s rst baby car seat and since then, we’ve
carried over 60 million babies home from the hospital! We were pioneers then, and we’re pioneers
now. We will never stop improving, designing, and perfecting the way new families move around
the world - wherever life’s adventures may take them.
Air Protect® Superior Side Impact Protection
Air Protect®is designed to reduce the severity of side impact crash forces by absorbing
the energy and transferring that energy away from your child’s head giving your child
180 degree protection in the instance of an accident
Accident Exchange
As a safety brand, we want to offer the best possible support during this time. Inthe
event of a car accident your car seat may have unseen damage. The Maxi-Cosi Accident
Exchange Service* offers new for old replacement of your car seat, giving you peace of
mind. One less thing to worry about as a new parent.
Cool baby wicking fabric
Maxi-Cosi car seats feature unique Cool Baby®Wicking Fabric that draws moisture
away from your baby’s skin, allowing air to ow in, keeping baby cool and comfortable.
Derived from Bamboo Charcoal, our Cool Baby®Wicking Fabric ensures a comfy and
dry ride each and every journey.
Warnings 6
Shoulder Height Markers 8
Forward Facing Mode
Information 11
Components 12
Preparation before Install 14
Install using Seatbelt 17
How to use 20
Additional Information 27
Seat Guide 28
Care and Maintenance 29
Anchorage Fittings 32
Accessories 34
Next seat for your child 35
Guarantee 39
Travel System
Compatible
Airprotect®
GCELL
Magnetic
Harness Holders
Harnessed
Adjustable
Recline
Adjustable
Recline
Cup Holders Accident
Exchange
Service
Wicking Fabric
Large Storage
Basket
Anti-vibration
Stabiliser
Expandable
Wings
Compact
Design
Designed &
Engineered
in Australia
Safety Shield
Technology
360˚ Access
Feel The
Difference
One-Hand
Fold
Free
Shipping
Ultra
Compact
Adaptors
Included
Easy to
Clean
ISOFIX
Lifetime
Warranty
3+1 Year
Warranty
Machine
Washable
UFP
UFP Canopy Added Extras Bassinet
to Seat
Converts to
Double Stroller
Easy to Store Water
Repellent
Easy to Move Easy to MoveEasy to Move
Reversible
Seat
Compact Storage
Extended
Rearward Facing
National
Customer
Service
0-4*
Suitability
0-6 Months*
Suitability
4-8*
Suitability
Adjustable
Headrest
Made From Recycled
Polyester/Material
Made From Recycled
Polyester/Material
2 Year
Warranty
6 Year
Warranty
3 Year
Warranty
3 + 1 Year
Warranty
Convertible
Booster Seat
Comfort
6
63+1
3
3 + 1 Year
Warranty
3 + 1 Year
Warranty
Travel System
Compatible
Airprotect®
GCELL
Magnetic
Harness Holders
Harnessed
Adjustable
Recline
Adjustable
Recline
Cup Holders Accident
Exchange
Service
Wicking Fabric
Large Storage
Basket
Anti-vibration
Stabiliser
Expandable
Wings
Compact
Design
Designed &
Engineered
in Australia
Safety Shield
Technology
360˚ Access
Feel The
Difference
One-Hand
Fold
Free
Shipping
Ultra
Compact
Adaptors
Included
Easy to
Clean
ISOFIX
Lifetime
Warranty
3+1 Year
Warranty
Machine
Washable
UFP
UFP Canopy Added Extras Bassinet
to Seat
Converts to
Double Stroller
Easy to Store Water
Repellent
Easy to Move Easy to MoveEasy to Move
Reversible
Seat
Compact Storage
Extended
Rearward Facing
National
Customer
Service
0-4*
Suitability
0-6 Months*
Suitability
4-8*
Suitability
Adjustable
Headrest
Made From Recycled
Polyester/Material
Made From Recycled
Polyester/Material
2 Year
Warranty
6 Year
Warranty
3 Year
Warranty
3 + 1 Year
Warranty
Convertible
Booster Seat
Comfort
6
63+1
3
3 + 1 Year
Warranty
3 + 1 Year
Warranty

