MAXIMUM Security CURTAIN-FLT User manual

Page 1of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
CURTAIN-FLT
Operating Guide

Page 2of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
CURTAIN-FLT
Flush mount Outdoor/Indoor intrusion detector with curtain field-of-view
PIR sensor + Microwave sensor + Anti-masking + Waterproof.
FEATURES
•Creates a super narrow protective screen of 3-50.
•Combines PIR & Microwave technology.
•Masking protected (Anti-masking) by active infrared beams.
•Anti-Vandalism (Shock & Vibration Sensor). Option.
•Flush mount.
•Horizontal inclination adjustment of up to +/- 50.
•Remote Controlled- Detector settings can also be controlled
by Remote Control (option).
•Ceiling or wall mounting (Vertical or Horizontal).
•Adjustable PIR detection sensitivity.
•Adjustable Microwave detection sensitivity.
•Extremely reliable & highly immune to false alarms.
•Auto temperature compensation.
•Automatic adaptation to background noise.
•A/D signal analyzer.
•Powerful microprocessor controlled.
•SPC - Smart Processing Controller.
•High level of RFI/EMI immunity.
•Two "Optomos" relays for lifetime operation.
CONGRATULATIONS
We thank you for choosing a product of MAXIMUM Security (1984) Ltd.
Based on over 30 years experience in R&D and in production of advanced security systems, we are
proud to introduce to you the best Outdoor / Indoor motion detector ever presented, for industrial,
commercial and residential security.
To ensure proper operation and maximum use of all its benefits, please read all parts of this installation
and operating manual, and follow the step-by-step instructions.

Page 3of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
INTRODUCTION
CURTAIN-FLT creates a super narrow protective screen of 3-50(like a curtain) to secure openings
and open fields against intruders.
This type of protection allows free movement of people within the protected site- without setting off an
alarm.
CURTAIN-FLT is waterproof and can be installed outdoors or indoors.
In addition to an unprecedented amazing and reliable detection capability, CURTAIN-FLT is
equipped with excellent protection against any attempt to disable its operation by blocking (masking)
its near field-of-view, whether the alarm system is Armed or Disarmed (Anti-masking protection).
The protection against masking the near field-of-view of the detector is achieved by a continuous
active infrared beams scan.
CURTAIN-FLT combines two detection technologies- Microwave and Passive Infrared (PIR), and
verifies any intrusion by both methods.
An advanced and unique algorithm enables it to work in the most difficult environmental conditions
and where high security is required, while maintaining unprecedented immunity to false alarms.
CURTAIN-FLT settings can also be controlled by Remote Control (option).
DETECTOR’S FIELD-OF-VIEW DIAGRAMS
CURTAIN-FLToperates its relays and LED indicators according to the type of detection as follows:
TYPE OF DETECTION
LED INDICATORS
RELAY STATUS + Remarks
Alarm- True motion detection
Red + Yellow +Green
Blinking simultaneously
ALARM relay will activate for 2 seconds
(Unless the time was changed by the
optional Remote Control RM-1)
P.I.R. detection
Red
No relay will operate
Microwave detection
Yellow
No relay will operate
Anti-masking detection
Green
Blinking
If masking persists for more than 90
seconds, the green LED will glow
continuously, and the Anti-masking relay
will operate for at least 2 seconds and for
as long as the masking exists.
Max. 3 m
20-40 cm
30-400
Ceiling or wall mounting

Page 4of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
MOUNTING
DIP switch and trimmers
for adjustments.
See page No. _4_
TERMINAL BLOCK WIRING
ALARM
RELAY
TAMPER
12V DC
(Relay-1)
ANTI-MASKING
(Relay-2)

Page 5of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
ADJUSTMENTS
High
Microwave
Detection Sensitivity
adjustment
PIR
Detection Sensitivity
adjustment
High
DIP SWITCH ADJUSTMENT
Horizontal inclination
adjustment of up to +/-50.
The procedure
1. Unscrew.
2. Incline to the desired angle.
3. Screw tightly.
Remove cover to adjust
LEDs
Remote Control
Mode
Sensitivity
Not in use
Not in use
ON
OFF
1
ON
OFF
2
Low
High
3
4
5

Page 6of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
ANTI-MASKING LEARNING PROCEDURE-
PREPARING THE MASKING CHANNEL FOR OPERATION (Obligatory for proper
Anti-masking operation!!!)
To enable proper operation of the masking detection (Anti-masking), it is necessary to allow the
detector to automatically study and analyze the environmental conditions of its protected area.
This is an obligatory action that should be performed by the installer, ensuring proper operation of the
Anti-masking channel!!!
Study Procedure to be performed in two cases:
1. Upon connecting the power supply to the detector (after about 1 minute, the time it takes the
detector to stabilize when first fed by power supply).
2. Upon switching DIP switch No. 1 from OFF to ON position.
Study Procedure:
- Immediately close the detector’s case (within 15 seconds maximum).
- Keep at least 1 meter away from its front part, until the Study Procedure is complete, about 1
minute.
LED indication during the Study Procedure:
1. The Red+Yellow LED indicators blink rapidly for about 30 seconds.
2. The Green LED lights for about additional 15 seconds, till the Study Procedure ends.
PERFORM A TEST
* To be carried out when the case is closed and the LED indicators are enabled.
DIP switch No.1 should be switched to ON position.
Test procedure for human movement detection (Alarm):
oWalk in the protected area.
oCompulsory reaction of the detector:
Upon each detection, the “Alarm Relay” will operate for 2 seconds.
The Red+Green+Yellow LED indicators will blink simultaneously during those 2 seconds.
Test procedure for masking detection (Anti-masking):
oAt a distance of about 5 cm from the front of the detector, place a white piece of paper (or any other
object).
oCompulsory reaction of the detector:
The Green LED will immediately blink continuously as long as the masking object exists.
If the masking object exists for more than 90 seconds, the Green LED will glow continuously
and the Anti-masking relay will operate for at least 2 seconds and for as long as
masking exists.

Page 7of 7
MAXIMUM Security (1984) Ltd.
www.maximum.co.il
SPECIFICATIONS
* Power supply……………………………...…………...12V to 14V DC
* Current drain…...… Standby: 20mA (Max.); Operation: 40 mA (Max.)
* Alarm relay contacts endurance………………...…… 15V DC / 20 mA
* Anti-masking relay contacts endurance……………… 15V DC / 20 mA
* TAMPER Switch endurance……………………….... 24V DC / 20 mA
* Warm-up time………………………………..………….…… 1 Minute
* Alarm period…………………………………………......…. 2 Seconds
* Shock & Vibration sensor output period……….………...… 2 Seconds
* Anti-masking relay respond time…………….……. 90 Seconds (Max.)
* Anti-masking relay activation period…………….. All time of masking
(at least 2 seconds)
* Detector horizontal inclination adjustment..…..………..… Up to +/- 50
* Motion detection coverage ............................................ 3 meter, 30-400
* Operating Temperature…………………….………..... (-)37 ~ (+)50oC
* Microwave operating Frequency……………………….... 24.125 GHz
