MaxiCosi Pebble Troubleshooting guide

GB
www.maxi-cosi.com
Maxi-Cosi Pebble
www.maxi-cosi.com

GB
EN
Congratulations on your purchase.
For the maximum protection and
comfort of your child, it is essential
that you read through the entire
manual carefully and follow all
instructions.
FR
Nous vous félicitons pour votre
achat.
Pour une protection maximale et
un confort optimal de votre bébé, il
est essentiel de lire attentivement et
intégralement le mode d’emploi et de
respecter les instructions.
DE
Wir beglückwünschen Sie zu Ihrem
Kauf.
Zum besten Schutz und optimalen
Komfort Ihres Baby ist es wichtig, die
Gebrauchsanweisung vollständig und
sorgfältig zu lesen und zu beachten.
NL
Gefeliciteerd met de aankoop.
Voor een maximale bescherming en
een optimaal comfort voor je baby is
het essentieel de volledige handleiding
zorgvuldig door te kijken en op te
volgen.
ES
¡Enhorabuena por tu compra!
Para ofrecer la máxima protección y
un óptimo confort para tu bebé, es
muy importante que leas el manual
atentamente y sigas las instrucciones
de uso.
IT
Congratulazioni per il vostro
acquisto.
Per la massima protezione e per un
comfort ottimale del vostro bambino
è molto importante leggere e seguire
attentamente tutte le istruzioni.
PT
Felicitámo-lo pela sua compra.
Para uma máxima protecção conforto
para o seu bebé, é importante que leia
atentamente e siga todas as instruções
de utilização.
JA
このたびはご購入いただきありがとう
ございます。
お子様を危険から守り、できる限り快
適な空間を整えていただくため、マニュ
アル全体を熟読し、注意事項は必ずお
守りください。
PL
Gratulujemy zakupu Maxi-Cosi
Pebble.
Aby zapewnić dziecku najwyższy
poziom bezpieczeństwa i komfortu,
należy uważnie zapoznać się
z niniejszą instrukcją i ściśle jej
przestrzegać.
UK
Вітаємо із вдалим придбанням.
Для максимальної безпеки і
комфорту Вашої дитини, необхідно
дуже уважно ознайомитись з
цією інструкцією та ретельно
дотримуватись ії при подальшому
використанні виробу.
HR
Čestitamo vam na kupnji.
Da biste djetetu zajamčili maksimalnu
zaštitu i udobnost, morate pažljivo
pročitati cijeli priručnik i slijediti sve
upute.
SK
Blahoželáme k nákupu.
Aby vaše dieťa malo maximálnu
ochranu a pohodlie, je potrebné
prečítať si pozorne celú príručku a
dodržiavať všetky pokyny.
HE
www.maxi-cosi.com

3
I
J
K
L
M
N
D
F
H
G
E
B
A
C
O
P
Q
R
S
T

4
Index
EN 18
FR 22
DE 26
NL 30
ES 34
IT 38
PT 42
JA 46
PL 50
UK 54
HR 58
SK 61
HE 65
6
8
10
13
14
15

5
Instructions for use/Warranty
Mode d’emploi/Garantie
Gebrauchsanweisung/Garantie
Gebruiksaanwijzing/Garantie
Modo de empleo/Garantia
Istruzioni per l’uso/Garanzia
Modo de emprego/Garantia
使用説明書/保証書
Instrukcja obsługi/Gwarancja
Інструкції з експлуатації/Гарантія
Upute za upotrebu/Jamstvo
Navodila za uporabo/Garancija

6
A
B
A
B
A
B
A
B
12

7
Max
1cm
Max
1cm
Max
1cm
Max
1cm
3 4
5 6

8
1
2
33
4
2
1
2
33
4
2
1
2
33
4
2

9
NO
OK
TEST
TEST
1
2
NO
OK
TEST
TEST
1
2
NO
OK
TEST
TEST
1
2
NO
OK
TEST
TEST
1
2
Maxi-Cosi FamilyFix & EasyBase 2
FamilyFix EasyBase 2

10
Pebble 29-12-2009

11
1
2
3
4
1
2
3
4

12
1
2
1
2
3
1
2
1
2
3
1
2
1
2
3
1
2
1
2
3

13
1
2
1
2
3
1
2
1
2
3

14
1
2
4
3
1
2
3
DO NOT REMOVE
1
2
4
3
1
2
3
DO NOT REMOVE
1
2
4
3
1
2
3
DO NOT REMOVE
www.maxi-cosi.com/airplane

15
1
2
4
3
1
2
3
DO NOT REMOVE

16
12

17
Maxi-Cosi Car seats
Maxi-Cosi
Pebble
Maxi-Cosi
Tobi
Maxi-Cosi
Pearl
Maxi-Cosi
Fero(Fix)
Maxi-Cosi
Axiss
FamilyFix
EasyBase 2
FamilyFix
0-13 kg 9-18 kg 9-18 kg 9-18 kg 15-36 kg