6 7
Read and follow all of the installation
instructions for maximum protection. If you
have any questions regarding the installation
or use of this restraint, please contact Dorel
Australia or agent, or a child restraint tting
station authorised by the relevant transport
authority, or in New Zealand, to consult the
agent for the vehicle.
No child restraint can guarantee absolute
protection from a crash. However proper use
of this restraint may reduce the risk of injury
or death.
To be used only in a forward-facing position
by a child whose shoulders are above the
lower shoulder height marker (approximately
6 months of age) until the child’s shoulders
reach the upper shoulder height marker
(approximately 8 years of age).
Continue to use this child restraint until the
child reaches this limit.
Do not use this child restraint until child’s
shoulders are above the lower shoulder height
marker.
Infants are at risk of serious injury if they face
forward too early.
Children are at risk of serious injury if they
move to booster seats too early.
Just using a seatbelt is not recommended for
children that have outgrown this restraint.
Children are safest in a booster seat until their
shoulders reach the upper shoulder height
marker of the booster seat.
TO BE USED WITH A LAP-SASH OR LAP
ONLY SEATBELT IN THE BACK OF MOST
CARS WITH FORWARD-FACING SEATS.
The use of child restraints in the front seat
may be restricted for children of specic ages
by local legislation. Please check with your
local legislation regarding any restriction for
child restraint.
THIS RESTRAINT MUST BE ATTACHED TO
A CHILD RESTRAINT UPPER ANCHORAGE
POINT IN THE CAR. REFER TO CAR
OWNER’S HANDBOOK FOR LOCATION OF
UPPER ANCHORAGE POINTS. REFER TO A
CHILD RESTRAINT FITTING STATION IF NO
UPPER ANCHORAGE POINTS ARE IN THE
MOTOR CAR.
This child restraint is not suitable for use on
an aircraft.
Always store the instruction book in the
pocket provided at the rear of the seat.
Fit the restraint rmly to the car seat.
Fit the harness rmly to the child.
A loose restraint or harness is dangerous.
Supervision of children is needed because
they may be able to undo the buckles and
adjusters.
Use the restraint exactly as shown in the
instructions.
DO NOT LEAVE CHILDREN
UNATTENDED IN THE CAR.
IF AN AIRBAG IS FITTED IN THE SEATING
POSITION WHERE THE CHILD RESTRAINT
IS TO BE FITTED, FOLLOW THE VEHICLE
MANUFACTURERS WARNINGS AND
INSTRUCTIONS.
The restraint should not be purchased or sold
as a second hand item. It is recommended not
to use child restraints older than 10 years as
the protection in an accident may be reduced.
This restraint must be used in conjunction
with a lap or lap-sash seatbelt.
Seatbelt extenders are not recommended to
be used if the seatbelt is not long enough to
secure the child restraint. If seatbelts are too
short then seek advice from a child restraint
tter and consider their recommendations
before using a seatbelt extender.
WARNINGS
Do not alter or modify this restraint.
Repairs must only be done by the
manufacturers or agent.
Do not allow the restraint to come into contact
with polishes, oils, bleach and other chemicals.
Destroy the restraint if it has been in a severe
crash, even if no damage is visible.
DO NOT USE THIS RESTRAINT WITHOUT
THE COVER.
Always secure the loose end of the top tether
strap. Do not use the child restraint where this
strap may fall into the seat back or off the side
of the seat.
Top Tether Strap: ALWAYS ATTACH HOOK
AND REMOVE SLACK.
THIS RESTRAINT IS NOT SUITABLE FOR
USE WHERE THE TOP TETHER STRAP
MAY FALL INTO A SPLIT IN THE SEAT
BACK OR OFF THE SIDE OF THE SEAT.
DO NOT ATTACH THIS CHILD RESTRAINT
TO ANY ISOFIX LOW ANCHORAGE.
ISOFIX low anchorages in cars are designed
to withstand only those loads imposed by
children aged up to approximately 4 years of
age in a correctly tted and approved ISOFIX
compatible child restraint. This child restraint
is not approved for use with the car’s ISOFIX
low anchorages.
WARNINGS

8 9
Shoulder Height Markers
The child’s shoulders must be in-line or above this marker. If the child’s
shoulders are below then the child should remain in their previous child
restraint.
When the child’s shoulders reach this upper marker, or the child no
longer ts in the child restraint, approximately 8 years of age, then the
child must be moved to the next form of child restraint.
Upper
Shoulder
Height
Marker
Lower
Shoulder
Height
Marker
Forward Facing
Marker B: Older child
Upper Shoulder Height Marker
When the child’s shoulders reach this upper marker,
or the child no longer ts in the child restraint,
approximately 8 years of age, then the child must be
moved to the next form of child restraint.
Marker A: Small child
The child’s shoulders must be in-line or above
this marker. If the child’s shoulders are below
then the child should remain in their previous
child restraint.
Marker B
Marker A
Marker B
Marker A
Marker A
Marker B