18
EN
Cover (fabric)
Support pillow for newborn child
Push button for releasing Maxi-Cosi Pebble
from pushchair
Ergonomic handle
Belt hook for shoulder part of belt
Height adjustment shoulder belts
Instruction manual
Storage compartment
Small hook for clamping sun canopy
Sun canopy (built-in)
Carrying handle
Adjustable pillow
Storage flap sun canopy
Push button for adjusting carrying handle
Shoulder belts with removable belt pads
Belt hook for lap part of belt
Belt buckle
Crotch strap with belt pad
Mounting bars for Maxi-Cosi FamilyFix and
Maxi-Cosi EasyBase 2
Belt tensioner strap
Safety
General Maxi-Cosi Pebble instructions
1. You are personally responsible for the safety
of your baby at all times.
2. Never hold your baby on your lap when
driving.
3. Do not use the Maxi-Cosi Pebble for more
than 5 years.
4. Do not use second-hand products where the
history is unknown.
5. Replace the Maxi-Cosi Pebble after an
accident.
6. Read this instruction manual carefully and
keep it in the storage compartment in the
Maxi-Cosi Pebble.
Warning: Do not make any changes to the
Maxi-Cosi Pebble whatsoever, as this could affect
the performance of the car seat and render it
unsafe.
Maxi-Cosi Pebble maintenance instructions
1. The cover, cushions and belt pads of the
Maxi-Cosi Pebble can be removed in order
for these to be cleaned. They can be
machine-washed. The flexible plastic edge
can be cleaned with water, soap and a soft
cloth.
2. If the cover needs to be replaced at any time,
only use official Maxi-Cosi fabrics.
3. The Maxi-Cosi Pebble must undergo regular
maintenance. Do not use lubricants or
aggressive cleaning agents.
The Maxi-Cosi Pebble and your baby
1. Never leave your baby unattended.
2. Always secure your baby with the harness
belt.
3. Before every use, make sure the harness is not
damaged or twisted.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T

19
EN
4. Make sure you can fit no more than one
finger between the harness and your baby
(1cm).
5. Only use the headrest of the Maxi-Cosi Pebble
when the shoulder belts are in the lowest
position.
Warning: Never place the Maxi-Cosi Pebble on
an elevated surface (such as a table or chair).
Maxi-Cosi Pebble car use
1. Always check to make sure the car seat can
be installed properly in your car before
purchasing it.
2. Make sure the fold-down rear seat is locked
into position.
3. Prevent the Maxi-Cosi Pebble from becoming
trapped or weighed down by luggage, seats
and/or slamming doors.
4. Make sure that all luggage and other loose
objects are secure.
5. The safest place for your baby is the rear of
your vehicle, however if you need to install
the seat in the front passenger seat, please
ensure that any airbag is deactivated.
6. Only use a forward-facing seat that is fitted
with a 3-point safety belt that complies with
the ECE R16 standard (at a minimum).
7. Make sure the car safety belt buckle runs in a
straight line and stays below the belt hook of
the Maxi-Cosi Pebble. See the p.8 example.
8. The car safety belt must be threaded along
all blue markings. For proper installation
instructions, see pages 8-9 and/or the sticker
on the side of the Maxi-Cosi Pebble.
9. Always cover the Maxi-Cosi Pebble when
exposed to direct sunlight in the car.
Otherwise, the cover, metal and plastic parts
could become too hot for your child’s skin.
Warning: The Maxi-Cosi Pebble may only be
installed in a rear-facing position in the car.
Maxi-Cosi Pebble in aeroplanes
• Installing the Maxi-Cosi Pebble with a 2-point
safety belt is only allowed when used in an
aircraft.
• In an aircraft, the Maxi-Cosi Pebble may only
be used on forward-facing passenger seats.
Environment
Keep all plastic packaging materials out of reach
of your child to avoid the risk of suffocation.
For environmental reasons, when you have
stopped using this product, we ask that you
dispose of the product in the proper waste
facilities in accordance with local legislation.

20
EN
Questions
If you have any questions, contact your local
Maxi-Cosi retailer (see www.maxi-cosi.com for
contact information). Make sure that you have
the following information on hand:
- Serial number at the bottom of the orange
ECE sticker
- Make and type of car and seat on which the
Maxi-Cosi Pebble is used
- Age, height and weight of your child
Warranty
We guarantee that this product was manufac-
tured in accordance with the current European
safety requirements and quality standards which
are applicable to this product, and that this
product is free from defects in workmanship and
material at the time of purchase. During the
production process the product was subjected to
various quality checks. If this product, despite our
efforts, shows a material/manufacturing fault
within the warranty period of 24 months, (with
normal use as described in the user instructions)
we will comply with the warranty terms and
conditions. In this case please contact your dealer.
For extensive information on applying the
warranty terms and conditions, you can contact
the dealer or look on our website:
www.maxi-cosi.com.
The warranty is not valid in the following
cases:
• In case of a use or purpose other than
described in the manual.
• If the product is submitted for repair through
a dealer that is not authorized by us.
• If the product is not supplied to the
manufacturer with the original purchase
receipt (via the retailer and/or importer).
• If repairs were carried out by third parties
or a dealer that is not authorized by us.
• If the defect is the result of improper or
careless use or maintenance, negligence or
impact damage to the fabric cover and/or
frame.
• If the parts show normal wear and tear that
may be expected from daily use of a product
(rotating and moving parts etc.)
Date of effect:
The warranty becomes effective on the date the
product is purchased.
Warranty term:
The warranty period applies for a period of 24
consecutive months. The warranty only applies for
the first owner and is not transferable.