1110
Congratulations! Your child has reached their forward
facing height markers. This seat is fully harnessed until 8
years of age.
Here’s a quick check list before you install this child restraint:
Check that your child’s shoulders reach the minimum entry point for this seat.
Check that your child’s shoulders are NOT above the upper height marker, and if they are, your
child may be ready for a larger booster or ready to use the car seatbelt.
Check if your child needs the infant padding.
Harness height is level or in the slot closest to the child shoulder height.
You have selected the appropriate recline for your child.
The crotch buckle has been adjusted for your child.
Forward Facing
Mode Instructions

12 13
Forward Facing Mode
Forward Facing Mode
Components
1. Adjustable Headrest
2. Headrest Height Adjuster button
3. Air Protect x 2
4. Shoulder Height Markers
5. Belt Mates x 2
111
17
13
12
4
10
9
3
2
6. Padded Insert
7. Adjustable Arm Rest
8. Buckle
9. Harness Release Lever (under the trim)
10. Harness Adjuster Strap
8
11. Headrest Activator Leaver (x2 if tted)
12. FORWARD-FACING BELT PATH
13. Cup Holders (x2)
14. Top Tether Strap Adjuster
15. Top Tether
16. Top Tether/Instruction Manual
Storage Pocket
17. Top Tether Hook
18. Anchor Fitting
19. Crotch Buckle Adjuster (3 positions -
under seat)
7
14
15
16
18
5
19
6

14 15
Forward Facing Mode
Forward Facing Mode
Preparation before install
Recline adjustment
Select the desired recline position
by swinging the recline arm back
(Figure1).
To select the upright position, simply
swing the recline arm back under the
seat as shown (Figure 2).
Pull
Push
Figure 1
Figure 2
Top tether adjustment
IMPORTANT: Always secure the loose
end of the top tether strap to prevent
it hanging out of the car or being
accessible by the child.
Always adjust the top tether to the
correct length before installing the car
seat.
To Loosen Top Tether
Step 1. Press the grey button and pull
on the main top tether strap with the
top tether hook attached to it (Figure
15).
Step 2. Ensure to loosen and check
that you have enough top tether
slack to attach to your vehicles top
anchorage location before beginning
the installation process.
To Tighten Top Tether
To tighten top tether strap, pull on
the free end of the tether to tighten.
Always stow excess tether in the
pocket provided (Figure 16).
CAUTION: CHILDREN CAN BE
INJURED OR RESTRAINTS AND
TOP TETHER STRAP DAMAGED
BY UNSECURED CARGO IN A
COLLISION. SECURE OR REMOVE
HAZARDOUS CARGO BEFORE
USING THIS CHILD RESTRAINT.
PRESS
BUTTON
PULL
Figure 15
Figure 16

16 17
Forward Facing Mode
Forward-facing belt path
IMPORTANT: Before installation,
locate the forward-facing belt path.
BEHIND TRIMBEHIND TRIM
Install using Seatbelt
How to position your car
seat correctly
Step 1. Loosen the top tether.
Step 2. Place the restraint on the
back seat of the vehicle in-line with
a top tether strap anchorage point.
Step 3. Select the desired recline
position by swing the recline arm
back for recline. (Figure 1)
Step 4. To select the upright
position, simply swing the recline
arm back under the seat (Figure 2).
Pull
Push
Figure 1
Figure 2
Forward Facing Mode Preparation before install
FORWARD-FACING BELT PATH

18 19
Forward Facing Mode
Route seatbelt through
forward facing belt path
Step 5. Thread the vehicle seat belt
through the side of the seat where the
forwardfacing belt path is indicated.
(Figure 3).
Step 6. Pull the vehicle seat belt across
the back and through to the other side
(Figure 4 & 5) ensuring to feed behind
the car seat trim.
Step 7. Fasten the vehicle belt and
listen for the click.
Figure 3
Figure 4 Figure 5
Figure 6
click
Forward Facing Mode Install using Seatbelt
Attach
Figure 8
Step 8. Firmly pushing down on the
seat with one hand or pressing down
with your knee (if possible) At the
same time pulling up on the sash part
of the vehicle seat belt to remove all of
the belt slack (Figure 7). Pull
Push
Figure 7
Attaching the top tether strap
Attach the top tether strap to the
top anchorage point in the vehicle
(Figure8).
NOTE: There is an option to install the
seat using seat belt locking clip. Please
see instructions provided with locking
clip for installation.

20 21
Forward Facing Mode
Remove slack from top tether
Step 1. Remove slack only. Do not
over-tighten the top tether strap so
that the restraint lifts up off the vehicle
seat (Figure 9).
Step 2. Ensure there are no twists
and turns in the top tether strap and
that the adjuster is positioned facing
outwards (Figure 9).
Note: There will be a half twist in the
top tether strap between the adjuster
and the shell of the restraint, allowing
the adjuster to be positioned facing
outwards.
Step 3. Roll up excess strap and store
in the pocket provided on the cover.
(Figure 10).
Store
Strap
Pull to
remove
slack
Figure 10
Figure 9
CAUTION: CHILDREN CAN BE INJURED OR RESTRAINTS AND TOP
TETHER STRAP DAMAGED BY UNSECURED CARGO IN A COLLISION.
SECURE OR REMOVE HAZARDOUS CARGO BEFORE USING THIS CHILD
RESTRAINT
Always secure the loose end of the top tether strap to prevent it hanging out of the car or being
accessible by the child.
When not in use, fold hanging tether strap and place in storage pocket provided.
Adjusting the harness
To Loosen harness
Step 1. Lift the harness release lever
at the front of the seat (between trim
cover opening - Figure 3).
Step 2. Pull both shoulder straps
simultaneously to loosen harness.
(Figure 3).
To tighten harness
Pull the harness adjustor strap at the
front of the seat until the shoulder
straps lay rmly against the child
(Figure 4).
Fitting the harness to
yourchild:
Step 1. Loosen the harness and release
the buckle by pressing the red button.
Step 2. Place the child in the seat,
fasten the buckle assembly (Figure 4).
Step 3. Pull the harness adjustor strap
to tighten (Figure 5)
Figure 3
Figure 5
Pull
Figure 4
DO NOT LEAVE
CHILDREN UNATTENDED
IN THE CAR.
FAILURE TO FASTEN AND
TIGHTEN THE HARNESS SYSTEM
CORRECTLY CAN RESULT IN
SERIOUS INJURY OR DEATH.
WARNING
Lift
Forward Facing Mode
How to use

22 23
Forward Facing Mode
Chin support
Adjustment (if fitted)
IMPORTANT: Always activate the
chin support before you start your
journey always take safety precautions
when using this feature, it is not
recommended to activate this feature
when vehicle is in motion.
Activating the comfort headrest:
Step 1. Locate the headrest leaver on
either side of the headrest (Figure 8).
Step 2. Pull the leaver outwards to
activate the comfort support wings
(Figure 9).
To close:
Push leaver back to original position
(Figure 10).
Figure 9
Figure 8
Figure 10
Forward Facing Mode How to use
Headrest and harness
height adjustment
Step 1. Push the button located at the
top of the headrest and lift up or down
to the desired height (Figure 6).
IMPORTANT: Always loosen the
harness before moving the headrest
up. Adjusting the headrest will
automatically adjust the harness
height as well.
IMPORTANT: The shoulder straps
must be in the slots which are nearest
to the child’s shoulders, but not
more than 25mm below the child’s
shoulders (Figure 7).
Figure 6
Figure 7
Harness
straps in
green zone
Always adjust the height of the shoulder straps as the child grows
WARNING

No twists
24 25
Forward Facing Mode
Fastening the buckle
assembly
Step 1. To RELEASE the buckle, press
the red button.
Step 2. Insert one buckle tongue
(Figure 14 - you will not hear a click).
Step 3. Insert the second buckle
tongue as illustrated above.
Now listen for a ‘CLICK’.
Step 4. Remember to always pull up
on the harness straps to make sure
buckle is locked tightly.
Tongue
Buckle
click
Figure 14
DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR
WARNING
Crotch buckle height and
length adjustment
To adjust:
Step 1. Release the valcro trim strap
on the underside of the seat (Figure
11).
Step 2. Locate the adjustor pins (x2)
and slide each side into the next
position (Figure 12).
Position 1: is for smaller children up to
3 years approx
Position 2: is for 3-6 years approx
Position 3: is for 6-8 years approx
NOTE: The seat is tted with a 3
position crotch adjustment. When
changing to the next position
the crotch height and depth with
both automatically be adjusted
automatically. Please adjust the crotch
position as your child grows.
Cup holders:
Cup holders are located on either side
of the car seat. Swing out to use and
swing back in to stow away when not
in use (Figur 13).
CAUTION: Do not use with hot
beverages
Figure 11
Figure 12
Figure 13
3
2
1
Forward Facing Mode How to use

Pull
26
Tighten the harness
Step 1. Before pulling on adjuster
strap to tighten harness, pull on
harness shoulder straps rst to
remove slack from the waist area
(Figure 11).
Step 2. Once slack is removed, pull on
adjuster strap so that the harness over
the shoulders is rm (Figure 12).
Step 3. Pinch the straps near the top
of the shoulder to check for correct
tment. This is achieved when you are
unable to pinch the harness (Figure
13). If you can pinch the harness,
tighten more.
Pinch
Test
Figure 11 Figure 12
Figure 13
WARNING
TIP Always use the Pinch test
when you buckle your child
as your harness may need
adjusting.
27
Additional
Information
Regularly checking and maintaining your seat will ensure
your seat remains comfortable and safe for your child.
This additional information section details information on:
• Seat Guide
• Care and maintenance
• Anchorage ttings
• Your Maxi-Cosi guarantee.
Forward Facing Mode How to use
DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR

3
2
1
28 29
Additional InformationAdditional Information
Care and Maintenance
Cleaning the buckle
Step 1. Start by moving the crotch position
into position number 3 (Figure 1).
Step 2. You can remove the seat trim cover
so it does not get wet or dirty during the
cleaning process.
Step 3. Fill any shallow container with
40˚C water.
Step 4. Lay the buckle gently into the
container and let it soak for 30 mins
(Figure 2).
Step 5. Simultaneously latch and unlatch
the buckle tongues into the buckle several
times until a strong audible CLICK is heard.
Step 6. If you cannot hear an audible
CLICK then repeat steps 1 - 4 above again.
Step 7. Allow the buckle to completely dry
before tting on the trim.
CAUTION: Do not oil any part of the
buckle. Water may be hot so proceed
with care
NOTE: If the buckle does not return to original working order, contact Dorel Australia Customer
Service on 1300 809 526.
If you are a New Zealand customer, please contact IGC Dorel New Zealand Customer Service on
0800 628 000.
Caring for the Restraint Buckle
Follow the manufacturer’s instructions at all times.
Your child car seat is equipped with a buckle designed to give your child
maximum protection during proper use. When working properly, your
buckle should always fasten with an audible ‘CLICK’.
If sticky liquids (such as baby food, fruit juice, etc.) get into the buckle it
may become sluggish and you will not hear a ‘CLICK’.
The buckle should be cleaned by following the steps below.
Figure 1
Figure 2
Seat Guide
Booster
Seatbelt
allowable
by law
2 4 6 7 8 10 12BIRTH
Infant Seat Child Seat Booster Seat Seat BeltExtended Rear Facing
Forward
Facing
Forward
Facing
Rear FacingRear Facing
Forward Facing
Rear Facing
Booster
Rear Facing restraint
Birth to approx 12 months
Convertible car seat
Birth to 4 years
Convertible car seat
Birth to 4 years
Forward Facing
Approx 6 months to 8 years
Harnessed booster seat
Approx 6 months to 8 years
Booster seat
Approx 4 years to 10 years
Seat belt
Approx 7 years and over*
Restraint type:
You have
this seat
Your Luna forward-facing car seat is suitable from 6 months to approximately
8 years of age. Once your child has out grown this seat, it is time for you to
move your child into either a booster seat or stand-alone seat belt.
*Check with your local state regulations

30 31
Removing the seat cover for cleaning
Do not forget to remove instruction manual. Do not use
the restraint without the cover.
Check the webbing for fraying.
To remove insert
To remove the padded insert, undo the buckle and pull
the insert out.
To replace insert
Feed the crotch part of the buckle through the opening
slot in the insert and fasten buckle assembly.
To remove belt mates
To remove the belt mates, simply undo press studs and
unwrap from harness straps. (x2).
To replace belt mates
Fit belt mates to harness straps by wrapping around
straps and closing press studs.
Additional Information Care and Maintenance
To remove the trim
To remove the trim start by releasing
the press studs located on the back of
the seat as well as the Velco webbing
straps located under the seat. Then
gently pull the trim free from the shell
around the armrests and up through
the top of the seat (Figure 3).
To replace the trim:
Follow the steps above in the reverse
order.
To remove the headrest:
To remove the headrest fabrics, lift the
headrest to the highest position and
release 2 press studs from the top and
2 from underneath. Gradually peel and
pull the trim away from the headrest
till completely removed (Figure 4).
If tted with chin support, carefully
release the Velcro from above and
below the lower Air Protect cell before
removing
To replace the headrest
Follow the steps above in the reverse
order.
Figure 3
Figure 4
Lukewarm setting
– delicate cycle
Tumble dry 10-15
minutes on low heat
Do not dry clean
All other surfaces
should be cleaned with
a mild soap and water Never clean with bleach
or spirit-type cleaners Do not iron
Washing instructions
VERY IMPORTANT:
Only replace the cover with a Maxi-Cosi supplied replacement cover
withidentical shoulder height markers or a replacement cover meeting
AS/NZS 8005.

Attachment bolt
Anchor tting
Spacer/s (if required)
Vehicle trim
Vehicle metal structure
Lock washer
200mm min.
Centre line of
seating position
Attachment bolt
Anchor tting
Spacer/s
(if required)
Vehicle trim
Vehicle metal
structure
Reinforcing
washer
Lock washer
Nut
32 33
Additional Information Care and Maintenance Additional Information
Install Upper Anchorage
For cars fitted with a child restraint
upper anchorage point
CAUTION: DO NOT OVER-TIGHTEN
THE ATTACHMENT BOLT.
OVER-TIGHTENING MAY FRACTURE
OR BREAK BOLT. MAXIMUM
TORQUE IS 20Nm.
Figure 1
Locate the upper anchorage point
behind the rear seating position
(consult the vehicle owner’s
handbook for the location of the upper
anchorage point).
Remove the thread plug from the
parcel shelf/oor/roof and install the
attachment bolt as shown in Figure 1.
For cars not fitted with a child restraint
upper anchorage point
For sedans only
Drill a 9mm diameter hole in the parcel
shelf on the centre-line of the seating
position as shown in Figure 2.
Install the anchor bolt as shown in
Figure 3. It is recommended that this
installation be carried out by a child
restraint tting station or licenced motor
mechanic.
For vehicles other than sedans
In Australia, consult your nearest child
restraint tting station or trafc authority
for vehicle inspection to nd the best,
correct position for the placement of
the upper anchorage point, and for the
correct attachment bolt length and use
of spacers. In New Zealand, consult the
agent for the vehicle.
CHILD RESTRAINTS MUST NOT BE
ATTACHED TO UNSOUND METAL
OR TO WOOD OR SYNTHETIC
STRUCTURES. WHEN DRILLING
THE 9MM HOLE DO NOT DRILL
THROUGH FUEL LINES, FUEL TANKS,
ELECTRICAL WIRING, OR RADIO
SPEAKERS. WEBBING STRAPS
MUST BE PROTECTED FROM SHARP
CORNERS AND EDGES.
THE ANCHOR FITTING MUST BE
USED ONLY AS DESCRIBED ABOVE.
IT MUST NOT BE HOOKED ONTO
ANY OTHER OBJECT.
Figure 3
Figure 2
WARNING

34 35
An extension strap may be needed for
vehicles without a xed parcel shelf.
Extension straps and extra ttings are
available from various stores.
Use of aftermarket accessories (i.e.
items not provided in the box with the
child restraint), can reduce the safety
provided by the child restraint and
may cause injury or death.
If an aftermarket accessory is to be
used then the manufacturer may
advise that it is compliant with AS/
NZS 8005 and is stated as suitable for
this child restraint.
Accessories
Dorel Extension Straps - 300mm
Dorel Extension Straps - 600mm
Dorel Locking clip
Dorel Extension Straps - 300mm & 600mm
Dorel Locking clip
74
IConvertible Car Seat IMaxi-Cosi
The Next Seat for your Child
To be used only in a forward-facing position
by a child whose shoulders are above the
lower shoulder height marker (approximately
6 months of age) until the child’s shoulders
reach the upper shoulder height marker
(approximately 8 years of age).
Option 1:
HARNESSED FORWARD-FACING CAR SEAT
To be used with a lap-sash seatbelt by a child
whose shoulders are above the lower shoulder
height marker (approximately 4 years of age)
until the child’s shoulders reach the upper
shoulder height marker (approximately 8 to
10 years of age). Can also be used with child
harness that is approved for use with this
booster seat.
To be used with a lap-sash seatbelt by a child
whose shoulders are above the lower shoulder
height marker (approximately 4 years of age)
until the child’s shoulders reach the upper
shoulder height marker (approximately 6 to
8 years of age). Can also be used with child
harness that is approved for use with this
booster seat.
Option 2:
BOOSTER SEAT
Option 3:
LARGER BOOSTER SEAT
For more information,
visit maxi-cosi.com.au
Additional InformationAdditional Information
The Next Seat for your Child
LARGER BOOSTER SEAT
When your child has outgrown the seat, you can use a booster seat
suitable for children up to 8-10 years of age until their shoulders
reach the upper height marker of the booster seat.
NOTE: This illustration is representative only
Alternatively, follow the steps below to see if your child is ready to
use a vehicle seat belt.
If your child is transitioning out of a booster, try this simple three
point test. You may nd that your child is not yet ready to use an
adult seatbelt without the booster
Three point test
1. Does the sash part of the seat belt
sit on the middle of the shoulder and
not touch the neck or face?
2. Does the lap part of the seat belt sit
low down on the hips and not on the
abdomen?
3. When you sit the child on the seat
with their bottom all the way back,
are their thighs long enough for their
knees to bend allowing the legs to
hang over the front of the seat?
If you answered “no” to any of these
questions, your child needs to be
in a booster seat to make both the
sash and the lap part of the seat belt
t right to ensure maximum crash
protection
Information obtained from www.raa.com.au
1
23
1
2
3
1
2
3
Sash part across
neck and face
and not shoulder
Sash on shoulder
and not on neck
or face
Lap belt low
across hips and
not stomach
Legs long enough
to bend at knees
- no slumping
Legs are not long
enough so child is
slumping in seat
Lap belt across
stomach and not
low on hips
1
23
1
2
3
1
2
3
Sash part across
neck and face
and not shoulder
Sash on shoulder
and not on neck
or face
Lap belt low
across hips and
not stomach
Legs long enough
to bend at knees
- no slumping
Legs are not long
enough so child is
slumping in seat
Lap belt across
stomach and not
low on hips
INCORRECT
CORRECT

36 37
NotesNotes

38 39
Additional Information
Guarantee
Dorel Australia Pty Ltd warrants your new product to be free from defects in materials
and workmanship for 10 years on the seat & 3 years on the trim, from the date
of purchase, provided that the product is used in accordance with accompanying
recommendations or instructions where provided. The benet of this warranty is in
addition to your rights under the Australian consumer law and to other rights and
remedies of the consumer under a law in relation to the goods or services to which the
warranty relates.
Dorel Australia Pty Ltd will provide you with your choice of a refund, repair or
exchange (where possible) for this product if it becomes defective within the warranty
period. Dorel Australia Pty Ltd will bear the reasonable expense of claiming the
warranty. This warranty will no longer apply where the defect is a result of alteration,
accident, misuse, abuse or neglect.
Please retain your receipt as proof of purchase or register your product with us within
3 months from point of purchase via our website www.maxi-cosi.com.au. If you are
having difculties with your product contact our Customer Service Team on ph: 1300
809 526 or alternatively, via our website at www.dorel.com.au. Warranty claims
and claims for expense incurred in returning this product can be addressed to our
Customer Service Team at 655-685 Somerville Road, West Sunshine, Vic, 3020.
Hours: 8:30 am to 5:00 pm, Monday to Friday.
For New Zealand please contact Customer Service Centre, 14 Sir William Avenue,
East Tamaki, Auckland, 2013. Auckland: [phone] NZ wide: 0800 628 000
(toll free). Hours: 8:00am - 4:00pm, Monday to Friday.
Our goods come with guarantees that cannot be excluded under the
Australian consumer law. You are entitled to a replacement or refund for a
major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Australian
Standard
AS/NZS 1754 Lic 1491
SAI Global
AS/NZS 1754 Lic 40071
SAI Global
Notes
